Chapter 7 – Register Operations
SECURITY_COMPLEXITY_TYPE_ALL
}
"Display Load Type" Select how the total amount of product being loaded will be displayed on the screen.
Enum{// Enumerated Value
DISPLAY_LOAD_TYPE_DISABLED
DISPLAY_LOAD_TYPE_GROSS
DISPLAY_LOAD_TYPE_NET
DISPLAY_LOAD_TYPE_MASS
}
"SCS Display Type" Select when the SCS Prompts will be displayed, either before or after the load.
Enum{// Enumerated Value
SCS_PROMPTS_DISPLAY_TYPE_AFTER
SCS_PROMPTS_DISPLAY_TYPE_BEFORE
}
000 – RCU L
7.1.2
EVEL
Prefix Register Description
R / U 004 Reload ROM Lang File
R / U 008 Driver Language
R / U 009 Program Mode Language
R / U 010 Card Reader Type
R / U 011 Prox Card Pull Secs
R / U 012 Processing Mode
R / U 013 Message Swap Delay
R / U 014 Message Hold Delay
Max GPS Site Distance
R / U 015 (MultiLoad Mobile Only)
R / U 016 Auto Authorize
R / U 017 MM/DD/YY Date
R / U 018 Mass Measure Used
R / U 019 Load Date From End
R / U 020 Measure Used
R / U 021 Print Blend Details
R / U 022 Compartment Entry
R / U 023 Config Timeout Mins
R / U 024 Print Totalizers
R / U 025 Simulation Mode
R / U 026 Large Prompts
R / U 027 Confirm Flow Starts
R / U 028 Display Adtv as CCs
C R
ONFIGURATION EGISTERS
disable/enable
remote processing
disable/enable
disable/enable
mass measure
disable/enable
disable/enable
disable/enable
disable/enable
disable/enable
disable/enable
Register Value
0
1
2
3
Register Value
0
1
Min Max
Data Type
Value Value
language
language
card-reader
unsigned int 2 30
unsigned int 1 60
unsigned int 1 60
unsigned int 0 10000
measures
unsigned int 0 2
unsigned int 0 99
totalizers
7
Modbus
Default
Protection Register
Value
Len=2
Enabled General 1008
English General 1016
English General 1018
1 General 1020
3 General 1022
Enabled General 1024
3 General 1026
10 General 1028
1030
200 General
Disabled General 1032
Enabled W & M 1034
None W&M 1036
Enabled General 1038
Gallons W & M 1040
1 General 1042
Disabled General 1044
20 General 1046
None General 1048
Disabled W & M 1050
Disabled General 1052
Disabled General 1054
Disabled General 1056
91
