Page 1 All-New Wrangler 2 0 1 8 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA This manual illustrates and describes the operation of With respect to any Vehicles Sold in Canada, the name features and equipment that are either standard or op- FCA US LLC shall be deemed to be deleted and the name tional on this vehicle.
Page 3 TABLE OF CONTENTS SECTION PAGE INTRODUCTION ..............3 GRAPHICAL TABLE OF CONTENTS .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 WARNINGS AND CAUTIONS ....8 ROLLOVER WARNING .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you Dear Customer, congratulations on selecting your new with the operation and maintenance of your vehicle. It is vehicle. Be assured that it represents precision workman- supplemented by Warranty Information, and customer ship, distinctive styling, and high quality.
Page 7: Rollover Warning
INTRODUCTION described for technical and/or commercial reasons. For Do not attempt sharp turns, abrupt maneuvers, or other further information, contact an authorized dealer. unsafe driving actions that can cause loss of vehicle con- trol. Failure to operate this vehicle safely may result in a If applicable, refer to the owners manual supplement for collision, rollover of the vehicle, and severe or fatal injury.
Page 8: How To Use This Manual
6 INTRODUCTION Failure to use the driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually.
Page 9: Symbols
INTRODUCTION Symbols Consult the following table for a description of the symbols that may be used on your vehicle or throughout this Owner’s Manual:...
Page 10: Warnings And Cautions
8 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against oper- ating procedures that could result in a collision, bodily injury and/or death. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information.
Page 11 GRAPHICAL TABLE OF CONTENTS CONTENTS FRONT VIEW ......10 INTERIOR ......13 REAR VIEW.
Page 12 10 GRAPHICAL TABLE OF CONTENTS FRONT VIEW Front View 1 — Hood/Engine Compartment 4 — Headlights 2 — Windshield 5 — Wheels 3 — Exterior Mirrors...
Page 13 GRAPHICAL TABLE OF CONTENTS 11 REAR VIEW Rear View 1 — Rear Lights 2— Swing Gate...
Page 14 12 GRAPHICAL TABLE OF CONTENTS INSTRUMENT PANEL Instrument Panel 1 — Air Outlet 4 — Multifunction Lever 7 — Steering Wheel 2 — Turn Signal/High Beam Control 5 — Storage Compartment 3 — Instrument Cluster 6 — Push Button Ignition...
Page 15 GRAPHICAL TABLE OF CONTENTS 13 INTERIOR Interior Features 1 — Door Handles 4 — Power Window Switches 2 — Seats 5 — Climate Controls 3 — Gear Selector 6 — Uconnect System...
Page 17 GETTING TO KNOW YOUR VEHICLE CONTENTS KEYS ....... . .19 SENTRY KEY .
Page 18 16 GETTING TO KNOW YOUR VEHICLE ▫ Rear Door Removal (Four-Door Models) ..41 MIRRORS ......60 ▫...
Page 19 GETTING TO KNOW YOUR VEHICLE 17 INTERIOR LIGHTS ..... . .65 FREEDOM TOP THREE-PIECE MODULAR HARD TOP — IF EQUIPPED ....91 ▫...
Page 20 18 GETTING TO KNOW YOUR VEHICLE ▫ Lowering The Soft Top ....127 REAR SWING GATE .....154 ▫...
Page 21: Keys
GETTING TO KNOW YOUR VEHICLE 19 KEYS Your vehicle uses a keyless ignition system. The ignition system consists of a key fob with Keyless Go and a Key Fob START/STOP push button ignition system. The Remote Keyless Entry system consists of a key fob with a mechani- cal key and Keyless Enter-N-Go feature if equipped.
Page 22 20 GETTING TO KNOW YOUR VEHICLE Backup Mode Starting To Unlock The Doors And Swing Gate In case the ignition switch does not change with the push Push and release the key fob unlock button once to unlock of a button, the key fob may have a low or dead battery. In the driver’s door only, or twice to unlock all the doors and this situation, a back up method can be used to operate the swing gate.
Page 23 GETTING TO KNOW YOUR VEHICLE 21 1-3 – Back Cover Pry Points Battery Replacement 2. Remove the depleted battery by inserting a small flat- 3. Install the new battery into the key fob, making sure the blade screwdriver into the battery removal slot and positive (+) side is facing up.
Page 24: Ignition Switch
22 GETTING TO KNOW YOUR VEHICLE Request For Additional Key Fobs General Information The following regulatory statement applies to all radio NOTE: Only key fobs that are programmed to the vehicle frequency (RF) devices equipped in this vehicle: electronics can be used to start and operate the vehicle. Once a key fob is programmed to a vehicle, it cannot be This device complies with Part 15 of the FCC Rules and programmed to any other vehicle.
Page 25 GETTING TO KNOW YOUR VEHICLE 23 NOTE: In case the ignition switch does not change with the The push button ignition can be placed in the following push of a button, the key fob may have a low or dead modes: battery.
Page 26: Vehicle On Message
24 GETTING TO KNOW YOUR VEHICLE Vehicle On Message WARNING! (Continued) When opening the driver’s door when the ignition is in • Never leave children alone in a vehicle, or with RUN (engine not running), a chime will sound to remind access to an unlocked vehicle.
Page 27: Remote Starting System - If Equipped
GETTING TO KNOW YOUR VEHICLE 25 REMOTE STARTING SYSTEM — IF EQUIPPED WARNING! (Continued) • Allowing children to be in a vehicle unattended is This system uses the key fob to start the engine dangerous for a number of reasons. A child or others conveniently from outside the vehicle while still could be seriously or fatally injured.
Page 28: Remote Start Cancel Message - If Equipped
26 GETTING TO KNOW YOUR VEHICLE • To drive the vehicle, push unlock button, and place the • Fuel level meets minimum requirement ignition in the ON/RUN position. • All removable doors must not be removed • With remote start, the engine will only run for 15 •...
Page 29: To Enter Remote Start Mode
GETTING TO KNOW YOUR VEHICLE 27 • Remote Start Cancelled — Time Expired To Exit Remote Start Mode Without Driving The Vehicle • Remote Start Disabled — Start Vehicle To Reset Push and release the Remote Start button one time or allow The message will stay active until the ignition is placed in the remote start cycle to complete the entire 15-minute the ON/RUN position.
Page 30: Remote Start Comfort Systems - If Equipped
28 GETTING TO KNOW YOUR VEHICLE Remote Start Comfort Systems — If Equipped SENTRY KEY When Remote Start is activated, the Climate Controls, The Sentry Key Immobilizer system prevents unauthorized optional heated seats, and optional heated steering wheel operation by disabling the vehicle. The system does not in temperatures below 40°...
Page 31: Replacement Keys
GETTING TO KNOW YOUR VEHICLE 29 NOTE: Duplication of key fobs may be performed at an CAUTION! authorized dealer. This procedure consists of programming a blank key fob to the vehicle electronics. A blank key fob The Sentry Key Immobilizer system is not compatible is one that has never been programmed.
Page 32: Vehicle Security Alarm - If Equipped
30 GETTING TO KNOW YOUR VEHICLE VEHICLE SECURITY ALARM — IF EQUIPPED 2. Perform one of the following methods to lock the vehicle: The vehicle security alarm monitors the vehicle doors for • Push lock on the interior power door lock switch with unauthorized entry and the ignition switch for unauthor- the driver and/or passenger door open.
Page 33: Doors
GETTING TO KNOW YOUR VEHICLE 31 NOTE: DOORS • The driver’s door key cylinder cannot arm or disarm the CAUTION! vehicle security alarm. Careless handling and storage of the removable door • When the vehicle security alarm is armed, the interior panels may damage the seals, causing water to leak power door lock switches will not unlock the doors.
Page 34: Power Door Locks - If Equipped
32 GETTING TO KNOW YOUR VEHICLE NOTE: The mechanical flip key can be used to lock or Power Door Locks — If Equipped unlock the doors, swing gate, glove compartment, and The power door lock switch is located on each front door console storage.
Page 35: Keyless Enter-N-Go - Passive Entry (If Equipped)
GETTING TO KNOW YOUR VEHICLE 33 NOTE: WARNING! • Passive Entry may be programmed ON/OFF; refer to • For personal security reasons and safety in a colli- “Uconnect Settings” in “Multimedia” for further infor- sion, lock the vehicle doors when you drive, as well mation.
Page 36 34 GETTING TO KNOW YOUR VEHICLE To Unlock From The Driver Side To Unlock From The Passenger Side With a valid Passive Entry key fob within 5 ft (1.5 m) of the With a valid Passive Entry key fob within 5 ft (1.5 m) of the driver’s door handle, grab the front driver door handle to passenger door handle, grab the front passenger door handle to unlock all doors and the swing gate automatically.
Page 37 GETTING TO KNOW YOUR VEHICLE 35 • A lock request is made by the door panel switch while To Lock The Vehicle’s Doors And Swing Gate the door is open. With one of the vehicle’s Passive Entry key fob within 5 ft When any of these situations occur, after all open doors are (1.5 m) of the driver or passenger front door handles, shut, the FOBIK-Safe search will be executed.
Page 38 36 GETTING TO KNOW YOUR VEHICLE NOTE: If “Unlock All Doors 1st Press” is programmed all doors & the swing gate will unlock when you grab hold of the swing gate handle. To select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press,” refer to “Uconnect Settings”...
Page 39: Child-Protection Door Lock System - Rear Doors
GETTING TO KNOW YOUR VEHICLE 37 NOTE: 3. Repeat steps one and two for the opposite rear door. • After pushing the door handle button, you must wait two seconds before you can lock or unlock the doors, using any Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle without the vehicle reacting and unlocking.
Page 40: Front Door Removal
38 GETTING TO KNOW YOUR VEHICLE NOTE: For emergency exit with the system engaged, move the lock lever rearward (located on the door trim panel), roll down the window and open the door with the outside door handle. Front Door Removal WARNING! Do not drive your vehicle on public roads with the doors removed as you will lose the protection they can...
Page 41 GETTING TO KNOW YOUR VEHICLE 39 1. Roll down the glass window to prevent any damage. 3. Remove the check screw from the center door check (using a #T40 Torx head driver). 2. Remove the hinge pin screws from the upper and lower outside hinges (using a #T50 Torx head driver).
Page 42 40 GETTING TO KNOW YOUR VEHICLE 4. Remove the plastic wiring access door under the instru- 5. Pull up on the red locking tab to unlock the wiring ment panel by sliding the plastic panel along the door harness. frame toward the seats until the tabs are detached. Closed Wiring Harness Wiring Access Door 1 –...
Page 43: Getting To Know Your Vehicle 41
GETTING TO KNOW YOUR VEHICLE 41 NOTE: The upper hinge has a longer pin, which can be used to assist in guiding the door into place when reinstalling. Rear Door Removal (Four-Door Models) WARNING! Do not drive your vehicle on public roads with the doors removed as you will lose the protection they can provide.
Page 44 42 GETTING TO KNOW YOUR VEHICLE WARNING! All occupants must wear seat belts during off-road operation with doors removed. NOTE: • Doors are heavy; use caution when removing them. • Hinge pin can break if overtightened during door reinstall (Max Torque: 10 N·m / 7.5 ft· lb). 1.
Page 45 GETTING TO KNOW YOUR VEHICLE 43 3. Remove the check screw from the center door check 5. Pry open and remove the plastic wiring access door (using a #T40 Torx head driver). from the bottom of the B-pillar. Door Check (Attached) Wiring Access Door 4.
Page 46: Seats
44 GETTING TO KNOW YOUR VEHICLE 6. Unplug the wiring connector. NOTE: The upper hinge has a longer pin, which can be used to assist in guiding the door into place when rein- NOTE: Squeeze the tab on the base of the wiring harness. stalling.
Page 47: Manual Front Seats
GETTING TO KNOW YOUR VEHICLE 45 Manual Front Seats WARNING! Front Seat Adjustment • Adjusting a seat while driving may be dangerous. The seat can be adjusted forward or rearward by using a Moving a seat while driving could result in loss of bar located by the front of the seat cushion, near the floor.
Page 48 46 GETTING TO KNOW YOUR VEHICLE Manual Seat Height Adjustment The driver’s seat height can be raised or lowered by using the ratcheting handle, located on the outboard side of the seat. Pull upward on the handle to raise the seat, push downward on the handle to lower the seat.
Page 49: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE 47 Lumbar Support The lumbar control knob is located on the outboard side of the front driver seat. Rotate the control forward to increase and rearward to decrease the desired amount of lumbar support. Heated Seat Buttons •...
Page 50 48 GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! • The engine must be running for the heated seats to • Persons who are unable to feel pain to the skin operate. because of advanced age, chronic illness, diabetes, • The level of heat selected will stay on until the operator spinal cord injury, medication, alcohol use, exhaus- changes it.
Page 51: Front Passenger Easy Entry Seat - Two Door Models
GETTING TO KNOW YOUR VEHICLE 49 Front Passenger Easy Entry Seat — Two Door NOTE: Models • The front passenger seats have a track memory, which returns the seat to its original position. Pull upward on the easy entry lever located on the out- board side of the seat back, and slide the entire seat •...
Page 52 50 GETTING TO KNOW YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 53: Fold And Tumble Rear Seat - Two Door Models
GETTING TO KNOW YOUR VEHICLE 51 To Raise The Rear Seat Folding The Rear Seat Raise the seatback and lock it into place. Then, raise the 1. Lift the seatback release lever and fold the seatback head restraint until it locks into place. If interference from forward.
Page 54 52 GETTING TO KNOW YOUR VEHICLE Using The Retention Straps Removing The Rear Seat 1. There are two retention straps located on the back of the 1. Push down on the release bar on each side, and pull the rear seat and two corresponding wire loops located on seat out and away from the lower bracket.
Page 55: Rear Seat Armrest - If Equipped
GETTING TO KNOW YOUR VEHICLE 53 WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 56: Head Restraints
54 GETTING TO KNOW YOUR VEHICLE HEAD RESTRAINTS To remove the head restraint, raise it as far as it can go then push the adjustment button and the release button at the Head restraints are designed to reduce the risk of injury by base of each post while pulling the head restraint up.
Page 57: Rear Head Restraints - Two Door Models
GETTING TO KNOW YOUR VEHICLE 55 WARNING! • A loose head restraint thrown forward in a collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow re- moved head restraints in a location outside the occupant compartment.
Page 58 56 GETTING TO KNOW YOUR VEHICLE WARNING! • Do not drive the vehicle without the rear seat head restraints installed while passengers are occupying the rear seat. In a collision, people riding in this area without the head restraints installed are more likely to be seriously injured or killed.
Page 59: Rear Head Restraints - Four Door Models
GETTING TO KNOW YOUR VEHICLE 57 Rear Head Restraints — Four Door Models The rear seat is equipped with nonadjustable, but foldable, outboard head restraints, as well as an adjustable, remov- able center head restraint. To fold the outboard head restraint, pull on the smaller of the release levers, located on the upper outboard side of the rear seat.
Page 60: Steering Wheel
58 GETTING TO KNOW YOUR VEHICLE To install the head restraint, hold the release button while pushing downward on the head restraint. Refer to “Occu- pant Restraint Systems” in “Safety” for information on child seat tether routing. NOTE: Lower the center head restraint to avoid contact with the center console when folding the seat down.
Page 61: Heated Steering Wheel - If Equipped
GETTING TO KNOW YOUR VEHICLE 59 NOTE: The engine must be running for the heated steering WARNING! wheel to operate. Do not adjust the steering column while driving. Vehicles Equipped With Remote Start Adjusting the steering column while driving or driv- On models that are equipped with remote start, the heated ing with the steering column unlocked, could cause the steering wheel can be programmed to come on during a...
Page 62: Mirrors
60 GETTING TO KNOW YOUR VEHICLE MIRRORS Automatic Dimming Mirror — If Equipped The mirror head can be adjusted up, down, left, and right Inside Day/Night Mirror — If Equipped for various drivers. The mirror should be adjusted to center The mirror head can be adjusted up, down, left, and right on the view through the rear window.
Page 63: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE 61 The Automatic Dimming feature can be turn on or off through the touchscreen. • Press the mirror dimmer button once to turn the feature • Press the mirror dimmer button a second time to turn the feature off.
Page 64: Power Mirrors - If Equipped
62 GETTING TO KNOW YOUR VEHICLE Power Mirrors — If Equipped Heated Mirrors — If Equipped The power mirror controls are located on the door panel next to the door handle. These mirrors are heated to melt frost or ice. This feature will be activated whenever you turn on the rear window defroster (if equipped).
Page 65: Exterior Lights
GETTING TO KNOW YOUR VEHICLE 63 EXTERIOR LIGHTS Rotate the headlight switch clockwise to the first detent for parking light and instrument panel light operation. Rotate Headlight Switch the headlight switch to the second detent for headlight, The headlight switch is located on the left side of the parking light, and instrument panel light operation.
Page 66: High/Low Beam Switch
64 GETTING TO KNOW YOUR VEHICLE High/Low Beam Switch Flash-To-Pass Push the multifunction lever toward the instrument panel You can signal another vehicle with your headlights by to switch the headlights to high beams. Pull the multifunc- lightly pulling the multifunction lever toward you. This tion lever back toward the steering wheel to return the will cause the high beam headlights to turn on, and remain lights to low beams.
Page 67: Front Fog Lights - If Equipped
GETTING TO KNOW YOUR VEHICLE 65 Front Fog Lights — If Equipped NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside To activate the front fog lights, turn on the parking lights or light bulb.
Page 68: Dimmer Controls
66 GETTING TO KNOW YOUR VEHICLE The interior courtesy lights are located in the center of the Dimmer Controls vehicle’s sport bar, and consist of one large center light and The dimmer controls are part of the headlight switch and four smaller reading lights.
Page 69: Windshield Wipers And Washers
GETTING TO KNOW YOUR VEHICLE 67 WINDSHIELD WIPERS AND WASHERS Rotate the end of the lever upward to the third detent past the intermittent settings for high-speed wiper operation. The windshield wiper/washer control lever is located on the right side of the steering column. The front wipers are operated by rotating a switch, located at the end of the lever.
Page 70 68 GETTING TO KNOW YOUR VEHICLE Intermittent Wiper System Windshield Washers Use the intermittent wiper when weather conditions make To use the washer, pull the lever toward you and hold a single wiping cycle, with a variable pause between cycles, while spray is desired.
Page 71 GETTING TO KNOW YOUR VEHICLE 69 NOTE: The mist feature does not activate the washer pump; therefore, no washer fluid will be sprayed on the windshield. The wash function must be used in order to spray the windshield with washer fluid. Rear Wiper/Washer Control Rotate the switch upward to the first detent position for intermittent operation and to the second detent...
Page 72: Climate Controls
70 GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Manual Climate Control Overview The air conditioning and heating system is designed to make you comfortable in all types of weather. Manual Climate Controls – Heater Only Manual Climate Controls...
Page 73 GETTING TO KNOW YOUR VEHICLE 71 Manual Climate Control Descriptions Icon Description A/C Button Push the A/C button to engage the Air Conditioning (A/C). An LED illuminates when the A/C system is engaged. MAX A/C Setting Turn the temperature control knob to the MAX Air Conditioning (A/C) setting to engage MAX Air Conditioning (A/C).
Page 74 72 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Defrost Button Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated outside mirrors (if equipped). An indicator will illuminate when the rear window de- froster is on.
Page 75 GETTING TO KNOW YOUR VEHICLE 73 Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 76: Automatic Climate Controls Overview
74 GETTING TO KNOW YOUR VEHICLE Automatic Climate Controls Overview The Climate Control System allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the instrument panel below the radio. Uconnect 4 With 7–inch Display Automatic Climate Controls...
Page 77 GETTING TO KNOW YOUR VEHICLE 75 Uconnect 4C/4C NAV With 8.4–inch Display Automatic Climate Controls...
Page 78 76 GETTING TO KNOW YOUR VEHICLE Automatic Control Descriptions Icon Description MAX A/C Button Press to change to the coldest setting, the indicator illuminates when MAX A/C is on. Pressing the button again causes the MAX A/C operation to switch into manual mode and the MAX A/C indicator turns off.
