Parameter
Host Name or Address
proxy_address
Proxy Port
proxy_port
Maximum Number of Authentication
Retries
auth_retries
Use SIP Proxy IP and Port for
Registration
use_proxy_ip_port_for_registrar
SIP Security
signalling/sip/proxy_only
Address Type
sip_entity_accept_in_type
SIP Entity Address
sip_entity_accept_in
Use Redundant Proxy
redundancy_mode/mode=Redundant
Proxy Mode
Redundant Proxy Address
redundant_proxy/addr
User's Manual
Defines the IP address or host name of the SIP proxy.
Note: This parameter is available only if the 'Use SIP Proxy'
check box is selected.
Defines the port (UDP, TCP, or TLS) of the SIP proxy.
Note: This parameter is available only if the 'Use SIP Proxy'
check box is selected.
Defines how many times authenticated register messages
are re-sent if SIP 401 or 407 responses with a different
"nonce" are received.
Note: This parameter is available only if the 'Use SIP Proxy'
check box is selected.
When selected (default), the SIP proxy's IP address and
port is also used for registration. When selected, there is no
need to configure the address / port of the registrar (only the
'Register Expires' and 'Register Expires Failed' parameters
– described later).
Note: This parameter is available only if the 'Use SIP Proxy'
check box is selected.
The device's firewall can be configured to block incoming
packets that have the SIP signaling port as their destination.
You can configure up to two SIP entities (for example, the
SIP Proxy or an SBC), which are not blocked by the firewall.
The default value is 'Allow all SIP traffic' [0].
[0] – 'Allow all SIP traffic'
[1] – 'Allow SIP traffic from Proxy only'
[2] – 'Allow SIP traffic from Proxy and additional SIP entity'
Note: This parameter is available only if the 'Use SIP Proxy'
check box is selected.
Selects the address type of the additional SIP entity - IP
address or host name.
Note: This parameter is available only if the 'Sip Security'
field is set to 'Allow SIP traffic from Proxy and Additional SIP
Entity'.
Defines the address or host name (depending on the
settings of the 'Address Type' field) of the additional SIP
entity.
Note: This parameter is available only if the 'Sip Security'
field is set to 'Allow SIP traffic from Proxy and Additional SIP
Entity'.
Enables the use of a redundant proxy.
Defines the IP address of the redundant proxy.
Note: This parameter is available only if the 'Use
Redundant Proxy' check box is selected.
