Preset Level Configuration Registers - Toptech MultiLoad II Manual

Chapter 7 – Register Operations
101 – P
7.1.4 L
RESET EVEL
Note: ppp = The specified zero-based preset or load arm number (000-011).
Modbus:
The Modbus Preset Index Register sets the ppp index, Read/Write Register=996, Len=1, 16-Bit Integer
Prefix Register Description
R / U 101000ppp Number of Meters
R / U 101001ppp Number of Components
R / U 101002ppp Number of Additives
R / U 101003ppp Preset Enabled
R / U 101004ppp Blending Type
R / U 101005ppp W&M Controlled
R / U 101006ppp Proving Flow Rate
R / U 101007ppp Excess Flw Alrm Rate
R / U 101008ppp Overrun Alarm Vol
R / U 101009ppp Low Flow Start Vol
R / U 101010ppp Low Flow Restart Vol
R / U 101011ppp Low Flow Rate
R / U 101012ppp High Flow Rate
R / U 101013ppp Proving Low Flow Vol
R / U 101014ppp Line Flush Vol
R / U 101015ppp Line Flush Min Vol
R / U 101016ppp Line Flush Comp#
R / U 101017ppp Take L.F. from Match
R / U 101018ppp Take L.F. from First
R / U 101019ppp Take L.F. from Last
R / U 101020ppp Compute Blend Density
R / U 101021ppp Alt. High Flow Rate
R / U 101022ppp Stop Start Delay
R / U 101023ppp Blnd Chk Start Vol
R / U 101024ppp Blnd Chk Restart Vol
R / U 101025ppp Blnd Chk Alarm %
R / U 101026ppp Blnd Chk Alarm Vol
R / U 101027ppp Blnd Chk Alarm Time
R / U 101028ppp Low Flow Start Percentage
R / U 101029ppp Blnd On Lead Comp
R / U 101030ppp Blnd Adj Start Vol
R / U 101031ppp Blnd Adj Restart Vol
R / U 101032ppp Blnd Adj Dev %
C R
ONFIGURATION EGISTERS
disable/enable
Blend_on_lead
Min
Data Type Value
unsigned int 1
unsigned int 1
unsigned int 0
disable/enable
blend_type
disable/enable
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
disable/enable
disable/enable
disable/enable
unsigned int 0
unsigned int 0
unsigned int 0
unsigned int 0
percent 0.10% 100.00%
unsigned int 0
unsigned int 0
percent 0
0
unsigned int 0
unsigned int 0
percent 0.00% 100.00%
Max Default
Value Value Protection
6 1 General
8 1 General
16 0 General
Enabled General
Disabled General
Disabled W & M
9999 600 General
9999 1100 General
65535 5 General
65535 50 General
65535 15 General
9999 150 General
9999 600 General
65535 50 General
65535 0 General
65535 0 General
8 0 General
Enabled General
Disabled General
Disabled General
Disabled W&M
9999 600 General
65535 0 General
65535 60 Conditional
65535 10 Conditional
5.00% Conditional
65535 25 Conditional
65535 10 Conditional
100 0 General
3 NONE General
65535 60 General
65535 10 General
1.00% General
95
Modbus
Register
Len=2
1400
1402
1404
1406
1408
1410
1412
1414
1416
1418
1420
1422
1424
1426
1428
1430
1432
1434
1436
1438
1440
1442
1444
1446
1448
1450
1452
1454
1456
1458
1460
1462
1464