Page 79 GETTING TO KNOW YOUR VEHICLE 77 Icon Description Front Defrost Button The Front Defrost button changes the current airflow setting to Defrost mode. The indicator illu- minates when this feature is on. Air comes from the windshield and side window demist out- lets.
Page 80 78 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate Knob Blower Control Blower Control is used to regulate the amount of air forced through the climate system. There are seven blower speeds available. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen.
Page 81 GETTING TO KNOW YOUR VEHICLE 79 Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel out- lets and warmer air from the floor outlets.
Page 82: Climate Control Functions
80 GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! • If fog or mist appears on the windshield or windows, Failure to follow these cautions can cause damage to select Defrost mode and increase the blower speed. the heating elements: • If the air conditioning performance is lower than ex- •...
Page 83: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE 81 NOTE: Using Recirculation in cold weather may cause the NOTE: windows to fog up and this mode may be unavailable on • It is not necessary to move the temperature settings for the touchscreen. cold or hot vehicles.
Page 84: Operating Tips
82 GETTING TO KNOW YOUR VEHICLE Operating Tips Window Fogging Vehicle windows tend to fog on the inside in mild, rainy, NOTE: Refer to the chart at the end of this section for and/or humid weather. To clear the windows, select De- suggested control settings for various weather conditions.
Page 85 GETTING TO KNOW YOUR VEHICLE 83 Operating Tips Chart...
Page 86: Power Windows - If Equipped
84 GETTING TO KNOW YOUR VEHICLE POWER WINDOWS — IF EQUIPPED The power window switches are located on the instrument panel below the climate controls. Push the switch down- ward to open the window and upward to close the window. The top left switch controls the left front window and the top right switch controls the right front window.
Page 87: Wind Buffeting
GETTING TO KNOW YOUR VEHICLE 85 Four-Door Models For your convenience, a tool kit is provided with your vehicle located in the center console. This kit includes the The lower left switch controls the left rear passenger necessary tools required for the operations described in the window, and the lower right switch controls the right rear following sections.
Page 88: Removing The Soft Top - Four Door Models
86 GETTING TO KNOW YOUR VEHICLE Removing The Soft Top — Four Door Models 3. Using the provided #40 Torx head driver and ratchet, unscrew the two Torx head screws on each lift assist 1. Fully lower the soft top. Refer to “Soft Top — Four Door mechanism, then lift the mechanism up and away from Models”...
Page 89 GETTING TO KNOW YOUR VEHICLE 87 4. Pull the release lever on top of the rail rearward to release the side link from the track. Pull To Release Top From Track 5. Repeat on the opposite side. Release Lever Location 6.
Page 90: Installing The Soft Top - Four Door Models
88 GETTING TO KNOW YOUR VEHICLE 7. Using the provided #50 Torx head driver and ratchet, Installing The Soft Top — Four Door Models unscrew the Torx screw on both rear corners of the NOTE: The following procedures are for first time set up vehicle, removing the retainers.
Page 91 GETTING TO KNOW YOUR VEHICLE 89 4. Install the rear retainers on each side of the rear of the 5. Making sure the lift assist mechanism is in the “lock” vehicle using the provided #50 Torx head driver and position, lift the soft top into the rear of the vehicle with ratchet.
Page 92 90 GETTING TO KNOW YOUR VEHICLE 6. Using the provided #40 Torx head driver and ratchet, Torque Maximum Minimum tighten the Torx screws by turning them clockwise. Specification Secure them until they are snug (refer to the table below For Torx Screws for recommended torque specifications), being careful 119.5 In-lbs 150.5 In-lbs...
Page 93: Freedom Top Three-Piece Modular Hard Top - If Equipped
GETTING TO KNOW YOUR VEHICLE 91 7. While pulling the release lever on the top of the rail NOTE: Be sure the wire harness in the left rear corner is not rearward, place the side link into the guide track on the tangled in the soft top bows before you lift the top.
Page 94: Front Panel(S) Removal
92 GETTING TO KNOW YOUR VEHICLE CAUTION! (Continued) • The hard top assembly must be positioned properly to ensure sealing. Improper installation can cause water to leak into the vehicle’s interior. • Careless handling and storage of the removable roof panels may damage the seals, causing water to leak into the vehicle’s interior.
Page 95: Freedom Top Storage Bag
GETTING TO KNOW YOUR VEHICLE 93 3. Unlatch the driver’s side header panel latch located at Freedom Top Storage Bag the top of the windshield. Vehicles equipped with a Freedom Top Modular Hard Top, come with a Freedom Top storage bag that allows you to store your Freedom Top panels.
Page 96 94 GETTING TO KNOW YOUR VEHICLE 2. Unfold the black panel divider (ensure the divider is 3. Insert the right side Freedom panel into the bag with the laying flat). latches facing downward. Fold Divider Over Left Panel Right Panel — Latches Facing Downward NOTE: Ensure the front Freedom panel latch is closed prior to inserting the panel into the bag.
Page 97: Front Panel(S) Installation
GETTING TO KNOW YOUR VEHICLE 95 4. Unfold the outer flap and zip the Freedom bag closed. 6. Wrap the upper strap around the rear head restraints and loop the strap through the buckle. Pull on the strap to tighten the Freedom bag securely against the rear seat.
Page 98: Rear Hard Top Removal
96 GETTING TO KNOW YOUR VEHICLE Rear Hard Top Removal 4. Remove the six Torx head screws that secure the hard top to the vehicle (along the interior bodyside — three 1. Remove both front panels. Refer to “Front Panel(s) screws on each side) using the #50 Torx head driver.
Page 99 GETTING TO KNOW YOUR VEHICLE 97 5. Open the swing gate all the way to ensure clearance of 6. Locate the wire harness and washer hose on the left rear the rear window glass. Lift the rear window glass. inside corner of the vehicle. Step Five Wire Harness...
Page 100 98 GETTING TO KNOW YOUR VEHICLE 7. Release the locking tab by pushing it downward. 8. To remove the wiring harness, push the tab inward while pulling downward to disconnect. Push Locking Tab Downward Push Tab Inward...
Page 101 GETTING TO KNOW YOUR VEHICLE 99 Pull Wiring Harness To Separate Release Button On Hose 10. Lower the rear window, and close the swing gate. 9. To remove the washer hose, push the release button on 11. Remove the hard top from the vehicle. Place the hard hose connector, and pull downward.
Page 102: Rear Hard Top Installation
100 GETTING TO KNOW YOUR VEHICLE Rear Hard Top Installation DOOR FRAME NOTE: If the door frames are installed from soft top usage, WARNING! they must be removed prior to installation of the hard top. Refer to “Door Frame” in this section for installation •...
Page 103: Door Frame Removal
GETTING TO KNOW YOUR VEHICLE 101 2. Once all the way loosened, remove the screws by CAUTION! (Continued) pulling downward. • The door frame(s) must be positioned properly to NOTE: Screws will not fall out once completely loose, as ensure sealing. Improper installation can cause water they are held in place by an internal mechanism.
Page 104: Door Frame Installation Four Door Models - If Equipped
102 GETTING TO KNOW YOUR VEHICLE 3. Lift the frame upward, removing it from the vehicle. WARNING! • Do not drive your vehicle on public roads with the door frame(s) removed as you will lose the protection that they can provide. This procedure is furnished for use during off-road operation only.
Page 105 GETTING TO KNOW YOUR VEHICLE 103 3. Swing the frame bracket around the side of the rail, and 4. Set the rear door frame pin into the hole on top of the insert the screws from underneath. Tighten with #40 body side, just behind the rear door opening.
Page 106 104 GETTING TO KNOW YOUR VEHICLE 5. Carefully position the top of the door frame onto the 6. Swing the frame bracket around the side of the rail, and rear of the front door rail, making sure rubber seals lay insert the screws from underneath.
Page 107: Door Frame Installation Two Door Models - If Equipped
GETTING TO KNOW YOUR VEHICLE 105 Door Frame Installation Two Door Models — CAUTION! If Equipped Do not overtighten the screws. You can strip the screws 1. Carefully place the front door rail in the rubber seal at if they are overtightened. the top of the windshield, and line up the holes for the Torx head screws (two for each door).
Page 108 106 GETTING TO KNOW YOUR VEHICLE CAUTION! CAUTION! • Do not run a fabric top through an automatic car wash. The soft top is not designed to carry any additional Window scratches and wax build up may result. loads such as roof racks, spare tires, building, hunting, •...
Page 109 GETTING TO KNOW YOUR VEHICLE 107 CAUTION! (Continued) lowering a window while the top is wet may allow water to drip into the vehicle’s interior. • Careless handling and storage of the soft top may damage the seals, causing water to leak into the vehicle’s interior.
Page 110: Lowering The Soft Top
108 GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top Side View Top And Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Rear Quarter Window 3 — #3 Bow 8 — Lower Window Retainer 4 —...
Page 111 GETTING TO KNOW YOUR VEHICLE 109 Rear View Top And Components 1 — Rear Window Retainer Attachment Points 2 — Quarter Window Pillars 3 — Swing Gate Bar Retainers NOTE: The rear window and rear quarter windows must to road dust, etc., clean them with a mild soap solution and be removed before lowering the soft top to prevent damage a small brush.
Page 112 110 GETTING TO KNOW YOUR VEHICLE Remove The Rear Window: 2. Grasp the swing gate bar, rotate it outward and upward releasing it from both the right and left retainers. 1. With the swing gate open, remove the rear window’s plastic retainers from the lower right and left corners.
Page 113 GETTING TO KNOW YOUR VEHICLE 111 3. While holding the window in place, slide the tailgate bar 4. Remove the plastic retainers from both quarter window to the left separating it from the rear window. Store in pillars. soft window bag, or a safe location. Step Four Step Three...
Page 114 112 GETTING TO KNOW YOUR VEHICLE 5. While keeping the rear window level, slide to the left Remove The Right And Left Quarter Windows: until it is completely separate from its retainer. Do not 1. Through the rear opening, push the bottom corner pull downward while removing the rear window.
Page 115 GETTING TO KNOW YOUR VEHICLE 113 2. Starting at the rear of the vehicle, remove plastic retainer 3. Remove plastic retainer from bottom to top of the from along the bottom of the window moving toward window. the front of the vehicle. Step Three Step Two...
Page 116 114 GETTING TO KNOW YOUR VEHICLE 4. While keeping the window level, slide rearward until it Lowering The Soft Top Into Sunrider Position is completely separate from its retainer. Do not pull 1. After removing the rear window and quarter panel downward while removing the window.
Page 117 GETTING TO KNOW YOUR VEHICLE 115 4. From both the driver and passenger sides, lift up on the NOTE: If leaving the soft top in the Sunrider position, #1 Bow of the soft top to start the operation. secure the top by using the two velcro straps provided in the center console.
Page 118 116 GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top Into Fully Lowered Position 3. Pull the latch downward to release the top, and allow the soft top to slide rearward freely in the guide tracks 1. From the Sunrider position, remove straps if previously to the stowed position.
Page 119 GETTING TO KNOW YOUR VEHICLE 117 4. While pushing downward slightly on the folded soft top, slide the lock lever on the driver and passenger side lift assist mechanisms to the “lock” position. Lock Position 5. Once the lock is in the “lock” position, push downward on each side of the folded soft top to ensure it is secure.
Page 120: Raising The Soft Top
118 GETTING TO KNOW YOUR VEHICLE Raising The Soft Top Raising The Soft Top From The Fully Lowered Position 1. While pushing down on the rear of the top, slide the lock lever on the driver and passenger side Lift Assist Mechanisms to the “unlock”...
Page 121 GETTING TO KNOW YOUR VEHICLE 119 2. Push up and forward from the #5 Bow along the guide 4. Using the side link, lift and push the soft top toward the track until it locks into the Sunrider position with an front of the vehicle guiding the top into the closed audible “click”.
Page 122 120 GETTING TO KNOW YOUR VEHICLE 5. From inside the vehicle, pull the handle on the header 6. Pull the handle back upward while squeezing the latch latch downward to engage the hook into its receiver. plate, locking the latch into place. Repeat on the other side.
Page 123 GETTING TO KNOW YOUR VEHICLE 121 Install The Right And Left Quarter Windows 2. Place the top of the quarter window pillar into the top cover, and insert the bottom tab into the clip. 1. From the rear of the vehicle, guide the top of the window into the retainer and slide forward while keep- ing the window level.
Page 124 122 GETTING TO KNOW YOUR VEHICLE Step Two Step Three 3. Engage the plastic retainers along the bottom of the quarter window and up the front of the window. Repeat on the other side.
Page 125 GETTING TO KNOW YOUR VEHICLE 123 Install The Rear Window 2. Insert the tailgate bar into the retainers at the bottom of the window from left to the right. 1. Guide the rear window into the retainer from left to right while keeping the window level.
Page 126 124 GETTING TO KNOW YOUR VEHICLE 3. Rotate the swing gate bar into the left and right side 5. Repeat with the driver’s side quarter window. retainers. Step Five Step Three 4. Line up the rear window to the passenger side quarter window first, and engage the plastic retainers.
Page 127: Soft Top Four Door Models - If Equipped
GETTING TO KNOW YOUR VEHICLE 125 6. Engage the rear window retainers in the lower right and WARNING! (Continued) left corners. • The fabric quarter windows and fabric top are de- signed only for protection against the elements. Do not rely on them to contain occupants within the vehicle or to protect against injury during an acci- dent.
Page 128 126 GETTING TO KNOW YOUR VEHICLE If the temperature is below 72°F (24°C) and/or the top has CAUTION! (Continued) been folded down for a period of time, the top will appear • Refer to “Appearance Care For Fabric Top Models” to have shrunk when you raise it, making it difficult to put in “Bodywork”...
Page 129: Lowering The Soft Top
GETTING TO KNOW YOUR VEHICLE 127 Lowering The Soft Top Side View Top And Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Rear Quarter Window 3 — #3 Bow 8 — Lower Window Retainer 4 —...
Page 130 128 GETTING TO KNOW YOUR VEHICLE Rear View Top And Components 1 — Rear Window Retainer Attachment Points 2 — Quarter Window Pillars 3 — Swing Gate Bar Retainers NOTE: The rear window and rear quarter windows must road dust, etc., clean them with a mild soap solution and a be removed before lowering the soft top to prevent damage small brush.
Page 131 GETTING TO KNOW YOUR VEHICLE 129 Remove The Rear Window: 2. Grasp the swing gate bar, rotate it outward and upward releasing it from both the right and left retainers. 1. With the swing gate open, remove the rear window’s plastic retainers from the lower right and left corners.
Page 132 130 GETTING TO KNOW YOUR VEHICLE 3. While holding the window in place, slide the tailgate bar 4. Remove the plastic retainers from both quarter window to the left separating it from the rear window. Store in pillars. soft window bag, or a safe location. Step Four Step Three...
Page 133 GETTING TO KNOW YOUR VEHICLE 131 5. While keeping the rear window level, slide to the left Remove The Right And Left Quarter Windows: until it is completely separate from its retainer. Do not 1. Through the rear opening, push the bottom corner pull downward while removing the rear window.
Page 134 132 GETTING TO KNOW YOUR VEHICLE 2. Starting at the rear of the vehicle, remove plastic retainer 3. Remove plastic retainer from the bottom to the top of from along the bottom of the window moving toward the front window. the front of the vehicle.
Page 135 GETTING TO KNOW YOUR VEHICLE 133 4. While keeping the window level, slide rearward until it Lowering The Soft Top Into Sunrider Position is completely separate from its retainer. Do not pull 1. After removing the rear window and quarter panel downward while removing the window.
Page 136 134 GETTING TO KNOW YOUR VEHICLE 4. From both the driver and passenger sides, lift up on the 5. Move to the side of the vehicle and use the side link to #1 Bow of the soft top to start the operation. fold the soft top rearward into the Sunrider position.
Page 137 GETTING TO KNOW YOUR VEHICLE 135 NOTE: If leaving the soft top in the Sunrider position, Lowering The Soft Top Into Fully Lowered Position secure the top by using the two velcro straps provided in 1. From the Sunrider position, remove straps if previously the center console.
Page 138 136 GETTING TO KNOW YOUR VEHICLE 3. Pull the latch to release the top, and allow the soft top to 4. While pushing downward slightly on the folded soft slide rearward freely in the guide tracks to the stowed top, slide the lock lever on the driver and passenger side position.
Page 139: Raising The Soft Top
GETTING TO KNOW YOUR VEHICLE 137 5. Once the lock is in the “lock” position, push downward Raising The Soft Top on each side of the folded soft top to ensure it is secure. Raising The Soft Top From The Fully Lowered Position An audible “click”...
Page 140 138 GETTING TO KNOW YOUR VEHICLE 2. Push up and forward from the #5 Bow along the guide 4. Using the side link, lift and push the soft top toward the track until it locks into the Sunrider position with an front of the vehicle manually guiding the top into the audible “click”.
Page 141 GETTING TO KNOW YOUR VEHICLE 139 5. From inside the vehicle, pull the handle on the header latch downward to engage the hook into its receiver. Repeat on the other side. Lower Top Into Closed Position Step Five...
Page 142 140 GETTING TO KNOW YOUR VEHICLE 6. Pull the handle back upward while squeezing the hook, Install The Right And Left Quarter Windows locking the latch into place. 1. From the rear of the vehicle, guide the top of the window into the retainer and slide forward while keep- ing the window level.
Page 143 GETTING TO KNOW YOUR VEHICLE 141 2. Place the top of the quarter window pillar into the top cover, and insert the bottom tab into the clip. Step Two Step Two...
Page 144 142 GETTING TO KNOW YOUR VEHICLE 3. Engage the plastic retainers along the bottom of the Install The Rear Window quarter window and up the front of the window. Repeat 1. Guide the rear window into the retainer from left to on the other side.
Page 145 GETTING TO KNOW YOUR VEHICLE 143 2. Insert the tailgate bar into the retainers at the bottom of 3. Rotate the swing gate bar into the left and right side the window from left to the right. retainers. Step Two Step Three...
Page 146 144 GETTING TO KNOW YOUR VEHICLE 4. Line up the rear window to the passenger side quarter 6. Engage the rear window retainers in the lower right and window first, and engage the plastic retainers. left corners. 5. Repeat with the driver’s side quarter window. Step Six Step Five...
Page 147: Power Sliding Top - If Equipped
GETTING TO KNOW YOUR VEHICLE 145 POWER SLIDING TOP — IF EQUIPPED NOTE: • The Power Top is non-removable. If desired, the rear If your vehicle is equipped with a Power Sliding Top, the quarter windows can be removed and stored in pro- control switch can be found on the front trim panel, to the vided storage bags.
Page 148: Opening The Power Top
146 GETTING TO KNOW YOUR VEHICLE position. Any release of the switch will stop the movement. WARNING! (Continued) The power top will remain in a partially opened position • In a collision, there is a greater risk of being thrown until the switch is pushed and held again.
Page 149: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE 147 positions. This is a normal occurrence and can be mini- Power Top Maintenance mized. If the buffeting occurs with the rear windows open, Use only a non-abrasive cleaner and a soft cloth to clean the then open the front and rear windows together to minimize quarter window glass panel.
Page 150: Rear Quarter Window Removal
148 GETTING TO KNOW YOUR VEHICLE 2. Ensure the power top is in the fully closed position. 3. Locate the rear quarter window latches (one on each window) on the interior of the windows. 3. Push and hold the Close switch for 10 seconds. This will put the power top into calibration mode.
Page 151 GETTING TO KNOW YOUR VEHICLE 149 6. From the outside of the vehicle, lift each window upward and away from the vehicle. NOTE: Do not pull down or apply any weight to the windows after the latches are released. Damage could result to the pins holding the windows in place.
Page 152: Folding Windshield
150 GETTING TO KNOW YOUR VEHICLE FOLDING WINDSHIELD replacement cowl-mounted outside mirror. Federal law requires outside mirrors on vehicles for on-road use. The fold-down windshield on your vehicle is a structural element that can provide some protection in some acci- WARNING! dents.
Page 153: Lowering The Windshield
GETTING TO KNOW YOUR VEHICLE 151 Lowering The Windshield 5. Using the provided #40 Torx head driver, remove the four Torx screws located along the interior of the wind- 1. Lower the soft top or remove the hard top following the shield.
