Toptech MultiLoad II Manual page 107

Chapter 7 – Register Operations
Prefix Register Description
R / U 104036pppaaa Over Add Alrm # Inj
R / U 104037pppaaa Check Add Tol Time
R / U 104038pppaaa Unauth Flow Alrm Vol
R / U 104039pppaaa Valve Fault Alrm Vol
R / U 104040pppaaa Over Inject Vol
R / U 104041pppaaa Creep Reset Time
R / U 104042pppaaa Unauth Reset Time
R / U 104043pppaaa Max Pistn Throw Time
R / U 104044pppaaa Pump Start Alrm Time
R / U 104045pppaaa Meter Creep Alrm Vol
R / U 104046pppaaa Remote Calibration
R / U 104047pppaaa B.V. Open Alrm Time
R / U 104048pppaaa B.V. Close Alrm Time
R / U 104049pppaaa Pump Stop Delay
R / U 104050pppaaa Flush Pump Run Time
R / U 104051pppaaa Meter Flushed
R / U 104052pppaaa Solenoid Flushed
R / U 104053pppaaa Unused
R / U 104054pppaaa W&M Alarm Promo Count
R / U 104055pppaaa W&M Alarm Reset Mode
R / U 104085pppaaa Unused
R / U 104086pppaaa Unused
R / U 104087pppaaa Unused
R / U 104088pppaaa Flush Pump Run FCM#
R / U 104089pppaaa Close Blk Val FCM#
R / U 104090pppaaa Blk Val Status FCM#
R / U 104091pppaaa Open Blk Val FCM#
R / U 104092pppaaa Test Button FCM#
R / U 104093pppaaa Pump Run FCM#
R / U 104094pppaaa Pump Kill FCM#
R / U 104095pppaaa Pump Status FCM#
R / U 104096pppaaa Alarm Out FCM#
R / U 104097pppaaa Authorized FCM#
R / U 104098pppaaa Permiss FCM#
R / U 104099pppaaa Permiss Out FCM#
Date Type Min Value Max Value Default Value Protection
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned div1000 0.100
unsigned int 0
unsigned int 0
disable/enable
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
disable/enable
disable/enable
unsigned int 0
alarm count
reset mode 0
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
fcm address
65535 3 Conditional
65535 10 Conditional
65535 100 General
65535 300 General
65535 0 Conditional
65535 0 General
65535 0 General
10.000 1.800 General
65535 2 General
65535 150 General
Enabled General
65535 10 General
65535 10 General
65535 3 General
65535 30 General
Disabled General
Disabled General
General
65535 0 W & M
10 0 W & M
General
General
General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
Disabled General
10
7
Modbus
Register
Len=2
2072
2074
2076
2078
2080
2082
2084
2086
2088
2090
2092
2094
2096
2098
2100
2102
2104
2106
2108
2110
2170
2172
2174
2176
2178
2180
2182
2184
2186
2188
2190
2192
2194
2196
2198
