User's Manual
5.6

Associated Elements

You can define certain elements and then use them later when configuring various features
throughout the Web interface. This is very convenient in that it eliminates the need to re-
configure the same element, especially if used in multiple configuration areas. These
elements include the following:

Scheduler Rules – see Section

Network Objects – see Section

Protocols – see Section
5.6.1

Configuring Scheduler Rules

Scheduler rules are used for limiting the activation of firewall rules to specific time periods,
specified in days of the week, and hours.

To define a Rule:
1. On the 'Advanced' screen, click the Scheduler
screen appears.
2. Click the New
3. In the 'Name' field, specify a name for the scheduler rule.
4. Under the Rule Activity Settings group, specify if the rule is active or inactive during
the designated time period, by selecting the appropriate check box.
Version 4.4.3
5.6.1
5.6.2
5.6.3 on page

Figure 5-6: Scheduler Rules Screen

icon; the 'Edit Scheduler Rule' screen appears.

Figure 5-7: Edit Scheduler Rule Screen

55
5. Getting Started with the Web Interface
on page 55
on page 57
59
icon; the 'Scheduler Rules'
MP-20x Multimedia Home Gateway