Page 154: Raising The Windshield
152 GETTING TO KNOW YOUR VEHICLE 6. Lower the windshield gently until it contacts the foot- Raising The Windshield man loop bumpers (if equipped). 1. Release the strap that secured the windshield in the lowered position. 2. Raise the windshield. 3.
Page 155: Hood
GETTING TO KNOW YOUR VEHICLE 153 4. Reinstall the windshield wiper arms and using the HOOD provided 15mm socket, reinstall the two hex bolts Opening The Hood securing the wiper arms. Secure them until they are Release both the hood latches. snug, careful not to over tighten.
Page 156: Closing The Hood
154 GETTING TO KNOW YOUR VEHICLE Closing The Hood To close the hood, remove the support rod from the hood panel and place it in the retaining clip. Lower the hood slowly. Secure both of the hood latches. WARNING! Be sure the hood is fully latched before driving your vehicle.
Page 157: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE 155 To install the adjustable slide, proceed as follows: CAUTION! 1. Place the slide into the rail while in the horizontal Do not push on rear wiper blade when closing the rear position. Then rotate the slide 90 degrees into the flip-up window, as damage to the blade will result.
Page 158 156 GETTING TO KNOW YOUR VEHICLE 3. Adjust the bar to the desired position by sliding the bar 4. To lock the slides in place, using your auxiliary key from up or down the rails. your key fob, insert the key into the keyhole on the rearward end of the slide and turn to lock.
Page 159: Garage Door Opener - If Equipped
GETTING TO KNOW YOUR VEHICLE 157 GARAGE DOOR OPENER — IF EQUIPPED Before You Begin Programming HomeLink HomeLink replaces up to three hand-held transmitters that Be sure that your vehicle is parked outside of the garage operate devices such as garage door openers, motorized before you begin programming.
Page 160 158 GETTING TO KNOW YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manufac- tured after 1995. These garage door openers can be identi- fied by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener. NOTE: It is NOT the button that is normally used to open and close the door.
Page 161 GETTING TO KNOW YOUR VEHICLE 159 4. Continue to hold both buttons and observe the indicator To program the remaining two HomeLink buttons, repeat light. The HomeLink indicator will flash slowly and each step for each remaining button. DO NOT erase the then rapidly after HomeLink has received the frequency channels.
Page 162: Canadian/Gate Operator Programming
160 GETTING TO KNOW YOUR VEHICLE 3. Press and hold the HomeLink button you want to 2. Press and hold the desired HomeLink button until the program while you press and hold the hand-held trans- indicator light begins to flash after 20 seconds. Do not mitter button.
Page 163: Using Homelink
GETTING TO KNOW YOUR VEHICLE 161 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) If you unplugged the garage door opener/device for away from the HomeLink button you wish to program programming, plug it back in at this time. while keeping the HomeLink indicator light in view.
Page 164: Security
162 GETTING TO KNOW YOUR VEHICLE Security WARNING! It is advised to erase all channels before you sell or turn in • Vehicle exhaust contains carbon monoxide, a danger- your vehicle. ous gas. Do not run your vehicle in the garage while To do this, push and hold the two outside buttons for 20 programming the transceiver.
Page 165: General Information
GETTING TO KNOW YOUR VEHICLE 163 General Information INTERNAL EQUIPMENT The following regulatory statement applies to all Radio Storage Frequency (RF) devices equipped in this vehicle: Glove Compartment This device complies with Part 15 of the FCC Rules and The glove compartment is located on the passenger side of with Industry Canada license-exempt RSS standard(s).
Page 166 164 GETTING TO KNOW YOUR VEHICLE Console Storage Compartment Rear Storage Compartment — If Equipped To lock or unlock the storage compartment, insert the The rear cargo area storage compartment is located under- ignition key and turn. To open the storage compartment, neath the load floor.
Page 167: Cupholders
GETTING TO KNOW YOUR VEHICLE 165 Cupholders The rear cupholders are located on the back of the center console, near the floor. The front cupholders are located in the center console. Rear Cupholders Front Cupholders...
Page 168: Electrical Power Outlets
166 GETTING TO KNOW YOUR VEHICLE There are also cupholders located in the rear seat armrest, Electrical Power Outlets if equipped. There are two 12 Volt (13 Amp) auxiliary power outlets that can provide power for accessories designed for use with the standard power outlet adapters.
Page 169 GETTING TO KNOW YOUR VEHICLE 167 On vehicles equipped with a rear subwoofer, there is a second power outlet located in the rear cargo area and is powered directly from the vehicle battery. Power Outlets Fuse Locations 1 — F81 Fuse 20A Yellow Rear Power Outlet (battery powered at all times) 2 —...
Page 170 168 GETTING TO KNOW YOUR VEHICLE CAUTION! CAUTION! • Do not exceed the maximum power of 160 Watts • Many accessories that can be plugged in draw power (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power from the vehicle’s battery, even when not in use (i.e., rating is exceeded the fuse protecting the system will cellular phones, etc.).
Page 171: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE 169 Power Inverter — If Equipped The power inverter is designed with built-in overload protection. If the power rating of 150 Watts is exceeded, the There is a 115 or 230 Volt, 150 Watt inverter outlet located power inverter will automatically shut down.
Page 172: Auxiliary Switches - If Equipped
170 GETTING TO KNOW YOUR VEHICLE Auxiliary Switches — If Equipped NOTE: Holding last state conditions are met when switch type is set to latching and power source is set to ignition. Four auxiliary switches located in the lower switch bank of the instrument panel can be used to power various electri- For more information, refer to “Uconnect Settings”...
Page 173: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE 171 ROOF LUGGAGE RACK — IF EQUIPPED NOTE: Roof rack applications are for Hard Top models ONLY. The load carried on the roof, when equipped with a luggage rack, must not exceed 100 lbs (45 kg), this includes the weight of the crossbars, and it should be uniformly distributed over the cargo area.
Page 174 172 GETTING TO KNOW YOUR VEHICLE WARNING! CAUTION! (Continued) • Travel at reduced speeds and turn corners carefully Cargo must be securely tied down before driving your when carrying large or heavy loads on the roof rack. vehicle. Improperly secured loads can fly off the ve- Wind forces, due to natural causes or nearby truck hicle, particularly at high speeds, resulting in personal traffic, can add sudden upward loads.
Page 175 GETTING TO KNOW YOUR INSTRUMENT PANEL CONTENTS ▫ Yellow Indicator Lights ....196 INSTRUMENT CLUSTER ....174 ▫...
Page 176: Instrument Cluster
174 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster...
Page 177 GETTING TO KNOW YOUR INSTRUMENT PANEL 175 Premium Instrument Cluster...
Page 178: Instrument Cluster Descriptions
176 GETTING TO KNOW YOUR INSTRUMENT PANEL Instrument Cluster Descriptions WARNING! Base Instrument Cluster Descriptions A hot engine cooling system is dangerous. You or 1. Tachometer others could be badly burned by steam or boiling • Indicates the engine speed in revolutions per minute coolant.
Page 179 GETTING TO KNOW YOUR INSTRUMENT PANEL 177 4. Fuel Gauge 3. Speedometer • The pointer shows the level of fuel in the fuel tank • Indicates vehicle speed. when the ignition switch is in the ON/RUN position. 4. Fuel Gauge •...
Page 180: Instrument Cluster Display
178 GETTING TO KNOW YOUR INSTRUMENT PANEL through and enter the main menus and submenus. You can CAUTION! access the specific information you want and make selec- tions and adjustments. Driving with a hot engine cooling system could dam- age your vehicle. If the temperature gauge reads “H” Instrument Cluster Display Location And Controls pull over and stop the vehicle.
Page 181 GETTING TO KNOW YOUR INSTRUMENT PANEL 179 7.0 Inch Instrument Cluster Display Location Instrument Cluster Display Control Buttons The system allows the driver to select information by 1 — OK Button pushing the following buttons mounted on the steering 2 — Up Arrow Button wheel: 3 —...
Page 182: Oil Change Reset
180 GETTING TO KNOW YOUR INSTRUMENT PANEL • Down Arrow Button • Off Road— If Equipped • Fuel Economy Push and release the down arrow button to scroll downward through the Main Menu items. • Trip Info • Stop/Start — If Equipped •...
Page 183: Instrument Cluster Display Menu Items
GETTING TO KNOW YOUR INSTRUMENT PANEL 181 Oil Life Reset Instrument Cluster Display Menu Items NOTE: The instrument cluster display menu items display 1. Without pushing the brake pedal, push and release the in the center of the instrument cluster. Menu items may ENGINE START/STOP button and place the ignition to vary depending on your vehicle features.
Page 184 182 GETTING TO KNOW YOUR INSTRUMENT PANEL Off Road Fuel Economy Push and release the up or down arrow button until the Off Push and release the up or down arrow button until the Road menu icon is displayed in the instrument cluster Fuel Economy icon is highlighted in the instrument cluster display.
Page 185 GETTING TO KNOW YOUR INSTRUMENT PANEL 183 • Phone Call Status Trip Info Push and release the up or down arrow button until the When a call is incoming, a Phone Call Status pop-up will Trip icon/title is highlighted in the instrument cluster display on the screen.
Page 186 184 GETTING TO KNOW YOUR INSTRUMENT PANEL • Average MPG Screen Setup Driver Selectable Items • Current MPG Upper Left • None • Trip A Distance • Compass (default setting) • Trip B Distance • Outside Temp • Audio • Time •...
Page 187: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL 185 Gear Display — If Equipped Defaults (Restores All Settings To Default Settings) • Full (default setting) • Cancel • Single • Restore Current Gear The menu with (show/hide) means user can press OK •...
Page 188 186 GETTING TO KNOW YOUR INSTRUMENT PANEL When load reduction is activated, the message “Battery Saver Loss of the battery charge may indicate one or more of the On” or “Battery Saver Mode” will appear in the instrument following conditions: cluster display.
Page 189: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL 187 • The battery was used for an extended period with the • The vehicle should have service performed if the mes- engine not running to supply radio, lights, chargers, sage is still present during consecutive trips and the +12V portable appliances like vacuum cleaner’s, game evaluation of the vehicle and driving pattern did not consoles and similar devices.
Page 190 188 GETTING TO KNOW YOUR INSTRUMENT PANEL with the air bag has been detected, it will stay on until the indicated by the Brake Warning Light, which will turn on fault is cleared. If the light is either not on during startup, when the brake fluid level in the master cylinder has stays on, or turns on while driving, have the system dropped below a specified level.
Page 191 GETTING TO KNOW YOUR INSTRUMENT PANEL 189 ON/RUN position. The light should illuminate for ap- — Electric Power Steering Fault Warning Light proximately two seconds. The light should then turn off This light will turn on when there’s a fault with the EPS unless the parking brake is applied or a brake fault is (Electric Power Steering) system.
Page 192 190 GETTING TO KNOW YOUR INSTRUMENT PANEL If the light continues to flash when the vehicle is running, — Hood Open Warning Light immediate service is required and you may experience This indicator will illuminate when the hood is ajar/open reduced performance, an elevated/rough idle, or engine and not fully closed.
Page 193: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 191 — Seat Belt Reminder Warning Light WARNING! This light indicates when the driver or passenger seat belt If you continue operating the vehicle when the Trans- is unbuckled. When the ignition is first placed in the mission Temperature Warning Light is illuminated you ON/RUN or ACC/ON/RUN position and if the driver’s could cause the fluid to boil over, come in contact with...
Page 194 192 GETTING TO KNOW YOUR INSTRUMENT PANEL • The “ESC Off Indicator Light” and the “ESC Indicator If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not function- Light” come on momentarily each time the ignition is ing and service is required as soon as possible.
Page 195 GETTING TO KNOW YOUR INSTRUMENT PANEL 193 — Low Fuel Warning Light When the engine is running, the MIL may flash to alert serious conditions that could lead to immediate loss of When the fuel level reaches approximately 2.0 gal (7.5 L), power or severe catalytic converter damage.
Page 196 194 GETTING TO KNOW YOUR INSTRUMENT PANEL — Service 4WD Warning Light — If Equipped — Tire Pressure Monitoring System (TPMS) Warning Light If the light stays on or comes on during driving, it means that the 4WD system is not functioning properly and that The warning light switches on and a message is displayed service is required.
Page 197 GETTING TO KNOW YOUR INSTRUMENT PANEL 195 Each tire, including the spare (if provided), should be Your vehicle has also been equipped with a TPMS malfunc- checked monthly when cold and inflated to the inflation tion indicator to indicate when the system is not operating pressure recommended by the vehicle manufacturer on the properly.
Page 198: Yellow Indicator Lights
196 GETTING TO KNOW YOUR INSTRUMENT PANEL — 4WD Part Time Indicator Light — CAUTION! (Continued) If Equipped damage may result when using replacement equip- This light alerts the driver that the vehicle is in the ment that is not of the same size, type, and/or style. four-wheel drive part time mode, and the front and rear Aftermarket wheels can cause sensor damage.
Page 199: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 197 — Rear Axle Lock Indicator Light — Active Speed Limiter SET Indicator Light — If Equipped With A Base Instrument Cluster This light indicates when the rear axle lock has been activated. This light will turn on when the Active Speed Limiter is on and set to a specific speed.
Page 200: Green Indicator Lights
198 GETTING TO KNOW YOUR INSTRUMENT PANEL instrument cluster display, for further information refer to — Cruise Control Set Indicator Light — “Instrument Cluster Display Menu Items” in “Getting To If Equipped Know Your Instrument Panel.” This light will turn on when the speed control is set to the desired speed.
Page 201: Blue Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 199 NOTE: — Active Speed Limiter ON Indicator Light — If Equipped With A Base Instrument Cluster • A continuous chime will sound if the vehicle is driven more than 1 mile (1.6 km) with either turn signal on. This light will turn on when the Active Speed Limiter is on, but not set.
Page 202: Onboard Diagnostic System (Obd Ii) Cybersecurity
200 GETTING TO KNOW YOUR INSTRUMENT PANEL CAUTION! WARNING! (Continued) • If unauthorized equipment is connected to the OBD • Prolonged driving with the MIL on could cause II connection port, such as a driver-behavior tracking further damage to the emission control system. It device, it may: could also affect fuel economy and driveability.
Page 203 GETTING TO KNOW YOUR INSTRUMENT PANEL 201 • The MIL will not flash at all and will remain fully Normally, the OBD II system will be ready. The OBD II system may not be ready if your vehicle was recently illuminated until you place the ignition in the off posi- serviced, recently had a dead battery or a battery replace- tion or start the engine.
Page 205 SAFETY CONTENTS ▫ Supplemental Restraint Systems (SRS) ..243 SAFETY FEATURES ..... .204 ▫ Anti-Lock Brake System (ABS) ... . .204 ▫...
Page 206: Safety Features
204 SAFETY SAFETY FEATURES These are all normal characteristics of ABS. Anti-Lock Brake System (ABS) WARNING! The Anti-Lock Brake System (ABS) provides increased • The ABS contains sophisticated electronic equip- vehicle stability and brake performance under most brak- ment that may be susceptible to interference caused ing conditions.
Page 207: Electronic Brake Control System
SAFETY Electronic Brake Control System WARNING! (Continued) Your vehicle is equipped with an advanced Electronic • The capabilities of an ABS equipped vehicle must Brake Control system (EBC). This system includes Elec- never be exploited in a reckless or dangerous manner tronic Brake Force Distribution (EBD), Anti-Lock Brake that could jeopardize the user’s safety or the safety of System (ABS), Brake Assist System (BAS), Hill Start Assist...
Page 208 206 SAFETY If the “Brake System Warning Light” remains on or comes WARNING! on while driving, it indicates that the brake system is not functioning properly and that immediate service is re- The Brake Assist System (BAS) cannot prevent the quired.
Page 209 SAFETY The following conditions must be met in order for HSA to WARNING! activate: • The feature must be enabled. There may be situations where the Hill Start Assist (HSA) will not activate and slight rolling may occur, • The vehicle must be stopped. such as on minor hills or with a loaded vehicle, or •...
Page 210 208 SAFETY Towing With HSA Traction Control System (TCS) HSA will also provide assistance to mitigate roll back while This system monitors the amount of wheel spin of each of towing a trailer. the driven wheels. If wheel spin is detected, the TCS may apply brake pressure to the spinning wheel(s) and/or WARNING! reduce engine power to provide enhanced acceleration and...
Page 211 SAFETY ESC uses sensors in the vehicle to determine the vehicle WARNING! path intended by the driver and compares it to the actual • Electronic Stability Control (ESC) cannot prevent the path of the vehicle. When the actual path does not match the intended path, ESC applies the brake of the appropriate natural laws of physics from acting on the vehicle, nor wheel to assist in counteracting the oversteer or understeer...
Page 212 210 SAFETY To enter the “Partial Off” mode, momentarily push the WARNING! (Continued) “ESC Off” switch and the “ESC Off Indicator Light” will that reduces the effectiveness of the ESC system can illuminate. To turn the ESC on again, momentarily push increase the risk of loss of vehicle control, vehicle the “ESC Off”...
Page 213 SAFETY Full Off — If Equipped WARNING! This mode is intended for off-highway or off-road use only • In the ESC “Full Off” mode, the engine torque and should not be used on any public roadways. In this reduction and stability features are disabled. There- mode, TCS and ESC features are turned OFF.
Page 214 212 SAFETY ESC Activation/Malfunction Indicator Light And NOTE: ESC OFF Indicator Light • The “ESC Activation/Malfunction Indicator Light” and the “ESC OFF Indicator Light” come on momentarily each time the ignition is turned ON. The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on •...
Page 215 SAFETY evasive driving maneuvers; it cannot prevent wheel lift NOTE: TSC cannot stop all trailers from swaying. Always due to other factors, such as road conditions, leaving the use caution when towing a trailer and follow the trailer roadway, or striking objects or other vehicles. tongue weight recommendations.
Page 216 214 SAFETY Rain Brake Support (RBS) NOTE: The DST feature is only meant to help the driver realize the correct course of action through small torques Rain Brake Support may improve braking performance in on the steering wheel, which means the effectiveness of the wet conditions.
Page 217 SAFETY Enabling HDC HDC Target Set Speeds • P = No set speed. HDC may be enabled but will not HDC is enabled by pushing the HDC switch, but the activate following conditions must also be met to enable HDC: •...
Page 218 216 SAFETY • Driver door opens (Driver door opens if doors are Driver Override attached or driver seatbelt is unbuckled if doors are The driver may override HDC activation with throttle or detached). brake application at anytime. • The vehicle is driven greater than 20 mph (32 km/h) for Deactivating HDC greater than 70 seconds.
Page 219: Auxiliary Driving Systems
SAFETY • The cluster icon and switch lamp will flash when HDC deactivates due to overheated brakes. The flashing will stop and HDC will activate again once the brakes have cooled sufficiently. WARNING! HDC is only intended to assist the driver in controlling vehicle speed when descending hills.
Page 220 218 SAFETY both sides of the vehicle when the vehicle speed reaches The area on taillights, where the radar sensors are located, approximately 6 mph (10 km/h) or higher and will alert must remain free of snow, ice, and dirt/road contamination the driver of vehicles in these areas.
Page 221 SAFETY Entering From The Side Vehicles that move into your adjacent lanes from either side of the vehicle. Warning Light Location The BSM system monitors the detection zone from three different entry points (side, rear, front) while driving to see if an alert is necessary.
Page 222 220 SAFETY Entering From The Rear Overtaking Traffic Vehicles that come up from behind your vehicle on either If you pass another vehicle slowly with a relative speed less side and enter the rear detection zone with a relative speed than 15 mph (24 km/h) and the vehicle remains in the of less than 30 mph (48 km/h).
Page 223 SAFETY Overtaking/Passing Stationary Objects The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
Page 224 222 SAFETY The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones. The BSM system is not designed to detect pedestrians, bicyclists, or animals.
Page 225 SAFETY Rear Cross Path (RCP) RCP monitors the rear detection zones on both sides of the vehicle, for objects that are moving toward the side of the The Rear Cross Path (RCP) feature is intended to aid the vehicle with a minimum speed of approximately 3 mph driver when backing out of parking spaces where their (5 km/h), to objects moving a maximum of approximately vision of oncoming vehicles may be blocked.
