Summary of Contents for Jeep Wrangler 2020

Page 1 Wrangler 2 0 2 0 O W N E R ’ S M A N U A L...
Page 2 This manual illustrates and describes the operation VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name of features and equipment that are either standard or optional on this vehicle. This manual may also include FCA US LLC shall be deemed to be deleted and the a description of features and equipment that are no name FCA Canada Inc.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ....................................13 GETTING TO KNOW YOUR VEHICLE ............................16 GETTING TO KNOW YOUR INSTRUMENT PANEL ......................201 SAFETY ......................................... 233 STARTING AND OPERATING ..............................326 IN CASE OF EMERGENCY ................................430 SERVICING AND MAINTENANCE .............................472 TECHNICAL SPECIFICATIONS ..............................550 MULTIMEDIA ....................................562 CUSTOMER ASSISTANCE ................................637 INDEX ........................................642...
Page 4 INTRODUCTION To Exit Remote Start Mode Without Driving The  Vehicle ................28  INTRODUCTION ..............13 To Exit Remote Start Mode And Drive The Vehicle ..28   ROLLOVER WARNING ...........14 Remote Start Comfort Systems — If Equipped ..28  ...
Page 5  SEATS ..................48  EXTERIOR LIGHTS ............68 Manual Front Seats............48 Headlight Switch ............68   Heated Seats — If Equipped........51 Daytime Running Lights — If Equipped ....68   Front Passenger Easy Entry Seat — Two Door High/Low Beam Switch ..........69 ...
Page 6  DUAL TOP FOUR DOOR MODELS —  POWER SLIDING TOP — IF EQUIPPED ....167 IF EQUIPPED ..............95 Opening The Power Top..........168  Removing The Soft Top — Four Door Models ..96 Closing The Power Top ..........169   Installing The Soft Top — Four Door Models ...99 Wind Buffeting ............169 ...
Page 7  INTERNAL EQUIPMENT ..........190  WARNING LIGHTS AND MESSAGES......217 Storage................190 Red Warning Lights ............217   Cupholders ..............192 Yellow Warning Lights ..........222   Electrical Power Outlets .........194 Yellow Indicator Lights ..........226   Power Inverter — If Equipped .........196 Green Indicator Lights ..........227 ...
Page 8  OCCUPANT RESTRAINT SYSTEMS ......265  ENGINE BREAK-IN RECOMMENDATIONS .....332 Occupant Restraint Systems Features .....265  PARKING BRAKE ............333  Important Safety Precautions ........266  MANUAL TRANSMISSION — IF EQUIPPED ..335  Seat Belt Systems ............267 Shifting ................336   Supplemental Restraint Systems (SRS) ....277 Downshifting..............337 ...
Page 9  STOP/START SYSTEM — MANUAL TRANSMISSION To Turn Off..............377  (IF EQUIPPED) ..............364 To Resume ..............377  Automatic Mode............365 To Vary The Speed Setting ........377   Possible Reasons The Engine Does Not Autostop..366 Setting The Following Distance In ACC ....379 ...
Page 10 IN CASE OF EMERGENCY  REFUELING THE VEHICLE ..........403 Fuel Filler Cap ............403   HAZARD WARNING FLASHERS .......430 Loose Fuel Filler Cap Message .........404   ASSIST AND SOS SYSTEM — IF EQUIPPED .....430  VEHICLE LOADING ............405 General Information ............435 Certification Label ............405 ...
Page 11  FREEING A STUCK VEHICLE ........468 Engine Air Cleaner Filter .........487   TOWING A DISABLED VEHICLE ......469 Accessory Drive Belt Inspection ........489  Four Wheel Drive Models ..........470 Air Conditioner Maintenance ........490   Emergency Tow Hooks — If Equipped ....470 Body Lubrication ............494 ...
Page 12  DEPARTMENT OF TRANSPORTATION UNIFORM  FUEL REQUIREMENTS ..........553 TIRE QUALITY GRADES ..........533 2.0L Engine ..............553  Treadwear..............533 3.6L Engine ..............553   Traction Grades ............533 Reformulated Gasoline ..........554   Temperature Grades ........... 533 Materials Added To Fuel ..........554 ...
Page 13  UCONNECT SETTINGS..........564  UCONNECT VOICE RECOGNITION QUICK TIPS ..615 Customer Programmable Features — Introducing Uconnect ..........615   Uconnect 3 Settings ............565 Get Started ..............616  Customer Programmable Features — Basic Voice Commands..........617   Uconnect 4 Settings ............576 Radio................617 ...
Page 14 CUSTOMER ASSISTANCE Puerto Rico And US Virgin Islands ......638  Customer Assistance For The Hearing Or Speech   SUGGESTIONS FOR OBTAINING SERVICE Impaired (TDD/TTY) ..........639 FOR YOUR VEHICLE .............637 Service Contract ............639  Prepare For The Appointment ........637  WARRANTY INFORMATION ........640 ...
Page 15: Introduction
INTRODUCTION operate this vehicle correctly may result in loss of control or INTRODUCTION a collision. Refer to the “Driving Tips” in “Starting and Oper- Dear Customer, congratulations on selecting your new ating” for further information. vehicle. Be assured that it represents precision workman- This Owner's Manual has been prepared with the assistance ship, distinctive styling, and high quality.
Page 16: Rollover Warning
14 INTRODUCTION tion, that may or may not be applicable to your vehicle, will Failure to operate this vehicle safely may result in a collision, be identified with the wording “If Equipped”. All data rollover of the vehicle, and severe or fatal injury. Drive care- contained in this publication are intended to help you use fully.
Page 17: How To Use This Manual
INTRODUCTION HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against oper- Essential Information ating procedures that could result in a collision, bodily injury Consult the Table of Contents to determine which section and/or death. It also contains CAUTIONS against proce- contains the information you desire.
Page 18: Vehicle User Guide - If Equipped
GETTING TO KNOW YOUR VEHICLE VEHICLE USER GUIDE — IF EQUIPPED Access your Owner’s Information right through your Ucon- nect 4C or 4C NAV touchscreen system (if equipped). To access the Vehicle User Guide on your Uconnect Touch- screen: Press the Uconnect Apps button. From there, press the Vehicle User Guide icon on your touchscreen.
Page 19: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE Pre-Installed Features Features/Benefits • Your User Guide — Updated in real-time • Pre-installed on your Uconnect touchscreen radio • Touchscreen convenience • Enhanced search and browsing capability • Maintenance schedules and information • Robust NAV application (if equipped) •...
Page 20: Keys
18 GETTING TO KNOW YOUR VEHICLE KEYS WARNING! Push the Mechanical Key Release Button only with the Key Fob key fob facing away from your body, especially your eyes and objects that may be damaged, such as clothing. Your vehicle uses a keyless ignition system. The ignition system consists of a key fob with Keyless Go and a START/ STOP push button ignition system.
Page 21 GETTING TO KNOW YOUR VEHICLE The key fob allows you to lock or unlock the doors and swing In this situation, a back up method can be used to operate the gate from distances up to approximately 66 ft (20 m) by ignition switch.
Page 22 20 GETTING TO KNOW YOUR VEHICLE To Lock The Doors And Swing Gate Push and release the lock button on the key fob to lock all doors. The turn signals will flash, and the horn will chirp once to acknowledge the lock signal. Key Fob Battery Replacement NOTE: When a key fob battery is low, a warning will be indicated on...
Page 23 GETTING TO KNOW YOUR VEHICLE Programming Additional Key Fobs Programming the key fob may be performed by an autho- rized dealer. NOTE: Once a key fob is programmed to a vehicle, it cannot be repurposed and reprogrammed to another vehicle. Request For Additional Key Fobs NOTE: Only key fobs that are programmed to the vehicle electronics...
Page 24 22 GETTING TO KNOW YOUR VEHICLE NOTE: Le présent appareil est conforme aux CNR d`Innovation, Science and Economic Development applicables aux appar- • When having the Sentry Key Immobilizer System eils radio exempts de licence. L'exploitation est autorisée aux serviced, bring all vehicle keys with you to an authorized deux conditions suivantes: dealer.
Page 25: Ignition Switch
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH Keyless Enter-N-Go — Ignition This feature allows the driver to operate the ignition switch with the push of a button as long as the key fob is in the passenger compartment. The Keyless Push Button Ignition has several operating modes that are labeled and will illuminate when in position.
Page 26 24 GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) • Engine is not started. • Do not leave the key fob in or near the vehicle, or in a • Some electrical devices are available. location accessible to children, and do not leave the igni- tion of a vehicle equipped with Keyless Enter-N-Go in the ON/RUN mode.
Page 27: Vehicle On Message
GETTING TO KNOW YOUR VEHICLE Vehicle On Message WARNING! (Continued) • Allowing children to be in a vehicle unattended is When opening the driver's door when the ignition is in the ON/RUN mode (engine not running), a chime will sound to dangerous for a number of reasons.
Page 28: Remote Starting System - If Equipped
26 GETTING TO KNOW YOUR VEHICLE • With remote start, the engine will only run for 15 minutes REMOTE STARTING SYSTEM — IF EQUIPPED (timeout) unless the ignition key is placed in the ON/RUN This system uses the key fob to start the engine position.
Page 29: Remote Start Cancel Message - If Equipped
GETTING TO KNOW YOUR VEHICLE • Fuel level meets minimum requirement • Remote Start Cancelled — Time Expired • All removable doors must not be removed • Remote Start Disabled — Start Vehicle To Reset • Malfunction indicator light not illuminated The message will stay active until the ignition is placed in the ON/RUN position.
Page 30: To Exit Remote Start Mode Without Driving The
28 GETTING TO KNOW YOUR VEHICLE To Exit Remote Start Mode Without Driving The Remote Start Comfort Systems — If Equipped Vehicle When Remote Start is activated, the Climate Controls may activate the heated seats (if equipped) and heated steering Push and release the Remote Start button one time or allow wheel (if equipped) in temperatures below 40°F (4.4°C).
Page 31: Sentry Key
GETTING TO KNOW YOUR VEHICLE Le présent appareil est conforme aux CNR d`Innovation, SENTRY KEY Science and Economic Development applicables aux appar- The Sentry Key Immobilizer system prevents unauthorized eils radio exempts de licence. L'exploitation est autorisée aux vehicle operation by disabling the engine. The system does deux conditions suivantes: not need to be armed or activated.
Page 32: Replacement Keys
30 GETTING TO KNOW YOUR VEHICLE If the vehicle security light turns on during normal vehicle CAUTION! operation (vehicle running for longer than ten seconds), it • Always remove the key fobs from the vehicle and lock indicates that there is a fault in the electronics. Should this all doors when leaving the vehicle unattended.
Page 33: General Information
GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las siguientes dos General Information condiciones: The following regulatory statement applies to all Radio 1. es posible que este equipo o dispositivo no cause interfer- Frequency (RF) devices equipped in this vehicle: encia perjudicial y This device complies with Part 15 of the FCC Rules and with 2.
Page 34: To Arm The System
32 GETTING TO KNOW YOUR VEHICLE To Arm The System To Disarm The System Follow these steps to arm the vehicle security alarm: The vehicle security alarm can be disarmed using any of the following methods: 1. Make sure the vehicle’s ignition is cycled to the OFF posi- •...
Page 35: Rearming Of The System
GETTING TO KNOW YOUR VEHICLE If the vehicle security alarm is armed and the battery Manual Door Locks becomes disconnected, the vehicle security alarm will All doors are equipped with an interior rocker-type door remain armed when the battery is reconnected; the exterior lock lever.
Page 36: Power Door Locks - If Equipped
34 GETTING TO KNOW YOUR VEHICLE NOTE: Power Door Locks — If Equipped The mechanical flip key can be used to lock or unlock the The power door lock switch is located on each front door doors, swing gate, glove compartment, and console storage. panel.
Page 37: Keyless Enter-N-Go - Passive Entry
GETTING TO KNOW YOUR VEHICLE Keyless Enter-N-Go — Passive Entry (If Equipped) WARNING! • For personal security reasons and safety in a collision, The Passive Entry system is a feature that allows you to lock lock the vehicle doors when you drive, as well as when and unlock the vehicle’s door(s) and swing gate without you park and exit the vehicle.
Page 38 36 GETTING TO KNOW YOUR VEHICLE To Unlock From The Driver Side To Unlock From The Passenger Side With a valid Passive Entry key fob within 5 ft (1.5 m) of the With a valid Passive Entry key fob within 5 ft (1.5 m) of the driver's door handle, grab the front driver door handle to passenger door handle, grab the front passenger door handle unlock the driver's door automatically.
Page 39 GETTING TO KNOW YOUR VEHICLE • A lock request is made by the Passive Entry door handle To Lock The Vehicle’s Doors And Swing Gate while a door is open. With one of the vehicle’s Passive Entry key fob within 5 ft •...
Page 40 38 GETTING TO KNOW YOUR VEHICLE NOTE: handle to unlock the swing gate automatically, and pull the DO NOT grab the door handle, when pushing the door swing gate to open. handle lock button. This could unlock the door(s). NOTE: If “Unlock All Doors 1st Press”...
Page 41 GETTING TO KNOW YOUR VEHICLE To Lock The Swing Gate General Information With a valid Passive Entry key fob within 5 ft (1.5 m) of the The following regulatory statement applies to all Radio swing gate handle, pushing the Passive Entry lock button Frequency (RF) devices equipped in this vehicle: will lock the vehicle doors and the swing gate.
Page 42: Child-Protection Door Lock System - Rear Doors
40 GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las siguientes dos condiciones: 1. es posible que este equipo o dispositivo no cause interfer- encia perjudicial y 2. este equipo o dispositivo debe aceptar cualquier interfer- encia, incluyendo la que pueda causar su operación no deseada.
Page 43: Automatic Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE Front Door Removal WARNING! Avoid trapping anyone in a vehicle in a collision. WARNING! Remember that the rear doors can only be opened from Do not drive your vehicle on public roads with the doors the outside when the Child-Protection locks are engaged removed as you will lose the protection they can provide.
Page 44 42 GETTING TO KNOW YOUR VEHICLE 1. Roll down the glass window to prevent any damage. WARNING! • All occupants must wear seat belts during off-road 2. Remove the hinge pin screws from the upper and lower operation with doors removed. Refer to “Off-Road outside hinges (using a #T50 Torx head driver).
Page 45 GETTING TO KNOW YOUR VEHICLE 3. Remove the plastic wiring access door under the instru- 4. Pull up on the red locking tab to unlock the wiring ment panel by sliding the plastic panel along the door harness. frame toward the seats until the tabs are detached. Closed Wiring Harness Wiring Access Door 1 –...
Page 46 44 GETTING TO KNOW YOUR VEHICLE 5. Push and hold down the black security tab under the wiring harness, and lift the harness into the open position. Door Check (Detached) 8. With the door open, lift the door with the help of another Open Wiring Harness person, to clear the hinge pins from their hinges and remove the door.
Page 47: Rear Door Removal (Four-Door Models)
GETTING TO KNOW YOUR VEHICLE Rear Door Removal (Four-Door Models) WARNING! • All occupants must wear seat belts during off-road WARNING! operation with doors removed. Refer to “Off-Road Do not drive your vehicle on public roads with the doors Driving Tips” in “Starting And Operating” for further removed as you will lose the protection they can provide.
Page 48 46 GETTING TO KNOW YOUR VEHICLE 1. Roll down the glass window to prevent any damage. 3. Slide the front seat(s) fully forward. 2. Remove the hinge pin screws from the upper and lower 4. Pry open and remove the plastic wiring access door from outside hinges (using a #T50 Torx head driver).
Page 49 GETTING TO KNOW YOUR VEHICLE 5. Unplug the wiring connector. NOTE: Squeeze the tab on the base of the wiring harness. This will unlock the connector tab, allowing the wiring connector to be unplugged. Door Check (Attached) 7. With the door open, lift the door with the help of another person, to clear the hinge pins from their hinges and remove the door.
Page 50: Seats
48 GETTING TO KNOW YOUR VEHICLE SEATS Manual Front Seats Seats are a part of the Occupant Restraint System of the Front Seat Adjustment vehicle. The seat can be adjusted forward or rearward by using a bar located by the front of the seat cushion, near the floor. While WARNING! sitting in the seat, lift up on the bar located under the seat •...
Page 51 GETTING TO KNOW YOUR VEHICLE WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
Page 52 50 GETTING TO KNOW YOUR VEHICLE Front Seatback Recline WARNING! To recline the seat, pull on the recline strap and lean forward Do not ride with the seatback reclined so that the or backward, depending on the direction you would like the shoulder belt is no longer resting against your chest.
Page 53: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE • Push the heated seat button once to turn the HI setting on. Heated Seats — If Equipped • Push the heated seat button a second time to turn the The heated seats control buttons are located on the center MED setting on.
Page 54: Front Passenger Easy Entry Seat - Two Door Models
52 GETTING TO KNOW YOUR VEHICLE Vehicles Equipped With Remote Start Front Passenger Easy Entry Seat — Two Door Models On models that are equipped with remote start, the driver’s Pull upward on the easy entry lever located on the outboard seat can be programmed to come on during a remote start.
Page 55: 60/40 Split Folding Rear Seat - Four Door Models
GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! • The front passenger seats have a track memory, which • It is extremely dangerous to ride in a cargo area, inside returns the seat to its original position. or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or •...
Page 56: Fold And Tumble Rear Seat - Two Door Models
54 GETTING TO KNOW YOUR VEHICLE To fold the seat, lift upward on the large release lever and To Raise The Rear Seat slowly fold down the seatback. The head restraint will fold Raise the seatback and lock it into place. Then, raise the head automatically with the seat when this lever is pulled.
Page 57 GETTING TO KNOW YOUR VEHICLE Folding The Rear Seat Using The Retention Straps 1. Lift the seatback release lever and fold the seatback 1. There are two retention straps located on the back of the forward. rear seat and two corresponding wire loops located on the back of each B-Pillar.
Page 58 56 GETTING TO KNOW YOUR VEHICLE Removing The Rear Seat NOTE: Do not drive the vehicle without reattaching the rear seat 1. Push down on the release bar on each side, and pull the latches. seat out and away from the lower bracket. WARNING! •...
Page 59: Rear Seat Armrest - If Equipped
GETTING TO KNOW YOUR VEHICLE Rear Seat Armrest — If Equipped WARNING! Be certain that the seatback is securely locked into The center part of the rear seat can also be used as a rear position. If the seatback is not securely locked into armrest with cupholders.
Page 60: Front Head Restraints
58 GETTING TO KNOW YOUR VEHICLE Front Head Restraints To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button located on the base of the head restraint, and push downward on the head restraint. The release button does not need to be pushed to adjust the head restraint.
Page 61: Rear Head Restraints - Two Door Models
GETTING TO KNOW YOUR VEHICLE Rear Head Restraints — Two Door Models WARNING! • A loose head restraint thrown forward in a collision or The rear seat is equipped with non-adjustable, but foldable hard stop could cause serious injury or death to occu- head restraints.
Page 62 60 GETTING TO KNOW YOUR VEHICLE WARNING! • Do not drive the vehicle without the rear seat head restraints installed while passengers are occupying the rear seat. In a collision, people riding in this area without the head restraints installed are more likely to be seriously injured or killed.
Page 63: Rear Head Restraints - Four Door Models
GETTING TO KNOW YOUR VEHICLE Rear Head Restraints — Four Door Models The rear seat is equipped with nonadjustable, but foldable, outboard head restraints, as well as an adjustable, removable center head restraint. To fold the outboard head restraint, pull on the inner release lever, located on the upper part of the rear seat.
Page 64: Steering Wheel
62 GETTING TO KNOW YOUR VEHICLE To install the head restraint, hold the release button while STEERING WHEEL pushing downward on the head restraint. Refer to “Occu- Tilt/Telescoping Steering Column pant Restraint Systems” in “Safety” for information on child seat tether routing. This feature allows you to tilt the steering column upward or downward.
Page 65: Heated Steering Wheel - If Equipped
GETTING TO KNOW YOUR VEHICLE To unlock the steering column, push the control handle The heated steering wheel control button is located on the downward (toward the floor). To tilt the steering column, center of the instrument panel below the touchscreen and move the steering wheel upward or downward as desired.
Page 66: Mirrors
64 GETTING TO KNOW YOUR VEHICLE Headlight glare from vehicles behind you can be reduced by WARNING! moving the small control under the mirror to the night position • Persons who are unable to feel pain to the skin because (toward the rear of the vehicle).
Page 67: Automatic Dimming Mirror - If Equipped
GETTING TO KNOW YOUR VEHICLE Automatic Dimming Mirror — If Equipped The mirror head can be adjusted up, down, left, and right for various drivers. The mirror should be adjusted to center on the view through the rear window. The mirror automatically adjusts to headlight glare from vehicles behind you.
Page 68: Outside Mirrors
66 GETTING TO KNOW YOUR VEHICLE CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror.
Page 69: Power Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE Power Mirrors — If Equipped Heated Mirrors — If Equipped The power mirror controls are located on the door panel next These mirrors are heated to melt frost or ice. This to the door handle. feature will be activated whenever you turn on the rear window defroster (if equipped).
Page 70: Exterior Lights
68 GETTING TO KNOW YOUR VEHICLE Rotate the headlight switch clockwise to the first detent for EXTERIOR LIGHTS parking light and instrument panel light operation. Rotate Headlight Switch the headlight switch to the second detent for headlight, parking light, and instrument panel light operation. The headlight switch is located on the left side of the instru- ment panel.
Page 71: High/Low Beam Switch
GETTING TO KNOW YOUR VEHICLE High/Low Beam Switch Automatic High Beam — If Equipped Push the multifunction lever toward the instrument panel to The Automatic High Beam Headlamp Control system switch the headlights to high beams. The lever will return to provides increased forward lighting at night by automating the centered position.
