3.6.7 - Interface > DI/DO
This section allows you to set the DI/DO parameters. Digital Input and Digital Output are the
specific interfaces for MULTIMAX. The DI interface can be used for triggering alarm, while the DO
can be used for controlling the slave device so as to realize real-time monitoring.
3.6.7.1 - DI
Click the right-most
The window is displayed as below when choosing "Counter" as the mode.
Item
Index
Enable
Multimax_user manual_v.4.0.4
Confidential
button of index as shown. The default mode is "ON-OFF"
Description
Indicate the ordinal of the list.
Click the toggle button to enable/disable this DI.
General Settings @ DI
July. 11, 2018
Default
--
OFF
52/139
