A.5.6 Wireless LAN Interface
WLAN standards
CONNECTOR
Frequency range
WLAN modes
Modulation Techniques
Automatic Rate Selection (ARS) Available.
Transmission rate
Data rates
Data rates for 802.11n, Long
Guard (800ns), 20 MHz
Data rates for 802.11n, Short
Guard (400ns), 20 MHz
Data rates for 802.11n, Long
Guard (800ns), 40 MHz
Data rates for 802.11n, Short
Guard (400ns), 20 MHz
Output power limitation (without
antenna gain)
Output Power
Teldat Router iM8
IEEE 802.11a/b/g/n.
Up to eight SMA-RP female connectors.
2.4 GHz: 2412 ~ 2472 MHz.
5 GHz: 5180 ~ 5825 MHz.
2,4 GHz Operation: 802.11b only; 802.11g only, 802.11b/g ; 802.11b/g/n ;
802.11g/n;
5 GHz Operation: 802.11a only;802.11a/n; 802.11n.
OFDM: BPSK, QPSK, DBPSK,DQPSK,16-QAM, 64-QAM, 256-QAM.
Automatic.
802.11a: 6~54 Mbps.
802.11b: 1~11 Mbps.
802.11g: 6~54 Mbps.
802.11n (HT20): MCS0 ~ MCS15.
802.11n (HT40): MCS0 ~ MCS15.
MSC0 6,5 Mbps; MSC1 13 Mbps; MCS2 19,5 Mbps; MCS3 26 Mbps; MCS4 39
Mbps; MSC5 52 Mbps; MCS6 58,5 Mbps; MCS7 65 Mbps; MCS8 13 Mbps; MCS9
26 Mbps; MCS10 39 Mbps; MCS11 52 Mbps;MCS12 78 Mbps; MCS13 104 Mbps;
MCS14 117 Mbps; MCS15 130 Mbps.
MSC0 7,2 Mbps; MSC1 14,4 Mbps; MCS2 21,7 Mbps; MCS3 28,9 Mbps; MCS4
43,3 Mbps; MSC5 57,8 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27
Mbps; MCS9 54 Mbps; MCS10 81 Mbps; MCS11108 Mbps; MCS12 162 Mbps;
MCS13 216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
MSC0 13,5 Mbps; MSC1 27 Mbps; MCS2 40,5 Mbps; MCS3 54 Mbps; MCS4 81
Mbps; MSC5 108 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27 Mbps;
MCS9 54 Mbps; MCS10 81 Mbps; MCS11108 Mbps; MCS12 162 Mbps; MCS13
216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
MSC0 15 Mbps; MSC1 30 Mbps; MCS2 45 Mbps; MCS3 60 Mbps; MCS4 90
Mbps; MSC5 120 Mbps; MCS6 135 Mbps; MCS7 150 Mbps.
Adjustable in dBm. Maximal power varies depending on data rate, frequency band
and country setting.
Note: The maximum RF power setting will vary according to specified country
regulations.
802.11a:
5.150~5.350 GHz Band:
• +16 dBm at 6~24 Mbps
• +14 dBm at 48 Mbps
