Chapter 7 – Register Operations
102 – M
7.1.5 L
ETER EVEL
Note: ppp = The specified zero-based preset or load arm number (000-011).
mmm = The specified zero-based meter number (000-005).
Modbus:
The Modbus Preset Index Register sets the ppp index, Read/Write Register=996, Len=1, 16-Bit Integer
The Modbus Meter Index Register sets the mmm index, Read/Write Register=998, Len=1, 16-Bit Integer
Prefix Register Description
R / U 102000pppmmm Flow Control Module#
R / U 102001pppmmm Side-Stream on Mtr#
R / U 102002pppmmm Side Stream on Any Meter
R / U 102003pppmmm Unused
R / U 102004pppmmm Meter Address
R / U 102005pppmmm Meter Type
R / U 102006pppmmm Max Quad Errors
R / U 102007pppmmm Reset Quad Errors
R / U 102008pppmmm Low Flow Alarm Rate
R / U 102009pppmmm Low Flow Alarm Time
R / U 102010pppmmm Excess Flw Alrm Rate
R / U 102011pppmmm Minimum Flow Rate
R / U 102012pppmmm Maximum Flow Rate
R / U 102013pppmmm Low Flow DB Rate
R / U 102014pppmmm High Flow DB Rate
R / U 102015pppmmm 1st Stage DB Rate
R / U 102016pppmmm 2nd Stage DB Rate
R / U 102017pppmmm Valve Cntl Alrm Time
R / U 102018pppmmm Valve Fault Alrm Vol
R / U 102019pppmmm Creep Reset Time
R / U 102020pppmmm Ratio Adj P. Factor
R / U 102021pppmmm Ratio Adj D. Factor
R / U 102022pppmmm Meter Creep Alrm Vol
R / U 102023pppmmm Flow Scan Time
R / U 102024pppmmm Valve Dwell Time
R / U 102025pppmmm Valve Dwell StepRate
R / U 102026pppmmm Valve Dwell StepTime
R / U 102027pppmmm Adaptive Valve Control
R / U 102028pppmmm Analog Valve Control
R / U 102029pppmmm 4-20mA Increase Step
R / U 102030pppmmm 4-20mA Decrease Step
C R
ONFIGURATION EGISTERS
Min
Data Type Value
unsigned int
unsigned int
disable/enable
unsigned int
meter type
unsigned int
unsigned int 1000
unsigned int
unsigned div1000 0.000 999.999
unsigned int
unsigned int
unsigned int
unsigned int
unsigned int
unsigned int
unsigned int
unsigned div1000 0.000 65.535
unsigned int
unsigned int
unsigned div100 0.00
unsigned div100 0.00
unsigned int
unsigned div1000 0.100
unsigned div1000 0.010 65.535
unsigned int
unsigned div1000 0.000
disable/enable
disable/enable
unsigned div 1000
unsigned div 1000
Max Default
Value Value Protection
0 31 0 General
0 6 0 General
Disabled General
General
0 255 0 W & M
Volume Pulse W & M
0 65535 10 W & M
65535 10000 W & M
0 65535 10 General
10.000 General
0 9999 800 General
0 9999 50 General
0 9999 650 General
0 9999 40 General
0 9999 40 General
0 9999 40 General
0 9999 40 General
10.000 General
0 65535 30 General
0 65535 0 General
655.35 10.00 General
655.35 0.30 General
0 65535 15 General
1.000 0.100 General
1.000 General
0 9999 0 General
5.000 0.000 General
Disabled General
Disabled General
0 4.000 0.080 General
0 4.000 0.800 General
99
Modbus
Register
Len=2
1600
1602
1604
1606
1608
1610
1612
1614
1616
1618
1620
1622
1624
1626
1628
1630
1632
1634
1636
1638
1640
1642
1644
1646
1648
1650
1652
1654
1656
1658
1660
