Before any intervention it is essential to cut off all supply of the machine
Repair
position switches FC4, FC5, FC201, FC202 and FC203 :
Checking
- Check the wiring.
- Power on the machine, actuate the end stops manually one by one, and check on the A1
feeder PLC that the indicator for the end stop actuated is lit. If the indicator corresponding to
the end stop actuated is not lit, the end stop actuated is faulty.
- Correspondence of the A1 feeder PLC indicators :
FC4
FC5
Replacing the FC4 and FC5 position switchs
- Remove the protection cover from the clamp guiding rail.
- Disconnect the cables from the faulty end stop.
- Remove the end stop detector from its bracket.
- Fit the new detector on the bracket.
- Refit the parts in the reverse sequence.
Motor M1 :
Checking
- Check the wiring.
- Power on the machines, actuate manually the KM201 and KM202 contactors, and check
that the M1 motor is started. Otherwise, the motor is faulty
Replacing
- Remove the left cover from the machine.
- Disconnect the supply wires of the motor.
- Remove the drive belt between the reducer and the control satellite.
- Remove the motor reducer bracket from the frame.
- Remove the motor and reducer from the bracket.
- Fit the new motor with the reducer.
- Refit the parts in the reverse sequence
04106016/GB
43-09
Feeding : Motion system
(electricity, steam, water, gas, compressed air...).
-> I0.8
-> I0.9
FC201 ->
FC202 ->
FC203 ->
12
I0.5
I0.6
I0.7
7
