5. CONFIGURATION FROM PC
5.12

Routing of incoming calls

When applying for IMN numbers, a Terminal Id (OID/DID) is received from the
Net service provider. All devices connected to FELCOM 70 can make outgoing
calls. For incoming calls it must be assured that the Terminal Ids and MSN
numbers configured are as commissioned.
To make an incoming call reach a particular device, an MSN number and the
Terminal Id "connected" to the IMN number must be programmed into the
Communication Unit (CU). See later in this manual.
The table below lists valid MSN numbers for the available ISDN services.
Numbers to be programmed:
In ISDN device:
MSN number
For an easy start, the some Terminal Ids and MSN numbers have been
preprogrammed into the CU (marked with a star in the table).
In the 4.8 kbps speech and 3.1 kHz audio columns of the ISDN PORTS table the
Term.Id is represented by an X, allowing an ISDN Term.Id to be used for
analogue ports.
Note: A Term.Id already entered is not accepted.
ANALOGUE PORTS
4.8 speech
Port Term.ld MSN
TEL 1 03* 01*
TEL 2 04* 02*
TEL 3 02* 03*
3.1 kHz audsio
Port Term.ld MSN
TEL 4 61* 04*
5-26
MSN number and Terminal Id
(the Terminal Id is paired with a specific IMN number)
LIST OF VALID TERMINAL IDs AND MSN NUMBERS
ISDN PORT
4.8 kbps speech 64 kbps speech
Term.ld MSN Term.ld MSN
01* 20* 91* 30*
0X 21 92 31
0X 22 93 32
0X 23 94 33
0X 24 95 34
0X 25 96 35
0X 26 97 36
0X 27 98 37
0X 28 99 38
01/20 Distress 91/30 Distress
Handset. First Handset. First
HS connected HS connected
via Distress via Distress
Alert Unit. Alert Unit.
In Communication Unit:
3.1 kHz audio 56 kbps data
Term.ld MSN Term.ld MSN
61* 40* 71* 50*
6X 41 72 51
6X 42 73 52
6X 43 74 53
6X 44 75 54
6X 45 76 55
6X 46 77 56
6X 47 78 57
6X 49 79 58
3.1 kHz/
64 kbps
audio service
ISDN/RS-232/
USB PORTS
64kbps data
Term.ld MSN
51* 60*
52* 61*
53* 62*
54* 63*
55 64
56 65
57 66
58 67
59 68
51/60, preset for ISDN port
52/61, preset for RS-232A port
53/62, preset for USB port
54/63, preset for RS-232B port
