AudioCodes MP-20 Series User Manual page 98

Parameter
3 Way Conference
3 Way Conference Mode
conference/conf_mode
Media Server Address
conference/conf_ms_addr
Message Waiting Indication
Enabled
msg_waiting_ind/enabled
Subscribe to MWI
msg_waiting_ind/subscribe
MWI Server IP Address or Host
Name
msg_waiting_ind/subscribe_ip
MWI Server Port
msg_waiting_ind/subscribe_port
MWI Subscribe Expiration Time
msg_waiting_ind/expiraition_timeout
Auto Attendant
Enabled
Line
Input Timeout
Greeting File
General Parameters
Stutter Tone Duration
stutter_tone_dur
Out of Service Behavior
out_of_service_bahavior
User's Manual
Selects how 3-way conference calls are handled:

Local: locally by the device

Remote: by a remote media server (RFC 4240)
The address of the remote media server that handles
conference calls.
Note: This parameter is available only when 'Remote' is
selected for the parameter '3 Way Conference Mode'.
If a user has an unheard voice mail message, a stutter dial tone
is heard when the user picks up the phone. In addition, the
device generates an FSK signal to the phone to indicate that a
message is waiting. If the telephone connected to the device
supports this feature, an MWI 'envelope icon' is displayed.
Select this check box if you must register with a MWI subscriber
server. If so, configure the three parameters below.
Defines the IP address or host name of the MWI server.
Note: This parameter is available only when the check box
'Subscribe to MWI' is selected.
Defines the port number of the MWI server.
Note: This parameter is available only when the check box
'Subscribe to MWI' is selected.
Defines the interval between registrations.
Note: This parameter is available only when the check box
'Subscribe to MWI' is selected.
Enables/Disables the Auto Attendant feature.
Enables line numbers as they appear in the Line Settings tab.
Enables the time in seconds, from the beginning of the Auto
Attendant message, until the conversation disconnects, if the
user hasn't received any input. This field should be set to the
length of the Auto Attendant message itself, plus a few seconds
to allow the user to press the required extension or to repeat the
message.
Defines the file name of the Auto Attendant message (.pcm).
When you enable message waiting and an unheard message
exists, a stutter tone is played to the phone for the duration
configured by this parameter and/or when you activate the call
forwarding feature (see Section
Defines the tone which is played instead of a dial tone if the user
configured a registrar IP and the registration failed. When the
Reorder tone is selected, a Reorder tone is played instead of a
dial tone. If "No Tone" is selected, then no tone is played.
98
MP-20x Multimedia Home Gateway
Description
10.5 on page 114).
Document #: LTRT-50614