Page 226 224 SAFETY Modes Of Operation NOTE: Whenever an audible alert is requested by the BSM system, the radio is also muted. Three selectable modes of operation are available in the Uconnect System. Refer to “Uconnect Settings” in “Multi- When the system is in RCP, the system shall respond with media”...
Page 227: Tire Pressure Monitor System (Tpms)
SAFETY 2. This device must accept any interference received, in- The TPMS will warn the driver of a low tire pressure if the cluding interference that may cause undesired opera- tire pressure falls below the low-pressure warning limit for tion. any reason, including low temperature effects and natural pressure loss through the tire.
Page 228 226 SAFETY and the measured tire pressure is 28 psi (193 kPa), a CAUTION! (Continued) temperature drop to 20°F (-7°C) will decrease the tire type, and/or style. The TPM sensor is not designed pressure to approximately 24 psi (165 kPa). This tire for use on aftermarket wheels, and may contribute to pressure is low enough to turn on the Tire Pressure a poor overall system performance.
Page 229 SAFETY • Driving on a significantly underinflated tire causes the tire to overheat and can lead to tire failure. Underinfla- tion also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability. • The TPMS is not a substitute for proper tire mainte- nance, and it is the driver’s responsibility to maintain correct tire pressure using an accurate tire pressure gauge, even if underinflation has not reached the level to...
Page 230 228 SAFETY Tire Pressure Monitoring Low Pressure Warnings Should this occur, you should stop as soon as possible and inflate the tires with low pressure (those in a different color The Tire Pressure Monitoring Telltale Light will in the instrument cluster graphic) to the vehicle’s recom- illuminate in the instrument cluster and a chime mended cold placard pressure value as shown in the will sound when tire pressure is low in one or more...
Page 231 SAFETY If the ignition key is cycled, this sequence will repeat, 2. If you install the compact or non-matching full size providing the system fault still exists. If the system fault no spare tire in place of a road tire that has a pressure below longer exists, the Tire Pressure Monitoring Telltale Light the low-pressure warning limit, upon the next ignition will no longer flash, and the “SERVICE TIRE PRESSURE...
Page 232 230 SAFETY new pressure value instead of dashes (- -), as long as no TPMS Deactivation — If Equipped tire pressure is below the low-pressure warning limit in The TPMS can be deactivated if replacing all four wheel any of the four active road tires. The vehicle may need to and tire assemblies (road tires) with wheel and tire assem- be driven for up to 20 minutes above 15 mph (24 km/h) blies that do not have TPMS sensors, such as when...
Page 233: Occupant Restraint Systems
SAFETY values in place of the dashes. On the next ignition cycle the OCCUPANT RESTRAINT SYSTEMS SERVICE TIRE PRESSURE SYSTEM message will no Some of the most important safety features in your vehicle longer be displayed as long as no system fault exists. are the restraint systems: General Information Occupant Restraint Systems Features...
Page 234: Seat Belt Systems
232 SAFETY seat as far back as possible and use the proper child bags will inflate forcefully into the space between occu- restraint (refer to “Child Restraints” in this section for pants and the door and occupants could be injured. further information).
Page 235 SAFETY vehicle. Seat belts reduce the possibility of ejection and the BeltAlert Warning Sequence risk of injury caused by striking the inside of the vehicle. The BeltAlert warning sequence is activated when the Everyone in a motor vehicle should be belted at all times. vehicle is moving above a specified vehicle speed range Enhanced Seat Belt Use Reminder System (BeltAlert) and the driver or outboard front seat passenger is unbuck-...
Page 236 234 SAFETY The outboard front passenger seat BeltAlert is not active and reduce your risk of striking the inside of the vehicle or when the outboard front passenger seat is unoccupied. being thrown out of the vehicle. BeltAlert may be triggered when an animal or other items are placed on the outboard front passenger seat or when WARNING! the seat is folded flat (if equipped).
Page 237 SAFETY WARNING! (Continued) WARNING! (Continued) • A twisted seat belt may not protect you properly. In driver, should always wear their seat belts whether or not an air bag is also provided at their seating a collision, it could even cut into you. Be sure the seat position to minimize the risk of severe injury or belt is flat against your body, without twists.
Page 238 236 SAFETY WARNING! (Continued) • A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.
Page 239 SAFETY Inserting Latch Plate Into Buckle Positioning The Lap Belt 4. Position the lap belt so that it is snug and lies low across 5. Position the shoulder belt across the shoulder and chest your hips, below your abdomen. To remove slack in the with minimal, if any slack so that it is comfortable and lap belt portion, pull up on the shoulder belt.
Page 240 238 SAFETY Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 241 SAFETY NOTE: The adjustable upper shoulder belt anchorage is Seat Belt Extender equipped with an Easy Up feature. This feature allows the If a seat belt is not long enough to fit properly, even when shoulder belt anchorage to be adjusted in the upward the webbing is fully extended and the adjustable upper position without pushing or squeezing the release button.
Page 242 240 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by removing slack from the seat belt early in a collision.
Page 243 SAFETY Switchable Automatic Locking Retractor (ALR) The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) which is used to secure a child restraint system. For additional information, refer to “Installing Child Restraints Using The Vehicle Seat Belt”...
Page 244 242 SAFETY In Automatic Locking Mode, the shoulder belt is automati- 3. Allow the seat belt to retract. As the seat belt retracts, cally pre-locked. The seat belt will still retract to remove you will hear a clicking sound. This indicates the seat any slack in the shoulder belt.
Page 245: Supplemental Restraint Systems (Srs)
SAFETY • Front and Side Impact Sensors Supplemental Restraint Systems (SRS) • Seat Belt Pretensioners Some of the safety features described in this section may be standard equipment on some models, or may be optional • Seat Track Position Sensors equipment on others.
Page 246 244 SAFETY The ORC also includes diagnostics that will illuminate the WARNING! instrument panel Air Bag Warning Light if a malfunction is detected that could affect the air bag system. The diagnos- Ignoring the Air Bag Warning Light in your instrument tics also record the nature of the malfunction.
Page 247 SAFETY Front Air Bags WARNING! This vehicle has front air bags and lap/shoulder belts for • Being too close to the steering wheel or instrument both the driver and front passenger. The front air bags are panel during front air bag deployment could cause a supplement to the seat belt restraint systems.
Page 248 246 SAFETY The first stage inflator is triggered immediately during an The Passenger Air Bag Disable (“PAD”) Indicator Light (an impact that requires air bag deployment. A low energy amber light located on the overhead sports bar) tells the output is used in less severe collisions. A higher energy driver and front passenger when the Passenger Advanced output is used for more severe collisions.
Page 249 SAFETY Because air bag sensors measure vehicle deceleration over WARNING! (Continued) time, vehicle speed and damage by themselves are not bags may no longer be functional. The protective good indicators of whether or not an air bag should have covers for the air bag cushions are designed to open deployed.
Page 250 248 SAFETY and for occupants whose seated weight classifies them in a Passenger Advanced Front Air Bag. In order for the OCS to category other than a properly seated adult. This could be operate as designed, it is important for the front passenger a child, teenager, or even an adult.
Page 251 SAFETY The OCS may deactivate the deployment of the Passenger Passenger Air Bag Disable (PAD) System Advanced Front Air Bag if the OCS estimates that: Front Passenger Front Passenger Front Passenger • The front passenger seat is unoccupied or has very light Seat Occupant Advanced Air Air Bag Status...
Page 252 250 SAFETY seat and never install a child restraint system, including a Passenger Air Bag Disable (PAD) System rear-facing child restraint, in the front passenger seat. Front Passenger Front Passenger Front Passenger Seat Occupant Advanced Air Air Bag Status WARNING! Status Bag Disabled Indicator Light...
Page 253 SAFETY placed on the seat and the seat belt is unbuckled, the NOTE: If the seat belt is buckled for an empty seat, the Passenger Advanced Front Air Bag will not deploy even PAD Indicator Light will illuminate. though the PAD indicator light is NOT illuminated. If The Pad Indicator Light Is Illuminated For An Adult The PAD indicator light should not be illuminated when an Passenger:...
Page 254 252 SAFETY lighter weight passenger, including a small adult (depend- WARNING! ing on size) who is seated in the passenger seat. This does • If the PAD Indicator Light remains illuminated for not mean that the OCS is working improperly. an adult passenger, have an authorized dealer service The driver and passenger must always use the PAD the air bag system immediately.
Page 255 SAFETY • Anything that may decrease or increase the front pas- improperly. Decreasing the front passenger’s seated weight on the front passenger seat may result in deactivation of senger’s seated weight. the Passenger Advanced Front Air Bag causing serious The OCS determines the front passenger’s most probable injury or death.
Page 256 254 SAFETY Not Seated Properly Not Seated Properly...
Page 257 SAFETY WARNING! (Continued) • Always wear your seat belt and sit properly, with the seatback in an upright position, your back against the seatback, sitting upright, facing forward, in the center of the seat, with your feet comfortably on or near the floor.
Page 258 256 SAFETY The passenger seat assembly contains critical OCS compo- WARNING! nents that may affect Passenger Advanced Front Air Bag • Ignoring the Air Bag Warning Light in your instru- inflation. In order for the OCS to properly classify the seated weight of a front seat passenger, the OCS compo- ment panel could mean you won’t have the air bags nents must function as designed.
Page 259 SAFETY • At no time should any Supplemental Restraint System WARNING! (SRS) component or SRS related component or fastener • Do not drill, cut, or tamper with the knee impact be modified or replaced with any part except those which are approved by FCA US LLC. bolsters in any way.
Page 260 258 SAFETY WARNING! Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury. Side Impacts The Side Air Bags are designed to activate in certain side impacts.
Page 261 SAFETY The Side Air Bags will not deploy in all side collisions, WARNING! (Continued) including some collisions at certain angles, or some side against the seats. Children must be properly re- collisions that do not impact the area of the passenger strained in a child restraint or booster seat that is compartment.
Page 262 260 SAFETY Air Bag System Components If A Deployment Occurs The front air bags are designed to deflate immediately after NOTE: The Occupant Restraint Controller (ORC) monitors deployment. the internal circuits and interconnecting wiring associated with electrical Air Bag System Components listed below: NOTE: Front and/or side air bags will not deploy in all •...
Page 263 SAFETY irritation, move to fresh air. If the irritation continues, Enhanced Accident Response System see your doctor. If these particles settle on your clothing, In the event of an impact, if the communication network follow the garment manufacturer’s instructions for remains intact, and the power remains intact, depending cleaning.
Page 264 262 SAFETY Enhanced Accident Response System Reset WARNING! (Continued) Procedure • It is dangerous to try to repair any part of the air bag In order to reset the Enhanced Accident Response System system yourself. Be sure to tell anyone who works on functions after an event, the ignition switch must be your vehicle that it has an air bag system.
Page 265: Child Restraints
SAFETY and safety systems for a short period of time, typically 30 law enforcement, that have the special equipment, can read seconds or less. The EDR in this vehicle is designed to the information if they have access to the vehicle or the record such data as: EDR.
Page 266 264 SAFETY There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat Owner’s Manual to make sure you have the correct seat for your child.
Page 267 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Recommended Type Child Size, Height, Weight Or Age Of Child Restraint Infants and Toddlers Children who are two years old or Either an Infant Carrier or a Convert- younger and who have not reached ible Child Restraint, facing rearward the height or weight limits of their in the rear seat of the vehicle...
Page 268 266 SAFETY Infant And Child Restraints WARNING! (Continued) Safety experts recommend that children ride rear-facing in • Only use a rear-facing child restraint in a vehicle the vehicle until they are two years old or until they reach with a rear seat. either the height or weight limit of their rear-facing child restraint.
Page 269 SAFETY should use the seat belt in a rear seat. Use this simple 5-step WARNING! test to decide whether the child can use the vehicle’s seat belt • Improper installation can lead to failure of an infant alone: or child restraint. It could come loose in a collision. 1.
Page 270 268 SAFETY WARNING! Never allow a child to put the shoulder belt under an arm or behind their back. In a crash, the shoulder belt will not protect a child properly, which may result in serious injury or death. A child must always wear both the lap and shoulder portions of the seat belt correctly.
Page 271 SAFETY Lower Anchors And Tethers For CHildren (LATCH) Your vehicle is equipped with the child restraint anchorage Restraint System system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH-equipped child seats.
Page 272 270 SAFETY LATCH Positions For Installing Child Restraints In This Vehicle LATCH Positions (Four-Door Models) Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol LATCH Positions (Two-Door Models) Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol...
Page 273 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit (child’s 65 lbs (29.5 kg) Use the LATCH anchorage system weight + weight of the child re- until the combined weight of the straint) for using the LATCH anchor- child and the child restraint is 65 lbs age system to attach the child re- (29.5 kg).
Page 274 272 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Can a child seat be installed in the Two Door Models- No Four Door Only: You can install child center position using the inner Four Door Models - Yes restraints with flexible lower anchors LATCH lower anchorages? in the center position.
Page 275 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Can the rear-facing child restraint The child seat may touch the back of touch the back of the front passenger the front passenger seat if the child seat? restraint manufacturer also allows contact.
Page 276 274 SAFETY Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage sym- bols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 277 SAFETY Locating The Upper Tether Anchorages Two-Door Models: There are tether strap anchorages behind each rear seating position located on the back of the seat, near the floor. Tether Strap Anchorages (Four-Door Models) LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side. Each will have a hook or connector to attach to the lower anchorage and a way to tighten the connection to the anchorage.
Page 278 276 SAFETY Center Seat LATCH WARNING! (Continued) Two-Door Models: Please refer to “Installing The LATCH-Compatible Child Restraint System” for typical installation in- WARNING! structions. This vehicle does not have a center seating position. Always follow the directions of the child restraint manu- Do not use the center lower LATCH anchorages to facturer when installing your child restraint.
Page 279 SAFETY move it to its rear-most position to make room for the How To Stow An Unused Switchable-ALR (ALR) child seat. You may also move the front seat forward to Seat Belt: allow more room for the child seat. When using the LATCH attaching system to install a child restraint, stow all ALR seat belts that are not being used by 3.
Page 280 278 SAFETY The seat belts in the passenger seating positions are WARNING! (Continued) equipped with a Switchable Automatic Locking Retractor • Child restraint anchorages are designed to withstand (ALR) that is designed to keep the lap portion of the seat only those loads imposed by correctly-fitted child belt tight around the child restraint so that it is not restraints.
Page 281 SAFETY Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Automatic Locking Retractor Locations (Four-Door Models) ALR = Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Automatic Locking Retractor Locations (Two-Door Models) ALR = Switchable Automatic Locking Retractor Top Tether Anchorage Symbol...
Page 282 280 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to the with the seat belt to attach a forward...
Page 283 SAFETY Installing A Child Restraint With A Switchable WARNING! Automatic Locking Retractor (ALR): Always make sure the head restraint is in its upright Child restraint systems are designed to be secured in position when the seat is to be used by an occupant who vehicle seats by lap belts or the lap belt portion of a is not in a child restraint.
Page 284 282 SAFETY 3. Slide the latch plate into the buckle until you hear a 8. If the child restraint has a top tether strap and the “click.” seating position has a top tether anchorage, connect the tether strap to the anchorage and tighten the tether 4.
Page 285 SAFETY Installing Child Restraints Using The Top Tether tether anchorage for that seating position, move the Anchorage child restraint to another position in the vehicle if one is available. WARNING! 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.
Page 286 284 SAFETY WARNING! • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchorage position directly be- hind the child seat to secure a child restraint top tether strap. •...
Page 287: Transporting Pets
SAFETY Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts. SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. WARNING! • Do not leave children or animals inside parked vehicles in hot weather.
Page 288: Exhaust Gas
286 SAFETY Exhaust Gas Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the WARNING! vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the complete Exhaust gases can injure or kill.
Page 289 SAFETY Air Bag Warning Light Floor Mat Safety Information The Air Bag warning light will turn on for four to Always use floor mats designed to fit your vehicle. Only eight seconds as a bulb check when the ignition switch use a floor mat that does not interfere with the operation of is first turned to ON/RUN.
Page 290 288 SAFETY WARNING! (Continued) WARNING! (Continued) • ONLY install floor mats designed to fit your vehicle. • NEVER place any objects under the floor mat (e.g., NEVER install a floor mat that cannot be properly towels, keys, etc.). These objects could change the attached and secured to your vehicle.
Page 291: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Periodic Safety Checks You Should Make Outside The Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread or sidewall. Inspect the tread for cuts and cracks.
Page 293 STARTING AND OPERATING CONTENTS STARTING THE ENGINE ....294 AUTOMATIC TRANSMISSION — IF EQUIPPED . .306 ▫ Manual Transmission — If Equipped ..294 ▫...
Page 294 292 STARTING AND OPERATING ▫ Possible Reasons The Engine Does ▫ To Vary The Speed Setting ....334 Not Autostop ......327 ▫...
Page 295 STARTING AND OPERATING 293 VEHICLE LOADING .....346 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) ....356 ▫...
Page 296: Starting The Engine
294 STARTING AND OPERATING STARTING THE ENGINE Manual Transmission — If Equipped Before starting your vehicle, adjust your seat, adjust both Apply the parking brake, place the gear selector in NEU- inside and outside mirrors, and fasten your seat belts. TRAL, and press the clutch pedal before starting the vehicle.
Page 297: Normal Starting
STARTING AND OPERATING 295 Normal Starting 3. If the gear selector is not in PARK (with vehicle stopped) and the ENGINE START/STOP button is pushed once, To Turn On The Engine Using The ENGINE START/ the transmission will automatically select PARK and the STOP Button engine will turn off, however the ignition will remain in 1.
Page 298 296 STARTING AND OPERATING ENGINE START/STOP Button Functions — With Driv- AutoPark er’s Foot OFF The Brake Pedal (In PARK Or NEUTRAL AutoPark is a supplemental feature to assist in placing the Position) vehicle in PARK should the situations on the following The ENGINE START/STOP button operates similar to an pages occur.
Page 299 STARTING AND OPERATING 297 • Vehicle is not in PARK If the vehicle is not in PARK and the driver turns off the engine, the vehicle may AutoPark. • Driver’s door is removed AutoPark will engage when all of these conditions are met: •...
Page 300: Extreme Cold Weather (Below -22°F Or −30°C)
298 STARTING AND OPERATING ALWAYS DO A VISUAL CHECK that your vehicle is in WARNING! PARK by looking for the P in the instrument cluster display and on the shifter. As an added precaution, always If vehicle speed is above 1.2 MPH (2.0 km/h), the apply the parking brake when exiting the vehicle.
Page 301: After Starting
STARTING AND OPERATING 299 WARNING! (Continued) WARNING! • If the vehicle has a discharged battery, booster cables Remember to disconnect the engine block heater cord may be used to obtain a start from a booster battery before driving. Damage to the 110-115 Volt AC electri- or the battery in another vehicle.
Page 302: Parking Brake
300 STARTING AND OPERATING CAUTION! Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as a problem.
Page 303 STARTING AND OPERATING 301 • This light only shows that the parking brake is applied. WARNING! (Continued) It does not show the degree of brake application. • Never leave children alone in a vehicle, or with When parking on a hill, it is important to turn the front access to an unlocked vehicle.
Page 304: Manual Transmission - If Equipped
302 STARTING AND OPERATING NOTE: During cold weather, you may experience in- CAUTION! creased effort in shifting until the transmission fluid warms up. This is normal. If the “Brake Warning Light” remains on with the parking brake released, a brake system malfunction is indicated.
Page 305: Shifting
STARTING AND OPERATING 303 To engage REVERSE gear from the NEUTRAL position, lift Shifting the REVERSE ring, located below the knob and move the Fully press the clutch pedal before shifting gears. As you gear selector all the way left and then forward. release the clutch pedal, lightly press the accelerator pedal.
