2.5 Ethernet Ports
There are two Ethernet ports, ETH0 and ETH1. Each Ethernet port has two LED indicators. The
yellow one is a link indicator, while the green one is a speed indicator. For details about status, see
the table below.
Indicator
Link indicator
Speed indicator
Multimax_user manual_v.4.0.4
Confidential
Status Description
On, solid Connection is established
On, blinking Data is being transferred
Off Connection is not established
On, solid 100 Mbps mode
Off 10 Mbps mode