Page 72: Flash-To-Pass
70 GETTING TO KNOW YOUR VEHICLE Flash-To-Pass Front Fog Lights — If Equipped You can signal another vehicle with your headlights by To activate the front fog lights, turn on the parking lights or lightly pulling the multifunction lever toward you. This will low beam headlights and push in the center of the headlight cause the high beam headlights to turn on, and remain on, switch control knob.
Page 73: Turn Signals
GETTING TO KNOW YOUR VEHICLE Turn Signals INTERIOR LIGHTS Move the multifunction lever up or down and the arrows on Courtesy Lights each side of the instrument cluster flash to show proper oper- The courtesy lights will turn on when the front doors are ation of the front and rear turn signal lights.
Page 74: Dimmer Controls
72 GETTING TO KNOW YOUR VEHICLE Dimmer Controls The dimmer controls are part of the headlight switch and are located on the left side of the instrument panel. Dome Lights When a door is open and the interior lights are on, rotating the dimmer control to the extreme bottom position will cause all the interior lights to turn off.
Page 75: Windshield Wipers And Washers
GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Windshield Wiper Operation The windshield wiper/washer control lever is located on the Rotate the end of the lever upward to the first detent past the right side of the steering column. The front wipers are oper- intermittent settings for low-speed wiper operation.
Page 76 74 GETTING TO KNOW YOUR VEHICLE CAUTION! In cold weather, always turn off the wiper switch and allow the wipers to return to the park position before turning off the engine. If the wiper switch is left on and the wipers freeze to the windshield, damage to the wiper motor may occur when the vehicle is restarted.
Page 77 GETTING TO KNOW YOUR VEHICLE Windshield Washers Mist Feature To use the washer, pull the lever toward you and hold while Push upward on the wiper lever to activate a single wipe to spray is desired. If the lever is pulled while in the delay clear off road mist or spray from a passing vehicle.
Page 78: Climate Controls
76 GETTING TO KNOW YOUR VEHICLE Rotate the switch upward to the first detent position Rear Window Wiper/Washer — If Equipped for intermittent operation and to the second detent A rotary switch on the center portion of the windshield for continuous rear wiper operation. wiper/washer lever controls the operation of the rear wiper/washer function.
Page 79: Manual Climate Control Overview
GETTING TO KNOW YOUR VEHICLE Manual Climate Control Overview Manual Climate Controls – Heater Only Manual Climate Controls...
Page 80 78 GETTING TO KNOW YOUR VEHICLE Manual Climate Control Descriptions Icon Description A/C Button — If Equipped Push the A/C button to engage the Air Conditioning (A/C). The A/C indicator illuminates when A/C is on. MAX A/C Setting — If Equipped Turn the temperature control knob to the MAX Air Conditioning (A/C) setting to engage MAX Air Conditioning (A/C).
Page 81 GETTING TO KNOW YOUR VEHICLE Icon Description Temperature Control Use the temperature control knob to regulate the temperature of the air inside the passenger compartment. Turning the knob counterclockwise, from top center into the blue area of the scale, indicates cooler temperatures. Turning the knob clockwise, into the red area, indicates warmer Heater Only temperatures.
Page 82 80 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed Bi-Level Mode through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 83: Automatic Climate Controls Overview
GETTING TO KNOW YOUR VEHICLE Automatic Climate Controls Overview Uconnect 4 With 7–inch Display Automatic Climate Controls...
Page 84 82 GETTING TO KNOW YOUR VEHICLE Uconnect 4C/4C NAV With 8.4–inch Display Automatic Climate Controls...
Page 85 GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Descriptions Icon Description MAX A/C Button Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output of air. The MAX A/C indicator illuminates when MAX A/C is on. Pressing the button again will cause the MAX A/C operation to exit.
Page 86 84 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate AUTO Button AUTO Button Press and release this button on the touchscreen, or push the button on the faceplate, to change the current setting. The AUTO indicator illuminates when AUTO is on. This feature automatically Touchscreen controls the airflow distribution and amount.
Page 87 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Defrost Button Press and release the button on the touchscreen, or push and release the button on the faceplate, to turn on the rear window defroster and the heated outside mirrors (if equipped). The Rear Defrost indicator illuminates when the rear window defroster is on.
Page 88 86 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate Blower Knob Blower Control Blower Control is used to regulate the amount of air forced through the climate system. There are seven blower speeds available. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen.
Page 89 GETTING TO KNOW YOUR VEHICLE Icon Description Panel Mode Panel Mode Air comes from the outlets in the instrument panel. Each of these outlets can be individually adjusted to direct the flow of air. The air vanes of the center outlets and outboard outlets can be moved up and down or side to side to regulate airflow direction.
Page 90 88 GETTING TO KNOW YOUR VEHICLE Icon Description Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.
Page 91: Climate Control Functions
GETTING TO KNOW YOUR VEHICLE MAX A/C Climate Control Functions MAX A/C sets the control for maximum cooling perfor- A/C (Air Conditioning) mance. The Air Conditioning (A/C) button allows the operator to manually activate or deactivate the air conditioning system. Press and release to toggle between MAX A/C and the prior settings.
Page 92: Automatic Temperature Control (Atc) - If Equipped
90 GETTING TO KNOW YOUR VEHICLE • The temperature can be displayed in US or Metric units by Automatic Temperature Control (ATC) — If Equipped selecting the US/Metric customer-programmable feature. Automatic Operation Refer to the “Uconnect Settings” in “Multimedia” for further information.
Page 93 GETTING TO KNOW YOUR VEHICLE Summer Operation Window Fogging The engine cooling system must be protected with a Vehicle windows tend to fog on the inside in mild, rainy, high-quality antifreeze coolant to provide proper corrosion and/or humid weather. To clear the windows, select Defrost protection and to protect against engine overheating.
Page 94 92 GETTING TO KNOW YOUR VEHICLE Outside Air Intake Operating Tips Chart Make sure the air intake, located directly in front of the wind- WEATHER CONTROL SETTINGS shield, is free of obstructions, such as leaves. Leaves collected Set the mode control to in the air intake may reduce airflow, and if they enter the plenum, they could plug the water drains.
Page 95: Power Windows - If Equipped
GETTING TO KNOW YOUR VEHICLE POWER WINDOWS — IF EQUIPPED The power window switches are located on the instrument panel below the climate controls. Push the switch downward to open the window and upward to close the window. The top left switch controls the left front window and the top right switch controls the right front window.
Page 96: Auto-Down Feature
94 GETTING TO KNOW YOUR VEHICLE Four-Door Models To stop the window from going all the way down during the Auto-Down operation, pull up on the switch briefly. The lower left switch controls the left rear passenger window, and the lower right switch controls the right rear WARNING! passenger window.
Page 97: Dual Top Four Door Models - If Equipped
GETTING TO KNOW YOUR VEHICLE DUAL TOP FOUR DOOR MODELS — IF EQUIPPED If your vehicle is equipped with a Dual Top, the soft top system will be provided in a separate box located in the rear of the vehicle for shipping purposes only. The soft top and the hard top are to be used independently.
Page 98: Removing The Soft Top - Four Door Models
96 GETTING TO KNOW YOUR VEHICLE Removing The Soft Top — Four Door Models 1. Fully lower the soft top. Refer to “Soft Top — Four Door Models” in this section. CAUTION! Failure to follow the next steps could result in damage to the Soft Top or vehicle.
Page 99 GETTING TO KNOW YOUR VEHICLE 3. Using the provided #40 Torx head driver and ratchet, 4. Pull the release lever on top of the rail rearward to release unscrew the two Torx head screws on each lift assist the side link from the track. mechanism, then lift the mechanism up and away from the vehicle.
Page 100 98 GETTING TO KNOW YOUR VEHICLE 6. Utilizing two people, lift the soft top up and away from the vehicle, careful to avoid the vehicle’s sport bar, trim, and tire carrier. Store the soft top in a safe, clean, and dry location. Pull To Release Top From Track 5.
Page 101: Installing The Soft Top - Four Door Models
GETTING TO KNOW YOUR VEHICLE 7. Using the provided #50 Torx head driver and ratchet, Installing The Soft Top — Four Door Models unscrew the Torx screw on both rear corners of the NOTE: vehicle, removing the retainers. The following procedures are for first time set up only. For future soft top procedures, refer to “Soft Top”...
Page 102 100 GETTING TO KNOW YOUR VEHICLE 4. Install the rear retainers on each side of the rear of the CAUTION! vehicle using the provided #50 Torx head driver and Do not over tighten Torx screws. Damage to the retainers ratchet. Refer to the table below for recommended torque will occur.
Page 103 GETTING TO KNOW YOUR VEHICLE 5. Making sure the lift assist mechanism is in the “lock” position, lift the soft top into the rear of the vehicle with the side links pointing toward the front. Lower the lift assist mechanisms onto its retainers on both sides (on the inside of the sport bar).
Page 104 102 GETTING TO KNOW YOUR VEHICLE 6. Using the provided #40 Torx head driver and ratchet, Torque tighten the Torx screws by turning them clockwise. Specification For Maximum Minimum Secure them until they are snug (refer to the table below Torx Screws for recommended torque specifications), being careful 119.5 in-lbs...
Page 105: Freedom Top Three-Piece Modular Hard
GETTING TO KNOW YOUR VEHICLE FREEDOM TOP THREE-PIECE MODULAR HARD TOP — IF EQUIPPED CAUTION! • The hard top is not designed to carry any additional loads, such as after-market roof racks, spare tires, building materials, hunting or camping supplies, etc. For optional Mopar accessory roof racks, refer to the Roof Luggage Rack portion of this Owner’s Manual for additional information.
Page 106: Front Panel(S) Removal
104 GETTING TO KNOW YOUR VEHICLE CAUTION! (Continued) • Careless handling and storage of the removable roof panels may damage the seals, causing water to leak into the vehicle’s interior. • The front panel(s) must be positioned properly to ensure sealing. Improper installation can cause water to leak into the vehicle’s interior.
Page 107: Freedom Top Storage Bag
GETTING TO KNOW YOUR VEHICLE Lay the bag for the Freedom Top panels down so the loops and hooks are facing upward. Unzip the bag and fold back the outer flap. NOTE: Ensure the front Freedom Top panel latch is closed prior to inserting the panel into the Freedom Top bag.
Page 108 106 GETTING TO KNOW YOUR VEHICLE 2. Unfold the black panel divider (ensure the divider is laying flat). Right Panel — Latches Facing Downward NOTE: Fold Divider Over Left Panel Ensure the front Freedom Top panel latch is closed prior to inserting the panel into the bag.
Page 109: Front Panel(S) Installation
GETTING TO KNOW YOUR VEHICLE 4. Unfold the outer flap and zip the Freedom Top bag closed. Front Panel(s) Installation 1. Set the right side panel on the windshield frame with the locating pin in the front receiver mounting hole followed by the left side panel, making sure there is no overhang.
Page 110 108 GETTING TO KNOW YOUR VEHICLE 3. Using the provided #50 Torx head driver and ratchet, 4. Remove the six Torx head screws that secure the hard top remove the two Torx head screws that secure the hard top to the vehicle (along the interior bodyside — three screws at the B-Pillar (near the top of the front doors).
Page 111 GETTING TO KNOW YOUR VEHICLE 5. Open the swing gate all the way to ensure clearance of the 6. Locate the wire harness and washer hose on the left rear rear window glass. Lift the rear window glass. inside corner of the vehicle. Step Five Wire Harness...
Page 112 110 GETTING TO KNOW YOUR VEHICLE 7. Release the locking tab by pushing it downward. 8. To remove the wiring harness, push the tab inward while pulling downward to disconnect. Push Locking Tab Downward Push Tab Inward...
Page 113 GETTING TO KNOW YOUR VEHICLE Pull Wiring Harness To Separate Release Button On Hose 9. To remove the washer hose, push the release button on 10. Lower the rear window, and close the swing gate. hose connector, and pull downward. 11.
Page 114: Rear Hard Top Installation
112 GETTING TO KNOW YOUR VEHICLE Rear Hard Top Installation DOOR FRAME NOTE: WARNING! If the door frames are installed from soft top usage, they • Do not drive your vehicle on public roads with the door must be removed prior to installation of the hard top. Refer frame(s) removed as you will lose the protection that to “Door Frame”...
Page 115: Door Frame Removal
GETTING TO KNOW YOUR VEHICLE 2. Once all the way loosened, remove the screws by pulling Door Frame Removal downward. NOTE: In four door models, the rear door frames must be removed NOTE: first, followed by the front door frames. Screws will not fall out once completely loose, as they are held in place by an internal mechanism.
Page 116: Door Frame Installation Four Door Models - If
114 GETTING TO KNOW YOUR VEHICLE 3. Lift the frame upward, removing it from the vehicle. WARNING! • Do not drive your vehicle on public roads with the door frame(s) removed as you will lose the protection that they can provide. This procedure is furnished for use during off-road operation only.
Page 117 GETTING TO KNOW YOUR VEHICLE 3. Swing the frame bracket around the side of the rail, and Torque insert the screws from underneath. Tighten with #40 Torx Specification For Maximum Minimum head driver until they are snug, being careful not to Torx Screws cross-thread the screws or overtighten.
Page 118 116 GETTING TO KNOW YOUR VEHICLE 4. Set the rear door frame pin into the hole on top of the body side, just behind the rear door opening. Position Of Frame Above Door 1 — Front Door Rail 2 — Rear Door Frame Step Four 6.
Page 119: Door Frame Installation Two Door Models - If Equipped
GETTING TO KNOW YOUR VEHICLE Step Six Step Two Torque Door Frame Installation Two Door Models — If Equipped Specification For Maximum Minimum 1. Carefully place the front door rail in the rubber seal at the Torx Screws top of the windshield, and line up the holes for the Torx 8.8 in-lbs 11.0 in-lbs 6.6 in-lbs...
Page 120: Soft Top Two Door Models - If Equipped
118 GETTING TO KNOW YOUR VEHICLE SOFT TOP TWO DOOR MODELS — IF EQUIPPED CAUTION! The soft top is not designed to carry any additional loads WARNING! such as roof racks, spare tires, building, hunting, or • Do not drive the vehicle with the rear window up/ camping supplies, and/or luggage, etc.
Page 121 GETTING TO KNOW YOUR VEHICLE CAUTION! CAUTION! (Continued) • Do not run a fabric top through an automatic car wash. Failure to follow these cautions may cause interior water Window scratches and wax build up may result. damage, stains or mildew on the top material: •...
Page 122: Lowering The Soft Top
120 GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top Side View Top And Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Rear Quarter Window 3 — #3 Bow 8 — Lower Window Retainer 4 —...
Page 123 GETTING TO KNOW YOUR VEHICLE Rear View Top And Components 1 — Rear Window Retainer Attachment Points 2 — Quarter Window Pillars 3 — Swing Gate Bar Retainers...
Page 124 122 GETTING TO KNOW YOUR VEHICLE NOTE: The rear window and rear quarter windows must be removed before lowering the soft top to prevent damage to the top. Clean the side and rear windows before removal to assist in preventing scratching during removal of the soft top.
Page 125 GETTING TO KNOW YOUR VEHICLE 2. Grasp the swing gate bar, rotate it outward and upward 3. While holding the window in place, slide the tailgate bar releasing it from both the right and left retainers. Store in to the left separating it from the rear window. Store a safe location.
Page 126 124 GETTING TO KNOW YOUR VEHICLE 4. Remove the plastic retainers from both quarter window 5. While keeping the rear window level, slide to the left until it is completely separate from its retainer. Do not pillars. pull downward while removing the rear window. Damage to the retainer could result.
Page 127 GETTING TO KNOW YOUR VEHICLE Remove The Right And Left Quarter Windows: 2. Undo the hook-and-loop fastener located at the upper front corner of each quarter window. 1. Through the rear opening, push the bottom corner outward and release tab from the bottom of the window pillar.
Page 128 126 GETTING TO KNOW YOUR VEHICLE 3. Starting at the rear of the vehicle, remove plastic retainer 4. Remove plastic retainer from bottom to top of the from along the bottom of the window moving toward the window. front of the vehicle. Step Four Step Three...
Page 129 GETTING TO KNOW YOUR VEHICLE 5. While keeping the window level, slide rearward until it is Lowering The Soft Top Into Sunrider® Position completely separate from its retainer. Do not pull down- 1. After removing the rear window and quarter panel ward while removing the window.
Page 130 128 GETTING TO KNOW YOUR VEHICLE 4. From both the left and right sides, lift up on the #1 Bow 5. Move to the side of the vehicle and use the side link to of the soft top to start the operation. fold the soft top rearward into the Sunrider®...
Page 131 GETTING TO KNOW YOUR VEHICLE NOTE: Lowering The Soft Top Into Fully Lowered Position If leaving the soft top in the Sunrider® position, secure the 1. From the Sunrider® position, remove straps if previously top by using the two hook-and-loop fasteners provided in secured and move to the rear of the vehicle.
Page 132 130 GETTING TO KNOW YOUR VEHICLE 3. Pull the latch downward to release the top, and allow the 4. While pushing downward slightly on the folded soft top, soft top to slide rearward freely in the guide tracks to the slide the lock lever on the left and right side lift assist stowed position.
Page 133 GETTING TO KNOW YOUR VEHICLE NOTE: Secure the top by using the two hook-and-loop fasteners provided in the center console. Lock Position 5. Once the lock lever is in the “lock” position, push down- ward on each side of the folded soft top to ensure it is secure.
Page 134: Soft Top Window Storage Bag
132 GETTING TO KNOW YOUR VEHICLE Soft Top Window Storage Bag To safely store the soft top rear window, and rear quarter windows, proceed as follows: NOTE: The swing gate bar, once removed from the rear window, does not store in the soft window storage bag. 1.
Page 135 GETTING TO KNOW YOUR VEHICLE 2. Fold the first divider upward, covering the first quarter window. Step One 1 — Quarter Window Facing Downward 2 — Both Dividers Folded Down Step Two...
Page 136 134 GETTING TO KNOW YOUR VEHICLE 3. Lay the second quarter window on top of the first divider 4. Fold the second divider upward, covering the second all the way to the left side with the inside of the window quarter window.
Page 137 GETTING TO KNOW YOUR VEHICLE 5. Lay the rear window on top of the second divider. 6. Close the storage bag and store in a safe location. Step Five Step Six...
Page 138: Raising The Soft Top
136 GETTING TO KNOW YOUR VEHICLE Raising The Soft Top Raising The Soft Top From The Fully Lowered Position 1. From the fully lowered position, remove straps if previ- ously secured. CAUTION! Failure to follow the next steps could result in damage to the Soft Top or vehicle.
Page 139 GETTING TO KNOW YOUR VEHICLE Unlocked Position Step Three 3. Push up and forward from the #5 Bow along the guide 4. Gently pull rearward on the #6 Bow to ensure the top is track until it locks into the Sunrider® position with an locked in the Sunrider®...
Page 140 138 GETTING TO KNOW YOUR VEHICLE 5. Using the side link, lift and push the soft top toward the front of the vehicle guiding the top into the closed position. Lower Top Into Closed Position Side Link Location...
Page 141 GETTING TO KNOW YOUR VEHICLE 6. From inside the vehicle, pull the handle on the header 7. Pull the handle back upward while squeezing the latch latch downward to engage the hook into its receiver. plate, locking the latch into place. Repeat on the other side.
Page 142 140 GETTING TO KNOW YOUR VEHICLE Install The Right And Left Quarter Windows 2. Place the top of the quarter window pillar into the top cover, and insert the bottom tab into the clip. 1. From the rear of the vehicle, guide the top of the window into the retainer and slide forward while keeping the window level.
Page 143 GETTING TO KNOW YOUR VEHICLE Step Two Fully Engage Quarter Window Retainers 1 — Retainer At Front Of Quarter Window CAUTION! 2 — Retainer At Bottom Of Quarter Window Failure to follow all Quarter Window Install steps could NOTE: result in damage to the Soft Top or vehicle. It is critical that the retainers are fully engaged before the 3.
Page 144 142 GETTING TO KNOW YOUR VEHICLE 4. Tuck Flap 1 between Flap 2 and Flap 3 on the Soft Top 5. Secure the hook-and-loop fastener at the upper front Cover. corner of each quarter window by pressing firmly. Flaps On Soft Top Cover Firmly Secure Hook-And-Loop Fastener 1 —...
Page 145 GETTING TO KNOW YOUR VEHICLE Install The Rear Window 2. Insert the tailgate bar into the retainers at the bottom of the window from left to the right. 1. Guide the rear window into the retainer from left to right while keeping the window level.
Page 146 144 GETTING TO KNOW YOUR VEHICLE 3. Rotate the swing gate bar into the left and right side 5. Repeat with the left side quarter window. retainers. Step Five Step Three 4. Line up the rear window to the right side quarter window first, and engage the plastic retainers.
Page 147: Soft Top Four Door Models - If Equipped
GETTING TO KNOW YOUR VEHICLE 6. Engage the rear window retainers in the lower right and SOFT TOP FOUR DOOR MODELS — IF EQUIPPED left corners. WARNING! • Do not drive the vehicle with the rear window up/ removed unless the quarter windows are also removed. Dangerous exhaust gases could enter the vehicle causing harm to the driver and passengers.
Page 148 146 GETTING TO KNOW YOUR VEHICLE If the temperature is below 72°F (24°C) and/or the top has CAUTION! (Continued) been folded down for a period of time, the top will appear to • Refer to “Appearance Care For Fabric Top Models” in have shrunk when you raise it, making it difficult to put up.
Page 149: Lowering The Soft Top
GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top Side View Top And Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Rear Quarter Window 3 — #3 Bow 8 — Lower Window Retainer 4 —...
Page 150 148 GETTING TO KNOW YOUR VEHICLE Rear View Top And Components 1 — Rear Window Retainer Attachment Points 2 — Quarter Window Pillars 3 — Swing Gate Bar Retainers...
