Figure 20-7: Time Server Settings Screen - AudioCodes MP-20 Series User Manual

5. For the device to perform an automatic time update, under the Automatic Time
Update group, do the following:
a. Select the 'Enabled' check box.
b. Select the protocol to be used for time update, by selecting either the 'Time of
Day' or 'Network Time Protocol' option.
c. In the 'Update Every' field, specify how often to perform the update.
d. You can define NTP servers, by clicking the New
Settings' screen appears.
e. In the 'Time Server' field, enter the IP address of the Time server (NTP), and then
click OK.
The following is an example of the relevant Telnet parameters:
rg_conf/admin/timezone=GMT
rg_conf/admin/tz_offset=0
rg_conf/admin/daylight_saving/enabled=0
rg_conf/admin/daylight_saving/from=28&3b;2
rg_conf/admin/daylight_saving/to=28&3b;9
rg_conf/admin/daylight_saving/offset=60
rg_conf/admin/daylight_saving/start/hour=0
rg_conf/admin/daylight_saving/start/minute=0
rg_conf/admin/daylight_saving/end/hour=1
rg_conf/admin/daylight_saving/end/minute=0
rg_conf/admin/tod/enabled=1
rg_conf/admin/tod/protocol=2
rg_conf/admin/tod/server/0/name=pool.ntp.org
rg_conf/admin/sntp/server/enabled=1
User's Manual

Figure 20-7: Time Server Settings Screen

304
MP-20x Multimedia Home Gateway
icon; the 'Time Server
Document #: LTRT-50614