Page 306: Downshifting
304 STARTING AND OPERATING Manual Transmission Shift Speeds in MPH (KM/H) Engine Speeds 1 to 2 2 to 3 3 to 4 4 to 5 5 to 6 3.6L Accel. 15 (24) 24 (39) 50 (80) 65 (104) 70 (112) Cruise 10 (16) 19 (31)
Page 307 STARTING AND OPERATING 305 Maximum Recommended Downshift Speeds CAUTION! (Continued) • When descending a hill, be very careful to downshift CAUTION! one gear at a time to prevent overspeeding the engine Failure to follow the maximum recommended down- which can cause engine damage, and/or clutch dam- shifting speeds may cause the engine to overspeed age, even if the clutch pedal is pressed.
Page 308: Automatic Transmission - If Equipped
306 STARTING AND OPERATING AUTOMATIC TRANSMISSION — IF EQUIPPED WARNING! (Continued) brake pedal released. Make sure the transmission is CAUTION! in PARK before exiting the vehicle. • The transmission may not engage PARK if the ve- Damage to the transmission may occur if the following precautions are not observed: hicle is moving.
Page 309: Ignition Park Interlock
STARTING AND OPERATING 307 Ignition Park Interlock WARNING! (Continued) This vehicle is equipped with an Ignition Park Interlock the transmission into PARK, and turn the ignition which requires the transmission to be in PARK before the OFF. When the ignition is in the OFF mode, the ignition can be turned to the OFF mode.
Page 310: Eight-Speed Automatic Transmission
308 STARTING AND OPERATING Eight–Speed Automatic Transmission Only shift from DRIVE to PARK or REVERSE when the accelerator pedal is released and the vehicle is stopped. Be The transmission gear range (PRNDM) is displayed both sure to keep your foot on the brake pedal when shifting beside the gear selector and in the instrument cluster.
Page 311 STARTING AND OPERATING 309 NOTE: After selecting any gear range, wait a moment to allow the selected gear to engage before accelerating. This is especially important when the engine is cold. PARK (P) This range supplements the parking brake by locking the transmission.
Page 312 310 STARTING AND OPERATING NOTE: On four-wheel drive vehicles be sure that the WARNING! (Continued) transfer case is in a drive position. vehicle could accelerate quickly forward or in re- verse. You could lose control of the vehicle and hit WARNING! someone or something.
Page 313 STARTING AND OPERATING 311 • Look at the transmission gear position display and WARNING! (Continued) verify that it indicates the PARK position (P), and is not touch the parking brake, brake pedal or the trans- blinking. mission gear selector. • With brake pedal released, verify that the gear selector •...
Page 314 312 STARTING AND OPERATING When frequent transmission shifting occurs (such as when WARNING! operating the vehicle under heavy loading conditions, in hilly terrain, traveling into strong head winds, or while Do not coast in NEUTRAL and never turn off the towing a heavy trailer), use the AutoStick shift control ignition to coast down a hill.
Page 315 STARTING AND OPERATING 313 Transmission Limp Home Mode 3. Push and hold the ignition switch until the engine turns OFF. Transmission function is monitored electronically for ab- normal conditions. If a condition is detected that could 4. Wait approximately 30 seconds. result in transmission damage, Transmission Limp Home 5.
Page 316 314 STARTING AND OPERATING • You can start out, from a stop, in first or second gear (or Operation third gear, in 4LO range). Tapping (+) (at a stop) will To activate AutoStick mode, move the gear selector into the allow starting in second gear.
Page 317: Four-Wheel Drive Operation
STARTING AND OPERATING 315 To disengage AutoStick mode, return the gear selector to Four-Position Transfer Case the DRIVE position. You can shift in or out of the AutoStick position at any time without taking your foot off the accelerator pedal. WARNING! Do not downshift for additional engine braking on a slippery surface.
Page 318 316 STARTING AND OPERATING For additional information on the appropriate use of each The transfer case is intended to be driven in the 2H transfer case mode position, see the information below: position for normal street and highway conditions, such as hard-surfaced roads.
Page 319 STARTING AND OPERATING 317 Proper operation of four-wheel drive vehicles depends on Shifting Procedures tires of equal size, type, and circumference on each wheel. 2H To 4H Or 4H To 2H Any difference will adversely affect shifting and cause Shifting between 2H and 4H can be made with the vehicle damage to the transfer case.
Page 320: Five-Position Transfer Case
318 STARTING AND OPERATING During cold weather, you may experience increased effort WARNING! in shifting until the transfer case fluid warms up. This is normal. Failure to engage a transfer case position completely can cause transfer case damage or loss of power and 4H To 4L Or 4L To 4H vehicle control.
Page 321 STARTING AND OPERATING 319 The transfer case provides five mode positions: and rear wheels to rotate at the same speed. This range provides additional traction for loose, slippery road surfaces • 2H (Two-Wheel Drive High Range) only. • 4H Auto (Four-Wheel Drive Auto High Range) NEUTRAL (N) •...
Page 322 320 STARTING AND OPERATING For variable driving conditions, the 4WD AUTO mode can models) that of the 2H or 4H positions at a given road be used. In this mode, the front axle is engaged, but the speed. Take care not to overspeed the engine. vehicle’s power is sent to the rear wheels.
Page 323 STARTING AND OPERATING 321 Shifting Procedures NOTE: • Do not attempt to make a shift while only the front or 2H To 4H Auto Or 4H Auto To 2H rear wheels are spinning. The front and rear driveshaft Shifting between 2H and 4H Auto can be made with the speeds must be equal for the shift to take place.
Page 324: Trac-Lok Rear Axle - If Equipped
322 STARTING AND OPERATING transfer case in N (Neutral). Once the shift is completed, Trac-Lok Rear Axle — If Equipped place the automatic transmission into DRIVE or release the The Trac-Lok rear axle provides a constant driving force to clutch pedal on a manual transmission. both rear wheels and reduces wheel spin caused by the loss of traction at one driving wheel.
Page 325: Axle Lock (Tru-Lok) - Rubicon Models
STARTING AND OPERATING 323 Axle Lock (Tru-Lok) — Rubicon Models This feature will only activate when the following condi- tions are met: The AXLE LOCK switch is located on the instrument panel • Ignition in RUN position, vehicle in 4L (Low) range. (to the right of the steering column).
Page 326: Electronic Sway Bar Disconnect - If Equipped
324 STARTING AND OPERATING Electronic Sway Bar Disconnect — If Equipped Push the SWAY BAR switch to activate the system. Push the switch again to deactivate the system. The “Sway Bar Your vehicle may be equipped with an electronic discon- Indicator Light”...
Page 327: Electro-Hydraulic Power Steering
STARTING AND OPERATING 325 To disconnect the stabilizer/sway bar, shift to either 4H or WARNING! 4L and push the SWAY BAR switch to obtain the off-road position. Refer to “Four-Wheel Drive Operation” in this If the stabilizer/sway bar will not return to on-road section for further information.
Page 328: Stop/Start System - Automatic Transmission (If Equipped)
326 STARTING AND OPERATING Refer to “Instrument Cluster Display” in “Getting To Know CAUTION! Your Instrument Panel” for further information. Extreme steering maneuvers may cause the electrically NOTE: driven pump to reduce or stop power steering assis- • Even if power steering assistance is no longer opera- tance in order to prevent damage to the system.
Page 329: Automatic Mode
STARTING AND OPERATING 327 Automatic Mode Possible Reasons The Engine Does Not Autostop The Stop/Start feature is enabled after every Prior to engine shut down, the system will check many normal customer engine start. At that time, the safety and comfort conditions to see if they are fulfilled. system will go into STOP/START READY and if Detailed information about the operation of the Stop/Start all other conditions are met, can go into a STOP/...
Page 330: To Start The Engine While In Autostop Mode
328 STARTING AND OPERATING • Hood is open. To Start The Engine While In Autostop Mode • Transfer case is in 4LO or Neutral While in a forward gear, the engine will start when the brake pedal is released or the throttle pedal is depressed. The •...
Page 331: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING 329 • STOP/START OFF switch is pushed. 2. The “STOP/START OFF” message will appear in instru- ment cluster display within the Stop/Start section. Refer • A STOP/START system error occurs. to “Instrument Cluster” in “Getting To Know Your •...
Page 332: Stop/Start System - Manual Transmission (If Equipped)
330 STARTING AND OPERATING STOP/START SYSTEM — MANUAL TRANSMISSION To Activate The STOP/START AUTO STOP ACTIVE Mode, (IF EQUIPPED) The Following Must Occur: • The system must be in STOP/START READY state. A The Stop/Start function is developed to reduce fuel con- STOP/START READY message will be displayed in the sumption.
Page 333: To Start The Engine While In Autostop Mode
STARTING AND OPERATING 331 • Actual cabin temperature is significantly different than To Start The Engine While In Autostop Mode temperature set on Auto HVAC. When the gear selector is in NEUTRAL, the engine will • HVAC is set to full defrost mode. start when the clutch pedal is pressed (does not require complete/full pedal press).
Page 334: To Manually Turn Off The Start/Stop System
332 STARTING AND OPERATING To Manually Turn Off The Start/Stop System 4. If the STOP/START system is manually turned off, the engine can only be started and stopped by cycling the 1. Push the STOP/START Off switch (located on the ignition switch switch bank).
Page 335: Speed Control - If Equipped
STARTING AND OPERATING 333 SPEED CONTROL — IF EQUIPPED NOTE: In order to ensure proper operation, the Speed Control System has been designed to shut down if multiple When engaged, the Speed Control takes over accelerator Speed Control functions are operated at the same time. If operations at speeds greater than 20 mph (32 km/h).
Page 336: To Set A Desired Speed
334 STARTING AND OPERATING The driver’s preferred units can be selected through the WARNING! Uconnect system if equipped. Refer to ”Uconnect Settings” in “Multimedia” for more information. The speed incre- Leaving the Speed Control system on when not in use ment shown is dependent on the chosen speed unit of U.S.
Page 337: To Accelerate For Passing
STARTING AND OPERATING 335 To Decrease Speed To Accelerate For Passing When the Speed Control is set, you can decrease speed by Press the accelerator as you would normally. When the pushing the SET (-) button. pedal is released, the vehicle will return to the set speed. The driver’s preferred units can be selected through the To Resume Speed Uconnect system if equipped.
Page 338: Parksense Rear Park Assist - If Equipped
336 STARTING AND OPERATING On steep hills, a greater speed loss or gain may occur so it ParkSense can be active only when the gear selector is in may be preferable to drive without Speed Control. REVERSE. If ParkSense is enabled at this gear selector position, the system will remain active until the vehicle WARNING! speed is increased to approximately 7 mph (11 km/h) or...
Page 339: Parksense Warning Display
STARTING AND OPERATING 337 ParkSense Warning Display single arc moving closer to the vehicle and the sound tone will change from slow, to fast, to continuous. The ParkSense Warning screen will only be displayed if “Sound and Display” is selected from the Customer - If an obstacle is detected in the left and/or right rear Programmable Features section of the Uconnect System.
Page 340 338 STARTING AND OPERATING Slow Tone/Solid Arc Fast Tone/Flashing Arc Slow Tone/Solid Arc Continuous Tone/Flashing Arc...
Page 341 STARTING AND OPERATING 339 The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle: WARNING ALERTS Rear Dis- Greater...
Page 342: Enabling And Disabling Parksense
340 STARTING AND OPERATING NOTE: ParkSense will reduce the volume of the radio, if When the gear selector is moved to REVERSE and the on, when the system is sounding an audio tone. system is disabled, the instrument cluster display will show the “PARKSENSE OFF”...
Page 343: Cleaning The Parksense System
STARTING AND OPERATING 341 • Jackhammers, large trucks, and other vibrations could If “PARKSENSE UNAVAILABLE WIPE REAR SENSORS” appears in the instrument cluster display, make sure the affect the performance of ParkSense. outer surface and the underside of the rear fascia/bumper •...
Page 344 342 STARTING AND OPERATING • The operation of the rear sensors is automatically deac- WARNING! (Continued) tivated when the trailer’s electric plug is inserted in the hitch ball will be much closer to the obstacle than the vehicle’s tow hook socket. The rear sensors are automati- rear fascia when the loudspeaker sounds the con- cally reactivated when the trailer’s cable plug is re- tinuous tone.
Page 345: Parkview Rear Back Up Camera
STARTING AND OPERATING 343 PARKVIEW REAR BACK UP CAMERA image will continue to be displayed for up to ten seconds after shifting out of REVERSE unless the vehicle speed Your vehicle is equipped with the ParkView Rear Back Up exceeds 8 mph (13 km/h), the vehicle is shifted into PARK Camera that allows you to see an on-screen image of the or the vehicle’s ignition is cycled to the OFF position.
Page 346: Refueling The Vehicle
344 STARTING AND OPERATING REFUELING THE VEHICLE WARNING! Fuel Filler Cap Drivers must be careful when backing up even when The fuel filler cap is located on the driver’s side of the using the ParkView Rear Back Up Camera. Always vehicle.
Page 347 STARTING AND OPERATING 345 CAUTION! • Damage to the fuel system or emission control sys- tem could result from using an improper fuel filler cap. A poorly fitting cap could let impurities into the fuel system. Also, a poorly fitting aftermarket cap can cause the “Malfunction Indicator Light (MIL)”...
Page 348: Loose Fuel Filler Cap Message
346 STARTING AND OPERATING Loose Fuel Filler Cap Message included on this label and indicates the Month, Day and Hour of manufacture. The bar code that appears on the After fuel has been added, the vehicle diagnostic system can bottom of the label is your VIN. determine if the fuel filler cap is possibly loose, improperly installed, or damaged.
Page 349 STARTING AND OPERATING 347 components sometimes specified by purchasers for in- Loading creased durability does not necessarily increase the vehi- The actual total weight and the weight of the front and rear cle’s GVWR. of your vehicle at the ground can best be determined by weighing it when it is loaded and ready for operation.
Page 350: Trailer Towing
348 STARTING AND OPERATING Gross Vehicle Weight Rating (GVWR) CAUTION! The GVWR is the total allowable weight of your vehicle. Do not load your vehicle any heavier than the GVWR This includes driver, passengers, cargo and tongue weight. or the maximum front and rear GAWR. If you do, parts The total load must be limited so that you do not exceed on your vehicle can break, or it can change the way the GVWR.
Page 351 STARTING AND OPERATING 349 rear GAWR. Refer to “Vehicle Loading/Vehicle Certifica- Weight-Carrying Hitch tion Label” in “Starting And Operating” for further infor- A weight-carrying hitch supports the trailer tongue weight, mation. just as if it were luggage located at a hitch ball or some other connecting point of the vehicle.
Page 352: Trailer Hitch Classification
350 STARTING AND OPERATING Trailer Hitch Classification WARNING! The following chart provides the industry standard for the • An improperly adjusted Weight Distributing Hitch maximum trailer weight a given trailer hitch class can tow system may reduce handling, stability, braking per- and should be used to assist you in selecting the correct formance, and could result in a collision.
Page 353: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 351 Trailer Towing Weights (Maximum Trailer Weight Ratings) GCWR Max. GTW Max. Trailer Engine/ (Gross Com- Model Frontal Area (Gross Trailer Tongue Wt. Transmission bined Wt. Wt.) (See Note) Rating) 2.0L Two–Door 8,016 lbs (3 20 ft2 (1.86 m2) 2,000 lbs 200 lbs (91 kg) 636 kg)
Page 354: Trailer And Tongue Weight
352 STARTING AND OPERATING Trailer And Tongue Weight NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional Never exceed the maximum tongue weight stamped on factory-installed options or dealer-installed options must your bumper or trailer hitch.
Page 355 STARTING AND OPERATING 353 Towing Requirements — Trailer Brakes CAUTION! • Do not interconnect the hydraulic brake system or If the trailer weighs more than 1,000 lbs (453 kg) vacuum system of your vehicle with that of the trailer. loaded, it should have its own brakes and they should This could cause inadequate braking and possible per- be of adequate capacity.
Page 356: Towing Tips
354 STARTING AND OPERATING NOTE: • Disconnect trailer wiring connector from the vehicle before launching a boat (or any other device plugged into vehicle’s electrical connect) into water. • Be sure to reconnect after clear from water area. Seven-Pin Connector 1 —...
Page 357 STARTING AND OPERATING 355 Automatic Transmission — If Equipped Electronic Speed Control — If Equipped • Do not use in hilly terrain or with heavy loads. Select the DRIVE range when towing. The transmission controls include a drive strategy to avoid frequent shifting •...
Page 358: Recreational Towing (Behind Motorhome, Etc.)
356 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Four-Wheel Drive Models Flat Tow NONE See Instructions • Automatic transmission in PARK. • Manual transmission in gear (NOT in NEUTRAL [N]).
Page 359: Recreational Towing - Four-Wheel Drive
STARTING AND OPERATING 357 Recreational Towing — Four-Wheel Drive Models CAUTION! (Continued) NOTE: The transfer case must be shifted into NEUTRAL • Towing this vehicle in violation of the above require- (N), automatic transmission must be in PARK, and manual ments can cause severe transmission and/or transfer transmission must be in gear (NOT in NEUTRAL) for case damage.
Page 360 358 STARTING AND OPERATING 11. Firmly apply the parking brake. CAUTION! 12. Shift the transmission into PARK or place manual It is necessary to follow these steps to be certain that transmission in gear (NOT in NEUTRAL). the transfer case is fully in NEUTRAL (N) before recreational towing to prevent damage to internal CAUTION! parts.
Page 361: Driving Tips
STARTING AND OPERATING 359 4. Press and hold the brake pedal. DRIVING TIPS 5. Shift the transmission into NEUTRAL. On-Road Driving Tips Utility vehicles have higher ground clearance and a nar- 6. Turn the engine OFF. rower track to make them capable of performing in a wide 7.
Page 362: Off-Road Driving Tips
360 STARTING AND OPERATING Off-Road Driving Tips 2. Remove both nuts from the underside of the vehicle for each bracket. Side Step Removal — If Equipped NOTE: Prior to off-road usage, the side steps should be removed to prevent damage if so equipped. 1.
Page 363 STARTING AND OPERATING 361 Bumper End Cap Removal The end caps on your vehicle’s front bumper can be removed by following the steps below: 1. Loosen the two bolts that retain the GAWR bracket (Bolts #1 and #2) to the end cap using a T45 torx bit screw driver.
Page 364 362 STARTING AND OPERATING The Basics Of Off-Road Driving CAUTION! You will encounter many types of terrain driving off-road. Never park your vehicle over dry grass or other com- You should be familiar with the terrain and area before bustible materials. The heat from your vehicle exhaust proceeding.
Page 365 STARTING AND OPERATING 363 CAUTION! CAUTION! Do not use 4L (Low) range when operating the vehicle on On icy or slippery roads, do not downshift at high dry pavement. Driveline hardware damage can result. engine RPM or vehicle speeds, because engine braking may cause skidding and loss of control.
Page 366 364 STARTING AND OPERATING Sand Crossing Obstacles (Rocks And Other High Points) Soft sand is very difficult to travel through with full tire While driving off-road, you will encounter many types of pressure. When crossing soft, sandy spots in a trail, main- terrain.
Page 367 STARTING AND OPERATING 365 Using A Spotter Crossing A Ravine, Gully, Ditch, Washout Or Rut There are many times where it is hard to see the obstacle or When crossing a ravine, gully, ditch, washout or a large rut, determine the correct path. Determining the correct path the angled approach is the key to maintaining your vehi- can be extremely difficult when you are confronting many cle’s mobility.
Page 368 366 STARTING AND OPERATING Crossing Logs CAUTION! To cross a log, approach it at a slight angle (approximately Winching or rocking the vehicle off hard objects in- 10 to 15 degrees). This allows one front tire to be on top of creases the risk of underbody damage.
Page 369 STARTING AND OPERATING 367 Driving Up Hill Driving Downhill Once you have determined your ability to proceed and Before driving down a steep hill, you need to determine if have shifted into the appropriate gear, line your vehicle up it is too steep for a safe descent. What is the surface for the straightest possible run.
Page 370 368 STARTING AND OPERATING Driving Across An Incline WARNING! If at all possible, avoid driving across an incline. If it is If the engine stalls or you lose headway or cannot necessary, know your vehicle’s abilities. Driving across an make it to the top of a steep hill or grade, never attempt incline places more weight on the downhill wheels, which to turn around.
