Furuno FELCOM 70 Operator's Manual page 176

6. DATA COMMUNICATION
6.5.2 Connecting up
Procedure for ISDN-to-USB installation
1. Connect the USB cable between the ISDN USB adapter and the PC USB
port.
2. Connect the ISDN cable between the ISDN USB adapter and the ISDN port
on the communication unit of the FELCOM 70. We recommend Eicon Diva
ISDN USB Adapter.
3. Turn on the FELCOM 70 and PC. Windows opens the Found New
Hardware Wizard.
6-86
ISDN
ISDN ISDN
4 5 3 6 4 5 3 6
4 5 3 6 4 5 3 6
ISDN ISDN
ISDN
FELCOM 70
Eicon Diva ISDN
USB Adapter
(Recommended adapter)
ISDN ISDN TEL 4
8 1 8 1 8 1
1 8 1 8 1 8
ISDN ISDN TEL 3
PC USB port
DTE
