3.2.4

Configuring Automatic Internet Dialer Detection

MP-20x supports the automatic detection of the user's Internet dialer type. This allows you
to ignore the Internet connection settings required in Configuring Your Internet Connection.
This support is customer ordered and pre-defined in the MP-20x factory settings. These
factory settings are according to the ISP's Internet connection requirements (e.g., PPPoE
user name and password), provided by the ISP for the parameters listed below.
Notes:
•
Detection of the dialer type occurs only at initial power up (or after restoring to
defaults).
•
If the Automatic Dialer Detection feature is enabled, the remote configuration file
mechanism only starts (immediately) once the automatic detection process is
performed successfully.
The parameters and their values required (from the ISP) for the Automatic Internet Dialer
Detection feature are shown below:
auto_dialer_detect/enabled=0
; where 0 = disabled and 1=enabled
auto_dialer_detect/done=1
; process completed successfully (1 = success and -1 = failed)
auto_dialer_detect/connection_type/0 /Type= PPPOE
auto_dialer_detect/connection_type/0/enabled=1
auto_dialer_detect/connection_type/0/user_name=xxx
; where xxx is the PPPoE username
auto_dialer_detect/connection_type/0/password=xxx
; where xxx is the PPPoE password
auto_dialer_detect/connection_type/1/type=L2TP
auto_dialer_detect/connection_type/1/enabled=1
auto_dialer_detect/connection_type/1/server_ip=xxx.xxx.xxx.xxx
; where xxx.xxx.xxx.xxx is the L2TP IP address
auto_dialer_detect/connection_type/1/username=xxx
; where xxx is the L2TP username
auto_dialer_detect/connection_type/1/password=xxx
; where xxx is the L2TP password
auto_dialer_detect/connection_type/2/type=DHCP
auto_dialer_detect/connection_type/2/enabled=1
auto_dialer_detect/auto_detect_retries=x
; number of retires for the detection feature
auto_dialer_detect/ping_retries=x
; number of pings to send for Internet connectivity check
auto_dialer_detect/ping_retries_timeout=x
; seconds to wait for ping response
auto_dialer_detect/max_dialer_conn_time=x
; seconds to wait for a dialer to connect