Page 151 GETTING TO KNOW YOUR VEHICLE NOTE: Remove The Rear Window: The rear window and rear quarter windows must be 1. With the swing gate open, remove the rear window’s removed before lowering the soft top to prevent damage to plastic retainers from the lower right and left corners. the top.
Page 152 150 GETTING TO KNOW YOUR VEHICLE 2. Grasp the swing gate bar, rotate it outward and upward 3. While holding the window in place, slide the tailgate bar releasing it from both the right and left retainers. to the left separating it from the rear window. Store in soft window bag, or a safe location.
Page 153 GETTING TO KNOW YOUR VEHICLE 4. Remove the plastic retainers from both quarter window 5. While keeping the rear window level, slide to the left until it is completely separate from its retainer. Do not pillars. pull downward while removing the rear window. Damage to the retainer could result.
Page 154 152 GETTING TO KNOW YOUR VEHICLE Remove The Right And Left Quarter Windows: 2. Undo the hook-and-loop fastener located at the upper front corner of each quarter window. 1. Through the rear opening, push the bottom corner outward and release tab from the bottom of the window pillar.
Page 155 GETTING TO KNOW YOUR VEHICLE 3. Starting at the rear of the vehicle, remove plastic retainer 4. Remove plastic retainer from the bottom to the top of the from along the bottom of the window moving toward the front window. front of the vehicle.
Page 156 154 GETTING TO KNOW YOUR VEHICLE 5. While keeping the window level, slide rearward until it is Lowering The Soft Top Into Sunrider® Position completely separate from its retainer. Do not pull down- 1. After removing the rear window and quarter panel ward while removing the window.
Page 157 GETTING TO KNOW YOUR VEHICLE 4. From both the left and right sides, lift up on the #1 Bow 5. Move to the side of the vehicle and use the side link to of the soft top to start the operation. fold the soft top rearward into the Sunrider®...
Page 158 156 GETTING TO KNOW YOUR VEHICLE NOTE: Lowering The Soft Top Into Fully Lowered Position If leaving the soft top in the Sunrider® position, secure the 1. From the Sunrider® position, remove straps if previously top by using the two hook-and-loop fasteners provided in secured and move to the rear of the vehicle.
Page 159 GETTING TO KNOW YOUR VEHICLE 3. Pull the latch to release the top, and allow the soft top to 4. While pushing downward slightly on the folded soft top, slide rearward freely in the guide tracks to the stowed slide the lock lever on the left and right side lift assist position.
Page 160: Raising The Soft Top
158 GETTING TO KNOW YOUR VEHICLE 5. Once the lock lever is in the “lock” position, push down- NOTE: ward on each side of the folded soft top to ensure it is Secure the top by using the two hook-and-loop fasteners secure.
Page 161 GETTING TO KNOW YOUR VEHICLE 3. Push up and forward from the #5 Bow along the guide CAUTION! track until it locks into the Sunrider® position with an Failure to follow the next steps could result in damage to audible “click”. the Soft Top or vehicle.
Page 162 160 GETTING TO KNOW YOUR VEHICLE 4. Gently pull rearward on the #6 Bow to ensure the top is locked in the Sunrider® position. 5. Using the side link, lift and push the soft top toward the front of the vehicle manually guiding the top into the closed position.
Page 163 GETTING TO KNOW YOUR VEHICLE 6. From inside the vehicle, pull the handle on the header 7. Pull the handle back upward while squeezing the hook, latch downward to engage the hook into its receiver. locking the latch into place. Repeat on the other side.
Page 164 162 GETTING TO KNOW YOUR VEHICLE Install The Right And Left Quarter Windows 2. Place the top of the quarter window pillar into the top cover, and insert the bottom tab into the clip. 1. From the rear of the vehicle, guide the top of the window into the retainer and slide forward while keeping the window level.
Page 165 GETTING TO KNOW YOUR VEHICLE 3. Engage the retainers on the front of the windows, ensuring they are fully engaged, followed by the retainers along the bottom of the windows. Step Two CAUTION! Failure to follow all Quarter Window Install steps could Fully Engage Quarter Window Retainers result in damage to the Soft Top or vehicle.
Page 166 164 GETTING TO KNOW YOUR VEHICLE NOTE: Install The Rear Window It is critical that the retainers are fully engaged before the 1. Guide the rear window into the retainer from left to right vehicle resumes motion. while keeping the window level. 4.
Page 167 GETTING TO KNOW YOUR VEHICLE 2. Insert the tailgate bar into the retainers at the bottom of 3. Rotate the swing gate bar into the left and right side the window from left to the right. retainers. Step Two Step Three 4.
Page 168 166 GETTING TO KNOW YOUR VEHICLE 5. Repeat with the left side quarter window. 6. Engage the rear window retainers in the lower right and left corners. Step Five Step Six NOTE: For information on removing your soft top, refer to “Removing The Soft Top —...
Page 169: Power Sliding Top - If Equipped
GETTING TO KNOW YOUR VEHICLE POWER SLIDING TOP — IF EQUIPPED CAUTION! Lowering of the windshield is NOT recommended in vehicles equipped with a Power Sliding Top. Damage will occur to the top as well as the header seal. If your vehicle is equipped with a Power Sliding Top, the control switch can be found on the front trim panel, to the right of the driver’s side sun visor.
Page 170: Opening The Power Top
168 GETTING TO KNOW YOUR VEHICLE • The Power Top will not open in temperatures below -4°F WARNING! (Continued) (-20°C). However, if it is opened at a higher temperature, it • In a collision, there is a greater risk of being thrown from a can be closed at temperatures above -40°F (-40°C).
Page 171: Closing The Power Top
GETTING TO KNOW YOUR VEHICLE If the buffeting occurs with the power top open, adjust the Closing The Power Top power top opening to minimize the buffeting or open any Express Mode window. Push the close switch and release it within one-half second. Pinch Protect Feature The power top will close fully and stop automatically.
Page 172: Power Top Maintenance
170 GETTING TO KNOW YOUR VEHICLE Power Top Maintenance Relearn Procedure Use only a non-abrasive cleaner and a soft cloth to clean the For vehicles equipped with a power top, there is a relearn quarter window glass panel. procedure that allows you to calibrate the power top when the “Express Mode”...
Page 173: Rear Quarter Window Removal
GETTING TO KNOW YOUR VEHICLE NOTE: If the close button is released anytime during the relearning process, the relearn may not be complete, and the procedure must be repeated. Rear Quarter Window Removal On vehicles equipped with a Power Sliding Top, the rear quarter windows can be removed.
Page 174 172 GETTING TO KNOW YOUR VEHICLE 6. From the outside of the vehicle, lift each window upward and away from the vehicle. NOTE: Do not pull down or apply any weight to the windows after the latches are released. Damage could result to the pins holding the windows in place.
Page 175 GETTING TO KNOW YOUR VEHICLE Quarter Window Storage Bag 2. Place the second window into the foam insert with the latches facing outward. Fully close the bag. To use the storage bags for the rear quarter windows, proceed as follows: NOTE: Once both windows are placed inside the bag, the outside of 1.
Page 176: Folding Windshield
174 GETTING TO KNOW YOUR VEHICLE 3. Store the bag in a safe location, or in the cargo area of the FOLDING WINDSHIELD vehicle by securing the bag in the vehicle’s cargo area. CAUTION! This is done by attaching the straps at the top of the bag to the rear head restraints, as well as attaching the clips at Lowering of the windshield is NOT recommended in the bottom of the bag to the forward most cargo hooks on...
Page 177: Lowering The Windshield
GETTING TO KNOW YOUR VEHICLE Raise the windshield as soon as the task that required its WARNING! (Continued) removal is completed and before you return to on-road • Be sure that you carefully follow the instructions for driving. Both you and your passengers should wear seat raising the windshield.
Page 178 176 GETTING TO KNOW YOUR VEHICLE 4. Move to the inside of the vehicle and lower both sun CAUTION! visors. Failure to follow this step will cause damage to the vehicle’s header seal. 5. Using the provided #40 Torx head driver, remove the four Torx screws located along the interior of the wind- 2.
Page 179 GETTING TO KNOW YOUR VEHICLE 6. Lower the windshield gently until it contacts the footman CAUTION! loop bumpers (if equipped). Do Not Overtighten! Damage to the windshield could result. ACC/FCW Sensor Protective Cover — If Equipped Your vehicle may be equipped with a protective cover that is to be used whenever the windshield is folded down in order to protect the ACC/FCW sensor.
Page 180: Raising The Windshield
178 GETTING TO KNOW YOUR VEHICLE Cleaning Instructions During windshield down applications, dust/dirt can accu- mulate in the cover and block the camera lens. Use a micro- fiber cloth to clean the camera lens, module, and inside cover, being careful not to damage or scratch the module. Raising The Windshield 1.
Page 181: Hood
GETTING TO KNOW YOUR VEHICLE 5. Replace the protective caps over the wiper arm hex bolts HOOD and push gently until they snap into place. Opening The Hood Release both the hood latches. Protective Cap Over Wiper Bolt 6. After completing the steps above: Hood Latch Locations •...
Page 182: Closing The Hood
180 GETTING TO KNOW YOUR VEHICLE Closing The Hood To close the hood, remove the support rod from the hood panel and place it in the retaining clip. Lower the hood slowly. Secure both of the hood latches. WARNING! Be sure the hood is fully latched before driving your vehicle.
Page 183: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE Cargo Area Features WARNING! Driving with the flip-up window open can allow poisonous Trail Rail Cargo Organizer — If Equipped exhaust gases into your vehicle. You and your passengers If your vehicle is equipped with the Trail Rail system, a rail could be injured by these fumes.
Page 184 182 GETTING TO KNOW YOUR VEHICLE To adjust the anchor loop, push down on the center button Lift the loop to use. while sliding the loop along the rail to the desired position. Release the button and move the loop slightly to the next fixed position in the notches of the rail.
Page 185: Garage Door Opener - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: GARAGE DOOR OPENER — IF EQUIPPED HomeLink® is disabled when the Vehicle Security Alarm is HomeLink® replaces up to three hand-held transmitters that active. operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink® Before You Begin Programming HomeLink®...
Page 186 184 GETTING TO KNOW YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manufac- tured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener. NOTE: It is NOT the button that is normally used to open and close the door.
Page 187 GETTING TO KNOW YOUR VEHICLE 4. Continue to hold both buttons and observe the indicator NOTE: light. The HomeLink® indicator will flash slowly and If the garage door opener/device does not activate, push the then rapidly after HomeLink® has received the button a third time (for two seconds) to complete the frequency signal from the hand-held transmitter.
Page 188 186 GETTING TO KNOW YOUR VEHICLE 5. Press and hold the programmed HomeLink® button and Programming A Non-Rolling Code observe the indicator light. For programming Garage Door Openers manufactured before 1995. • If the indicator light stays on constantly, programming is complete and the garage door/device should acti- 1.
Page 189: Canadian/Gate Operator Programming
GETTING TO KNOW YOUR VEHICLE 3. Continue to press and hold the HomeLink® button, while Canadian/Gate Operator Programming you press and release (“cycle”) your hand-held trans- For programming transmitters in Canada/United States that mitter every two seconds until HomeLink® has success- require the transmitter signals to “time-out”...
Page 190: Using Homelink
188 GETTING TO KNOW YOUR VEHICLE Reprogramming A Single HomeLink® Button (Canadian/ Security Gate Operator) It is advised to erase all channels before you sell or turn in To reprogram a channel that has been previously trained, your vehicle. follow these steps: To do this, push and hold the two outside buttons for 20 1.
Page 191: General Information
GETTING TO KNOW YOUR VEHICLE If you have any problems, or require assistance, please call General Information toll-free 1-800-355-3515 or, on the Internet at HomeLink.com The following regulatory statement applies to all Radio for information or assistance. Frequency (RF) devices equipped in this vehicle: WARNING! This device complies with Part 15 of the FCC Rules and with •...
Page 192 190 GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las siguientes dos INTERNAL EQUIPMENT condiciones: Storage 1. es posible que este equipo o dispositivo no cause interfer- Glove Compartment encia perjudicial y The glove compartment is located on the passenger side of 2.
Page 193 GETTING TO KNOW YOUR VEHICLE To access the lower storage compartment, lift the bottom WARNING! latch. Do not operate this vehicle with a glove compartment in the open position. Driving with the glove compartment open may result in injury in a collision. Console Storage Compartment The center console has both an upper and lower storage compartment.
Page 194 192 GETTING TO KNOW YOUR VEHICLE Rear Storage Compartment — If Equipped Cupholders The rear cargo area storage compartment is located under- The front cupholders are located in the center console. neath the load floor. To access the storage compartment, lift up on the cargo strap at the rear of the cargo area.
Page 195 GETTING TO KNOW YOUR VEHICLE There are also cupholders located in the rear seat armrest, if equipped. These cupholders can be removed for cleaning. Rear Cupholders NOTE: Rear Seat Armrest Cupholders Cupholders located in the front center console, as well as the back of the center console are not removable.
Page 196 194 GETTING TO KNOW YOUR VEHICLE On vehicles equipped with a rear subwoofer, there is a Electrical Power Outlets second power outlet located in the rear cargo area and is There are two 12 Volt (13 Amp) auxiliary power outlets that powered directly from the vehicle battery.
Page 197 GETTING TO KNOW YOUR VEHICLE WARNING! To avoid serious injury or death: • Do not insert any objects into the receptacles. • Do not touch with wet hands. • Close the lid when not in use. • If this outlet is mishandled, it may cause an electric shock and failure.
Page 198 196 GETTING TO KNOW YOUR VEHICLE Power Inverter — If Equipped CAUTION! • Many accessories that can be plugged in draw power There is a 115 Volt, 150 Watt inverter outlet located on the from the vehicle's battery, even when not in use (i.e., back of the center console to convert DC current to AC cellular phones, etc.).
Page 199 GETTING TO KNOW YOUR VEHICLE The power inverter is designed with built-in overload Auxiliary Switches — If Equipped protection. If the power rating of 150 Watts is exceeded, the Four auxiliary switches located in the lower switch bank of power inverter automatically shuts down. Once the electrical the instrument panel can be used to power various electrical device has been removed from the outlet, the inverter should devices.
Page 200 198 GETTING TO KNOW YOUR VEHICLE NOTE: Holding last state conditions are met when switch type is set to latching and power source is set to ignition. For more information, refer to “Uconnect Settings” in “Multimedia”. The auxiliary switches manage the relays that power four blunt cut wires.
Page 201 GETTING TO KNOW YOUR VEHICLE Wire Color Chart Circuit Function Fuse Wire Color Locations Interior (passenger side under instrument panel) & Underhood Aux Switch 1 F93 – 40 Amp Beige/Pink (right side near battery) Interior (passenger side under instrument panel) & Underhood Aux Switch 2 F92 –...
Page 202 200 GETTING TO KNOW YOUR VEHICLE External racks do not increase the total load carrying CAUTION! (Continued) capacity of the vehicle. Be sure that the total occupant and • Travel at reduced speeds and turn corners carefully luggage load inside the vehicle, plus the load on the luggage when carrying large or heavy loads on the roof rack.
Page 203: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster...
Page 204 202 GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster...
Page 205 GETTING TO KNOW YOUR INSTRUMENT PANEL Instrument Cluster Descriptions WARNING! A hot engine cooling system is dangerous. You or others Base Instrument Cluster Descriptions could be badly burned by steam or boiling coolant. You 1. Tachometer may want to call an authorized dealer for service if your •...
Page 206 204 GETTING TO KNOW YOUR INSTRUMENT PANEL 4. Fuel Gauge 3. Speedometer • The pointer shows the level of fuel in the fuel tank • Indicates vehicle speed. when the ignition switch is in the ON/RUN position. 4. Fuel Gauge •...
Page 207 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY WARNING! A hot engine cooling system is dangerous. You or others Your vehicle may be equipped with an instrument cluster could be badly burned by steam or boiling coolant. You display, which offers useful information to the driver. With may want to call an authorized dealer for service if your the ignition in the STOP/OFF mode, opening/closing of a vehicle overheats.
Page 208 206 GETTING TO KNOW YOUR INSTRUMENT PANEL Instrument Cluster Display Location And Controls The instrument cluster display is located in the center of the instrument cluster. 7.0 Inch Instrument Cluster Display Location 3.5 Inch Instrument Cluster Display Location...
Page 209 GETTING TO KNOW YOUR INSTRUMENT PANEL The system allows the driver to select information by • Up Arrow Button pushing the following buttons mounted on the steering Push and release the up arrow button to scroll wheel: upward through the Main Menu items. •...
Page 210 208 GETTING TO KNOW YOUR INSTRUMENT PANEL The Main Menu items consists of the following: Unless reset, this message will continue to display each time you place the ignition in the ON/RUN position. To turn off • Speedometer the message temporarily, push and release the OK button. •...
Page 211 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Vehicle Info If the indicator message illuminates when you start the Push and release the up or down arrow button until the vehicle, the oil change indicator system did not reset. If Vehicle Info menu icon is displayed in the instrument cluster necessary, repeat this procedure.
Page 212 210 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Off Road When vehicle speed becomes too high to display the pitch Push and release the up or down arrow button until the Off and roll, “- -” will display in place of the numbers, and the Road menu icon is displayed in the instrument cluster graphic will be greyed out.
Page 213 GETTING TO KNOW YOUR INSTRUMENT PANEL Push the Adaptive Cruise Control (ACC) ON/OFF button • System Off (located on the steering wheel) until one of the following • ACC Proximity Warning displays in the instrument cluster display: • ACC Unavailable Warning Adaptive Cruise Control Off For further information, refer to “Adaptive Cruise Control When ACC is deactivated, the display will read “Adaptive...
Page 214 212 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Stop/Start — If Equipped Significant changes in driving style or vehicle loading will Push and release the up or down arrow button until the greatly affect the actual drivable distance of the vehicle, Stop/Start icon/title is highlighted in the instrument cluster regardless of the Range displayed value.
Page 215 GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup Driver Selectable Items Messages Push and release the up or down arrow button until the Upper Left Messages Menu item is highlighted. This feature shows the • None number of stored warning messages. Pushing the right •...
Page 216 214 GETTING TO KNOW YOUR INSTRUMENT PANEL Center • Time • None • Range To Empty • Compass • Average MPG (or L/100km, km/L) • Outside Temp • Current MPG (or L/100km, km/L) • Time • Trip A Distance • Range to Empty •...
Page 217 GETTING TO KNOW YOUR INSTRUMENT PANEL Favorite Menus Battery Saver On/Battery Saver Mode Message — Electrical Load Reduction Actions — If Equipped • Speedometer • Vehicle Info This vehicle is equipped with an Intelligent Battery Sensor (IBS) to perform additional monitoring of the electrical •...
Page 218 216 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: • Turning on all possible vehicle electrical loads (e.g. HVAC to max settings, exterior and interior lights, overloaded • The charging system is independent from load reduction. power outlets +12 Volt, 150W, USB ports) during certain The charging system performs a diagnostic on the driving conditions (city driving, towing, frequent stop- charging system continuously.
Page 219 GETTING TO KNOW YOUR INSTRUMENT PANEL What to do when an electrical load reduction action WARNING LIGHTS AND MESSAGES message is present (“Battery Saver On” or “Battery Saver The warning/indicator lights will illuminate in the instru- Mode”) ment panel together with a dedicated message and/or During a trip: acoustic signal when applicable.
Page 220 218 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: — Brake Warning Light The light may flash momentarily during sharp cornering maneu- This warning light monitors various brake functions, vers, which change fluid level conditions. The vehicle should have including brake fluid level and parking brake application. If service performed, and the brake fluid level checked.
Page 221 GETTING TO KNOW YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is applied — Electric Power Steering (EPS) Fault Warning Light with the ignition switch in the ON/RUN position. This warning light will turn on when there's a fault with the NOTE: Electric Power Steering (EPS) system.
Page 222 220 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Refer to “If Your Engine Overheats” in “In Case Of Emer- This light may turn on if the accelerator and brake pedals are gency” for further information. pressed at the same time. —...
Page 223 GETTING TO KNOW YOUR INSTRUMENT PANEL — Seat Belt Reminder Warning Light — Transmission Temperature Warning Light — If Equipped This warning light indicates when the driver or passenger seat belt is unbuckled. When the ignition is first placed in the This warning light will illuminate to warn of a high transmis- ON/RUN or ACC/ON/RUN position and if the driver’s sion fluid temperature.
Page 224 222 GETTING TO KNOW YOUR INSTRUMENT PANEL — Vehicle Security Warning Light — If Equipped — Electronic Stability Control (ESC) Active Warning Light — If Equipped This light will flash at a fast rate for approximately 15 seconds when the vehicle security alarm is arming, and then This warning light will indicate when the Electronic Stability will flash slowly until the vehicle is disarmed.
Page 225 GETTING TO KNOW YOUR INSTRUMENT PANEL — Electronic Stability Control (ESC) OFF Warning — Engine Check/Malfunction Indicator Warning Light Light — If Equipped (MIL) This warning light indicates the Electronic Stability Control The Engine Check/Malfunction Indicator Light (MIL) is a (ESC) is off.
Page 226 224 GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING! — Service Forward Collision Warning (FCW) Light — If Equipped A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal This warning light will illuminate to indicate a fault in the operating conditions.
Page 227 GETTING TO KNOW YOUR INSTRUMENT PANEL As an added safety feature, your vehicle has been equipped — Tire Pressure Monitoring System (TPMS) Warning with a Tire Pressure Monitoring System (TPMS) that illumi- Light nates a low tire pressure telltale when one or more of your The warning light switches on and a message is displayed to tires is significantly under-inflated.