Page 371 STARTING AND OPERATING 369 Determine if it has ingested water first. The key to any Before You Cross Any Type Of Water crossing is low and slow. Shift into first gear (manual As you approach any type of water, you need to determine if transmission), or DRIVE (automatic transmission), with the you can cross it safely and responsibly.
Page 372 370 STARTING AND OPERATING CAUTION! WARNING! Muddy waters can reduce the cooling system effective- Never drive through fast moving deep water. It can ness by depositing debris onto the radiator. push your vehicle downstream, sweeping it out of control. This could put you and your passengers at risk Crossing Ditches, Streams, Shallow Rivers Or Other of injury or drowning.
Page 373 STARTING AND OPERATING 371 • Check for accumulations of plants or brush. These things could be a fire hazard. They might hide damage to fuel lines, brake hoses, axle pinion seals, and propeller shafts. • After extended operation in mud, sand, water, or similar dirty conditions, have the radiator, fan, brake rotors, wheels, brake linings, and axle yokes inspected and cleaned as soon as possible.
Page 375 IN CASE OF EMERGENCY CONTENTS HAZARD WARNING FLASHERS ... .374 MANUAL PARK RELEASE ....401 ASSIST AND SOS MIRROR —...
Page 376: Hazard Warning Flashers
374 IN CASE OF EMERGENCY HAZARD WARNING FLASHERS ASSIST AND SOS MIRROR — IF EQUIPPED The Hazard Warning flasher switch is located on the instrument panel below the climate controls. Push the switch to turn on the Hazard Warning flasher. When the switch is activated, all direc- tional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 377 IN CASE OF EMERGENCY 375 just push the ASSIST button and you’ll be connected to WARNING! someone who can help. Roadside Assistance will know what vehicle you’re driving and its location. Additional ALWAYS obey traffic laws and pay attention to the road.
Page 378 376 IN CASE OF EMERGENCY 3. Once a connection between the vehicle and a SOS NOTE: operator is made, the SOS Call system may transmit the • Your vehicle may be transmitting data as authorized following important vehicle information to a SOS op- by the subscriber.
Page 379 IN CASE OF EMERGENCY 377 WARNING! WARNING! (Continued) AN ACCIDENT), THE UCONNECT FEATURES, • If anyone in the vehicle could be in danger (e.g., fire APPS AND SERVICES, AMONG OTHERS, WILL or smoke is visible, dangerous road conditions or NOT OPERATE. location), do not wait for voice contact from an •...
Page 380 378 IN CASE OF EMERGENCY • An In-Vehicle Audio message will state “Vehicle device • The SOS Call system software and/or hardware are requires service. Please contact your dealer.” damaged during a crash. • The vehicle battery loses power or becomes discon- WARNING! nected during a vehicle crash.
Page 381 IN CASE OF EMERGENCY 379 NOTE: CAUTION! • Your vehicle may be transmitting data as authorized by To avoid damage to the mirror during cleaning, never the subscriber. spray any cleaning solution directly onto the mirror. • Never place anything on or near the vehicle’s LTE Apply the solution onto a clean cloth and wipe the (voice/data) or 4G (data) and GPS antennas.
Page 382: Bulb Replacement
380 IN CASE OF EMERGENCY BULB REPLACEMENT Replacement Bulbs Interior Bulbs Bulb Number Automatic Transmission Indicator Lamp Heater Control Lamps (2) Rocker Switch Indicator Lamp (Rear Window Defogger, and Rear Wash/Wipe) Soundbar Dome Lamp ** Bulbs only available from an authorized dealer. Exterior Bulbs Bulb Number Headlamps (2)
Page 383: Bulb Replacement
IN CASE OF EMERGENCY 381 Bulb Number Premium Fog Lamps LED – (Serviced At Authorized Dealer) Rear Premium LED Tail Lamps LED – (Serviced At Authorized Dealer) Rear Base Tail Lamp Stop/Tail/Turn Bulb 3157 Rear Base Tail Lamp Backup Bulb 7440 Rear Base Tail Lamp Side Marker LED –...
Page 384 382 IN CASE OF EMERGENCY 10. Remove connector from bulb. 11. Push connector onto new bulb base, and push the connector locking tab to the lock position. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol.
Page 385 IN CASE OF EMERGENCY 383 Halogen Front Fog Lamp LED Front Fog Lamp 1. Reach under the vehicle to access the back of the front If your vehicle is equipped with LED fog lamps they are fog lamp. replaced as an assembly. 2.
Page 386 384 IN CASE OF EMERGENCY 2. Remove retaining screw and disconnect electrical con- nector, then remove tail lamp assembly from the vehicle. NOTE: If necessary, push in on the assembly tab located inboard behind the lamp housing. Assembly Bracket 4. Rotate the appropriate socket 1/4 turn counterclock- wise, then remove it from the housing.
Page 387: Fuses
IN CASE OF EMERGENCY 385 Center High-Mounted Stop Lamp (CHMSL) FUSES The stop lamp is mounted on a bracket that extends WARNING! upward from the tailgate behind the spare tire. If service is needed, obtain the LED Assembly from an authorized •...
Page 388: General Information
386 IN CASE OF EMERGENCY General Information Power Distribution Center (PDC) The fuses protect electrical systems against excessive current. The Power Distribution Center is located in the engine compartment near the battery. This center contains car- When a device does not work, you must check the fuse tridge fuses, mini fuses, and relays.
Page 389 IN CASE OF EMERGENCY 387 Cavity Cartridge Fuse Micro Fuse Description – – Spare 40 Amp Green – Starter – 5 Amp Tan – 20 Amp Yellow Fuel Pump MTR/FPCM – 5 Amp Tan Security Gateway – – Spare – 15 Amp Blue LTR Cool Pump —...
Page 390 388 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 20 Amp Yellow REAR WIPER – 10 Amp Red ECM/PCM/MGU WAKE UP/ PPU WAKE UP – 10 Amp Red PCM/ECM – – Spare – 10 Amp Red MOD_SBW 40 Amp Green –...
Page 391 IN CASE OF EMERGENCY 389 Cavity Cartridge Fuse Micro Fuse Description – 15 Amp Blue DTCM/AXLE LOCK FT_RR – 15 Amp Blue IC/SGW WAKE UP – 10 Amp Red PCR CTRL FEED (ESS)/SPARE (BSG) — If Equipped 20 Amp Yellow PWR OUTLET (CARGO) BATT –...
Page 392 390 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 20 Amp Yellow Frt Pass Htd Seat – – Spare – 15 Amp Blue CSWM (HTD STR WHEEL) – 10 Amp Red LBSS/RBSS – – Spare – 10 Amp Red –...
Page 393 IN CASE OF EMERGENCY 391 Cavity Cartridge Fuse Micro Fuse Description – 10 Amp Red HTD MIRRORS – 10 Amp Red COMP/INTRUSION/SIREN/INTRUSION SNSRS – 20 Amp Yellow SMART BAR CTRL MOD – 15 Amp Blue 30 Amp Pink – REAR DEFROSTER (EBL) 30 Amp Pink –...
Page 394 392 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 10 Amp Red PWR MIRROR SW – 20 Amp Yellow RADIO/TBM – 10 Amp Red SW BANK-HD ELEC/OFF ROAD – – Spare F100 30 Amp Pink – ESC-ECU & VALVES F101 30 Amp Pink –...
Page 395: Jacking And Tire Changing
IN CASE OF EMERGENCY 393 JACKING AND TIRE CHANGING CAUTION! • When installing the power distribution center cover, WARNING! it is important to ensure the cover is properly posi- • Do not attempt to change a tire on the side of the tioned and fully latched.
Page 396: Jack Location
394 IN CASE OF EMERGENCY Jack Location 2. Remove the hardware storage cover by pinching the latch on the left side and pulling upward. The jack and lug wrench are located in the rear cargo area. To remove jack and tools proceed as follows: 1.
Page 397 IN CASE OF EMERGENCY 395 Jack And Lug Wrench Plastic Wing Nut Location 3. Turn the black plastic wing nut counterclockwise to 4. Remove tool kit and assemble tools. loosen the jack from the storage bin.
Page 398: Spare Tire Removal
396 IN CASE OF EMERGENCY Spare Tire Removal Stowing The Replaced Spare Tire 1. To remove the spare tire from the carrier, remove the tire 1. Mount the spare tire onto the carrier. Torque down lug cover, if equipped. nuts and locking lug nut. 2.
Page 399: Jacking Instructions
IN CASE OF EMERGENCY 397 4. Shift the automatic transmission into PARK, or a manual WARNING! (Continued) transmission into REVERSE. • Set the parking brake firmly and set an automatic 5. Turn the ignition to LOCK. transmission in PARK; a manual transmission in REVERSE.
Page 400 398 IN CASE OF EMERGENCY 2. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground. 3. Assemble the jack and jacking tools. Connect the jack handle driver to the extension, then to the lug wrench.
Page 401 IN CASE OF EMERGENCY 399 4. Operate the jack from the front or the rear of the vehicle. Place the jack under the axle tube, as shown. Do not raise the vehicle until you are sure the jack is fully engaged.
Page 402 400 IN CASE OF EMERGENCY 6. Remove the lug nuts and wheel. 11. Secure the jack and tools in their proper locations. 7. Position the spare wheel/tire on the vehicle and install 12. Secure the damaged wheel/tire on the spare tire car- the lug nuts with the cone-shaped end toward the rier.
Page 403: Road Tire Installation
IN CASE OF EMERGENCY 401 Road Tire Installation 5. After 25 miles (40 km), check the lug nut torque with a torque wrench to ensure that all lug nuts are properly 1. Mount the road tire on the axle. seated against the wheel. 2.
Page 404 402 IN CASE OF EMERGENCY 2. Remove the manual park release cover, located above 3. Using a small screwdriver or similar tool, fish the tether the gear selector, to access the release tether strap. strap up through the opening in the console base. Manual Park Release Cover Tether Strap 4.
Page 405: Jump Starting
IN CASE OF EMERGENCY 403 To Reset The Manual Park Release: WARNING! 1. Pull upward on the tether strap, releasing it from the Do not attempt jump starting if the battery is frozen. It “locked” position. could rupture or explode and cause personal injury. 2.
Page 406: Preparations For Jump Start
404 IN CASE OF EMERGENCY Preparations For Jump Start WARNING! The battery in your vehicle is located in the right rear of the • Take care to avoid the radiator cooling fan whenever engine compartment, behind the Power Distribution Cen- the hood is raised.
Page 407: Jump Starting Procedure
IN CASE OF EMERGENCY 405 Connecting The Jumper Cables WARNING! 1. Connect the positive (+) end of the jumper cable to the Do not allow vehicles to touch each other as this could remote positive (+) post of the discharged vehicle. establish a ground connection and personal injury 2.
Page 408: If Your Engine Overheats
406 IN CASE OF EMERGENCY If frequent jump starting is required to start your vehicle CAUTION! you should have the battery and charging system tested at an authorized dealer. Do not run the booster vehicle engine above 2000 rpm since it provides no charging benefit, wastes fuel and CAUTION! can damage booster vehicle engine.
Page 409: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY 407 CAUTION! WARNING! You or others can be badly burned by hot engine Driving with a hot cooling system could damage your coolant (antifreeze) or steam from your radiator. If you vehicle. If the temperature gauge reads HOT (H), pull see or hear steam coming from under the hood, do not over and stop the vehicle.
Page 410 408 IN CASE OF EMERGENCY NOTE: CAUTION! • For vehicles with automatic transmission: Shifts be- • Racing the engine or spinning the wheels may lead tween DRIVE and REVERSE can only be achieved at to transmission overheating and failure. Allow the wheel speeds of 5 mph (8 km/h) or less.
Page 411: Towing A Disabled Vehicle
IN CASE OF EMERGENCY 409 TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmis- sion and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing” in the “Starting And Operating”...
Page 412: Four-Wheel Drive Models
410 IN CASE OF EMERGENCY Proper towing or lifting equipment is required to prevent Four–Wheel Drive Models damage to your vehicle. Use only tow bars and other The manufacturer recommends towing with all wheels equipment designed for this purpose, following equipment OFF the ground.
Page 413: Emergency Tow Hooks - If Equipped
IN CASE OF EMERGENCY 411 Emergency Tow Hooks — If Equipped ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) If your vehicle is equipped with tow hooks, they are mounted in the front and the rear. This vehicle is equipped with an Enhanced Accident Response System.
Page 415 SERVICING AND MAINTENANCE CONTENTS ▫ Air Conditioner Maintenance ....430 SCHEDULED SERVICING ....415 ▫...
Page 416 414 SERVICING AND MAINTENANCE ▫ Tire Types ......466 BODYWORK ......474 ▫...
Page 417: Scheduled Servicing
SERVICING AND MAINTENANCE 415 SCHEDULED SERVICING Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change scheduled oil change is performed by someone other than indicator system.
Page 418: Maintenance Plan
416 SERVICING AND MAINTENANCE Once A Month Or Before A Long Trip: At Every Oil Change Interval As Indicated By Oil • Check engine oil level Change Indicator System: • Change oil and filter • Check windshield washer fluid level •...
Page 419 SERVICING AND MAINTENANCE 417 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, and replace if necessary. Inspect the front and rear axle fluid. Inspect the brake linings, replace as necessary Adjust parking brake on vehicles equipped with four wheel disc...
Page 420 418 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace engine air cleaner filter. Replace air conditioning/cabin air filter. Replace Spark Plugs – 2.0L Engine** Replace spark plugs – 3.6L Engine** Flush and replace the engine, in- tercooler (if equipped), battery (if equipped), and Motor Generator Unit (MGU) (if equipped) coolant...
Page 421 SERVICING AND MAINTENANCE 419 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, po- lice, delivery service (commercial service), off-road, desert operation or more than 50% of your driving is at sustained high speeds during...
Page 422: Heavy Duty Use Of The Vehicle
420 SERVICING AND MAINTENANCE ** The spark plug change interval is mileage based only, yearly intervals do not apply. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 423: Engine Compartment
SERVICING AND MAINTENANCE 421 ENGINE COMPARTMENT 2.0L Engine 1 — Power Distribution Center (Fuses) 8 — Power Pack Unit Pressure Cap — If Equipped 2 — Battery 9 — Power Pack Unit Pressure Reservoir — If Equipped 3 — Engine Oil Dipstick 10 —...
Page 424: L Engine
422 SERVICING AND MAINTENANCE 3.6L Engine 1 — Power Distribution Center (Fuses) 8 — Power Pack Unit Pressure Cap — If Equipped 2 — Battery 9 — Power Pack Unit Pressure Reservoir — If Equipped 3 — Engine Oil Dipstick 10 —...
Page 425: Checking Oil Level
SERVICING AND MAINTENANCE 423 Checking Oil Level When refilling the washer fluid reservoir, take some washer fluid and apply it to a cloth or towel and wipe clean To ensure proper lubrication of your vehicle’s engine, the the wiper blades; this will help blade performance. engine oil must be maintained at the correct level.
Page 426: Dealer Service
424 SERVICING AND MAINTENANCE WARNING! (Continued) CAUTION! (Continued) contact your eyes, skin, or clothing. Do not lean over and are identified on the battery case. Cable clamps should be tight on the terminal posts and free of a battery when attaching clamps. If acid splashes in corrosion.
Page 427: Engine Oil
SERVICING AND MAINTENANCE 425 Engine Oil Selection 3.6L Engine WARNING! For best performance and maximum protection under all You can be badly injured working on or around a types of operating conditions, the manufacturer only rec- motor vehicle. Only do service work for which you ommends engine oils that are API Certified and meet the have the knowledge and the proper equipment.
Page 428 426 SERVICING AND MAINTENANCE Engine Oil Viscosity (SAE Grade) — 2.0L Engine Lubricants which do not have both the engine oil certifi- cation mark and the correct SAE viscosity grade number Mopar SAE 5W-30 engine oil approved to FCA Material should not be used.
Page 429: Engine Oil Filter
SERVICING AND MAINTENANCE 427 or governmental agency for advice on how and where used WARNING! oil and oil filters can be safely discarded in your area. The air induction system (air cleaner, hoses, etc.) can Engine Oil Filter provide a measure of protection in the case of engine The engine oil filter should be replaced with a new filter at backfire.
Page 430 428 SERVICING AND MAINTENANCE Engine Air Cleaner Filter Removal 2. Lift the air cleaner cover to access the air cleaner filter. 1. Loosen the retainers from the air cleaner cover using a suitable tool. Air Cleaner Filter Cover Air Cleaner Filter Cover 1 —...
Page 431: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE 429 3. Remove the air cleaner filter element from the housing 2. Tighten air cleaner cover retainers using a suitable tool. assembly. Accessory Drive Belt Inspection WARNING! • Do not attempt to inspect an accessory drive belt with vehicle running.
Page 432: Air Conditioner Maintenance
430 SERVICING AND MAINTENANCE • “Groove jumping (belt does not maintain correct posi- normal. Any belt with cracks running along a rib must be replaced. Also have the belt replaced if it has excessive tion on pulley) wear, frayed cords or severe glazing. •...
Page 433 SERVICING AND MAINTENANCE 431 Refrigerant Recovery And Recycling R-134a — WARNING! If Equipped • Use only refrigerants and compressor lubricants ap- R-134a Air Conditioning Refrigerant is a hydrofluoro- proved by the manufacturer for your air conditioning carbon (HFC) that is an ozone-friendly substance. The system.
Page 434 432 SERVICING AND MAINTENANCE Air Conditioning Filter Replacement (A/C Air Filter) WARNING! Do not remove the cabin air filter while the vehicle is running, or while the ignition is in the ACC or ON/ RUN mode. With the cabin air filter removed and the blower operating, the blower can contact hands and may propel dirt and debris into your eyes, resulting in personal injury.
Page 435 SERVICING AND MAINTENANCE 433 4. Disengage the two retaining tabs that secure the air filter 5. Remove the air filter from the HVAC air inlet housing. access door to the HVAC housing. Pull the filter elements out pinching them to the right for clearance.
Page 436 434 SERVICING AND MAINTENANCE CAUTION! The cabin air filter is identified with an arrow to indicate airflow direction through the filter. Failure to properly install the filter will result in the need to replace it more often. 7. Close A/C Air Filter access door and secure retaining tabs.
Page 437: Body Lubrication
SERVICING AND MAINTENANCE 435 Body Lubrication Windshield Wiper Blades Locks and all body pivot points, including such items as Clean the rubber edges of the wiper blades and the seat tracks, door hinge pivot points and rollers, liftgate, windshield periodically with a sponge or soft cloth and a tailgate, decklid, sliding doors and hood hinges, should be mild nonabrasive cleaner.
Page 438 436 SERVICING AND MAINTENANCE The wiper blades and wiper arms should be inspected 1. Lift the wiper arm to raise the wiper blade off of the periodically, not just when wiper performance problems glass, until the wiper arm is in the full up position. are experienced.
Page 439 SERVICING AND MAINTENANCE 437 2. To disengage the wiper blade from the wiper arm, raise 3. With the wiper blade disengaged, remove the wiper the cover, press the release tab on the wiper blade and blade from the wiper arm. while holding the wiper arm with one hand, slide the 4.
Page 440 438 SERVICING AND MAINTENANCE Rear Wiper Blade Removal/Installation 2. Lift wiper arm off of the glass and rotate wiper blade outward to disengage the wiper blade from the wiper 1. Open tailgate to access the wiper arm. arm. Rear Wiper Assembly Wiper Blade And Wiper Arm 1 —...
Page 441: Exhaust System
SERVICING AND MAINTENANCE 439 3. Gently set the arm on the glass. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. If you notice a change in the sound of the exhaust system; or if the exhaust fumes can be detected inside the vehicle;...
Page 442 440 SERVICING AND MAINTENANCE Under normal operating conditions, the catalytic converter WARNING! (Continued) will not require maintenance. However, it is important to • A hot exhaust system can start a fire if you park over keep the engine properly tuned to assure proper catalyst materials that can burn.
Page 443: Cooling System
SERVICING AND MAINTENANCE 441 Cooling System appearance, the system should be drained, flushed and refilled with fresh coolant (antifreeze). Check the front of the A/C condenser (if equipped) or radiator for any WARNING! accumulation of bugs, leaves, etc. If dirty, clean by gently •...
