Administrator's Guide for ViewStation EX, ViewStation FX, and VS4000
Network and Call Status Tools
Diagnostic Tool
Call Status screen
Displays call type, data speed, and
number dialed for the current call.
In ISDN calls, this screen also
displays connection status for each
channel. Selecting a channel call
progress indicator displays its ISDN
number.
In calls placed through the
V.35/RS-449/RS-530 network
interface, this screen displays the
states of these signals:
• DTR
• RTS
• CTS
• DSR
• DCD
• RI
Bright indicators show high signals;
dim indicators show low signals.
Call Log screen
Displays the current Call Detail
Report (CDR) and provides access
to the archived CDR.
7-4
In the system's user interface
On the Diagnostics screen, select
Call Status.
For more information about this screen, see
Not available.
For more information about this screen, see
In the ViewStation web interface
On the Diagnostics screen, select
Call Status.
Call Status on page
On the Diagnostics screen, select
Call Log.
Call Log on page 6-5.
www.polycom.com/videodocumentation
6-3.