Page 228 226 GETTING TO KNOW YOUR INSTRUMENT PANEL signal low tire pressure as intended. TPMS malfunctions Yellow Indicator Lights may occur for a variety of reasons, including the installation — 4WD Indicator Light — If Equipped of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly.
Page 229 GETTING TO KNOW YOUR INSTRUMENT PANEL — Active Speed Limiter Fault Indicator Light — If — Rear Axle Lock Indicator Light (If Equipped) Equipped This light indicates when the rear axle lock has been acti- This warning light will illuminate to signal when there is a vated.
Page 230 228 GETTING TO KNOW YOUR INSTRUMENT PANEL — Adaptive Cruise Control (ACC) Set With Target — Park/Headlight On Indicator Light Light — If Equipped This indicator light will illuminate when the park lights or This will display when the ACC is set and a target vehicle is headlights are turned on.
Page 231 GETTING TO KNOW YOUR INSTRUMENT PANEL White Indicator Lights — Cruise Control Ready Indicator Light — If Equipped With A Premium Instrument Cluster — Adaptive Cruise Control (ACC) Ready Light — If This light will turn on when the speed control has been turned Equipped on, but not set.
Page 232 230 GETTING TO KNOW YOUR INSTRUMENT PANEL Gray Indicator Lights CAUTION! • Prolonged driving with the MIL on could cause further — Cruise Control Ready Indicator Light — If Equipped damage to the emission control system. It could also With Base Instrument Cluster affect fuel economy and driveability.
Page 233 GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND MAINTENANCE WARNING! PROGRAMS • ONLY an authorized service technician should connect equipment to the OBD II connection port in order to In some localities, it may be a legal requirement to pass an read the VIN, diagnose, or service your vehicle.
Page 234 232 GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has a simple ignition actuated test, which you • The MIL will not flash at all and will remain fully illumi- can use prior to going to the test station. To check if your nated until you place the ignition in the off position or start vehicle's OBD II system is ready, you must do the following: the engine.
Page 235: Safety
SAFETY You also may experience the following when ABS activates: SAFETY FEATURES • The ABS motor noise (it may continue to run for a short Anti-Lock Brake System (ABS) time after the stop) The Anti-Lock Brake System (ABS) provides increased •...
Page 236 234 SAFETY the conventional brake system will continue to operate normally WARNING! (Continued) if the “Anti-Lock Brake Warning Light” is on. • The ABS cannot prevent the natural laws of physics from If the “Anti-Lock Brake Warning Light” is on, the brake acting on the vehicle, nor can it increase braking or system should be serviced as soon as possible to restore the steering efficiency beyond that afforded by the condition...
Page 237 SAFETY Brake System Warning Light WARNING! The Brake Assist System (BAS) cannot prevent the The red “Brake System Warning Light” will turn on when the ignition is placed in the ON/RUN mode and may stay on natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road for as long as four seconds.
Page 238 236 SAFETY Electronic Roll Mitigation (ERM) WARNING! Electronic Roll Mitigation (ERM) anticipates the potential for Many factors, such as vehicle loading, road conditions wheel lift by monitoring the driver’s steering wheel input and driving conditions, influence the chance that wheel and the speed of the vehicle.
Page 239 SAFETY ESC uses sensors in the vehicle to determine the vehicle path WARNING! intended by the driver and compares it to the actual path of • Electronic Stability Control (ESC) cannot prevent the the vehicle. When the actual path does not match the natural laws of physics from acting on the vehicle, nor intended path, ESC applies the brake of the appropriate can it increase the traction afforded by prevailing road...
Page 240 238 SAFETY To enter the “Partial Off” mode, momentarily push the “ESC ESC Operating Modes OFF” switch and the “ESC Off Indicator Light” will illumi- NOTE: nate. To turn the ESC on again, momentarily push the “ESC Depending upon model and mode of operation, the ESC OFF”...
Page 241 SAFETY Full Off — If Equipped WARNING! • In the ESC “Full Off” mode, the engine torque reduc- The “Full Off” mode is intended for off-highway or off-road use only and should not be used on any public roadways. In tion and stability features are disabled.
Page 242 240 SAFETY NOTE: ESC Activation/Malfunction Indicator Light And ESC OFF Indicator Light • The “ESC Activation/Malfunction Indicator Light” and the “ESC Off Indicator Light” come on momentarily each The “ESC Activation/Malfunction Indicator Light” time the ignition is turned ON. in the instrument cluster will come on when the igni- tion is turned to the “ESC on”...
Page 243 SAFETY HDC has three states: Activating HDC 1. Off (feature is not enabled and will not activate) Once HDC is enabled it will activate automatically if driven down a grade of sufficient magnitude. The set speed for HDC 2. Enabled (feature is enabled and ready but activation is selectable by the driver, and can be adjusted by using the conditions are not met, or driver is actively overriding gear shift +/-.
Page 244 242 SAFETY NOTE: Disabling HDC During HDC the +/- shifter input is used for HDC target HDC will be deactivated and disabled if any of the following speed selection, but will not affect the gear chosen by the conditions occur: transmission.
Page 245 SAFETY Feedback To The Driver Hill Start Assist (HSA) The instrument cluster has an HDC icon and the HDC switch The Hill Start Assist (HSA) system is designed to mitigate has an indicator light, which offers feedback to the driver roll back from a complete stop while on an incline.
Page 246 244 SAFETY • HSA will work in REVERSE gear and all forward gears. Towing With HSA The system will not activate if the transmission is in PARK HSA will also provide assistance to mitigate roll back while (P) or NEUTRAL (N). For vehicles equipped with a towing a trailer.
Page 247 SAFETY NOTE: Ready Alert Braking (RAB) TSC cannot stop all trailers from swaying. Always use Ready Alert Braking (RAB) may reduce the time required to caution when towing a trailer and follow the trailer tongue reach full braking during emergency braking situations. It weight recommendations.
Page 248 246 SAFETY Traction Control System (TCS) The Traction Control System (TCS) monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, the TCS may apply brake pressure to the spinning wheel(s) and/or reduce engine power to provide enhanced acceleration and stability.
Page 249 SAFETY The BSM detection zone covers approximately one lane The area on taillights, where the radar sensors are located, width on both sides of the vehicle 12 ft (3.8 m). The zone must remain free of snow, ice, and dirt/road contamination length starts at the outside rear view mirror and extends so that the BSM system can function properly.
Page 250 248 SAFETY The BSM system notifies the driver of objects in the detection Entering From The Side zones by illuminating the BSM warning light located in the Vehicles that move into your adjacent lanes from either side outside mirrors in addition to sounding an audible (chime) of the vehicle.
Page 251 SAFETY Entering From The Rear Overtaking Traffic Vehicles that come up from behind your vehicle on either If you pass another vehicle slowly with a relative speed less side and enter the rear detection zone with a relative speed than 15 mph (24 km/h) and the vehicle remains in the blind of less than 30 mph (48 km/h).
Page 252 250 SAFETY Overtaking/Passing Stationary Objects The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
Page 253 SAFETY The BSM system will not alert you of objects that are trav- Rear Cross Path (RCP) eling in the opposite direction of the vehicle in adjacent The Rear Cross Path (RCP) feature is intended to aid the lanes. driver when backing out of parking spaces where their vision of oncoming vehicles may be blocked.
Page 254 252 SAFETY RCP monitors the rear detection zones on both sides of the Modes Of Operation vehicle, for objects that are moving toward the side of the Three selectable modes of operation are available in the vehicle with a minimum speed of approximately 3 mph Uconnect System.
Page 255 SAFETY NOTE: General Information Whenever an audible alert is requested by the BSM system, The following regulatory statement applies to all Radio the radio is also muted. Frequency (RF) devices equipped in this vehicle: When the system is in RCP, the system shall respond with This device complies with Part 15 of the FCC Rules and with both visual and audible alerts when a detected object is Innovation, Science and Economic Development Canada...
Page 256 254 SAFETY La operación de este equipo está sujeta a las siguientes dos NOTE: condiciones: FCW monitors the information from the forward looking sensors as well as Electronic Brake Controller (EBC), to calcu- 1. es posible que este equipo o dispositivo no cause interfer- late the probability of a forward collision.
Page 257 SAFETY • It is unsafe to test the FCW system. To prevent such misuse of the system, after four Active Braking events within a key cycle, the Active Braking portion of FCW will be deac- tivated until the next Key Cycle. •...
Page 258 256 SAFETY • When FCW status is set to “Warning and Braking”, this Turning FCW On or Off allows the system to warn the driver of a possible collision The FCW button is located in the Uconnect display in the with the vehicle in front using audible/visual warnings control settings.
Page 259 SAFETY • Medium FCW Limited Warning • When the sensitivity of FCW is set to the “Medium” If the instrument cluster displays “ACC/FCW Limited Func- setting and the system status is “Only Warning”, this tionality” or “ACC/FCW Limited Functionality Clean Front allows the system to warn the driver of a possible colli- Windshield”...
Page 260 258 SAFETY La operación de este equipo está sujeta a las siguientes dos General Information condiciones: The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: 1. es posible que este equipo o dispositivo no cause interfer- encia perjudicial y This device complies with Part 15 of the FCC Rules and with Innovation, Science and Economic Development Canada...
Page 261 SAFETY The tire pressure will vary with temperature by approxi- NOTE: mately 1 psi (7 kPa) for every 12°F (6.5°C). This means that When filling warm tires, the tire pressure may need to be when the outside temperature decreases, the tire pressure increased up to an additional 4 psi (28 kPa) above the recom- will decrease.
Page 262 260 SAFETY NOTE: CAUTION! (Continued) When filling warm tires, the tire pressure may need to be • After inspecting or adjusting the tire pressure always increased up to an additional 4 psi (28 kPa) above the recom- reinstall the valve stem cap. This will prevent moisture mended cold placard pressure in order to turn the TPMS and dirt from entering the valve stem, which could Warning Light off.
Page 263 SAFETY NOTE: System Operation It is particularly important for you to check the tire pressure The Tire Pressure Monitoring System (TPMS) uses wireless in all of the tires on your vehicle monthly and to maintain the technology with wheel rim mounted electronic sensors to proper pressure.
Page 264 262 SAFETY NOTE: When filling warm tires, the tire pressure may need to be increased up to an additional 4 psi (28 kPa) above the recom- mended cold placard pressure in order to turn the TPMS Warning Light off. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information.
Page 265 SAFETY longer display, and a pressure value will display in place of 3. After driving the vehicle for up to 20 minutes above the dashes. A system fault can occur due to any of the 15 mph (24 km/h), the TPMS Warning Light will flash on following: and off for 75 seconds and then remain on solid.
Page 266 264 SAFETY Vehicles With a Full Size Matching Spare To deactivate the TPMS, first replace all four wheel and tire assemblies (road tires) with tires not equipped with Tire 1. If your vehicle is equipped with a matching full-size Pressure Monitoring (TPM) Sensors. Then, drive the vehicle spare wheel and tire assembly, it has a tire pressure moni- for 20 minutes above 15 mph (24 km/h).
Page 267 SAFETY La operación de este equipo está sujeta a las siguientes dos General Information condiciones: The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: 1. es posible que este equipo o dispositivo no cause interfer- encia perjudicial y This device complies with Part 15 of the FCC Rules and with Innovation, Science and Economic Development Canada...
Page 268 266 SAFETY Some of the safety features described in this section may be stan- 4. Never allow children to slide the shoulder belt behind dard equipment on some models, or may be optional equipment them or under their arm. on others. If you are not sure, ask an authorized dealer. 5.
Page 269 SAFETY Enhanced Seat Belt Use Reminder System (BeltAlert) WARNING! • Never place a rear-facing child restraint in front of an Driver and Passenger BeltAlert (if equipped) air bag. A deploying passenger front air bag can cause BeltAlert is a feature intended to remind the driver and death or serious injury to a child 12 years or younger, outboard front seat passenger (if equipped with outboard including a child in a rear-facing child restraint.
Page 270 268 SAFETY BeltAlert Warning Sequence The outboard front passenger seat BeltAlert is not active when the outboard front passenger seat is unoccupied. The BeltAlert warning sequence is activated when the BeltAlert may be triggered when an animal or other items are vehicle is moving above a specified vehicle speed range and placed on the outboard front passenger seat or when the seat the driver or outboard front seat passenger is unbuckled (if...
Page 271 SAFETY Lap/Shoulder Belts WARNING! (Continued) All seating positions in your vehicle are equipped with lap/ • It is dangerous to ride in a cargo area, inside or outside shoulder belts. of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 272 270 SAFETY WARNING! WARNING! (Continued) • A lap belt worn too high can increase the risk of injury • A seat belt that is worn under your arm is dangerous. in a collision. The seat belt forces won’t be at the strong Your body could strike the inside surfaces of the hip and pelvic bones, but across your abdomen.
Page 273 SAFETY 3. When the seat belt is long enough to fit, insert the latch Lap/Shoulder Belt Operating Instructions plate into the buckle until you hear a “click.” 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2.
Page 274 272 SAFETY Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 275 SAFETY anchorage button, try to move it up or down to make sure Adjustable Upper Shoulder Belt Anchorage that it is locked in position. In the driver and outboard front passenger seats, the top of the shoulder belt can be adjusted upward or downward to NOTE: position the seat belt away from your neck.
Page 276 274 SAFETY Seat Belt Extender Seat Belts And Pregnant Women If a seat belt is not long enough to fit properly, even when the webbing is fully extended and the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, an authorized dealer can provide you with a Seat Belt Extender.
Page 277 SAFETY Seat Belt Pretensioner Switchable Automatic Locking Retractor (ALR) The front outboard seat belt system is equipped with preten- The seat belts in the passenger seating positions are sioning devices that are designed to remove slack from the equipped with a Switchable Automatic Locking Retractor seat belt in the event of a collision.
Page 278 276 SAFETY In Automatic Locking Mode, the shoulder belt is automati- cally pre-locked. The seat belt will still retract to remove any slack in the shoulder belt. Use the Automatic Locking Mode anytime a child restraint is installed in a seating position that has a seat belt with this feature.
Page 279 SAFETY How To Engage The Automatic Locking Mode WARNING! (Continued) 1. Buckle the combination lap and shoulder belt. • Do not use the Automatic Locking Mode to restrain occupants who are wearing the seat belt or children 2. Grasp the shoulder portion and pull downward until the who are using booster seats.
Page 280 278 SAFETY • Instrument Panel The ORC turns on the Air Bag Warning Light in the instru- ment panel for approximately four to eight seconds for a • Knee Impact Bolsters self-check when the ignition switch is first in the ON/RUN •...
Page 281 SAFETY NOTE: Redundant Air Bag Warning Light If the speedometer, tachometer, or any engine related gauges If a fault with the Air Bag Warning Light is are not working, the Occupant Restraint Controller (ORC) detected, which could affect the Supplemental may also be disabled.
Page 282 280 SAFETY Front Air Bags WARNING! This vehicle has front air bags and lap/shoulder belts for • Being too close to the steering wheel or instrument both the driver and front passenger. The front air bags are a panel during front air bag deployment could cause supplement to the seat belt restraint systems.
Page 283 SAFETY This vehicle has an Occupant Classification System (OCS) in Driver And Passenger Front Air Bag Features the front passenger seat. The OCS is designed to activate or The Advanced Front Air Bag system has multistage driver deactivate the Passenger Advanced Front Air Bag depending and front passenger air bags.
Page 284 282 SAFETY vehicle damage — for example, some pole collisions, truck WARNING! underrides, and angle offset collisions. • No objects should be placed over or near the air bag on the instrument panel or steering wheel because any On the other hand, depending on the type and location of such objects could cause harm if the vehicle is in a colli- impact, front air bags may deploy in crashes with little sion severe enough to cause the air bag to inflate.
Page 285 SAFETY Occupant Classification Module (OCM) And Sensor Occupant Classification System (OCS) — Front Passenger Seat The Occupant Classification Module (OCM) is located The Occupant Classification System (OCS) is part of a Feder- underneath the front passenger seat. The Sensor is located ally regulated safety system for this vehicle.
Page 286 284 SAFETY • The front passenger seat is occupied by a small passenger, including a child or small adult. • The front passenger is not properly seated or his or her weight is taken off of the seat for a period of time. Passenger Air Bag Disable (PAD) System Front Passenger Front Passenger...
Page 287 SAFETY ** It is possible for a child to be classified as an adult, Passenger Air Bag Disable (PAD) System allowing the deployment of the Passenger Advanced Front Front Passenger Air Bag. Never allow children to ride in the front passenger Front Passenger Advanced Air Front Passenger...
Page 288 286 SAFETY Passenger Advanced Front Air Bag Disabled (PAD) Indi- The PAD Indicator Light should be illuminated and the Passenger Advanced Front Air Bag should be deactivated for cator Light most properly seated and restrained children in the The Passenger Advanced Front Air Bag Disabled (PAD) passenger seat and for most properly installed child restraint Indicator Light (an amber light located on the overhead systems.
Page 289 SAFETY If The PAD Indicator Light Is Illuminated For An Adult WARNING! Passenger: • If the PAD Indicator Light remains illuminated for an If an adult passenger is seated in the front passenger seat and adult passenger, have an authorized dealer service the air bag system immediately.
Page 290 288 SAFETY Lighter Weight Passengers (Including Small Adults) Do Not Decrease OR Increase The Front Passenger’s Seated Weight On The Front Passenger Seat When a lighter weight passenger, including a small adult, occupies the passenger seat, the Passenger Advanced Front The front passenger’s seated weight must be properly posi- Air Bag may be deactivated.
Page 291 SAFETY • The front passenger’s seatback is not in the full upright The OCS determines the front passenger’s most probable position. classification. If an occupant in the front passenger seat is seated improperly, the occupant may provide an output • The front passenger carries or holds an object while seated signal to the OCS that is different from the occupant’s prop- (e.g., backpack, box, etc.).
Page 292 290 SAFETY Not Seated Properly Not Seated Properly...
Page 293 SAFETY WARNING! (Continued) • Always wear your seat belt and sit properly, with the seatback in an upright position, your back against the seatback, sitting upright, facing forward, in the center of the seat, with your feet comfortably on or near the floor.
Page 294 292 SAFETY The passenger seat assembly contains critical OCS compo- WARNING! nents that may affect Passenger Advanced Front Air Bag • Ignoring the Air Bag Warning Light in your instrument inflation. In order for the OCS to properly classify the seated panel could mean you won’t have the air bags to protect weight of a front seat passenger, the OCS components must you in a collision.
Page 295 SAFETY Supplemental Side Air Bags WARNING! • Unapproved modifications or service procedures to the Supplemental Seat-Mounted Side Air Bags (SABs) passenger seat assembly, its related components, seat This vehicle is equipped with Supplemental Seat-Mounted cover, or cushion may inadvertently change the air bag Side Air Bags (SABs).
Page 296 294 SAFETY WARNING! Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury. Side Impacts The Side Air Bags are designed to activate in certain side impacts.
Page 297 SAFETY The Side Air Bags will not deploy in all side collisions, WARNING! including some collisions at certain angles, or some side • Side Air Bags need room to inflate. Do not lean against collisions that do not impact the area of the passenger the door or window.
Page 298 296 SAFETY Air Bag System Components If A Deployment Occurs NOTE: The front air bags are designed to deflate immediately after The Occupant Restraint Controller (ORC) monitors the deployment. internal circuits and interconnecting wiring associated with NOTE: electrical Air Bag System Components listed below: Front and/or side air bags will not deploy in all collisions.
Page 299 SAFETY • As the air bags deflate, you may see some smoke-like parti- NOTE: cles. The particles are a normal by-product of the process • Air bag covers may not be obvious in the interior trim, but that generates the non-toxic gas used for air bag inflation. they will open during air bag deployment.
Page 300 298 SAFETY Your vehicle may also be designed to perform any of these NOTE: other functions in response to the Enhanced Accident After an accident, remember to cycle the ignition to the Response System: START or ON/OFF position and remove the key from the ignition switch to avoid draining the battery.
Page 301 SAFETY Maintaining Your Air Bag System Event Data Recorder (EDR) This vehicle is equipped with an Event Data Recorder (EDR). WARNING! The main purpose of an EDR is to record, in certain crash or • Modifications to any part of the air bag system could cause near crash-like situations, such as an air bag deployment or it to fail when you need it.
Page 302 300 SAFETY NOTE: WARNING! EDR data are recorded by your vehicle only if a non-trivial In a collision, an unrestrained child can become a crash situation occurs; no data are recorded by the EDR projectile inside the vehicle. The force required to hold under normal driving conditions and no personal data (e.g., even an infant on your lap could become so great that name, gender, age, and crash location) are recorded.
Page 303 SAFETY NOTE: • Canadian residents should refer to Transport Canada’s website for additional information: http://www.tc.gc.ca/eng/motorve- • For additional information, refer to http://www.nhtsa.gov/ hiclesafety/safedrivers-childsafety-index-53.htm parents-and-caregivers or call: 1–888–327–4236 Summary Of Recommendations For Restraining Children In Vehicles Recommended Type Of Child Child Size, Height, Weight Or Age Restraint Children who are two years old or Either an Infant Carrier or a Convertible...
Page 304 302 SAFETY Infant And Child Restraints WARNING! (Continued) Safety experts recommend that children ride rear-facing in • Never install a rear-facing child restraint in the front seat the vehicle until they are two years old or until they reach of a vehicle. Only use a rear-facing child restraint in the either the height or weight limit of their rear-facing child rear seat.
Page 305 SAFETY Children Too Large For Booster Seats WARNING! • Improper installation can lead to failure of an infant or Children who are large enough to wear the shoulder belt child restraint. It could come loose in a collision. The comfortably, and whose legs are long enough to bend over the child could be badly injured or killed.
Page 306 304 SAFETY child’s squirming or slouching can move the belt out of posi- WARNING! tion. If the shoulder belt contacts the face or neck, move the Never allow a child to put the shoulder belt under an child closer to the center of the vehicle, or use a booster seat arm or behind their back.