Page 444 442 SERVICING AND MAINTENANCE • This vehicle has not been designed for use with propyl- Refer to the “Maintenance Plan” in this section for the proper maintenance intervals. ene glycol-based engine coolant (antifreeze). Use of propylene glycolbased engine coolant (antifreeze) is not Selection Of Coolant recommended.
Page 445 SERVICING AND MAINTENANCE 443 • Some vehicles require special tools to add coolant prop- Please review these recommendations for using Organic Additive Technology (OAT) engine coolant (antifreeze) erly. Failure to fill these systems properly could lead to that meets the requirements of FCA Material Standard severe internal engine damage.
Page 446 444 SERVICING AND MAINTENANCE Coolant Level WARNING! The coolant bottle provides a quick visual method for • Do not open hot engine cooling system. Never add determining that the coolant level is adequate. With the engine coolant (antifreeze) when the engine is over- engine OFF and cold, the level of the engine coolant heated.
Page 447 SERVICING AND MAINTENANCE 445 Engine Coolant Level — 2.0L 4. Remove the cap with dipstick and check the coolant level on the dipstick. WARNING! The radiator normally remains completely full, so there is • Do not open hot engine cooling system. Never add no need to remove the radiator/coolant pressure cap unless checking for engine coolant (antifreeze) freeze point engine coolant (antifreeze) when the engine is over-...
Page 448: Brake System
446 SERVICING AND MAINTENANCE • Do not overfill the coolant expansion bottle. Brake System • Check the coolant freeze point in the radiator and in the In order to assure brake system performance, all brake coolant expansion bottle. If engine coolant (antifreeze) system components should be inspected periodically.
Page 449: Front/Rear Axle Fluid
SERVICING AND MAINTENANCE 447 pads wear. Brake fluid level should be checked when pads WARNING! (Continued) are replaced. If the brake fluid is abnormally low, check the to boil unexpectedly during hard or prolonged brak- system for leaks. ing, resulting in sudden brake failure. This could Refer to “Fluids And Lubricants”...
Page 450: Transfer Case
448 SERVICING AND MAINTENANCE Fluid Level Check Fluid Level Check Lubricant should be approximately 1/8 inch (3 mm) below This fluid level can be checked by removing the filler plug. the bottom edge of the oil fill hole. The fluid level should be to the bottom edge of the filler plug hole with the vehicle in a level position.
Page 451: Automatic Transmission
SERVICING AND MAINTENANCE 449 Frequency Of Fluid Change CAUTION! Under normal operating conditions, the fluid installed at Using a transmission fluid other than the manufactur- the factory will give satisfactory lubrication for the life of er’s recommended fluid may cause deterioration in the vehicle.
Page 452: Raising The Vehicle
450 SERVICING AND MAINTENANCE Fluid Level Check Routine fluid and filter changes are not required. However, change the fluid and filter if the fluid becomes contami- The fluid level is preset at the factory and does not require nated (with water, etc.), or if the transmission is disas- adjustment under normal operating conditions.
Page 453 SERVICING AND MAINTENANCE 451 Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards.
Page 454 452 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or ..blank..= Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
Page 455 SERVICING AND MAINTENANCE 453 EXAMPLE: Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol – A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under cer- tain operating conditions –...
Page 456 454 SERVICING AND MAINTENANCE Tire Identification Number (TIN) the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on the The TIN may be found on one or both sides of the tire; outboard side, then you will find it on the inboard side of however, the date code may only be on one side.
Page 457 SERVICING AND MAINTENANCE 455 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located be- hind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 458 456 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle.
Page 459 SERVICING AND MAINTENANCE 457 Tire And Loading Information Placard Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard in “Vehicle Loading”...
Page 460 458 SERVICING AND MAINTENANCE Steps For Determining Correct Load Limit— Metric Example For Load Limit (1) Locate the statement “The combined weight of For example, if “XXX” amount equals 635 kg and there will occupants and cargo should never exceed XXX kg or be five 68 kg passengers in your vehicle, the amount of XXX lbs.”...
Page 461 SERVICING AND MAINTENANCE 459 WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the rec- ommended load capacity for your vehicle. Never over- load them.
Page 462: Tires - General Information
460 SERVICING AND MAINTENANCE Tires — General Information WARNING! (Continued) Tire Pressure • Overinflated or underinflated tires can affect vehicle handling and can fail suddenly, resulting in loss of Proper tire inflation pressure is essential to the safe and vehicle control. satisfactory operation of your vehicle.
Page 463 SERVICING AND MAINTENANCE 461 Fuel Economy CAUTION! Underinflated tires will increase tire rolling resistance After inspecting or adjusting the tire pressure, always resulting in higher fuel consumption. reinstall the valve stem cap. This will prevent moisture Tread Wear and dirt from entering the valve stem, which could damage the valve stem.
Page 464 462 SERVICING AND MAINTENANCE pressure should be increased by 3 psi (21 kPa), which Radial Ply Tires equals 1 psi (7 kPa) for every 12°F (7°C) for this outside temperature condition. WARNING! Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) Combining radial ply tires with other types of tires on during operation.
Page 465 SERVICING AND MAINTENANCE 463 Run Flat Tires — If Equipped Tire Spinning Run Flat tires allow you the capability to drive 50 miles When stuck in mud, sand, snow, or ice conditions, do not (80 km) at 50 mph (80 km/h) after a rapid loss of inflation spin your vehicle’s wheels above 30 mph (48 km/h) or for pressure.
Page 466 464 SERVICING AND MAINTENANCE Tread Wear Indicators These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth Tread wear indicators are in the original equipment tires to becomes a 1/16 of an inch (1.6 mm). When the tread is help you in determining when your tires should be re- worn to the tread wear indicators, the tire should be placed.
Page 467 SERVICING AND MAINTENANCE 465 See the Tire Sizing Chart example found in the “Tire Safety WARNING! Information” section of this manual for more information relating to the Load Index and Speed Symbol of a tire. Tires and the spare tire should be replaced after six years, regardless of the remaining tread.
Page 468: Tire Types
466 SERVICING AND MAINTENANCE Tire Types WARNING! (Continued) All Season Tires — If Equipped and suspension components. You could lose control and have a collision resulting in serious injury or All Season tires provide traction for all seasons (Spring, death. Use only the tire and wheel sizes with load Summer, Fall, and Winter).
Page 469: Spare Tires - If Equipped
SERVICING AND MAINTENANCE 467 While studded tires improve performance on ice, skid and WARNING! traction capability on wet or dry surfaces may be poorer than that of non-studded tires. Some states prohibit stud- Do not use Summer tires in snow/ice conditions. You ded tires;...
Page 470 468 SERVICING AND MAINTENANCE your vehicle. If your vehicle has this option, refer to an WARNING! authorized tire dealer for the recommended tire rotation pattern. Compact and collapsible spares are for temporary emergency use only. With these spares, do not drive Compact Spare Tire —...
Page 471: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE 469 Limited Use Spare — If Equipped Wheel And Wheel Trim Care The limited use spare tire is for temporary emergency use All wheels and wheel trim, especially aluminum and chrome only. This tire is identified by a label located on the limited plated wheels, should be cleaned regularly using mild (neu- tral Ph) soap and water to maintain their luster and to use spare wheel.
Page 472: Tire Chains (Traction Devices)
470 SERVICING AND MAINTENANCE When cleaning extremely dirty wheels including excessive Dark Vapor Chrome, Black Satin Chrome, or Low Gloss brake dust, care must be taken in the selection of tire and Clear Coat Wheels wheel cleaning chemicals and equipment to prevent dam- age to the wheels.
Page 473: Tire Rotation Recommendations
SERVICING AND MAINTENANCE 471 WARNING! CAUTION! (Continued) • Observe the traction device manufacturer’s instruc- Using tires of different size and type (M+S, Snow) tions on the method of installation, operating speed, between front and rear axles can cause unpredictable and conditions for use. Always use the suggested handling.
Page 474: Department Of Transportation Uniform Tire Quality Grades
472 SERVICING AND MAINTENANCE The suggested rotation method is the “rearward-cross” DEPARTMENT OF TRANSPORTATION UNIFORM shown in the following diagram. TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manu- facturer in each category is shown on the sidewall of the tires on your vehicle.
Page 475: Traction Grades
SERVICING AND MAINTENANCE 473 Traction Grades corresponds to a level of performance, which all pas- senger vehicle tires must meet under the Federal Motor The Traction grades, from highest to lowest, are AA, A, B, Vehicle Safety Standard No. 109. Grades B and A and C.
Page 476: Bodywork
474 SERVICING AND MAINTENANCE • Salt in the air near seacoast localities. BODYWORK • Atmospheric fallout/industrial pollutants. Protection From Atmospheric Agents Vehicle body care requirements vary according to geo- Body And Underbody Maintenance graphic locations and usage. Chemicals that make roads Cleaning Headlights passable in snow and ice and those that are sprayed on Your vehicle is equipped with plastic headlights and fog...
Page 477 SERVICING AND MAINTENANCE 475 • If insects, tar, or other similar deposits have accumulated Special Care on your vehicle, use Mopar Super Kleen Bug and Tar • If you drive on salted or dusty roads or if you drive near Remover to remove.
Page 478 476 SERVICING AND MAINTENANCE Appearance Care For Fabric Top Models Rinsing – Be sure to remove all traces of cleaner by rinsing the top thoroughly with clean water. Remember to allow To maintain the appearance of your vehicle’s interior trim the top to dry before lowering it.
Page 479 To maintain ease of use of the window plastic dow, not up and down. Mopar Jeep Soft Glass Window retainers, each window plastic retainer should be Cleaner or equivalent will safely clean all plastic win- cleaned and lubricated regularly.
Page 480: Interiors
478 SERVICING AND MAINTENANCE INTERIORS 2. Pull the carpet out from the front to the rear. Carpet Removal Front Carpets (Two And Four Door Models): 1. Remove the front grommets. Front Carpet Pulled Away Front Carpet 1 — Grommets...
Page 481 SERVICING AND MAINTENANCE 479 3. Remove the grommets under the front seat. First for the 4. Under the back of the front seat, open the carpet split rear carpet and then the front carpet. and then pull out the rear edge and slide the carpet to the front (do not remove the harness).
Page 482 480 SERVICING AND MAINTENANCE 5. Finally open the carpet split around seat bracket and Rear Carpet (Four Door Models): then remove the last two grommets. 1. Remove the grommets under the front seat (one left and one right). 2. Then pull the carpet out, to the rear and open the carpet split around the front seats brackets.
Page 483 SERVICING AND MAINTENANCE 481 4. Pull the carpet out to the front and open the carpet split Rear Carpet (Two Door Models): around the rear seats brackets. 1. Remove the rear seats. 2. Remove the sides grommets (one left and one right). First the grommet from the side carpet and then the rear carpet.
Page 484 482 SERVICING AND MAINTENANCE 4. Then pull the carpet out to the rear and open the carpet Cargo Carpet (Four Door Models): split around the front seats brackets. 1. Remove the grommets under the rear seat (one left and one right). 2.
Page 485 SERVICING AND MAINTENANCE 483 3. Remove the carpet under the load floor and the side Cargo Carpet (Four Door Models) With Gap Hider: support and then pull the carpet out. 1. Remove the grommets under the rear seat (one left and one right).
Page 486 484 SERVICING AND MAINTENANCE 3. When reinstalling carpet please preform these steps in 3. When reinstalling carpet please preform these steps in reverse order making sure that the carpet is tucked under reverse order making sure that the carpet is tucked the scuffs, B pillar, console, and refasten grommets.
Page 487: Seats And Fabric Parts
SERVICING AND MAINTENANCE 485 Seats And Fabric Parts Use Mopar Total Clean to clean fabric upholstery and carpeting. WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents Inside Sidewall...
Page 488: Plastic And Coated Parts
486 SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster Lenses WARNING! The lenses in front of the instruments in this vehicle are A frayed or torn belt could rip apart in a collision and molded in clear plastic. When cleaning the lenses, care leave you with no protection.
Page 489: Glass Surfaces
SERVICING AND MAINTENANCE 487 NOTE: If equipped with light colored leather, it tends to show any foreign material, dirt, and fabric dye transfer more so than darker colors. The leather is designed for easy cleaning, and FCA recommends Mopar total care leather cleaner applied on a cloth to clean the leather seats as needed.
Page 491: Technical Specifications
TECHNICAL SPECIFICATIONS CONTENTS ▫ Do Not Use E-85 In Non-Flex Fuel Vehicles ..494 VEHICLE IDENTIFICATION NUMBER ..490 ▫ CNG And LP Fuel System Modifications ..494 WHEEL AND TIRE TORQUE SPECIFICATIONS .
Page 492: Vehicle Identification Number
490 TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER NOTE: It is illegal to remove or alter the VIN plate. The Vehicle Identification Number (VIN) is found on the WHEEL AND TIRE TORQUE SPECIFICATIONS left front corner of the A pillar, visible from outside of the Proper lug nut/bolt torque is very important to ensure that vehicle through the windshield.
Page 493 TECHNICAL SPECIFICATIONS 491 Spare Tire Torque Specifications Tighten the lug nuts/bolts in a star pattern until each nut/bolt has been tightened twice. Ensure that the socket is Lug Nut/Bolt **Lug Nut/Bolt Lug Nut/Bolt fully engaged on the lug nut/bolt (do not insert it half- Torque Size Socket Size...
Page 494: Fuel Requirements
492 TECHNICAL SPECIFICATIONS octane number can cause engine failure and may void or WARNING! not be covered by the New Vehicle Limited Warranty. To avoid the risk of forcing the vehicle off the jack, do Poor quality gasoline can cause problems such as hard not tighten the lug nuts fully until the vehicle has been starting, stalling, and hesitations.
Page 495: Reformulated Gasoline
TECHNICAL SPECIFICATIONS 493 Poor quality gasoline can cause problems such as hard Designated TOP TIER Detergent Gaso- starting, stalling, and hesitations. If you experience these line contains a higher level of detergents symptoms, try another brand of gasoline before consider- to further aide in minimizing engine ing service for the vehicle.
Page 496: Do Not Use E-85 In Non-Flex Fuel Vehicles
494 TECHNICAL SPECIFICATIONS • Poor cold start and cold drivability. CAUTION! (Continued) • Increased risk for fuel system component corrosion. cause emissions to exceed the applicable standard, and/or cause the “Malfunction Indicator Light” to CNG And LP Fuel System Modifications illuminate.
Page 497: Fuel System Cautions
TECHNICAL SPECIFICATIONS 495 Fuel System Cautions NOTE: Intentional tampering with the emissions control system can result in civil penalties being assessed against you. CAUTION! Carbon Monoxide Warnings Follow these guidelines to maintain your vehicle’s performance: • The use of leaded gasoline is prohibited by Federal WARNING! law.
Page 498: Fluid Capacities
496 TECHNICAL SPECIFICATIONS FLUID CAPACITIES U.S. Metric Fuel (Approximate) Two Door Models 18.5 Gallons 70 Liters Four Door Models 21.5 Gallons 81 Liters Engine Oil with Filter 2.0L Engine 5 Quarts 4.73 Liters 3.6L Engine 5 Quarts 4.73 Liters Cooling System * 2.0L Engine (Mopar Antifreeze/ 9.9 Quarts 9.4 Liters...
Page 499 TECHNICAL SPECIFICATIONS 497 U.S. Metric 2.0L Battery Coolant (Mopar 2.5 Quarts 2.4 Liters Antifreeze/Engine Coolant 10 Year/ 150,000 Mile Formula or equivalent) 3.6L Engine (Mopar Antifreeze/ 10.7 Quarts 10.1 Liters Engine Coolant 10 Year/150,000 Mile Formula or equivalent) 3.6L Motor Generator Unit (MGU) 1.9 Quarts 1.8 Liters (Mopar Antifreeze/Engine Coolant...
Page 500: Fluids And Lubricants
498 TECHNICAL SPECIFICATIONS FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Tech- nology) or equivalent meeting the requirements of FCA Material Standard MS.90032. Intercooler/Motor Generator Unit (if equipped) We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Tech-...
Page 501 TECHNICAL SPECIFICATIONS 499 Component Fluid, Lubricant, or Genuine Part Engine Oil — 3.6L Engine We recommend you use API Certified SAE 0W-20 Engine Oil, meeting the requirements of FCA Material Standard MS-6395 such as Mopar, Pennzoil, and Shell Helix. Refer to your engine oil filler cap for correct SAE grade.
Page 502: Chassis
500 TECHNICAL SPECIFICATIONS CAUTION! (Continued) be compatible with the radiator engine coolant and may plug the radiator. • This vehicle has not been designed for use with propylene glycol-based engine coolant (antifreeze). Use of propylene glycol-based engine coolant (anti- freeze) is not recommended. Chassis Component Fluid, Lubricant, or Genuine Part...
Page 503 TECHNICAL SPECIFICATIONS 501 Component Fluid, Lubricant, or Genuine Part Axle Differential (Rear) We recommend you use Mopar Gear & Axle Lubricant (SAE 75W85)(API GL-5). Models equipped with Trac-Lok Limited Slip Differential require a friction modifier addi- tive. Brake Master Cylinder We recommend you use Mopar DOT 3 Brake Fluid, SAE J1703.
Page 505 MULTIMEDIA CONTENTS UCONNECT SYSTEMS ....505 STEERING WHEEL AUDIO CONTROLS ..556 ▫ Radio Operation......556 DRAG &...
Page 506 504 MULTIMEDIA ▫ Climate ......572 ▫ Siri Eyes Free — If Equipped ....576 ▫...
Page 507: Uconnect Systems
MULTIMEDIA UCONNECT SYSTEMS For detailed information about your Uconnect system, refer to your Uconnect Owner’s Manual Supplement. NOTE: Uconnect screen images are for illustration pur- poses only and may not reflect exact software for your vehicle. DRAG & DROP MENU BAR The Uconnect features and services in the main menu bar are easily changed for your convenience.
Page 508: Cybersecurity
506 MULTIMEDIA CYBERSECURITY WARNING! Your vehicle may be a connected vehicle and may be • It is not possible to know or to predict all of the equipped with both wired and wireless networks. These possible outcomes if your vehicle’s systems are networks allow your vehicle to send and receive informa- breached.
Page 509: Uconnect Settings
MULTIMEDIA NOTE: UCONNECT SETTINGS • FCA US LLC or your dealer may contact you directly The Uconnect system uses a combination of buttons on the regarding software updates. touchscreen and buttons on the faceplate located on the center of the instrument panel that allow you to access and •...
Page 510: Customer Programmable Features
508 MULTIMEDIA Customer Programmable Features — Uconnect 3 Push the “Settings” button on the touchscreen to display Settings the settings menu screen. In this mode the Uconnect system allows you to access all of the available program- mable features. NOTE: Only one touchscreen area may be selected at a time.
Page 511 MULTIMEDIA Display After pressing the “Display” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto Manual Brightness NOTE: The “Brightness” setting can also be adjusted by selecting any point on the scale between the “+” and “-” buttons on the touchscreen.
Page 512 510 MULTIMEDIA Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measure. • The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L) and “Pressure” (kPa, or bar) units of measure independently.
Page 513 MULTIMEDIA Setting Name Selectable Options Show Time Status — If Equipped Sync Time — If Equipped Safety/Assistance After pressing the “Safety/Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay — If Equipped NOTE: The “ParkView Backup Camera Delay”...
Page 514 512 MULTIMEDIA Setting Name Selectable Options ParkView Backup Camera Active Guide Lines — If Equipped NOTE: The “ParkView Backup Camera Active Guide Lines” setting overlays the Rear Backup Camera image with active, or dynamic, grid lines to help illustrate the width of the vehicle and its project back up path, based on the steering wheel position when the option is checked.
Page 515 MULTIMEDIA Setting Name Selectable Options Blind Spot Alert — Lights Lights and Chime If Equipped Rain Sensing Auto Wipers — If Equipped Auto Park Brake Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay...
Page 516 514 MULTIMEDIA Setting Name Selectable Options Interior Ambient Lights NOTE: The “Interior Ambient Lights” setting can also be adjusted by selecting any point on the scale between the “+” and “-” buttons on the touchscreen. Doors & Locks After pressing the “Doors & Locks” button on the touch- screen, the following settings will be available: Setting Name Selectable Options...
