Toptech MultiLoad II Manual page 100

Chapter 7 – Register Operations
Prefix Register Description
R / U 102031pppmmm Excess Flow Alarm Time
R / U 102032pppmmm Analog Valve No Flow mA
R / U 102033pppmmm Unused
R / U 102034pppmmm Analog Meter Flow Rate @ 4mA
R / U 102035pppmmm Analog Meter Flow Rate @ 20mA
R / U 102036pppmmm Analog Meter Flow Rate Offset
R / U 102037pppmmm Analog Meter Flow Rate Cutoff
R / U 102038pppmmm Unused
R / U 102039pppmmm Unused
R / U 102040pppmmm Density Sensor FCM#
R / U 102041pppmmm Unused
R / U 102042pppmmm Default Density
R / U 102043pppmmm Alarm Low Density
R / U 102044pppmmm Alarm High Density
R / U 102045pppmmm Density Alarm Time
R / U 102046pppmmm Density @ Low Value
R / U 102047pppmmm Density @ High value
R / U 102048pppmmm Density Offset
R / U 102049pppmmm Unused
R / U 102050pppmmm Unused
R / U 102051pppmmm Pressure Sensor FCM#
R / U 102052pppmmm Unused
R / U 102053pppmmm Default Pressure
R / U 102054pppmmm Alarm Low Pressure
R / U 102055pppmmm Alarm High Pressure
R / U 102056pppmmm Pressure Alarm Time
R / U 102057pppmmm Pressure @ Low Value
R / U 102058pppmmm Pressure @ High Value
R / U 102059pppmmm Pressure Offset
R / U 102060pppmmm Unused
R / U 102061pppmmm Relative Density Sensor FCM#
R / U 102062pppmmm Unused
R / U 102063pppmmm Default Relative Density
R / U 102064pppmmm Alarm Low Relative Density
R / U 102065pppmmm Alarm High Relative Density
R / U 102066pppmmm Relative Density Alarm Time
R / U 102067pppmmm Relative Density @ Low Value
Data Type
unsigned div 1000
unsigned div 1000
unsigned int
unsigned int
signed div1000
unsigned int
fcm address analog input
unsigned div10
unsigned div10
unsigned div10
unsigned int
unsigned div10
unsigned div10
signed div10
fcm address analog input
unsigned div100
unsigned div100
unsigned div100
unsigned int
unsigned div100
unsigned div100
signed div100
fcm address analog input
unsigned div10000
unsigned div10000
unsigned div10000
unsigned int
unsigned div10000
Min Max Default
Value Value Value
0 65535 0
0.000 20.000 0.000
0 9999 0
0 9999 600
-9.999 9.999 0
0 9999 0
Disabled
0 9999.9 0
0 9999.9 0
0 9999.9 12000
0 60 0
0 4000.0 0
0 4000.0 12000
-300 300 0
Disabled
0 9999.99 9999.99
0 9999.99 100.00
0 9999.99 450.00
0 60 0
0 4000.00 0
0 4000.00 650.00
-30.00 30.00 0.00
Disabled
0.0000 2.0000 0.0000
0.0000 2.0000 0.0000
0.0000 2.0000 1.2000
0 60 0.0000
0.0000 4.0000 0.0000
10
0
Modbus
Register
Protection Len=2
General 1662
General 1664
General 1666
W & M 1668
W & M 1670
W & M 1672
W & M 1674
General 1676
General 1678
W & M 1680
General 1682
General 1684
General 1686
General 1688
General 1690
W & M 1692
W & M 1694
W & M 1696
General 1698
General 1700
W & M 1702
General 1704
W & M 1706
General 1708
General 1710
General 1712
W & M 1714
W & M 1716
W & M 1718
General 1678
W & M 1680
General 1682
General 1684
General 1686
General 1688
General 1690
W & M 1692