Page 307 SAFETY Your vehicle is equipped with the child restraint anchorage Lower Anchors And Tethers For CHildren (LATCH) system called LATCH, which stands for Lower Anchors and Restraint System Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH-equipped child seats. There are two lower anchorages located at the back of the seat cushion where it meets the seatback and one top tether anchorage located behind the seating position.
Page 308 306 SAFETY LATCH Positions For Installing Child Restraints In This Vehicle LATCH Positions (Four-Door Models) Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol LATCH Positions (Two-Door Models) Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol...
Page 309 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit (child’s weight Use the LATCH anchorage system until the combined weight of + weight of the child restraint) for using the child and the child restraint is 65 lbs (29.5 kg). Use the seat 65 lbs (29.5 kg) the LATCH anchorage system to attach belt and tether anchor instead of the LATCH system once the...
Page 310 308 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH The child seat may touch the back of the front passenger Can the rear-facing child restraint touch seat if the child restraint manufacturer also allows the back of the front passenger seat? contact.
Page 311 SAFETY NOTE: If the folding, non-adjustable head restraint interferes with the installation of the child restraint, the head restraint may be folded and the child seat installed in front of it (Two-Door Models). WARNING! Always make sure the head restraint is in its upright position when the seat is to be used by an occupant who is not in a child restraint.
Page 312 310 SAFETY Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seat- back. They are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the gap between the seat- back and seat cushion.
Page 313 SAFETY Locating The Upper Tether Anchorages Two-Door Models: There are tether strap anchorages behind each rear seating position located on the back of the seat, near the floor. Tether Strap Anchorages (Four-Door Models) LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side.
Page 314 312 SAFETY Always follow the directions of the child restraint manu- Center Seat LATCH facturer when installing your child restraint. Not all child Two-Door Models: restraint systems will be installed as described here. WARNING! To Install A LATCH-Compatible Child Restraint This vehicle does not have a center seating position.
Page 315 SAFETY 3. Attach the lower hooks or connectors of the child restraint How To Stow An Unused Switchable-ALR (ALR) Seat Belt: to the lower anchorages in the selected seating position. When using the LATCH attaching system to install a child restraint, stow all ALR seat belts that are not being used by 4.
Page 316 314 SAFETY The seat belts in the passenger seating positions are WARNING! (Continued) equipped with a Switchable Automatic Locking Retractor • Child restraint anchorages are designed to withstand (ALR) that is designed to keep the lap portion of the seat belt only those loads imposed by correctly-fitted child tight around the child restraint so that it is not necessary to restraints.
Page 317 SAFETY Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Automatic Locking Retractor Locations (Four-Door Models) ALR — Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Automatic Locking Retractor Locations (Two-Door Models) ALR — Switchable Automatic Locking Retractor Top Tether Anchorage Symbol...
Page 318 316 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + Always use the tether anchor when using the weight of the child restraint) for using the Weight limit of the Child seat belt to install a forward facing child Tether Anchor with the seat belt to attach a Restraint...
Page 319 SAFETY Installing A Child Restraint With A Switchable Automatic WARNING! Locking Retractor (ALR): Always make sure the head restraint is in its upright position when the seat is to be used by an occupant who Child restraint systems are designed to be secured in vehicle is not in a child restraint.
Page 320 318 SAFETY 3. Slide the latch plate into the buckle until you hear a 7. Finally, pull up on any excess webbing to tighten the lap “click.” portion around the child restraint while you push the child restraint rearward and downward into the vehicle seat. 4.
Page 321 SAFETY 1. Look behind the seating position where you plan to Installing Child Restraints Using The Top Tether install the child restraint to find the tether anchorage. You Anchorage may need to move the seat forward to provide better WARNING! access to the tether anchorage.
Page 322 320 SAFETY 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and where possible, route the tether strap under the head restraint and between the two posts.
Page 323 SAFETY WARNING! • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchorage position directly behind the child seat to secure a child restraint top tether strap. • If your vehicle is equipped with a split rear seat, make sure the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap.
Page 324 322 SAFETY Transporting Pets Exhaust Gas Air Bags deploying in the front seat could harm your pet. An WARNING! unrestrained pet will be thrown about and possibly injured, Exhaust gases can injure or kill. They contain carbon or injure a passenger during panic braking or in a collision. monoxide (CO), which is colorless and odorless.
Page 325 SAFETY Whenever a change is noticed in the sound of the exhaust Air Bag Warning Light system, when exhaust fumes can be detected inside the The Air Bag warning light will turn on for four to eight vehicle, or when the underside or rear of the vehicle is seconds as a bulb check when the ignition switch is first damaged, have a competent mechanic inspect the complete turned to ON/RUN.
Page 326 324 SAFETY Floor Mat Safety Information WARNING! (Continued) Always use floor mats designed to fit your vehicle. Only use • ONLY install floor mats designed to fit your vehicle. a floor mat that does not interfere with the operation of the NEVER install a floor mat that cannot be properly pedal assemblies.
Page 327 SAFETY Periodic Safety Checks You Should Make Outside WARNING! (Continued) The Vehicle • NEVER place any objects under the floor mat (e.g., towels, keys, etc.). These objects could change the posi- Tires tion of the floor mat and may cause interference with Examine tires for excessive tread wear and uneven wear the accelerator, brake, or clutch pedals.
Page 328: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE Manual Transmission — If Equipped Before starting your vehicle, adjust your seat, adjust both Apply the parking brake, place the gear selector in inside and outside mirrors, and fasten your seat belts. NEUTRAL, and press the clutch pedal before starting the vehicle.
Page 329 STARTING AND OPERATING To Turn Off The Engine Using ENGINE START/STOP Automatic Transmission — If Equipped Button Start the vehicle with the gear selector in the PARK position 1. Place the gear selector in PARK, then push and release the (vehicle can also be started in NEUTRAL).
Page 330 328 STARTING AND OPERATING NOTE: AutoPark The system will automatically time out and the ignition will AutoPark is a supplemental feature to assist in placing the cycle to the OFF mode after 30 minutes of inactivity if the vehicle in PARK should the situations on the following ignition is left in the ACC or RUN (engine not running) mode pages occur.
Page 331 STARTING AND OPERATING If the vehicle is not in PARK and the driver turns off the If the vehicle is not in PARK and the driver exits the engine, the vehicle may AutoPark. vehicle with the engine running, the vehicle may Auto- Park.
Page 332 330 STARTING AND OPERATING If the driver shifts into PARK while moving, the vehicle Additional customer warnings will be given when both of may AutoPark. these conditions are met: • Vehicle is not in PARK AutoPark will engage ONLY when vehicle speed is 1.2 mph (2.0 km/h) or less.
Page 333 STARTING AND OPERATING If Engine Fails To Start WARNING! (Continued) • If the vehicle has a discharged battery, booster cables If the engine fails to start after you have followed the "Normal Starting" or "Extreme Cold Weather" procedure, may be used to obtain a start from a booster battery or and has not experienced an extended park condition as iden- the battery in another vehicle.
Page 334 332 STARTING AND OPERATING While cruising, brief full-throttle acceleration within the ENGINE BLOCK HEATER — IF EQUIPPED limits of local traffic laws contributes to a good break-in. The engine block heater warms the engine, and permits Wide-open throttle acceleration in low gear can be detri- quicker starts in cold weather.
Page 335 STARTING AND OPERATING When the parking brake is applied with the ignition switch PARKING BRAKE ON, the “Brake Warning Light” in the instrument cluster Before exiting the vehicle, make sure that the parking brake will illuminate. is fully applied. Also, be certain to leave an automatic trans- NOTE: mission in PARK, or manual transmission in REVERSE or FIRST gear.
Page 336 334 STARTING AND OPERATING WARNING! WARNING! (Continued) • Never use the PARK position on an automatic transmis- • Always fully apply the parking brake when leaving sion as a substitute for the parking brake. Always apply your vehicle or it may roll and cause damage or injury. the parking brake fully when parked to guard against Also, be certain to leave an automatic transmission in vehicle movement and possible injury or damage.
Page 337 STARTING AND OPERATING MANUAL TRANSMISSION — IF EQUIPPED WARNING! You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied. The parking brake should always be applied when the driver is not in the vehicle, especially on an incline.
Page 338 336 STARTING AND OPERATING To engage REVERSE gear from the NEUTRAL position, lift Shifting the REVERSE ring, located below the knob and move the Fully press the clutch pedal before shifting gears. As you gear selector all the way left and then forward. release the clutch pedal, lightly press the accelerator pedal.
Page 339 STARTING AND OPERATING Recommended Vehicle Shift Speeds To utilize your manual transmission efficiently for both fuel economy and performance, it should be upshifted as listed in recommended shift speed chart. Shift at the vehicle speeds listed for acceleration. When heavily loaded or pulling a trailer these recommended up-shift speeds may not apply.
Page 340 338 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • Skipping gears and downshifting into lower gears at • Failure to follow the maximum recommended down- higher vehicle speeds can damage the engine and shifting speeds may cause the engine damage and/or clutch systems, Any attempt to shift into lower gear damage the clutch, even if the clutch pedal is pressed.
Page 341 STARTING AND OPERATING Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4 4 to 3 3 to 2 2 to 1 Maximum Speed 80 (129) 70 (113) 50 (81) 30 (48) 15 (24) NOTE: WARNING! Vehicle speeds shown in the chart above are for 2H and 4H •...
Page 342 340 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • It is dangerous to shift out of PARK or NEUTRAL if the • Never leave children alone in a vehicle, or with access engine speed is higher than idle speed. If your foot is to an unlocked vehicle.
Page 343 STARTING AND OPERATING Ignition Park Interlock Eight–Speed Automatic Transmission This vehicle is equipped with an Ignition Park Interlock The transmission gear range (PRNDM) is displayed both which requires the transmission to be in PARK before the beside the gear selector and in the instrument cluster. To ignition can be turned to the OFF mode.
Page 344 342 STARTING AND OPERATING The electronically-controlled transmission adapts its shift schedule based on driver inputs, along with environmental and road conditions. The transmission electronics are self-calibrating; therefore, the first few shifts on a new vehicle may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles (kilometers).
Page 345 STARTING AND OPERATING When exiting the vehicle, always: Gear Ranges • Apply the parking brake Do not depress the accelerator pedal when shifting from PARK or NEUTRAL into another gear range. • Shift the transmission into PARK • Turn the ignition OFF and NOTE: After selecting any gear range, wait a moment to allow the •...
Page 346 344 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • The transmission may not engage PARK if the vehicle • When exiting the vehicle, always make sure the igni- is moving. Always bring the vehicle to a complete stop tion is in the OFF mode, remove the key fob from the before shifting to PARK, and verify that the transmis- vehicle, and lock the vehicle.
Page 347 STARTING AND OPERATING NOTE: CAUTION! If the gear selector cannot be moved to the PARK position • Before moving the transmission gear selector out of (when pushed forward), it is probably in the AutoStick (+/-) PARK, you must start the engine, and also press the position (beside the DRIVE position).
Page 348 346 STARTING AND OPERATING During extremely cold temperatures (-22°F [-30°C] or CAUTION! below), transmission operation may be modified depending Towing the vehicle, coasting, or driving for any other on engine and transmission temperature as well as vehicle reason with the transmission in NEUTRAL can cause speed.
Page 349 STARTING AND OPERATING Indicator Light (MIL) may be illuminated. A message in the NOTE: instrument cluster will inform the driver of the more serious Even if the transmission can be reset, we recommend that conditions, and indicate what actions may be necessary. you visit an authorized dealer at your earliest possible convenience.
Page 350 348 STARTING AND OPERATING Operation • You can start out, from a stop, in FIRST or SECOND gear (or THIRD gear, in 4L range). Tapping (+) (at a stop) will To activate AutoStick mode, move the gear selector into the allow starting in SECOND gear.
Page 351 STARTING AND OPERATING NOTE: Four-Position Transfer Case When Hill Descent Control is enabled, AutoStick is not active. To disengage AutoStick mode, return the gear selector to the DRIVE position. You can shift in or out of the AutoStick posi- tion at any time without taking your foot off the accelerator pedal.
Page 352 350 STARTING AND OPERATING For additional information on the appropriate use of each Neutral — This range disengages both the front and rear transfer case mode position, see the information below: driveshafts from the powertrain. To be used for flat towing behind another vehicle.
Page 353 STARTING AND OPERATING tions on hard-surfaced roads will cause increased tire wear Shifting Procedures and damage to the driveline components. Refer to “Shifting 2H To 4H Or 4H To 2H Procedures” in this section for further information on shifting into 4H or 4L. Shifting between 2H and 4H can be made with the vehicle stopped or in motion.
Page 354 352 STARTING AND OPERATING 4H To 4L Or 4L To 4H Five-Position Transfer Case With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift an automatic transmission into NEUTRAL (N), or press the clutch pedal on a manual transmission. While the vehicle is coasting at 2 to 3 mph (3 to 5 km/h), shift the transfer case lever firmly to the desired position.
Page 355 STARTING AND OPERATING For additional information on the appropriate use of each N (Neutral) transfer case mode position, see the information below: WARNING! You or others could be injured or killed if you leave the vehicle unattended with the transfer case in the Two-Wheel Drive High Range —...
Page 356 354 STARTING AND OPERATING intended for loose, slippery road surfaces only and not intended for normal driving. Driving in the 4H and 4L posi- Four-Wheel Drive Low Range — This range provides low tions on hard-surfaced roads will cause increased tire wear speed four-wheel drive.
Page 357 STARTING AND OPERATING NOTE: Shifting Procedures • Do not attempt to make a shift while only the front or rear 2H To 4H Auto Or 4H Auto To 2H wheels are spinning. The front and rear driveshaft speeds must be equal for the shift to take place. Shifting while Shifting between 2H and 4H Auto can be made with the only the front or rear wheels are spinning can cause vehicle stopped or in motion.
Page 358 356 STARTING AND OPERATING NOTE: Trac-Lok Rear Axle — If Equipped Shifting into or out of 4L is possible with the vehicle The Trac-Lok rear axle provides a constant driving force to completely stopped; however, difficulty may occur due to both rear wheels and reduces wheel spin caused by the loss the mating teeth not being properly aligned.
Page 359 STARTING AND OPERATING To activate the system, push the axle lock switch down to Axle Lock (Tru-Lok) — Rubicon Models lock the rear axle only (the “REAR ONLY” will illuminate), The axle lock switch is located on the instrument panel (to push the switch up to lock the front axle and rear axle (the the right of the steering column).
Page 360 358 STARTING AND OPERATING nate when the bar is disconnected. The “Sway Bar Indicator Electronic Sway Bar Disconnect — If Equipped Light” will flash during activation transition, or when activa- Your vehicle may be equipped with an electronic discon- tion conditions are not met. The stabilizer/sway bar should necting stabilizer/sway bar.
Page 361 STARTING AND OPERATING NOTE: ELECTRO-HYDRAULIC POWER STEERING The stabilizer/sway bar may be torque locked due to left and Your vehicle is equipped with an electro-hydraulic power right suspension height differences. This condition is due to steering system that will give you good vehicle response and driving surface differences or vehicle loading.
Page 362 360 STARTING AND OPERATING If the “POWER STEERING HOT” message and an icon are STOP/START SYSTEM — AUTOMATIC displayed on the instrument cluster screen, it indicates that TRANSMISSION (IF EQUIPPED) extreme steering maneuvers may have occurred, which The Engine Stop/Start (ESS) function is developed to reduce caused an over temperature condition in the power steering fuel consumption.
Page 363 STARTING AND OPERATING Secondary Battery Automatic Mode Your vehicle may be equipped with a secondary battery used WARNING! to power the Stop/Start system and the 12 Volt vehicle elec- • Vehicles with the Stop/Start system will be equipped trical system. The secondary battery is located behind the with two batteries.
Page 364 362 STARTING AND OPERATING • The vehicle must be completely stopped. • HVAC is set to full defrost mode at a high blower speed. • The shifter must be in a forward gear and the brake pedal • HVAC set to MAX A/C. depressed.
Page 365 STARTING AND OPERATING To Start The Engine While In Autostop Mode To Manually Turn Off The Stop/Start System While in a forward gear, the engine will start when the brake 1. Push the Stop/Start OFF switch (located on the switch pedal is released or the throttle pedal is depressed.
Page 366 364 STARTING AND OPERATING 3. At the next vehicle stop (after turning off the Stop/Start STOP/START SYSTEM — MANUAL TRANSMISSION system), the engine will not be stopped. (IF EQUIPPED) 4. The Stop/Start system will reset itself back to an ON condi- The Engine Stop/Start function is developed to reduce fuel tion every time the ignition is turned off and back on.
Page 367 STARTING AND OPERATING Secondary Battery Automatic Mode Your vehicle may be equipped with a secondary battery used WARNING! to power the Stop/Start system and the 12 Volt vehicle elec- • Vehicles with the Stop/Start system will be equipped trical system. The secondary battery is located behind the with two batteries.
Page 368 366 STARTING AND OPERATING To Activate The STOP/START AUTO STOP ACTIVE • Actual cabin temperature is significantly different than Mode, The Following Must Occur: temperature set on Auto HVAC. • The system must be in STOP/START READY state. A • HVAC is set to full defrost mode. STOP/START READY message will be displayed in the •...
Page 369 STARTING AND OPERATING To Start The Engine While In Autostop Mode To Manually Turn Off The Stop/Start System When the gear selector is in NEUTRAL, the engine will start 1. Push the Stop/Start OFF switch (located on the switch when the clutch pedal is pressed (does not require complete/ bank).
Page 370 368 STARTING AND OPERATING 3. At the next vehicle stop (after turning off the Stop/Start SPEED CONTROL — IF EQUIPPED system), the engine will not be stopped. When engaged, the Speed Control takes over accelerator 4. If the Stop/Start system is manually turned off, the operations at speeds greater than 20 mph (32 km/h).
Page 371 STARTING AND OPERATING NOTE: WARNING! • In order to ensure proper operation, the Speed Control Leaving the Speed Control system on when not in use is System has been designed to shut down if multiple Speed dangerous. You could accidentally set the system or Control functions are operated at the same time.
Page 372 370 STARTING AND OPERATING Metric Speed (km/h) To Vary The Speed Setting • Pushing the SET (+) button once will result in a 1 km/h To Increase Speed increase in set speed. Each subsequent tap of the button When the Speed Control is set, you can increase speed by results in an increase of 1 km/h.
Page 373 STARTING AND OPERATING Metric Speed (km/h) WARNING! • Pushing the SET (-) button once will result in a 1 km/h Speed Control can be dangerous where the system decrease in set speed. Each subsequent tap of the button cannot maintain a constant speed. Your vehicle could go results in a decrease of 1 km/h.
Page 374 372 STARTING AND OPERATING ACC will allow you to keep cruise control engaged in light to ADAPTIVE CRUISE CONTROL (ACC) — IF EQUIPPED moderate traffic conditions without the constant need to reset your cruise control. ACC utilizes a radar sensor and a forward facing camera designed to detect a vehicle directly ahead of you.
Page 375 STARTING AND OPERATING WARNING! WARNING! (Continued) • Adaptive Cruise Control (ACC) is a convenience • On vehicles with automatic transmission, will bring system. It is not a substitute for active driving involve- the vehicle to a complete stop while following a ment.
Page 376 374 STARTING AND OPERATING NOTE: Adaptive Cruise Control (ACC) Operation You cannot engage ACC under the following conditions: The Speed Control buttons (located on the right side of the • When in Four-Wheel Drive Low steering wheel) operate the ACC system. •...
Page 377 STARTING AND OPERATING To Activate/Deactivate Push and release the Adaptive Cruise Control (ACC) on/off button. The ACC menu in the instrument cluster displays “ACC Ready.” Adaptive Cruise Control Off WARNING! Leaving the Adaptive Cruise Control (ACC) system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want.
Page 378 376 STARTING AND OPERATING To Set A Desired ACC Speed To Cancel When the vehicle reaches the speed desired, push the SET (+) The following conditions cancel the system: button or the SET (-) button and release. The instrument • The brake pedal is applied cluster display will display the set speed.
Page 379 STARTING AND OPERATING To Turn Off WARNING! The Resume function should only be used if traffic and The system will turn off and clear the set speed in memory if: road conditions permit. Resuming a set speed that is too •...
Page 380 378 STARTING AND OPERATING • If the button is continually pushed, the set speed will US Speed (mph) continue to increase in 5 mph increments until the button • Pushing the SET (-) button once will result in a 1 mph is released.
Page 381 STARTING AND OPERATING NOTE: Setting The Following Distance In ACC • When you override and push the SET (+) button or SET (-) The specified following distance for ACC can be set by button, the new set speed will be the current speed of the varying the distance setting between four bars (longest), vehicle.
Page 382 380 STARTING AND OPERATING Distance Setting 3 Bars (Long) Distance Setting 2 Bars (Medium)
Page 383 STARTING AND OPERATING If there is no vehicle ahead, the vehicle will maintain the set speed. If a slower moving vehicle is detected in the same lane, the instrument cluster displays the “Sensed Vehicle Indicator” icon, and the system adjusts vehicle speed auto- matically to maintain the distance setting, regardless of the set speed.
Page 384 382 STARTING AND OPERATING A Proximity Warning will alert the driver if ACC predicts that its Overtake Aid maximum braking level is not sufficient to maintain the set When driving with ACC engaged and following a vehicle, distance. If this occurs, a visual alert “BRAKE!” will flash in the the system will provide an additional acceleration up to the instrument cluster display and a chime will sound while ACC ACC set speed to assist in passing the vehicle.
