Technical Information

A.4.6 USB Connector

USB Type A
A.4.7 Configuration Connector
RJ45 CONFIGURATION
A.4.8 Power Supply Connector
Jack 5.5/2.5mm
A.5 Technical Specifications
A.5.1 Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
32
PIN
1
2
3
4
Shell
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal -> POSITIVE
External -> NEGATIVE
Freescale QorIQ.
1 Gbyte in SDRAM.
FLASH Memory (32 Mbytes).
USB
VCC
DATA-
DATA+
GND
Shield
CONF
--
RxD
GND
--
--
GND
TxD
--
Teldat S.A.
Teldat Router iM8