Page 517 MULTIMEDIA Setting Name Selectable Options Flash Lights With Lock Horn With Lock Horn With Remote Start — If Equipped Remote Door Unlock/Door Unlock Driver NOTE: When “Driver” is selected, only the driver’s door will unlock on the first push of the key fob unlock button, you must push the key fob unlock button twice to unlock the passenger’s doors.
Page 518 516 MULTIMEDIA Auto Comfort Systems — If Equipped After pressing the “Auto-On Comfort Systems” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat & Steering Remote Start All Starts Wheel With Vehicle Start — If Equipped NOTE: When this feature is selected, the driver’s heated seat and heated steering wheel will automatically turn on when temperatures are below 40°...
Page 519 MULTIMEDIA Audio After pressing the “Audio” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and “–”...
Page 520 518 MULTIMEDIA Setting Name Selectable Options Loudness NOTE: The “Loudness” feature improves sound quality at lower volumes when enabled. AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input.
Page 521 MULTIMEDIA SiriusXM Setup — If Equipped After pressing the “SiriusXM Setup” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Channel Skip List of Channels NOTE: SiriusXM can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scanning.
Page 522 520 MULTIMEDIA Restore Settings After pressing the “Restore Settings” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected, it will reset all settings to their default settings. Clear Personal Data After pressing the “Clear Personal Data”...
Page 523: Customer Programmable Features
MULTIMEDIA Customer Programmable Features — Uconnect 4 Press the “Settings” button on the bottom bar, or press the “Apps ” button, then press the “Settings” button on Settings the touchscreen to display the menu setting screen. In this mode the Uconnect system allows you to access all of the available programmable features.
Page 524 522 MULTIMEDIA Language After pressing the “Language” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Espanol Francais Display After pressing the “Display” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode...
Page 525 MULTIMEDIA Setting Name Selectable Options Touchscreen Beep Control Screen Timeout Phone Pop- ups Displayed in Cluster Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measure. •...
Page 526 524 MULTIMEDIA Voice After pressing the “Voice” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed Show Command List Always With Help Never Time & Date After pressing the “Time & Date” button on the touch- screen, the following settings will be available: Setting Name Selectable Options...
Page 527 MULTIMEDIA Camera After pressing the “Camera” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay — If Equipped NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE.
Page 528 526 MULTIMEDIA Safety/Driving Assistance — If Equipped After pressing the “Safety/Driving Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkSense — If Equipped Sound Sound and Display Rear ParkSense Volume Medium High Rain Sensing Auto Wipers Lights After pressing the “Lights”...
Page 529 MULTIMEDIA Setting Name Selectable Options Auto Dim High Beams — If Equipped NOTE: When the “Cornering Lights” feature is selected, if the steering wheel rotation angle is large or the turn signal indica- tors are on, a light (incorporated in the fog light) will turn on, on the relevant side to improve visibility at night. Flash Lights With Lock —...
Page 530 528 MULTIMEDIA Setting Name Selectable Options Auto Unlock On Exit NOTE: When this feature is selected, all doors will unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL position and the driver’s door is opened. Flash Lights With Lock Remote Door Unlock Driver Door...
Page 531 MULTIMEDIA Aux Switches After pressing the “Aux Switches” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Aux 1-4 Type Latching Momentary Power Source Battery Ignition Recalled Last State NOTE: Holding last state conditions are met when switch type is set to latching and power source is set to ignition. Audio After pressing the “Audio”...
Page 532 530 MULTIMEDIA Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and “–” setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the touchscreen.
Page 533 MULTIMEDIA Phone After pressing the “Phone” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Do Not Disturb Do Not Distrurb Options Paired Phones And Audio Devices List Of Paired Phones And Audio Devices NOTE: This feature shows which phones and audio devices are paired to the Phone/Bluetooth system.
Page 534 532 MULTIMEDIA Setting Name Selectable Options Subscription Info Sirius ID NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.
Page 535 MULTIMEDIA Clear Personal Data After pressing the “Clear Personal Data” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Clear Personal Data Cancel NOTE: When this feature is selected it will remove all personal data including Bluetooth devices and presets.
Page 536: Customer Programmable Features - Uconnect 4/4C Nav Settings
534 MULTIMEDIA Customer Programmable Features — Uconnect Press the “Apps ” button, then press the “Settings 4/4C NAV Settings ” button on the touchscreen to display the menu setting screen. In this mode the Uconnect system allows you to access all of the available programmable features. NOTE: •...
Page 537 MULTIMEDIA Display After pressing the “Display” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Manual Auto Display Brightness With Headlights ON NOTE: To make changes to the Display Brightness with Headlights ON setting, the headlights must be on and the interior dimmer switch must not be in the party or parade positions.
Page 538 536 MULTIMEDIA Setting Name Selectable Options Set Language NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Espa- ñol) for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the “Set Language”...
Page 539 MULTIMEDIA Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measure. • The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L), “Pressure” (kPa, or bar), and “Temperature”...
Page 540 538 MULTIMEDIA Clock After pressing the “Clock” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS — If Equipped Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. The “Sync time with GPS” button on the touch- screen must be unchecked.
Page 541 MULTIMEDIA Camera After pressing the “Camera” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay — If Equipped NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE.
Page 542 540 MULTIMEDIA Safety & Driving Assistance After pressing the “Safety & Driving Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkSense — If Equipped Sound Only Sound and Display Front ParkSense Volume Medium High Medium High...
Page 543 MULTIMEDIA Setting Name Selectable Options Auto Folding Side Mirrors — If Equipped Headlights with Wipers Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay 0 sec 30 sec 60 sec 90 sec NOTE:...
Page 544 542 MULTIMEDIA Setting Name Selectable Options Auto Dim High Beams — If Equipped NOTE: When the “Auto Dim High Beams” feature is selected, the high beam headlights will activate/deactivate automati- cally under certain conditions. Doors & Locks After pressing the “Doors & Locks” button on the touch- screen, the following settings will be available: Setting Name Selectable Options...
Page 545 MULTIMEDIA Setting Name Selectable Options 1st Press Of Key Fob Unlocks Driver Door All Doors NOTE: When Driver Door is selected with 1st Press Of Key Fob Unlocks, only the driver’s door will unlock with the first press of the key fob unlock button. You must press the key fob unlock button twice to unlock the passenger’s doors. When All Doors is selected for 1st Press Of Key Fob Unlocks, all doors will unlock on the first press of the key fob unlock button.
Page 546 544 MULTIMEDIA Auto Comfort Systems — If Equipped After pressing the “Auto-On Comfort Systems” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat & Steering Wheel Remote Start All Starts With Vehicle Start — If Equipped NOTE: When this feature is selected the driver’s heated seat and heated steering wheel will automatically turn on when tem- peratures are below 40°...
Page 547 MULTIMEDIA Engine Off Options After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Doors On Engine Off Power Delay Doors Off Engine Off Power Delay Headlight Off Delay Audio After pressing the “Audio”...
Page 548 546 MULTIMEDIA Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and “–” setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the touchscreen.
Page 549 MULTIMEDIA Setting Name Selectable Options Paired Audio Sources List Of Paired Audio Sources NOTE: This feature shows which Audio Sources are paired to the Phone/Bluetooth system. For further information, refer to the Uconnect Owner’s Manual Supplement. SiriusXM Setup — If Equipped After pressing the “SiriusXM Setup”...
Page 550 548 MULTIMEDIA Setting Name Selectable Options Subscription Info Sirius ID NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.
Page 551 MULTIMEDIA Clear Personal Data After pressing the “Clear Personal Data” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Clear Personal Data Cancel NOTE: When this feature is selected it will remove all personal data including Bluetooth devices and presets.
Page 552 550 MULTIMEDIA System Information After pressing the “System Information” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Software Licenses Software Information Screen NOTE: When this feature is selected, a “Licensing Information” screen will appear, displaying a licensing information website for the radio.
Page 553: Off Road Pages - If Equipped
MULTIMEDIA OFF ROAD PAGES — IF EQUIPPED Your vehicle is equipped with Off Road Pages, which provides the vehicle status while operating on off road conditions. It supplies information relating to the vehicle ride height, the status of the transfer case, the pitch and roll of the vehicle (if equipped).
Page 554: Off Road Pages Status Bar
552 MULTIMEDIA Off Road Pages has the following selectable pages: • Drivetrain • Pitch and Roll • Accessory Gauge Off Road Pages Status Bar The Off Road Pages Status Bar is located along the bottom of Off Road Pages and is present in each of the three selectable page options.
Page 555: Drivetrain
MULTIMEDIA Drivetrain The Drivetrain page displays information concerning the vehicle’s drivetrain. The following information is displayed: • Steering angle in degrees • Status of Transfer Case • Status of the Rear Axles — If Equipped Drivetrain Menu 2WD/4WD 1 — Steering Angle 2 —...
Page 556: Pitch And Roll
554 MULTIMEDIA Pitch And Roll The Pitch And Roll page displays the vehicle’s current pitch (angle up and down) and roll (angle side to side) in degrees. The pitch and roll gauges provide a visualization of the current vehicle angle. Pitch And Roll Menu 2WD/4WD 1 —...
Page 557: Accessory Gauges
MULTIMEDIA Accessory Gauges The Accessory Gauges page displays the current status of the vehicle’s Coolant Temperature, Oil Temperature, Oil Pressure (Gas Vehicles Only), Transmission Temperature, and Battery Voltage. Accessory Gauges Menu 2WD/4WD 1 — Coolant Temperature 2 — Oil Temperature 3 —...
Page 558: Steering Wheel Audio Controls
556 MULTIMEDIA STEERING WHEEL AUDIO CONTROLS The right-hand control is a rocker-type switch with a push-button in the center and controls the volume and The remote sound system controls are located on the rear mode of the sound system. Pushing the top of the rocker surface of the steering wheel.
Page 559: Aux/Usb/Mp3 Control - If Equipped
MULTIMEDIA AUX/USB/MP3 CONTROL — IF EQUIPPED For example, if a device is plugged into the Type A USB port and another device is plugged into the Type C port, The Media Hub is located on the Instrument Panel, below connection to the Type A port will be lost. Alternatively, if the Climate Controls.
Page 560 558 MULTIMEDIA Media Hub Center Console USB 1 — AUX Port 2 — Type C USB Port 3 — Type A USB Port Located inside the center console, a second USB Port allows you to play music from iPod/MP3 players or USB devices through your vehicle’s sound system.
Page 561 MULTIMEDIA A third and fourth USB Ports are located behind the center console, above the Power Inverter. One is a charge only port, and can only charge USB devices. The other USB Port allows you to play music from iPod/MP3 players or USB devices through your vehicle’s sound system.
Page 562 560 MULTIMEDIA Phone Plugged In Message Screen Phone or USB Plugged In Message Screen NOTE: Plugging in a phone or another USB device may cause the connection to a previous device to be lost. WARNING! Do not plug in or remove the iPod or external device while driving.
Page 563: Radio Operation And Mobile Phones
MULTIMEDIA RADIO OPERATION AND MOBILE PHONES The radio manufacturer believes the internal wireless radio is safe for use by consumers. The level of energy emitted is Under certain conditions, the mobile phone being on in far less than the electromagnetic energy emitted by wire- your vehicle can cause erratic or noisy performance from less devices such as mobile phones.
Page 564: Uconnect Voice Recognition Quick Tips
562 MULTIMEDIA NOTE: UCONNECT VOICE RECOGNITION QUICK TIPS • This equipment has been tested and found to comply Introducing Uconnect with the limits for a Class B digital device, pursuant to Start using Uconnect Voice Recognition with these helpful Part 15 of the FCC Rules. These limits are designed to quick tips.
Page 565 MULTIMEDIA Uconnect 4 Uconnect 4/4C NAV If you see the NAV icon on the bottom bar, or in the Apps menus, of your 8.4-inch touchscreen, you have the Uconnect 4C NAV system. If not, you have a Uconnect 4 with 8.4-inch display system.
Page 566: Get Started
564 MULTIMEDIA Get Started All you need to control your Uconnect system with your voice are the buttons on your steering wheel. 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instruc- tions. 2. Reduce background noise. Wind and passenger conver- sations are examples of noise that may impact recogni- tion.
Page 567: Basic Voice Commands
MULTIMEDIA Basic Voice Commands TIP: At any time, if you are not sure of what to say or want to learn a Voice Command, push the VR button and say The basic Voice Commands below can be given at any “Help.”...
Page 568 566 MULTIMEDIA Uconnect 4 Radio Uconnect 4/4C NAV Radio...
Page 569: Media
MULTIMEDIA Media Uconnect offers connections via USB, Bluetooth and auxil- iary ports (If Equipped). Voice operation is only available for connected USB and AUX devices. Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
Page 570 568 MULTIMEDIA Uconnect 4 Media Uconnect 4/4C NAV Media...
Page 571: Phone
MULTIMEDIA Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system ready. Check UconnectPhone.com for mobile phone compatibility and pairing instructions. Push the Phone button . After the beep, say one of the following commands •...
Page 572 570 MULTIMEDIA Uconnect 4 Phone Uconnect 4/4C NAV Phone...
Page 573: Voice Text Reply
MULTIMEDIA Voice Text Reply TIP: Your mobile phone must have the full implementation of the Message Access Profile (MAP) to take advantage of Uconnect announces incoming text messages. Push the this feature. details about MAP, visit Phone button and say “ Listen.” (Must have compat- UconnectPhone.com.
Page 574: Climate
572 MULTIMEDIA TIP: Voice Text Reply is not compatible with iPhone, but if your vehicle is equipped with Siri Eyes Free, you can use your voice to send a text message. Climate Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead.
Page 575: Siriusxm Guardian (4C Nav) - If Equipped
MULTIMEDIA • For the Uconnect 4 System, say: “ Enter state.” SiriusXM Guardian (4C NAV) — If Equipped • For the 4C NAV Uconnect System, say: “ Find address CAUTION! 800 Chrysler Drive Auburn Hills, Michigan.” Some SiriusXM Guardian services, including SOS Call 2.
Page 576: Register (4C Nav)
574 MULTIMEDIA Send & Go 3. Select “Customer Care” to speak with a SiriusXM Guardian Customer Care agent who will activate ser- Vehicle Finder vices in your vehicle, or select “Enter Email” to activate Stolen Vehicle Assistance on the web. •...
Page 577: Mobile App (4C Nav)
MULTIMEDIA • Press the Location button on the navigation bar at the Mobile App (4C NAV) bottom of the app to bring up a map to locate your You’re only a few steps away from using remote com- vehicle or send a location to your vehicle’s navigation mands.
Page 578: Siri Eyes Free - If Equipped
576 MULTIMEDIA TIP: Traffic alerts are not accessible with Voice Command. designed to keep your eyes on the road and your hands on the wheel by letting Siri help you perform useful tasks. To enable Siri, push and hold, then release the Uconnect Voice Recognition (VR) button on the steering wheel.
Page 579: Android Auto - If Equipped
MULTIMEDIA Android Auto — If Equipped Android Auto allows you to use your voice to interact with Android’s best-in-class speech technology through your vehicle’s voice recognition system, and use your smart- phone’s data plan to project your Android powered smart- phone and a number of its apps onto your Uconnect touchscreen.
Page 580: Apple Carplay - If Equipped
578 MULTIMEDIA Apple CarPlay — If Equipped Apple CarPlay allows you to use your voice to interact with Siri through your vehicle’s voice recognition system, and use your smartphone’s data plan to project your iPhone and a number of its apps onto your Uconnect touchscreen.
Page 581 MULTIMEDIA Apple CarPlay On 7-inch Display Apple CarPlay On 8.4-inch Display Refer to your Uconnect Owner’s Manual Supplement for further information.
Page 582: General Information
580 MULTIMEDIA General Information Additional Information The following regulatory statement applies to all Radio © 2017 FCA US LLC. All rights reserved. Mopar and Frequency (RF) devices equipped in this vehicle: Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. Android is a This device complies with Part 15 of the FCC Rules and trademark of Google Inc.
Page 583: Cd/Dvd Disc Maintenance
MULTIMEDIA CD/DVD DISC MAINTENANCE To keep a CD/DVD in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge. 3.
Page 585 CUSTOMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or Speech SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ......584 Impaired (TDD/TTY) .
Page 586: Suggestions For Obtaining Service For Your Vehicle
584 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR IF YOU NEED ASSISTANCE YOUR VEHICLE The manufacturer and its authorized dealer are vitally interested in your satisfaction. We want you to be happy Prepare For The Appointment with our products and services. If you are having warranty work done, be sure to have the right papers with you.
Page 587: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE 585 Any communication to the manufacturer’s customer center In Mexico Contact should include the following information: Av. Prolongacion Paseo de la Reforma, 1240 • Owner’s name and address Sante Fe C.P. 05109 • Owner’s telephone number (home and office) Mexico, D.
Page 588: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
586 CUSTOMER ASSISTANCE Customer Assistance For The Hearing Or Speech questions about the service contract, call the manufactur- Impaired (TDD/TTY) er’s Service Contract National Customer Hotline at 1-800- 521-9922 (Canadian residents, call (800) 465-2001 English / To assist customers who have hearing difficulties, the (800) 387-9983 French).
Page 589: Warranty Information
CUSTOMER ASSISTANCE 587 REPORTING SAFETY DEFECTS WARNING! In The 50 United States And Washington, D.C. Engine exhaust (internal combustion engines only), If you believe that your vehicle has a defect that could some of its constituents, and certain vehicle compo- cause a crash or cause injury or death, you should nents contain, or emit, chemicals known to the State of immediately inform the National Highway Traffic...
Page 590: In Canada
588 CUSTOMER ASSISTANCE In Canada Diagnostic Procedure Manuals If you believe that your vehicle has a safety defect, you Diagnostic Procedure Manuals are filled with diagrams, should contact the Customer Service Department imme- charts and detailed illustrations. These practical manuals diately.
Page 591 INDEX...
Page 592 590 INDEX Adding Engine Coolant (Antifreeze) ... . .442 Alarm Adding Fuel ......344 Arm The System .
Page 593 INDEX 591 Axle Fluid .......500 Caps, Filler Axle Lock ....... .323 Fuel .
Page 594 592 INDEX Infants And Child Restraints ....266 Drain, Flush, And Refill ....441 LATCH Positions .
Page 595 INDEX 593 Door Frame Installation ..... .100 Emission Control System Maintenance... .200 Door Frame Removal .
Page 596 594 INDEX Exhaust Gas Caution .....286, 495 Fog Light Service......383 Exhaust System .
Page 597 INDEX 595 Fueling........344 Head Restraints ......54 Fuses .
Page 598 596 INDEX Inverter, Power ......169 Lights........289 Air Bag .
Page 599 INDEX 597 Seat Belt Reminder ..... . .191 Lug Nuts ....... .490 Security Alarm .
Page 600 598 INDEX Monitor, Tire Pressure System....225 Opener, Garage Door (HomeLink)....157 Mopar Parts .
Page 601 INDEX 599 Pretensioners Remote Keyless Entry Seat Belts ......240 Arm The Alarm ......30 Disarm The Alarm .
Page 602 600 INDEX Safety Information, Tire ..... .450 Pretensioners ......240 Safety Tips .
Page 603 INDEX 601 Automatic Transmission ....306, 308 Speed Control Manual Transmission ..... .302 Accel/Decel .
Page 604 602 INDEX Stuck, Freeing ......407 Jacking ......393, 398, 450 Sun Roof .
Page 605 INDEX 603 Trac-Lok Rear Axle ......322 Uconnect Traction Control ......208 Customer Programmable Features .
Page 606 604 INDEX Wind Buffeting......85, 146 Window Fogging ......82 Windows Power .
Page 607 INSTALLATION OF RADIO TRANSMITTING The antenna cable should be as short as practical and EQUIPMENT routed away from the vehicle wiring when possible. Use Special design considerations are incorporated into this only fully shielded coaxial cable. vehicle’s electronic system to provide immunity to radio Carefully match the antenna and cable to the radio to frequency signals.
Page 608 18JL-126-AA ©2017 FCA US LLC. All Rights Reserved. First Edition Jeep is a registered trademark of FCA US LLC. Printed in the U.S.A.