Page 385 STARTING AND OPERATING will release. A cancel message will display on the instrument Adaptive Cruise Control Ready cluster display and produce a warning chime. Driver inter- When ACC is activated, but the vehicle speed setting has not vention will be required at this moment. been selected, the display will read “Adaptive Cruise Control Ready.”...
Page 386 384 STARTING AND OPERATING If weather conditions are not a factor, the driver should Display Warnings And Maintenance examine the sensor. It may require cleaning or removal of an “Wipe Front Radar Sensor In Front Of Vehicle” Warning obstruction. The sensor is located in the center of the vehicle behind the lower grille.
Page 387 STARTING AND OPERATING NOTE: The “ACC/FCW Limited Functionality Clean Front Wind- shield” message can sometimes be displayed while driving • If the “ACC/FCW Unavailable Wipe Front Radar Sensor” in adverse weather conditions. The ACC/FCW system will message occurs frequently (e.g. more than once on every recover after the vehicle has left these areas.
Page 388 386 STARTING AND OPERATING “Service ACC/FCW” Warning Towing A Trailer If the system turns off, and the instrument cluster displays Towing a trailer is not advised when using ACC. “ACC/FCW Unavailable Service Required” or “Cruise/ Offset Driving FCW Unavailable Service Required”, there may be an internal system fault or a temporary malfunction that limits ACC may not detect a vehicle in the same lane that is offset ACC functionality.
Page 389 STARTING AND OPERATING Turns And Bends Using ACC On Hills When driving on a curve with ACC engaged, the system When driving on hills, ACC may not detect a vehicle in your may decrease the vehicle speed and acceleration for stability lane.
Page 390 388 STARTING AND OPERATING Lane Changing Narrow Vehicles ACC may not detect a vehicle until it is completely in the Some narrow vehicles traveling near the outer edges of the lane in which you are traveling. In the illustration shown, lane or edging into the lane are not detected until they have ACC has not yet detected the vehicle changing lanes and it moved fully into the lane.
Page 391 STARTING AND OPERATING General Information Stationary Objects And Vehicles ACC does not react to stationary objects and stationary vehi- The following regulatory statement applies to all Radio cles. For example, ACC will not react in situations where the Frequency (RF) devices equipped in this vehicle: vehicle you are following exits your lane and the vehicle This device complies with Part 15 of the FCC Rules and with ahead is stopped in your lane.
Page 392 390 STARTING AND OPERATING La operación de este equipo está sujeta a las siguientes dos Pushing the Normal (Fixed Speed) Cruise Control on/off condiciones: button will result in turning on (changing to) the Normal (Fixed Speed) Cruise Control mode. 1. es posible que este equipo o dispositivo no cause interfer- encia perjudicial y WARNING! 2.
Page 393 STARTING AND OPERATING • If the button is continually pushed, the set speed will To Vary The Speed Setting continue to increase in 10 km/h increments until the To Increase Speed button is released. The increase in set speed is reflected in the instrument cluster display.
Page 394 392 STARTING AND OPERATING Metric Speed (km/h) • The vehicle speed is less than 15 mph (24 km/h) (manual transmission only). • Pushing the SET (-) button once will result in a 1 km/h decrease in set speed. Each subsequent tap of the button •...
Page 395 STARTING AND OPERATING PARKSENSE REAR PARK ASSIST — IF EQUIPPED ParkSense Sensors The ParkSense Rear Park Assist system provides visual and The four ParkSense sensors, located in the rear fascia/bumper, audible indications of the distance between the rear fascia monitor the area behind the vehicle that is within the sensors’ and a detected obstacle when backing up, e.g.
Page 396 394 STARTING AND OPERATING ParkSense Display When the vehicle is in REVERSE, the instrument cluster display will show the park assist ready system status. The system will indicate a detected obstacle by showing a single arc in one or more regions based on the obstacle’s distance and location relative to the vehicle.
Page 397 STARTING AND OPERATING Slow Tone/Solid Arc Slow Tone/Solid Arc...
Page 398 396 STARTING AND OPERATING Fast Tone/Flashing Arc Continuous Tone/Flashing Arc...
Page 399 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Greater than Less than Rear Distance...
Page 400 398 STARTING AND OPERATING the instrument cluster display will show the “PARKSENSE Enabling And Disabling ParkSense OFF” message for as long as the vehicle is in REVERSE (Not ParkSense can be enabled and disabled with the ParkSense in 4L). switch, located on the switch panel below the climate The ParkSense switch LED will be on when ParkSense is controls.
Page 401 STARTING AND OPERATING If “PARKSENSE UNAVAILABLE WIPE REAR SENSORS” • When you turn ParkSense OFF, the instrument cluster appears in the instrument cluster display, make sure the display will read “PARKSENSE OFF.” Furthermore, once outer surface and the underside of the rear fascia/bumper is you turn ParkSense OFF, it remains off until you turn it on clean and clear of snow, ice, mud, dirt or other obstruction again, even if you cycle the ignition.
Page 402 400 STARTING AND OPERATING WARNING! CAUTION! • Drivers must be careful when backing up even when • ParkSense is only a parking aid and it is unable to using ParkSense. Always check carefully behind your recognize every obstacle, including small obstacles. vehicle, look behind you, and be sure to check for Parking curbs might be temporarily detected or not pedestrians, animals, other vehicles, obstructions, and...
Page 403 STARTING AND OPERATING Manual Activation Of The Rear View Camera NOTE: • If the vehicle speed remains below 8 mph (13 km/h), the 1. Press the “Controls” button located on the bottom of the Rear View Camera image will be displayed continuously Uconnect display.
Page 404 402 STARTING AND OPERATING The following table shows the approximate distances for CAUTION! each zone: • To avoid vehicle damage, ParkView should only be used as a parking aid. The ParkView camera is unable Distance To The Rear Of The Zone to view every obstacle or object in your drive path.
Page 405 STARTING AND OPERATING REFUELING THE VEHICLE Fuel Filler Cap The fuel filler cap is located on the driver's side of the vehicle. If the fuel filler cap is lost or damaged, be sure the replace- ment cap is the correct one for this vehicle. Fuel Filler Cap Fuel Filler Door...
Page 406 404 STARTING AND OPERATING NOTE: WARNING! • When the fuel nozzle “clicks” or shuts off, the fuel tank is • Never have any smoking materials lit in or near the vehicle full. when the fuel door is open or the tank is being filled. •...
Page 407 STARTING AND OPERATING VEHICLE LOADING Payload The payload of a vehicle is defined as the allowable load Certification Label weight a truck can carry, including the weight of the driver, As required by National Highway Traffic Safety Administra- all passengers, options and cargo. tion regulations, your vehicle has a certification label affixed to the driver's side door or pillar.
Page 408 406 STARTING AND OPERATING The entire vehicle should first be weighed on a commercial Rim Size scale to insure that the GVWR has not been exceeded. The This is the rim size that is appropriate for the tire size listed. weight on the front and rear of the vehicle should then be determined separately to be sure that the load is properly Inflation Pressure...
Page 409 STARTING AND OPERATING rary) loaded in or on the trailer in its "loaded and ready for TRAILER TOWING operation" condition. In this section you will find safety tips and information on The recommended way to measure GTW is to put your fully limits to the type of towing you can reasonably do with your vehicle.
Page 410 408 STARTING AND OPERATING Tongue Weight (TW) Weight-Distributing Hitch The tongue weight is the downward force exerted on the A weight-distributing hitch works by applying leverage hitch ball by the trailer. You must consider this as part of the through spring (load) bars. They are typically used for load on your vehicle.
Page 411 STARTING AND OPERATING Trailer Hitch Classification WARNING! (Continued) • Weight Distributing Systems may not be compatible The following chart provides the industry standard for the with Surge Brake Couplers. Consult with your hitch maximum trailer weight a given trailer hitch class can tow and trailer manufacturer or a reputable Recreational and should be used to assist you in selecting the correct Vehicle dealer for additional information.
Page 412 410 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) GCWR Max. GTW (Gross Max. Trailer Tongue Wt. Engine/Transmission Model Frontal Area (Gross Trailer Combined (See Note) Wt.) Wt. Rating) 8,016 lbs 20 ft2 2,000 lbs Two–Door 200 lbs (91 kg) (3 636 kg) (1.86 m2) (907 kg)
Page 413 STARTING AND OPERATING NOTE: Trailer And Tongue Weight Remember that everything put into or on the trailer adds to Never exceed the maximum tongue weight stamped on your the load on your vehicle. Also, additional factory-installed bumper or trailer hitch. options or dealer-installed options must be considered as part of the total load on your vehicle.
Page 414 412 STARTING AND OPERATING Towing Requirements — Trailer Brakes CAUTION! • Do not interconnect the hydraulic brake system or vacuum If the trailer weighs more than 1,000 lbs (453 kg) loaded, system of your vehicle with that of the trailer. This could it should have its own brakes and they should be of cause inadequate braking and possible personal injury.
Page 415 STARTING AND OPERATING NOTE: • Disconnect trailer wiring connector from the vehicle before launching a boat (or any other device plugged into vehicle’s electrical connect) into water. • Be sure to reconnect once clear from water area. Seven-Pin Connector 1 — Battery 2 —...
Page 416 414 STARTING AND OPERATING • To prevent excess heat generation, avoid continuous driving Towing Tips at high RPM. Reduce vehicle speed as necessary to avoid Before setting out on a trip, practice turning, stopping and extended driving at high RPM. Return to a higher gear or backing the trailer in an area away from heavy traffic.
Page 417 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Four-Wheel Drive Models See Instructions • Automatic transmission in PARK. Flat Tow NONE • Manual transmission in gear (NOT in NEUTRAL [N]). •...
Page 418 416 STARTING AND OPERATING Recreational Towing — Four-Wheel Drive Models CAUTION! (Continued) NOTE: • Towing this vehicle in violation of the above require- The transfer case must be shifted into NEUTRAL (N), auto- ments can cause severe transmission and/or transfer matic transmission must be in PARK, and manual transmis- case damage.
Page 419 STARTING AND OPERATING 11. Firmly apply the parking brake. CAUTION! It is necessary to follow these steps to be certain that the 12. Shift the transmission into PARK or place manual trans- transfer case is fully in NEUTRAL (N) before mission in gear (NOT in NEUTRAL).
Page 420 418 STARTING AND OPERATING 4. Press and hold the brake pedal. DRIVING TIPS 5. Shift the transmission into NEUTRAL. On-Road Driving Tips 6. Turn the engine off. Utility vehicles have higher ground clearance and a narrower track to make them capable of performing in a 7.
Page 421 STARTING AND OPERATING Off-Road Driving Tips Bumper End Cap Removal The end caps on your vehicle’s front bumper can be removed Side Step Removal — If Equipped by following the steps below: NOTE: NOTE: Prior to off-road usage, the side steps should be removed to Bumper end caps are removable on steel bumper only.
Page 422 420 STARTING AND OPERATING The Basics Of Off-Road Driving You will encounter many types of terrain driving off-road. You should be familiar with the terrain and area before proceeding. There are many types of surface conditions: hard-packed dirt, gravel, rocks, grass, sand, mud, snow and ice.
Page 423 STARTING AND OPERATING Simultaneous Brake And Throttle Operation WARNING! Always wear your seat belt and firmly tie down cargo. Many off-road driving conditions require the simultaneous Unsecured cargo can become projectiles in an off-road use of the brake and throttle (two-footed driving). When situation.
Page 424 422 STARTING AND OPERATING cally improve your traction and handling while driving on the soft sand, but you must return the tires to normal air Deep mud creates a great deal of suction around the tires and pressure before driving on pavement or other hard surfaces. is very difficult to get through.
Page 425 STARTING AND OPERATING WARNING! CAUTION! Crossing obstacles can cause abrupt steering system • Never attempt to straddle a rock that is large enough to loading which could cause you to loose control of your strike your axles or undercarriage. vehicle. •...
Page 426 424 STARTING AND OPERATING Crossing Logs CAUTION! To cross a log, approach it at a slight angle (approximately 10 Winching or rocking the vehicle off hard objects to 15 degrees). This allows one front tire to be on top of the increases the risk of underbody damage.
Page 427 STARTING AND OPERATING Driving Up Hill Driving Downhill Once you have determined your ability to proceed and have Before driving down a steep hill, you need to determine if it shifted into the appropriate gear, line your vehicle up for the is too steep for a safe descent.
Page 428 426 STARTING AND OPERATING Driving Across An Incline WARNING! If at all possible, avoid driving across an incline. If it is neces- If the engine stalls or you lose headway or cannot make sary, know your vehicle's abilities. Driving across an incline it to the top of a steep hill or grade, never attempt to turn places more weight on the downhill wheels, which increases around.
Page 429 STARTING AND OPERATING 4L (Low) position and proceed very slowly with a constant Before You Cross Any Type Of Water slow speed of {3 to 5 mph (5 to 8 km/h) maximum} and light As you approach any type of water, you need to determine if throttle.
Page 430 428 STARTING AND OPERATING Crossing Puddles, Pools, Flooded Areas Or Other Standing still a high risk of personal injury and vehicle damage with Water slower water currents in depths greater than the vehicle's running ground clearance. You should never attempt to Puddles, pools, flooded or other standing water areas cross flowing water which is deeper than the vehicle's normally contain murky or muddy waters.
Page 431 STARTING AND OPERATING • After extended operation in mud, sand, water, or similar After Driving Off-Road dirty conditions, have the radiator, fan, brake rotors, Off-road operation puts more stress on your vehicle than wheels, brake linings, and axle yokes inspected and does most on-road driving.
Page 432: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS ASSIST AND SOS SYSTEM — IF EQUIPPED The Hazard Warning flasher switch is located on the instru- ment panel below the climate controls. Push the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 433 IN CASE OF EMERGENCY ASSIST Call WARNING! ALWAYS obey traffic laws and pay attention to the road. The ASSIST Button is used to automatically connect you to ALWAYS drive safely with your hands on the steering any one of the following support centers: wheel.
Page 434 432 IN CASE OF EMERGENCY 2. The LED light located between the ASSIST and SOS NOTE: buttons on the overhead console will turn green once a • Your vehicle may be transmitting data as authorized by connection to a SOS operator has been made. the subscriber.
Page 435 IN CASE OF EMERGENCY SOS Call System Limitations WARNING! (Continued) Vehicles sold in Mexico DO NOT have SOS Call system • Never place anything on or near the vehicle’s operable capabilities. network and GPS antennas. You could prevent oper- able network and GPS signal reception, which can SOS or other emergency line operators in Mexico may not prevent your vehicle from placing an emergency call.
Page 436 434 IN CASE OF EMERGENCY • The vehicle battery loses power or becomes disconnected WARNING! during a vehicle crash • Ignoring the Rearview Mirror light could mean you • LTE (voice/data) or 4G (data) network and/or Global will not have SOS Call services. If the Rearview Mirror Positioning Satellite signals are unavailable or obstructed light is illuminated, have your authorized dealer service the SOS Call system immediately.
Page 437 IN CASE OF EMERGENCY General Information CAUTION! To avoid damage to the mirror during cleaning, never The following regulatory statement applies to all Radio spray any cleaning solution directly onto the mirror. Frequency (RF) devices equipped in this vehicle: Apply the solution onto a clean cloth and wipe the This device complies with Part 15 of the FCC Rules and with mirror clean.
Page 438 436 IN CASE OF EMERGENCY La operación de este equipo está sujeta a las siguientes dos NOTE: condiciones: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s 1. es posible que este equipo o dispositivo no cause interfer- authority to operate the equipment.
Page 439 IN CASE OF EMERGENCY Exterior Bulbs Bulb Name Bulb Number Headlamps (2) Premium Head Lamps LED – (Serviced At Authorized Dealer) Sport Front Park/Turn Signal Lamps (2) 7442NALL Premium Front Park/Turn Signal Lamps (2) LED – (Serviced At Authorized Dealer) Base (Sahara/Rubicon) Turn Lamp 7440NA Base (Sahara/Rubicon) Park DRL Lamp...
Page 440 438 IN CASE OF EMERGENCY 6. Remove the lamp from the collar. Bulb Replacement NOTE: 7. Grasp the bulb and rotate a quarter turn counterclock- Lens fogging can occur under certain atmospheric condi- wise. tions. This will usually clear as atmospheric conditions 8.
Page 441 IN CASE OF EMERGENCY Front Park/Turn Signal LED Front Side Marker 1. Remove the front wheel liner fasteners to access bulb 1. Remove the front wheel liner fasteners to access side sockets. maker screw and electrical connector. 2. Remove fastening screw in the back of the front side maker assembly and disconnect electrical connector.
Page 442 440 IN CASE OF EMERGENCY 3. Firmly grasp the bulb by the two latch features and Rear Tail, Stop, Turn Signal, And Backup Lamp squeeze them together to unlock the bulb from the back 1. Remove interior trim panel cap to access single retaining of the front fog lamp housing.
Page 443 IN CASE OF EMERGENCY 2. Remove retaining screw and disconnect electrical connector, then remove tail lamp assembly from the vehicle. NOTE: If necessary, push in on the assembly tab located inboard behind the lamp housing. Assembly Bracket 4. Rotate the appropriate socket a quarter turn counter- clockwise, then remove it from the housing.
Page 444 442 IN CASE OF EMERGENCY Center High Mounted Stop Lamp (CHMSL) FUSES The stop lamp is mounted on a bracket that extends upward WARNING! from the tailgate behind the spare tire. If service is needed, • When replacing a blown fuse, always use an appro- obtain the LED Assembly from an authorized dealer.
Page 445 IN CASE OF EMERGENCY General Information Power Distribution Center (PDC) The fuses protect electrical systems against excessive current. The Power Distribution Center is located in the engine compartment near the battery. This center contains cartridge When a device does not work, you must check the fuse fuses, mini fuses, and relays.
Page 446 444 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – – Spare 40 Amp Green – Starter – 5 Amp Tan Intelligent Battery Sensor (IBS) – 20 Amp Yellow Fuel Pump MTR/FPCM – 5 Amp Tan Security Gateway –...
Page 447 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – – Spare 30 Amp Pink – Central Body Controller (CBC) 1-INTERIOR LIGHTS – 20 Amp Yellow REAR WIPER Engine Control Module (ECM)/Powertrain Control – 10 Amp Red Module (PCM)/Motor Generator Unit (MGU) WAKE UP/ Power Pack Unit (PPU) WAKE UP Powertrain Control Module (PCM)/Engine Control...
Page 448 446 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description Electronic Stability Control (ESC)/Electric Hydraulic – 10 Amp Red Power Steering (EHPS)/Smart Bar Control Module (SBCM) WAKE UP 30 Amp Pink – BRAKE VAC PMP — If Equipped 30 Amp Pink –...
Page 449 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 10 Amp Red Occupant Restraint Controller ORC – 10 Amp Red HD ACC — If Equipped Digital (DSRC)/USB/InSide RearView Mirror – 10 Amp Red (ISRVM)/ Compass Module (CSGM) – 20 Amp Yellow CIGAR LTR –...
Page 450 448 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 40 Amp Green – HVAC BLOWER MTR Front – – Spare – – Spare Motor Generator Unit MGU Belt Starter Generator – 5 Amp Tan (BSG) — If Equipped –...
Page 451 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 60 Amp Yellow – GLOW PLUG — If Equipped 30 Amp Pink – UREA HTR CTRL UNIT — If Equipped – 10 Amp Red PM SENSOR — If Equipped 30 Amp Pink –...
Page 452 450 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description F102 – 15 Amp Blue DUAL USB PORT F103 – 15 Amp Blue HD ACCY #3 — If Equipped F104 – 15 Amp Blue PPU COOL PUMP — If Equipped Integrated Center Stack (ICS)/Heat Ventilation Air F105 –...
Page 453 IN CASE OF EMERGENCY JACKING AND TIRE CHANGING Jack Location The jack and lug wrench are located in the rear cargo area. To WARNING! remove jack and tools proceed as follows: • Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 454 452 IN CASE OF EMERGENCY 2. Remove the hardware storage cover by pinching the latch on the left side and pulling upward. Plastic Wing Nut Location 4. Remove tool kit and assemble tools. Hardware Storage Cover Latch 3. Turn the plastic wing nut counterclockwise to loosen the jack from the storage bin.
Page 455 IN CASE OF EMERGENCY 3. Remove the lug nuts with the lug wrench turning them Spare Tire Removal counterclockwise. If equipped, remove the locking lug 1. To remove the spare tire from the carrier, remove the tire nut with the lock key (located in the glove box) turning it cover, if equipped.
Page 456 454 IN CASE OF EMERGENCY Preparations For Jacking 1. Park on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid being hit when operating the jack or changing the wheel.
Page 457 IN CASE OF EMERGENCY Jacking Instructions WARNING! (Continued) • If working on or near a roadway, be extremely careful WARNING! of motor traffic. Carefully follow these tire changing warnings to help • To assure that spare tires, flat or inflated, are securely prevent personal injury or damage to your vehicle: stowed, spares must be stowed with the valve stem •...
Page 458 456 IN CASE OF EMERGENCY CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated. 1. Remove the spare tire, jack and tools from the stored loca- tion. 2. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground.
Page 459 IN CASE OF EMERGENCY 4. Operate the jack from the front or the rear of the vehicle. Place the jack under the axle tube, as shown. Do not raise the vehicle until you are sure the jack is fully engaged. Front Jacking Location Front Lifting Point...
Page 460 458 IN CASE OF EMERGENCY Rear Lifting Point Rear Jacking Location 5. Raise the vehicle by turning the jack screw clockwise. Raise the vehicle only until the tire just clears the surface and enough clearance is obtained to install the spare tire. Minimum tire lift provides maximum stability.
Page 461 IN CASE OF EMERGENCY 7. Mount the spare tire on the axle. 14. Secure the damaged wheel/tire on the spare tire carrier. Torque down lug nuts and locking lug nut. 8. Install the lug nuts with the cone-shaped end toward the wheel.
