User's Manual
14.4.2.2.3 LAN Status

Table 14-15: InternetGatewayDevice.LANDevice.i.LANEthernetInterfaceConfig.i.Stats

TR-069/TR-104
Parameter
BytesReceived
BytesSent
PacketsReceived
PacketsSent
14.4.2.2.4 VoIP Status via TR-104

Table 14-16: InternetGatewayDevice.Services.VoiceService.i.VoiceProfile.i.Line.i.Stats

TR-069/TR-104
Parameter
ResetStatistics
PacketsSent
PacketsReceived
BytesSent
BytesReceived
PacketsLost
Overruns
Underruns
IncomingCalls
Received
IncomingCalls
Answered
IncomingCalls
Connected
IncomingCallsFailed
Version 4.4.3
Configuration File
Parameter
mt_voip_get_state (line,
state)
mt_voip_get_state(line,
state)
mt_voip_get_state(line,
state)
mt_voip_get_state(line,
state)
Configuration File
Parameter
-
mt_voip_get_state(line,
state)
mt_voip_get_state(line,
state)
mt_voip_get_state(line,
state)
mt_voip_get_state(line,
state)
mt_voip_get_state(line,
state)
-
-
-
-
-
-
14. Remote Device Management
Total number of bytes received over the
interface since the device was last reset.
Total number of bytes sent over the interface
since the device was last reset.
Total number of packets received over the
interface since the device was last reset.
Total number of packets sent over the
interface since the device was last reset.
When set to one, it resets the statistics for
this voice line. Always False when read.
Total number of RTP packets sent for this
line.
Total number of RTP packets received for
this line.
Total number of RTP payload bytes sent for
this line.
Total number of RTP payload bytes received
for this line.
Total number of RTP packets that have
been lost for this line.
Total number of times the receive jitter buffer
has overrun for this line.
Total number of times the receive jitter buffer
has underrun for this line.
Total incoming calls received.
Total incoming calls answered by the local
user.
Total incoming calls that successfully
completed call setup signaling.
Total incoming calls that failed to
successfully complete call setup signaling.
225 MP-20x Multimedia Home Gateway
Description
Description
