Chapter 6 – Meter Commands
Note: The Host will still need to send a MEB command for each preset that reaches a
PRESET_END_OF_BATCH state.
Modbus:
Write Only Register=7044, Len=1, 16-Bit Integer (any value)
6.5 B C
ATCH OMPLETE
MBCppp
Where:
ppp = The specified zero-based preset or load arm number (000-011).
When a BC command is received, the preset flow will stop and the batch will be marked as complete. The
operator will not be able to restart the batch, but will be allowed to clear the batch and preset another (pending
Host authorization).
Modbus:
Write Only Register=7045+ppp, Len=1, 16-Bit Integer (any value)
6.6 B E
ATCH ND
MBEppp
Where:
ppp = The specified zero-based preset or load arm number (000-011).
Command used to start end batch processing and to transition state to PRESET_END_OF_BATCH when flow
stops and final values are received.
Note: Typical end of batch command order is:
MSMppp (tell Multiload to stop flow)
MBCppp (tell Multiload to mark batch as complete, no further flowing on batch)
MBEppp (tell Multiload to get ready for total pickup)
wait for state==PRESET_END_OF_BATCH (ok to get totals)
MRSppp to get totals
MEBppp (ok to clear totals on Multiload)
Modbus:
Write Only Register=7057+ppp, Len=1, 16-Bit Integer (any value)
6.7 E B
ND ATCH
MEBppp
Where:
ppp = The specified zero-based preset or load arm number (000-011).
Command is used to finish end-of-batch processing and that totals can be cleared.
Modbus:
Write Only Register=7069+ppp, Len=1, 16-Bit Integer (any value)
:
:
27