Page 462 460 IN CASE OF EMERGENCY Road Tire Installation MANUAL PARK RELEASE 1. Mount the road tire on the axle. WARNING! Always secure your vehicle by fully applying the 2. Install the remaining lug nuts with the cone shaped end parking brake before activating the Manual Park of the nut toward the wheel.
Page 463 IN CASE OF EMERGENCY Follow these steps to use the Manual Park Release: 1. Firmly apply the parking brake. 2. Using a small screwdriver or similar tool, remove the manual park release cover, located above the gear selector, to access the release tether strap. Tether Strap 4.
Page 464 462 IN CASE OF EMERGENCY To Reset The Manual Park Release: WARNING! 1. Pull upward on the tether strap, releasing it from the Do not attempt jump starting if the battery is frozen. It “locked” position. could rupture or explode and cause personal injury. 2.
Page 465 IN CASE OF EMERGENCY Preparations For Jump Start WARNING! (Continued) • Battery gas is flammable and explosive. Keep flame or sparks away from the battery. Do not use a booster battery or any other booster source with an output greater than 12 Volts. Do not allow cable clamps to touch each other.
Page 466 464 IN CASE OF EMERGENCY WARNING! • Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is ON. You can be injured by moving fan blades. • Remove any metal jewelry such as rings, watch bands and bracelets that could make an inadvertent electrical contact.
Page 467 IN CASE OF EMERGENCY 3. If using another vehicle to jump start the battery, park the Connecting The Jumper Cables vehicle within the jumper cable’s reach, apply the parking brake and make sure the ignition is OFF. WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result.
Page 468 466 IN CASE OF EMERGENCY 4. Connect the opposite end of the negative (-) jumper cable Disconnecting The Jumper Cables to a good engine ground (exposed metal part of the 1. Disconnect the negative (-) end of the jumper cable from discharged vehicle’s engine) away from the battery and the engine ground of the vehicle with the discharged the fuel injection system.
Page 469 IN CASE OF EMERGENCY NOTE: CAUTION! There are steps that you can take to slow down an impending Accessories plugged into the vehicle power outlets draw overheat condition: power from the vehicle’s battery, even when not in use • If your Air Conditioner (A/C) is on, turn it off. The A/C (i.e., cellular devices, etc.).
Page 470 468 IN CASE OF EMERGENCY FREEING A STUCK VEHICLE WARNING! Fast spinning tires can be dangerous. Forces generated by If your vehicle becomes stuck in mud, sand or snow, it can often excessive wheel speeds may cause damage, or even failure, of be moved using a rocking motion.
Page 471 IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing” in the “Starting And Operating”...
Page 472 470 IN CASE OF EMERGENCY CAUTION! CAUTION! • Do not use sling type equipment when towing. Vehicle • Front or rear wheel lifts must not be used (if the damage may occur. remaining wheels are on the ground). Internal damage to the transmission or transfer case will occur if a front •...
Page 473 IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) WARNING! • Do not use a chain for freeing a stuck vehicle. Chains This vehicle is equipped with an Enhanced Accident may break, causing serious injury or death. Response System. • Stand clear of vehicles when pulling with tow hooks. Please refer to “Occupant Restraint Systems”...
Page 474: Servicing And Maintenance
SERVICING AND MAINTENANCE On vehicles equipped with instrument cluster display, “Oil SCHEDULED SERVICING Change Required” will be displayed and a single chime will Your vehicle is equipped with an automatic oil change indi- sound, indicating that an oil change is necessary. cator system.
Page 475 SERVICING AND MAINTENANCE NOTE: Once A Month Or Before A Long Trip: Under no circumstances should oil change intervals exceed • Check the engine oil level. 10,000 miles (16,000 km), 12 months or 350 hours of engine • Check the windshield washer fluid level. run time, whichever comes first.
Page 476 474 SERVICING AND MAINTENANCE Maintenance Plan Required Maintenance Intervals Refer to the maintenance plan on the following pages for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: • Change oil and filter •...
Page 477 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first): Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints Inspect front suspension, tie rod ends, rear suspension, and replace if necessary Inspect the front and rear axle fluid Inspect the brake linings, replace as necessary Adjust parking brake on vehicles equipped with four...
Page 478 476 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first): Or Years: Or Kilometers: Additional Maintenance Replace engine air cleaner filter Replace air conditioning/cabin air filter Replace Spark Plugs – 2.0L Engine Replace spark plugs – 3.6L Engine Flush and replace the engine, intercooler (if equipped), battery (if equipped), and Motor Generator Unit (MGU) (if...
Page 479 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first): Or Years: Or Kilometers: Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more than 50% of your driving is at sustained high speeds during hot...
Page 480 478 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first): Or Years: Or Kilometers: Inspect and replace PCV valve if necessary Change front and rear axle fluid if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing 1.
Page 481 SERVICING AND MAINTENANCE Heavy Duty Use Of The Vehicle WARNING! • You can be badly injured working on or around a motor Change engine oil at 4,000 miles (6,500 km) or 350 hours of vehicle. Do only service work for which you have the engine run time if the vehicle is operated in a dusty and off knowledge and the right equipment.
Page 482 480 SERVICING AND MAINTENANCE ENGINE COMPARTMENT 2.0L Engine 1 — Power Distribution Center (Fuses) 7 — Power Pack Unit Pressure Reservoir Cap — If Equipped 2 — Battery 8 — Washer Fluid Reservoir Cap 3 — Engine Oil Dipstick 9 — Intercooler/Motor Generator Unit Coolant Reservoir — If Equipped 4 —...
Page 483 SERVICING AND MAINTENANCE 3.6L Engine 1 — Power Distribution Center (Fuses) 7 — Power Pack Unit Pressure Cap — If Equipped 2 — Battery 8 — Washer Fluid Reservoir Cap 3 — Engine Oil Dipstick 9 — Motor Generator Unit Coolant Reservoir — If Equipped 4 —...
Page 484 482 SERVICING AND MAINTENANCE Checking Oil Level Adding Washer Fluid To ensure proper lubrication of your vehicle's engine, the The fluid reservoir for the windshield washers and the rear engine oil must be maintained at the correct level. The engine window washer (if equipped) is shared.
Page 485 SERVICING AND MAINTENANCE Maintenance-Free Battery WARNING! (Continued) • Serious injury or death could result if you do not Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic mainte- disconnect both batteries. To learn how to properly nance required.
Page 486 484 SERVICING AND MAINTENANCE Pressure Washing WARNING! You can be badly injured working on or around a motor CAUTION! vehicle. Only do service work for which you have the Cleaning the engine compartment with a high pressure knowledge and the proper equipment. If you have any washer is not recommended.
Page 487 SERVICING AND MAINTENANCE Engine Oil Selection — 2.0L Engine CAUTION! Do not use chemical flushes in your engine oil as the For best performance and maximum protection under all types of operating conditions, the manufacturer only recom- chemicals can damage your engine. Such damage is not covered by the New Vehicle Limited Warranty.
Page 488 486 SERVICING AND MAINTENANCE Engine Oil Viscosity (SAE Grade) — 3.6L Engine Materials Added To Engine Oil Mopar SAE 0W-20 engine oil approved to FCA Material The manufacturer strongly recommends against the addi- Standard MS-6395 such as Pennzoil, Shell Helix or equiva- tion of any additives (other than leak detection dyes) to the lent is recommended for all operating temperatures.
Page 489 SERVICING AND MAINTENANCE Engine Air Cleaner Filter Engine Air Cleaner Filter Inspection and Replacement — Gasoline Engine Refer to the “Maintenance Plan” in this section for the proper Follow the recommended maintenance intervals as shown in maintenance intervals. the Maintenance Schedule in this section. NOTE: Engine Air Cleaner Filter Removal Be sure to follow the “Severe Duty Conditions”...
Page 490 488 SERVICING AND MAINTENANCE 2. Lift the air cleaner cover to access the air cleaner filter. 3. Remove the air cleaner filter element from the housing assembly. Air Cleaner Filter Cover Air Cleaner Filter 1 — Air Cleaner Filter Inspection Surface 2 —...
Page 491 SERVICING AND MAINTENANCE Engine Air Cleaner Filter Installation When inspecting accessory drive belts, small cracks that run across the ribbed surface of the belt, from rib to rib, are NOTE: considered normal. These are not a reason to replace a belt. Inspect and clean the housing if dirt or debris is present However, cracks running along a rib (not across) are not before replacing the air filter element.
Page 492 490 SERVICING AND MAINTENANCE Conditions that would require replacement: Air Conditioner Maintenance • Rib chunking (one or more ribs has separated from belt For best possible performance, your air conditioner should body) be checked and serviced by an authorized dealer at the start •...
Page 493 SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling — R–1234yf CAUTION! Do not use chemical flushes in your air conditioning R–1234yf Air Conditioning Refrigerant is a hydrofluo- system as the chemicals can damage your air conditioning roolefin (HFO) that is endorsed by the Environmental components.
Page 494 492 SERVICING AND MAINTENANCE The A/C air filter is located in the fresh air inlet behind the 3. Pivot the glove compartment downward. glove compartment. Perform the following procedure to 4. Disengage the two retaining tabs that secure the air filter replace the filter: access door to the HVAC housing.
Page 495 SERVICING AND MAINTENANCE 5. Remove the air filter from the HVAC air inlet housing. 6. Install the A/C air filter with the air filter position indica- Pull the filter elements out pinching them to the right for tors pointing in the same direction as removal. clearance.
Page 496 494 SERVICING AND MAINTENANCE 8. Rotate the glove compartment door back into position Body Lubrication ensuring you have properly engaged the travel damper. Locks and all body pivot points, including such items as seat tracks, door hinge pivot points and rollers, liftgate, tailgate, decklid, sliding doors and hood hinges, should be lubricated periodically with a lithium based grease, such as Mopar Spray White Lube to ensure quiet, easy operation and to...
Page 497 SERVICING AND MAINTENANCE The wiper blades and wiper arms should be inspected peri- Windshield Wiper Blades odically, not just when wiper performance problems are Clean the rubber edges of the wiper blades and the wind- experienced. This inspection should include the following shield periodically with a sponge or soft cloth and a mild points: nonabrasive cleaner.
Page 498 496 SERVICING AND MAINTENANCE 2. To disengage the wiper blade from the wiper arm, press Wiper Blade Removal/Installation the release tab on the wiper blade and while holding the CAUTION! wiper arm with one hand, slide the wiper blade down towards the base of the wiper arm.
Page 499 SERVICING AND MAINTENANCE 3. With the wiper blade disengaged, remove the wiper Rear Wiper Blade Removal/Installation blade from the wiper arm. 1. Open tailgate to access the wiper arm. 4. Gently lower the wiper arm onto the glass. Installing The Front Wipers 1.
Page 500 498 SERVICING AND MAINTENANCE 2. Lift wiper arm off of the glass and rotate wiper blade outward to disengage the wiper blade from the wiper arm. Wiper Blade Removed From Wiper Arm 1 — Wiper Blade Pivot Pin 2 — Wiper Arm Receptacle Wiper Blade And Wiper Arm 1 —...
Page 501 SERVICING AND MAINTENANCE Exhaust System WARNING! (Continued) • A hot exhaust system can start a fire if you park over The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust materials that can burn. Such materials might be grass system.
Page 502 500 SERVICING AND MAINTENANCE Under normal operating conditions, the catalytic converter Cooling System will not require maintenance. However, it is important to WARNING! keep the engine properly tuned to ensure proper catalyst operation and prevent possible catalyst damage. • You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator.
Page 503 SERVICING AND MAINTENANCE Coolant Checks Cooling System — Drain, Flush And Refill Check the engine, battery (if equipped), intercooler (if NOTE: equipped), and Motor Generator Unit (MGU) (if equipped) Some vehicles require special tools to add coolant properly. coolant (antifreeze) protection every 12 months (before the Failure to fill these systems properly could lead to severe onset of freezing weather, where applicable).
Page 504 502 SERVICING AND MAINTENANCE • Some vehicles require special tools to add coolant properly. Selection Of Coolant Failure to fill these systems properly could lead to severe Refer to “Fluids And Lubricants” in “Technical Specifica- internal engine damage. If any coolant is needed to be added tions”...
Page 505 SERVICING AND MAINTENANCE • Mix a minimum solution of 50% OAT engine coolant that Cooling System Pressure Cap meets the requirements of FCA Material Standard The cap must be fully tightened to prevent loss of engine MS.90032 and distilled water. Use higher concentrations coolant (antifreeze), and to ensure that engine coolant (anti- (not to exceed 70%) if temperatures below −34°F (−37°C) freeze) will return to the radiator from the coolant expansion...
Page 506 504 SERVICING AND MAINTENANCE Disposal Of Used Coolant Engine Coolant Level — 2.0L Used ethylene glycol-based coolant (antifreeze) is a regu- WARNING! lated substance requiring proper disposal. Check with your • Do not open hot engine cooling system. Never add engine local authorities to determine the disposal rules for your coolant (antifreeze) when the engine is overheated.
Page 507 SERVICING AND MAINTENANCE The radiator normally remains completely full, so there is no • Do not overfill the coolant expansion bottle. need to remove the radiator/coolant pressure cap unless • Check the coolant freeze point in the radiator and in the checking for engine coolant (antifreeze) freeze point or coolant expansion bottle.
Page 508 506 SERVICING AND MAINTENANCE If the brake fluid is abnormally low, check the system for Brake System leaks. In order to ensure brake system performance, all brake Refer to “Fluids And Lubricants” in “Technical Specifica- system components should be inspected periodically. Refer to the “Maintenance Plan”...
Page 509 SERVICING AND MAINTENANCE Fluid Level Check WARNING! (Continued) • Overfilling the brake fluid reservoir can result in Lubricant should be approximately 1/8 inch (3 mm) below the bottom edge of the oil fill hole. spilling brake fluid on hot engine parts, causing the brake fluid to catch fire.
Page 510 508 SERVICING AND MAINTENANCE Transfer Case Selection Of Lubricant Use only the manufacturer's recommended fluid. Refer to “Fluids And Lubricants” in “Technical Specifications” for further information. Fluid Level Check The fluid level should be to the bottom edge of the fill hole when the vehicle is in a level position.
Page 511 SERVICING AND MAINTENANCE Manual Transmission Automatic Transmission Selection Of Lubricant Selection Of Lubricant Use only manufacturer's recommended manual transmis- It is important to use the proper transmission fluid to ensure sion fluid. Refer to “Fluids And Lubricants” in “Technical optimum transmission performance and life. Use only the Specifications”...
Page 512 510 SERVICING AND MAINTENANCE Special Additives Fluid Level Check The manufacturer strongly recommends against using any The fluid level is preset at the factory and does not require special additives in the transmission. Automatic Transmis- adjustment under normal operating conditions. Routine sion Fluid (ATF) is an engineered product and its perfor- fluid level checks are not required;...
Page 513 SERVICING AND MAINTENANCE Fluid And Filter Changes Tire Markings Under normal operating conditions, the fluid installed at the factory will provide satisfactory lubrication for the life of the vehicle. Routine fluid and filter changes are not required. However, change the fluid and filter if the fluid becomes contaminated (with water, etc.), or if the transmission is disassembled for any reason.
Page 514 512 SERVICING AND MAINTENANCE NOTE: same as for P-Metric tires except for the letters “LT” that are molded into the sidewall preceding the size designa- • P (Passenger) — Metric tire sizing is based on US design tion. Example: LT235/85R16. standards.
Page 515 SERVICING AND MAINTENANCE EXAMPLE: 65, 85, 80 = Aspect ratio in percent (%) • Ratio of section height to section width of tire, or 10.5 = Section width in inches (in) R = Construction code • "R" means radial construction, or •...
Page 516 514 SERVICING AND MAINTENANCE EXAMPLE: Maximum Load – Maximum load indicates the maximum load this tire is designed to carry Maximum Pressure – Maximum pressure indicates the maximum permissible cold tire inflation pressure for this tire Tire Identification Number (TIN) The Tire Identification Number (TIN) may be found on one or both sides of the tire;...
Page 517 SERVICING AND MAINTENANCE EXAMPLE: 01 = Number representing the year in which the tire was manufactured (two digits) • 01 means the year 2001 • Prior to July 2000, tire manufacturers were only required to have one number to represent the year in which the tire was manufactured.
Page 518 516 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver's side door. Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recom- mended pressure for your vehicle.
Page 519 SERVICING AND MAINTENANCE Tire And Loading Information Placard Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire's load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pres- sures specified on the Tire and Loading Information placard in “Vehicle Loading”...
Page 520 518 SERVICING AND MAINTENANCE Steps For Determining Correct Load Limit— (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this (1) Locate the statement “The combined weight of occu- manual to determine how this reduces the available cargo pants and cargo should never exceed XXX kg or XXX lbs.”...
Page 521 SERVICING AND MAINTENANCE...
Page 522 520 SERVICING AND MAINTENANCE Safety WARNING! Overloading of your tires is dangerous. Overloading can WARNING! cause tire failure, affect vehicle handling, and increase • Improperly inflated tires are dangerous and can cause your stopping distance. Use tires of the recommended collisions.
Page 523 SERVICING AND MAINTENANCE Both underinflation and overinflation affect the stability of Tire Inflation Pressures the vehicle and can produce a feeling of sluggish response or The proper cold tire inflation pressure is listed on the driver's over responsiveness in the steering. side B-Pillar or rear edge of the driver's side door.
Page 524 522 SERVICING AND MAINTENANCE Check tire pressures more often if subject to a wide range of required for high-speed vehicle operation. Refer to an autho- outdoor temperatures, as tire pressures vary with tempera- rized tire dealer or original equipment vehicle dealer for ture changes.
Page 525 SERVICING AND MAINTENANCE Tire Repair Run Flat Tires — If Equipped If your tire becomes damaged, it may be repaired if it meets Run Flat tires allow you the capability to drive 50 miles the following criteria: (80 km) at 50 mph (80 km/h) after a rapid loss of inflation pressure.
Page 526 524 SERVICING AND MAINTENANCE Tire Spinning Tread Wear Indicators When stuck in mud, sand, snow, or ice conditions, do not Tread wear indicators are in the original equipment tires to spin your vehicle's wheels above 30 mph (48 km/h) or for help you in determining when your tires should be replaced.
Page 527 SERVICING AND MAINTENANCE Refer to “Replacement Tires” in this section for further infor- NOTE: mation. Wheel Valve Stem must be replaced as well when installing new tires due to wear and tear in existing tires. Life Of Tire Keep dismounted tires in a cool, dry place with as little expo- The service life of a tire is dependent upon varying factors sure to light as possible.
Page 528 526 SERVICING AND MAINTENANCE It is recommended to replace the two front tires or two rear WARNING! (Continued) tires as a pair. Replacing just one tire can seriously affect • Never use a tire with a smaller load index or capacity, your vehicle’s handling.
Page 529 SERVICING AND MAINTENANCE Summer Or Three Season Tires — If Equipped Snow Tires Summer tires provide traction in both wet and dry condi- Some areas of the country require the use of snow tires tions, and are not intended to be driven in snow or on ice. If during the Winter.
Page 530 528 SERVICING AND MAINTENANCE Spare Tires — If Equipped Compact Spare Tire — If Equipped The compact spare is for temporary emergency use only. NOTE: You can identify if your vehicle is equipped with a compact For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to “Tire Service Kit”...
Page 531 SERVICING AND MAINTENANCE Limited Use Spare — If Equipped WARNING! Compact and collapsible spares are for temporary The limited use spare tire is for temporary emergency use emergency use only. With these spares, do not drive only. This tire is identified by a label located on the limited more than 50 mph (80 km/h).
Page 532 530 SERVICING AND MAINTENANCE When cleaning extremely dirty wheels including excessive Wheel And Wheel Trim Care brake dust, care must be taken in the selection of tire and All wheels and wheel trim, especially aluminum and chrome wheel cleaning chemicals and equipment to prevent damage plated wheels, should be cleaned regularly using mild to the wheels.
Page 533 SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or Low Gloss • Original equipment 255/70R18 and LT285/70R17 tire Clear Coat Wheels sizes are not chainable. • The use of S-class snow chains is permitted with the use of CAUTION! 245/75R17 tires on size 17 x 7.5 ET44.45 wheels.
Page 534 532 SERVICING AND MAINTENANCE The suggested rotation method is the “rearward-cross” CAUTION! (Continued) shown in the following diagram. • Drive cautiously and avoid severe turns and large bumps, especially with a loaded vehicle. • Do not drive for a prolonged period on dry pavement. •...
Page 535 SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION UNIFORM Traction Grades TIRE QUALITY GRADES The Traction grades, from highest to lowest, are AA, A, B, The following tire grading categories were established by and C. These grades represent the tire's ability to stop on the National Highway Traffic Safety Administration.
Page 536 534 SERVICING AND MAINTENANCE Sustained high temperature can cause the material of the STORING THE VEHICLE tire to degenerate and reduce tire life, and excessive WARNING! temperature can lead to sudden tire failure. The grade C corresponds to a level of performance, which all •...
Page 537 SERVICING AND MAINTENANCE CAUTION! If the negative battery cables are not isolated properly it can cause a potential power spike or surge in the system, resulting in damage to essential electrical components. If you are storing your vehicle for more than 21 days, we recommend that you take the following steps to minimize the drain on your vehicle's battery: •...
Page 538 536 SERVICING AND MAINTENANCE NOTE: What Causes Corrosion? • You must isolate the supplemental battery connection Corrosion is the result of deterioration or removal of paint point, as well as the main battery terminal from the post, and protective coatings from your vehicle. as shown in the image, to fully de-energize both batteries The most common causes are: for storage.
Page 539 SERVICING AND MAINTENANCE Do not use abrasive cleaning components, solvents, steel Special Care wool or other aggressive material to clean the lenses. • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month. Preserving The Bodywork •...
