3.5 Logs

The SuperSonix-NG keeps logs of all clone, hash, and wipe operations. Logs
can be viewed directly on the SuperSonix-NG or from a computer's browser (if
the SuperSonix-NG is connected to a network). In addition to viewing, the logs
can be exported to an external USB location such as a USB flash drive. Logs are
exported in PDF, HTML and XML format.
3.5.1 Step-by-step instructions – Viewing or exporting logs
1. Select Logs from the types of operation on the left side. A list of log files
will appear sorted by date (newest on top).
2. Select the log file to view by tapping the name of the log file. This will
highlight the log file chosen.
3. Tap the View icon to view the log file on-screen. The log files can also be
exported to a USB drive. To export the log files:
Repeat steps 2 through 4 if other log files need to be exported or viewed.
To print the log files, it is recommended to use the web interface as described in
Chapter 8: Remote Operation
of the screen. The browser's print menu will appear and the log can be printed
to an available printer on configured on the computer.
Logicube SuperSonix-NG™ User's Manual
a. Connect a formatted USB drive (USB flash drive or USB external
drive) to one of the two USB ports located on the front of the
SuperSonix-NG.
b. Tap the Export icon to export the log file via USB. The log will be
exported/copied to the attached USB drive and will be in HTML,
PDF, and XML formats.
and click the print icon on the upper-right corner
