USB
Wi-Fi 1
Wi-Fi 2
LAN Switch
Eth WAN
Cell
Teldat Router iM8
USB Interface Status
Wifi-1 Interface Status
Wifi 2 Interface Status
LAN Switch interface activity
Base-T
SFP
Status
RSSI.
Coverage indication
Off -> system stopped.
Red -> interface is unavailable because it is installing, it is dis-
abled (shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not registered in the network or the quality
is insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Blinking (green/red) -> activity/maintenance.
Off -> Interface not available or not installed (not supported).
Red -> Interface not found, no data connection.
Amber -> Connecting.
Green -> Communications established. Blinking: depends on the
activity.
Off -> Interface not available or not installed (not supported).
Red -> Interface not found, no data connection.
Amber -> Connecting.
Green -> Communications established. Blinking: depends on the
activity.
Green -> connected. Blinking: connection data activity.
Red -> disconnected.
Off -> interface off.
Green -> connected. Blinking: connection data activity.
Off -> not used.
Green -> connected. Blinking: connection data activity.
Off -> not used.
Off -> system stopped.
Red -> interface is unavailable because it is installing, it is dis-
abled (shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not registered in the network or the quality
is insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Green -> connected. Blinking: connection data activity.
Green -> Good level.
Amber -> Fair level.
Red -> Critical level.
