Toptech MultiLoad II Manual page 101

Chapter 7 – Register Operations
Prefix Register Description
R / U 102068pppmmm Relative Density @ High Value
R / U 102069pppmmm Relative Density Offset
R / U 102070pppmmm 2% MF Limit Ref
R / U 102071pppmmm Adjacent MF Dev Limt
R / U 102072pppmmm Temp Offset Limit
R / U 102073pppmmm Output Pulse FCM#
R / U 102074pppmmm Output Pulse Factor
R / U 102080pppmmm Unused
R / U 102081pppmmm Alarm Out FCM#
R / U 102082pppmmm Authorized FCM#
R / U 102083pppmmm Permiss FCM#
R / U 102084pppmmm Permiss Out FCM#
R / U 102085pppmmm Meter K-Factor
R / U 102086pppmmm Quad Check Enable
R / U 102087pppmmm Unused
R / U 102088pppmmm Temperature Offset
R / U 102089pppmmm Temperature Alarm Time
R / U 102090pppmmm Temp Sensor FCM#
R / U 102091pppmmm Temperature Sensor
R / U 102092pppmmm Default Temperature
R / U 102093pppmmm Alarm Low Temp
R / U 102094pppmmm Alarm High Temp
R / U 102095pppmmm Temp Module Type
R / U 102096pppmmm Temperature @ Low Value
R / U 102097pppmmm Temperature @ High Value
R / U 102098pppmmm Unused
R / U 102099pppmmm unused
R / U 102100pppmmm Unused
R / U 102101pppmmm Unused
R / U 102102pppmmm Unused
R / U 102103pppmmm Unused
R / U 102104pppmmm Unused
R / U 102105pppmmm Unused
R / U 102106pppmmm Unused
R / U 102107pppmmm Unused
R / U 102108pppmmm API Gravity Sensor FCM#
R / U 102109pppmmm Default API Gravity
Data Type
unsigned div10000
signed div10000
unsigned div10000
unsigned div10000
unsigned div100
fcm address
unsigned div 1000
fcm address
fcm address
fcm address
fcm address
unsigned int
disable/enable
signed div100
unsigned int
fcm address analog input
disable/enable
signed div10
signed div10
signed div10
unsigned int
signed div10
signed div10
fcm address analog input
unsigned div10
Min Max Default
Value Value Value
0.0000 4.0000 1.2000
-0.3000 0.3000 0.0000
0.0000 6.5535 0.0000
0.0000 0.1000 0.0000
0.00 5.00 3.00
Disabled
1.000 50.000 10.000
Disabled
Disabled
Disabled
Disabled
1 65535 50
Disabled
-5.00 5.00 0.00
0 60 0
Disabled
Enabled
-999.9 999.9 999.9
-999.9 999.9 -999.9
-999.9 999.9 999.9
0 19 0
-999.9 999.9 -50.0
-999.9 999.9 350.0
Disabled
-1000 11000 0
10
1
Modbus
Register
Protection Len=2
W & M 1694
W & M 1696
W & M 1740
W & M 1742
W & M 1744
General 1746
General 1748
General 1760
General 1762
General 1764
General 1766
General 1768
W & M 1770
W & M 1772
General 1774
W & M 1776
General 1778
W & M 1780
W & M 1782
W & M 1784
General 1786
General 1788
W & M 1790
W & M 1792
W & M 1794
General 1796
General 1798
General 1800
General 1802
General 1804
General 1806
General 1808
General 1810
General 1812
General 1814
W & M 1816
Conditional 1818
