Chapter 8 – Communication Trace Example
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0000)
Sent:(R112001) Received:
(0001120010000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0000)
Sent:(R112002) Received:
(0001120020000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0000)
Sent:(R112003) Received:
(0001120030000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0000)
Sent:(R112004) Received:
(0001120040000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0000)
Modbus:
Fn=0x03, Read Registers 3000 ... 3006 (Preset Gross Totalizers)
Fn=0x03, Read Registers 3144 ... 3191 (Component Gross Totalizers)
Fn=0x03, Read Registers 3336 ... 3432 (Additive Gross Totalizers)
Etc...
8.3 B A
ATCH UTHORIZATION
8.3.1 A B
UTHORIZE A ATCH ON
Checking status found a preset authorization request for a preset.
Sent:(Q) Received: (0a1CA1A)
Modbus:
Fn=0x03, Read Register 7000 -> a
Prompt driver for batch information.
Display available product names
Sent:(T_H_K_Y! 1. Regular Unlead_Y" 2. Premium Unlead) Received: (0a1)
Modbus:
Use Extended Services Register
Prompt for product name
Sent:(T_H_>Enter Preset #01 Product Code: _@ _L02_E) Received: (0a1)
Modbus:
Use Extended Services Register
Wait for driver input done
M L
ULTI OAD
168
