Technical Information
A.3.1 LAN Connector
RJ45 LAN
A.3.2 DSL Connector
RJ11 DSL
A.3.3 ANT Connectors
A.3.4 USB Connector
USB Type A
18
RJ45 PIN
1
2
3
4
5
6
7
8
RJ11 PIN
1
2
3
4
PIN
Internal
External
PIN
1
2
3
4
Shell
LAN
Tx+(input)
Tx-(input)
Rx+(output)
--
--
Rx-(output)
--
--
DSL
Joined to 2
Line
Line
Joined to 3
ANT
RF in/out
GND
USB
VCC
DATA-
DATA+
GND
Shield
Teldat S.A.
Teldat C1+L Router
