Chapter 2 –MultiLoad Responses
CHAPTER 2
<command_status> <rcu_status> <card_status> <command specific response data>
For MultiLoad to acknowledge a message two conditions must be met. First the message must fit the Message
Framing Protocol with a valid LRC, BCC or CRC. Second, the address specified in the first two characters of
the command must match the configured MultiLoad address.
requirements will be sent a response.
Modbus:
If using the Modbus protocol, the Modbus Extended Services Registers must be used to pass in
these ASCII string commands.
The first three characters of every response will contain command, RCU and card status data as defined below.
enum
{
VALID_COMMAND
INVALID_PARAMETER
INVALID_COMMAND
} command_status;
enum
{
IDLE
AUTH_BAY
MENU_MODE
DIAG_MODE
AUTHORIZING_LOAD
LOAD_AUTHORIZED
COMPLETING_LOAD
TRANSACTION_DONE
TRANSACTION_CANCEL
PULLING_TRANSACTION
ARCHIVING_TRANSACTION
TRANSACTION_AUTHORIZED
RCU_NOT_CONFIGURED
RCU_POWER_UP
INITIALIZING
NO_TRANSACTION
REMOTE_AUTH_PRESET1
REMOTE_AUTH_PRESET2
REMOTE_AUTH_PRESET3
REMOTE_AUTH_PRESET4
REMOTE_AUTH_PRESET5
REMOTE_AUTH_PRESET6
M L C
ULTI OAD OMMAND
R
ESPONSES
Any message that satisfies both of these
= '0',
= '1',
= '2'
= '0',
= 4',
= '9',
= '%',
= 'A',
= 'B',
= 'C',
= 'D',
= 'E',
= 'P',
= 'R',
= 'T',
= '?',
= '!',
= 'I',
= 'N',
= 'a',
= 'b',
= 'c',
= 'd',
= 'e',
= 'f',
16
