Teldat S.A.
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+ by MC7430
Bands
Band 1
Band 8
B.2 WIFI Specifications
The WMCND03TD module provides Wifi Radio communications, in accordance with standards 802.11a/b/g/n.
This product is supplied without any antennas. The operator must make sure that the antennas of his/her picking
comply with the local regulations.
Frequency Range
Operating
Output Power.
(tolerance ± 2 dB)
Teldat Router iM8
Frequencies
Tx: 1920–1980 MHz
Rx: 2110–2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
802.11a, 802.11n @ 5 GHz
• USA & Canada: 5.15 ~ 5.35GHz. , 5.47 ~ 5.725GHz and 5.725~5.850 GHz
• Europe: 5.15 ~ 5.35GHz and 5.47 ~ 5.725GHz GHz
• Japan: 5.15 ~ 5.35GHz and 5.47 ~ 5.725GHz GHz
• China: 5.725 ~ 5.850GHz
802.11b
• •2400 ~2497 MHz
802.11g
• 2400 ~2497 MHz
802.11n @ 2.4 GHz
• 2.4 ~2.5 GHz
802.11a/n:
• USA/Canada: 24 non-overlapping channels.
• Major Europe Countries: 19 non-overlapping channels.
• Japan: 19 non-overlapping channels.
• China: 5 non-overlapping channels.
802.11b:
• USA: 11 channels.
• Europe Countries: 13 channels.
• Japan: 14 channels.
802.11g/n:
• USA: 11 channels.
• Europe Countries: 13 channels.
• Japan: 13 channels.
Note: The maximum RF power setting will vary according to country-specific reg-
ulations.
802.11a:
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
Radio Information
