Toptech MultiLoad II Manual page 97

Chapter 7 – Register Operations
Prefix Register Description
R / U 101070ppp BSW 2 Offset
R / U 101071ppp Oil Density
R / U 101072ppp Water Density
R / U 101073ppp Flow Rate Mode
R / U 101074ppp Number of Samplers
R / U 101075ppp Unused
R / U 101076ppp Unused
R / U 101077ppp Unused
R / U 101078ppp Unused
R / U 101079ppp Unused
R / U 101080ppp Diverter Valve FCM#
R / U 101081ppp Divert BSW Value
R / U 101082ppp Divert Start Time
R / U 101083ppp Divert Restart Time
R / U 101084ppp BSW Divert Alarm Time
R / U 101085ppp BSW Stabilization Time
R / U 101086ppp Remote Clear FCM#
R / U 101087ppp Alt. H.F. Rate FCM#
R / U 101088ppp Close Blk Val FCM#
R / U 101089ppp Blk Val Status FCM#
R / U 101090ppp Open Blk Val FCM#
R / U 101091ppp Flow Active FCM#
R / U 101092ppp Batch Authorizd FCM#
R / U 101093ppp Remote Start FCM#
R / U 101094ppp Swing Arm FCM#
R / U 101095ppp Meter Stop FCM#
R / U 101096ppp Alarm Out FCM#
R / U 101097ppp Authorized FCM#
R / U 101098ppp Permiss FCM#
R / U 101099ppp Permiss Out FCM#
R / U 101100ppp Unused
R / U 101101ppp Recipe Select Bit 0 FCM#
R / U 101102ppp Recipe Select Bit 1 FCM#
R / U 101103ppp Recipe Select Bit 2 FCM#
R / U 101104ppp Recipe Select Bit 3 FCM#
R / U 101105ppp Recipe Select Bit 4 FCM#
R / U 101106ppp Unused
Min
Data Type Value
signed div 10 -3.00
unsigned div 10 0
unsigned div 100 0
Flow Rate Mode
unsigned int 0
-
fcm address
signed div 100 -10.00
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
Max Default
Value Value Protection
3.00 0 General
99999 0 General
99999 0 General
Minute General
20 0 General
- General
General
General
General
General
Disabled General
110.00 110.00 General
60 30 General
60 15 General
60 10 General
60 5 General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
General
97
Modbus
Register
Len=2
1540
1542
1544
1546
1548
1550
1552
1554
1556
1558
1560
1562
1564
1566
1568
1570
1572
1574
1576
1578
1580
1582
1584
1586
1588
1590
1592
1594
1596
1598
N/A
N/A
N/A
N/A
N/A
N/A
N/A