Page 540 538 SERVICING AND MAINTENANCE Appearance Care For Fabric Top Models CAUTION! To maintain the appearance of your vehicle's interior trim Failure to follow these cautions may cause interior water and top, follow these precautions: damage, stains or mildew on the top material: •...
Page 541 Mopar Jeep Soft Glass Window Cleaner or window plastic retainer should be cleaned and lubricated equivalent will safely clean all plastic windows without regularly.
Page 542 540 SERVICING AND MAINTENANCE 2. Pull the carpet out from the front to the rear. INTERIORS Carpet Removal Front Carpets (Two And Four Door Models): 1. Remove the front grommets. Front Carpet Pulled Away Front Carpet 1 — Grommets...
Page 543 SERVICING AND MAINTENANCE 3. Remove the grommets under the front seat. First for the 4. Under the back of the front seat, open the carpet split and rear carpet and then the front carpet. then pull out the rear edge and slide the carpet to the front (do not remove the harness).
Page 544 542 SERVICING AND MAINTENANCE 5. Finally open the carpet split around seat bracket and then Rear Carpet (Four Door Models): remove the last two grommets. 1. Remove the grommets under the front seat (one left and one right). 2. Then pull the carpet out, to the rear and open the carpet split around the front seats brackets.
Page 545 SERVICING AND MAINTENANCE 3. Remove the grommets under the rear seat (one left and Rear Carpet (Two Door Models): one right). First the grommet for the cargo carpet and 1. Remove the rear seats. then the rear carpet. 2. Remove the sides grommets (one left and one right). First 4.
Page 546 544 SERVICING AND MAINTENANCE 4. Then pull the carpet out to the rear and open the carpet Cargo Carpet (Four Door Models): split around the front seats brackets. 1. Remove the grommets under the rear seat (one left and one right). 2.
Page 547 SERVICING AND MAINTENANCE 3. Remove the carpet under the load floor and the side Cargo Carpet (Four Door Models) With Gap Hider: support and then pull the carpet out. 1. Remove the grommets under the rear seat (one left and one right).
Page 548 546 SERVICING AND MAINTENANCE 3. When reinstalling carpet please preform these steps in reverse order making sure that the carpet is tucked under the scuffs, B pillar, console, and refasten grommets. Side Carpet (Four Door Models): 1. Remove the side grommet (one left and one right). 2.
Page 549 SERVICING AND MAINTENANCE Side Carpet (Two Door Models): Seat Belt Maintenance 1. Remove the side grommet and then the lower one (left Do not bleach, dye or clean the belts with chemical solvents and right). or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric.
Page 550 548 SERVICING AND MAINTENANCE Plastic And Coated Parts Leather Parts Use Mopar Total Clean to clean vinyl upholstery. Mopar Total Clean is specifically recommended for leather upholstery. CAUTION! Your leather upholstery can be best preserved by regular • Direct contact of air fresheners, insect repellents, cleaning with a damp soft cloth.
Page 551 SERVICING AND MAINTENANCE NOTE: Glass Surfaces If equipped with light colored leather, it tends to show any All glass surfaces should be cleaned on a regular basis with foreign material, dirt, and fabric dye transfer more so than Mopar Glass Cleaner, or any commercial household-type darker colors.
Page 552: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER The Vehicle Identification Number (VIN) is found on the left front corner of the A pillar, visible from outside of the vehicle through the windshield. This number also appears under- body, on the right side of the frame rail near the center of the vehicle, as well as on the Automobile Information Disclosure Label affixed to a window on your vehicle.
Page 553 TECHNICAL SPECIFICATIONS BRAKE SYSTEM Torque Specifications Your vehicle is equipped with dual hydraulic brake systems. Lug Nut/Bolt **Lug Nut/Bolt Lug Nut/Bolt If either of the two hydraulic systems loses normal capa- Torque Size Socket Size bility, the remaining system will still function. However, 130 Ft-Lbs M14 x 1.50 22 mm...
Page 554 552 TECHNICAL SPECIFICATIONS Spare tire torque is for the spare tire carrier located on the tailgate. Torque Patterns After 25 miles (40 km), check the lug nut/bolt torque to be sure that all the lug nuts/bolts are properly seated against the wheel.
Page 555 TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS 3.6L Engine This engine is designed to meet all emissions regula- 2.0L Engine tions and provide satisfactory fuel economy and This engine is designed to meet all emission performance when using high-quality unleaded requirements, and provide satisfactory fuel “Regular”...
Page 556 554 TECHNICAL SPECIFICATIONS Indiscriminate use of fuel system cleaning agents should be Reformulated Gasoline avoided. Many of these materials intended for gum and Many areas of the country require the use of cleaner burning varnish removal may contain active solvents or similar gasoline referred to as “Reformulated Gasoline”.
Page 557 TECHNICAL SPECIFICATIONS Do Not Use E-85 In Non-Flex Fuel Vehicles MMT In Gasoline Non-Flex Fuel Vehicles (FFV) are compatible with gasoline Methylcyclopentadienyl Manganese Tricarbonyl (MMT) is a containing up to 15% ethanol (E-15). Use of gasoline with manganese-containing metallic additive that is blended into higher ethanol content may void the New Vehicle Limited some gasoline to increase octane.
Page 558 556 TECHNICAL SPECIFICATIONS Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to over- Carbon monoxide (CO) in exhaust gases is deadly. heat. If you notice a pungent burning odor or some Follow the precautions below to prevent carbon light smoke, your engine may be out of tune or monoxide poisoning:...
Page 559 TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) Two Door Models 17.5 Gallons 66 Liters Four Door Models 21.5 Gallons 81 Liters Engine Oil with Filter 2.0L Engine 5 Quarts 4.73 Liters 3.6L Engine 5 Quarts 4.73 Liters Cooling System * 2.0L Engine (Mopar Antifreeze/Engine Coolant 10 Year/ 10.3 Quarts 9.7 Liters...
Page 560 558 TECHNICAL SPECIFICATIONS Metric 3.6L Motor Generator Unit (MGU) (Mopar Antifreeze/ 1.9 Quarts 1.8 Liters Engine Coolant 10 Year/150,000 Mile Formula or equivalent) 3.6L Battery Coolant (Mopar Antifreeze/Engine Coolant 2.5 Quarts 2.4 Liters 10 Year/150,000 Mile Formula or equivalent) * Includes coolant recovery bottle filled to MAX level. FLUIDS AND LUBRICANTS Engine Component...
Page 561 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar API SN PLUS Certified SAE 5W-30 Full Synthetic Engine Oil which meets the requirements of FCA Material Standard MS-13340. Equivalent full synthetic SAE 5W-30 engine oil can be used if it meets API SN PLUS Certification.
Page 562 560 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) • Mixing of engine coolant (antifreeze) other than speci- • Do not use water alone or alcohol-based engine coolant fied Organic Additive Technology (OAT) engine (antifreeze) products. Do not use additional rust inhib- coolant (antifreeze), may result in engine damage and itors or antirust products, as they may not be compat- may decrease corrosion protection.
Page 563 TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part Use only Mopar ZF 8&9 Speed Automatic Transmission Fluid (ATF) or equivalent. Failure to use the correct fluid may affect the function or Automatic Transmission – If Equipped performance of your transmission. Manual Transmission –...
Page 564: Multimedia
MULTIMEDIA UCONNECT SYSTEMS For detailed information about your Uconnect system, refer to your Uconnect Owner’s Manual Supplement. NOTE: Uconnect screen images are for illustration purposes only and may not reflect exact software for your vehicle. DRAG & DROP MENU BAR The Uconnect features and services in the main menu bar are easily changed for your convenience.
Page 565 MULTIMEDIA CYBERSECURITY WARNING! • It is not possible to know or to predict all of the Your vehicle may be a connected vehicle and may be possible outcomes if your vehicle’s systems are equipped with both wired and wireless networks. These breached.
Page 566 564 MULTIMEDIA NOTE: UCONNECT SETTINGS • FCA US LLC or your dealer may contact you directly The Uconnect system uses a combination of buttons on the regarding software updates. touchscreen and buttons on the faceplate located on the • To help further improve vehicle security and minimize the center of the instrument panel.
Page 567 MULTIMEDIA NOTE: Customer Programmable Features — Uconnect 3 When pressing the touchscreen buttons, only one selection Settings can be made at a time. When making a setting’s menu selection, press the button on the touchscreen to enter the desired menu screen. Once in the desired menu, select the preferred setting option by pressing the corresponding button.
Page 568 566 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Español Français Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode...
Page 569 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the vehicle displays to metric units of measurement. • The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L) and “Pressure” (kPa, or bar) units of measurement independently.
Page 570 568 MULTIMEDIA Safety/Assistance After pressing the Safety/Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning — Warning Only Warning & Braking If Equipped Forward Collision Warning Near Sensitivity — If Equipped ParkView Backup Camera Delay NOTE:...
Page 571 MULTIMEDIA Setting Name Selectable Options Blind Spot Alert — If Lights Lights & Chime Equipped NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor alignment. A sensor that is misaligned results in the Blind Spot Monitor (BSM) not operating to specification.
Page 572 570 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned or or off. The feature is only available if allowed by law in the country of the vehicle purchase. Flash Lights With Lock —...
Page 573 MULTIMEDIA Setting Name Selectable Options Horn With Remote Start — If Equipped Remote Door Unlock/Door Unlock Driver NOTE: When “Driver” is selected, only the driver's door will unlock on the first push of the key fob unlock button; you must push the key fob unlock button twice to unlock the passengers’...
Page 574 572 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Equalizer Bass Treble Levels NOTE: When in this display, you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the + and – setting buttons or by selecting any point on the scale between the + and –...
Page 575 MULTIMEDIA Setting Name Selectable Options NOTE: The “Loudness” feature improves sound quality at lower volumes when enabled. AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset” feature provides the ability to adjust the audio level for portable devices connected through the AUX input.
Page 576 574 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Channel Skip List of Channels NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude unde- sirable channels while scanning.
Page 577 MULTIMEDIA Restore Settings After pressing the Restore Settings button on the touchscreen, the following settings will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected, it will reset all settings to their default settings. Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following settings will be available: Setting Name...
Page 578 576 MULTIMEDIA NOTE: Customer Programmable Features — Uconnect 4 Depending on the vehicle’s options, feature settings may Settings vary. When making a selection, press the button on the touch- screen to enter the desired menu. Once in the desired menu, press and release the preferred setting “option”...
Page 579 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Español Français Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto...
Page 580 578 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measurement. • The “Custom” option allows setting the “Distance, Fuel Consumption” (MPG (US), MPG (UK), L/100km, or km/L),“Pres- sure”...
Page 581 MULTIMEDIA Setting Name Selectable Options NOTE: The “Set Time Hours” feature allows you to adjust the hours. Set Time Minutes NOTE: The “Set Time Minutes” feature allows you to adjust the minutes. 12 hrs 24 hrs Time Format Camera After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay...
Page 582 580 MULTIMEDIA Setting Name Selectable Options NOTE: The “ParkView Backup Camera Active Guide Lines” feature overlays the Rear Backup Camera image with active, or dynamic, grid lines to help illustrate the width of the vehicle and its projected backup path, based on the steering wheel posi- tion when the option is checked.
Page 583 MULTIMEDIA Setting Name Selectable Options Forward Collision Warning Sensitivity — If Near Equipped NOTE: Sets the distance in which a Forward Collision Warning occurs. ParkSense — If Equipped Sound Sound & Display Rear ParkSense Volume Medium High Hill Start Assist Blind Spot Alert —...
Page 584 582 MULTIMEDIA Setting Name Selectable Options Daytime Running Lights NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchase. Auto Dim High Beams —...
Page 585 MULTIMEDIA Setting Name Selectable Options Auto Door Locks — If Equipped NOTE: When this feature is selected, all doors will lock automatically when the vehicle reaches a speed of 12 mph (20 km/h). Engine Off Options — If Equipped After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Doors On Engine Off Power Delay...
Page 586 584 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance & Fade Speaker Icon NOTE: When in this display, you may adjust the “Balance & Fade” of the audio by pressing and dragging the Speaker icon toward any location in the box.
Page 587 MULTIMEDIA Setting Name Selectable Options NOTE: This feature provides the ability to adjust the audio level for portable devices connected through the AUX input. Auto Play NOTE: The “Auto Play” feature automatically starts playing audio when a USB device is connected and turned on. Phone/Bluetooth®...
Page 588 586 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tune Start NOTE: The “Tune Start” feature begins playing the current song from the beginning when you tune to a music channel using one of the 12 presets, so you can enjoy the complete song.
Page 589 MULTIMEDIA Restore Settings After pressing the Restore Settings button on the touchscreen, the following settings will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When this feature is selected it will reset all settings to their default settings. Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following settings will be available: Setting Name...
Page 590 588 MULTIMEDIA NOTE: Customer Programmable Features — Uconnect Depending on the vehicle’s options, feature settings may 4C/4C NAV Settings vary. When making a selection, press the button on the touch- screen to enter the desired menu. Once in the desired menu, press and release the preferred setting “option”...
Page 591 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Language English Español Français NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 592 590 MULTIMEDIA Setting Name Selectable Options NOTE: If the Display Mode setting is set to “Auto”, this setting is unavailable. To make changes to the "Display Brightness With Headlights OFF" setting, the headlights must be off and the interior dimmer switch must not be in the "party" or "parade" position.
Page 593 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measurement. • The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L), “Pressure” (kPa, or bar), and “Temperature”...
Page 594 592 MULTIMEDIA Clock After pressing the Clock button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS — If Equipped Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. The Sync Time With GPS button on the touchscreen must be unchecked.
Page 595 MULTIMEDIA Camera After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to 10 seconds after the vehicle is shifted out of REVERSE.
Page 596 594 MULTIMEDIA Safety & Driving Assistance After pressing the Safety & Driving Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning — If Equipped Warning Only Warning & Braking NOTE: Changing the FCW status to “Off” prevents the system from warning you of a possible collision with the vehicle in front of you.
Page 597 MULTIMEDIA Setting Name Selectable Options Blind Spot Alert — If Equipped Lights Lights & Chime NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor alignment. A sensor that is misaligned will result in the BSM not operating to specification.
Page 598 596 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchase. Flash Lights With Lock — If Equipped Interior Ambient Lights NOTE: The “Interior Ambient Lights”...
Page 599 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Auto Unlock On Exit” feature is selected, all doors will unlock when the vehicle is stopped, the transmission is in the PARK or NEUTRAL position, and the driver's door is opened. Flash Lights With Lock Sound Horn With Lock —...
Page 600 598 MULTIMEDIA Auto Comfort Systems — If Equipped After pressing the Auto-On Comfort Systems button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated Seat & Steering Wheel Remote Start All Starts With Vehicle Start — If Equipped NOTE: When this feature is selected the driver’s heated seat and heated steering wheel will automatically turn on when tempera- tures are below 40°F (4.4°C).
Page 601 MULTIMEDIA Engine Off Options After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Doors On Engine Off Power Delay Doors Off Engine Off Power Delay Headlight Off Delay Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options...
Page 602 600 MULTIMEDIA Setting Name Selectable Options NOTE: When in this display, you may adjust the Uconnect system’s ability to increase audio volume to compensate for increased speeds and road noise. Select the desired setting from Off to 3 to increase the audio volume as speeds increase. AUX Volume Offset —...
Page 603 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tune Start NOTE: The “Tune Start” feature begins playing the current song from the beginning when you tune to a music channel using one of the 12 presets, so you can enjoy the complete song.
Page 604 602 MULTIMEDIA Reset After pressing the Reset button on the touchscreen, the following settings will be available: Setting Name Selectable Options Reset App Drawer Cancel Restore Apps Back Next NOTE: Restoring Apps will delete all installed apps. This feature is used if there is an issue using or installing apps. To restore apps, press the Next button in the pop-up screen.
Page 605 MULTIMEDIA System Information After pressing the System Information button on the touchscreen, the following settings will be available: Setting Name Selectable Options Software Licenses Software Information Screen NOTE: When this feature is selected, a “Licensing Information” screen will appear, displaying a licensing information website for the radio.
Page 606 604 MULTIMEDIA OFF-ROAD PAGES — IF EQUIPPED Your vehicle is equipped with Off-Road Pages, which provides the vehicle status while operating on-off road conditions. It supplies information relating to the vehicle ride height, the status of the transfer case, the pitch and roll of the vehicle (if equipped).
Page 607 MULTIMEDIA Off-Road Pages Status Bar The Off-Road Pages Status Bar is located along the bottom of Off-Road Pages and is present in each of the three selectable page options. It provides continually updating information for the following items: • Current Transfer Case Status •...
Page 608 606 MULTIMEDIA Drivetrain The Drivetrain page displays information concerning the vehicle’s drivetrain. The following information is displayed: • Steering angle in degrees • Status of Transfer Case • Status of the Rear Axles — If Equipped Drivetrain Menu 2WD/4WD 1 — Steering Angle 2 —...
Page 609 MULTIMEDIA Pitch & Roll Accessory Gauge The Accessory Gauge page displays the current status of the The Pitch & Roll page displays the vehicle’s current pitch vehicle’s Coolant Temperature, Oil Temperature, Oil Pressure (Gas (angle up and down) and roll (angle side to side) in degrees. Vehicles Only), Transmission Temperature, and Battery Voltage.
Page 610 608 MULTIMEDIA Pushing the center button will make the radio switch STEERING WHEEL AUDIO CONTROLS between the various modes available (AM/FM/SAT/CD/ The remote sound system controls are located on the rear USB/AUX, etc.). surface of the steering wheel. Reach behind the wheel to The left-hand control is a rocker-type switch with a access the switches.
Page 611 MULTIMEDIA For example, if a device is plugged into the Type A USB port and AUX/USB/MP3 CONTROL another device is plugged into the Type C USB port, a message The Media Hub is located on the instrument panel, below the will appear and allow you to select which device to use.
Page 612 610 MULTIMEDIA Located inside the center console, a second USB Port allows you to play music from iPod®/MP3 players or USB devices through your vehicle’s sound system. Media Hub 1 — AUX Port 2 — Type C USB Port 3 — Type A USB Port Center Console USB...
Page 613 MULTIMEDIA A third and fourth USB Ports (if equipped) are located When a new device or smartphone is plugged into the USB behind the center console, above the power inverter. One is ports, the following message may display depending on the a charge only port, and can only charge USB devices.
Page 614 612 MULTIMEDIA Phone Plugged In Message Screen Phone or USB Plugged In Message Screen WARNING! Do not plug in or remove any external device while driving. Failure to follow this warning could result in a collision.
Page 615 MULTIMEDIA The radio manufacturer believes the internal wireless radio RADIO OPERATION AND MOBILE PHONES is safe for use by consumers. The level of energy emitted is Under certain conditions, the mobile phone being on in your far less than the electromagnetic energy emitted by wireless vehicle can cause erratic or noisy performance from your devices such as mobile phones.
Page 616 614 MULTIMEDIA Le présent appareil est conforme aux CNR d`Innovation, NOTE: Science and Economic Development applicables aux appar- • This equipment has been tested and found to comply with eils radio exempts de licence. L'exploitation est autorisée aux the limits for a Class B digital device, pursuant to Part 15 deux conditions suivantes: of the FCC Rules.
Page 617 MULTIMEDIA UCONNECT VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 3, Uconnect 4, or Uconnect 4C/4C NAV system. Uconnect 4 Uconnect 3...
Page 618 616 MULTIMEDIA Get Started All you need to control your Uconnect system with your voice are the buttons on your steering wheel. 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instruc- tions. 2. Reduce background noise. Wind noise and passenger conversations are examples of noise that may impact recognition.
Page 619 MULTIMEDIA 4. Each time you give a Voice Command, you must first Basic Voice Commands push either the Voice Recognition (VR) or Phone button, The basic Voice Commands below can be given at any point wait until after the beep, then say your Voice Command. while using your Uconnect system.
Page 620 618 MULTIMEDIA TIP: At any time, if you are not sure of what to say or want to learn a Voice Command, push the VR button and say “Help”. The system provides you with a list of commands. Uconnect 4 Radio Uconnect 3 Radio...
Page 621 MULTIMEDIA Media Uconnect offers connections via USB, Bluetooth® and auxil- iary ports (if equipped). Voice operation is only available for connected USB and iPod® devices. (Remote CD player optional and not available on all vehicles). Push the VR button on the steering wheel. After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist/album/song/ genre.
Page 622 620 MULTIMEDIA TIP: Press the Browse button on the touchscreen to see all of the music on your iPod® or USB device. Your Voice Command must match exactly how the artist, album, song and genre information is displayed. Uconnect 4 Media Uconnect 3 Media...
Page 623 MULTIMEDIA Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready to make a phone call. You may have to wait for a few more moments to issue a Voice Command for hands-free calling.
Page 624 622 MULTIMEDIA TIP: When providing a Voice Command, push the VR button on the steering wheel or Phone button and say “Call”, then pronounce the name exactly as it appears in your phone book. When a contact has multiple phone numbers, you can say “Call John Smith work/home/cell/ect.”...
Page 625 MULTIMEDIA 1. Once an incoming text message is read to you, push the VR button or Phone button (if enabled). After the beep, say: “Reply”. 2. Listen to the Uconnect prompts. After the beep, repeat one of the pre-defined messages and follow the system prompts.
Page 626 624 MULTIMEDIA TIP: TIP: Your mobile phone must have the full implementation of the Voice Text Reply is not compatible with iPhone®, but if your Message Access Profile (MAP) to take advantage of this vehicle is equipped with Siri® Eyes Free, you can use your feature.
Page 627 MULTIMEDIA TIP: Voice Command for climate may only be used to adjust the interior temperature of your vehicle. Voice Command will not work to adjust the heated seats or steering wheel (if equipped). Uconnect 4C/4C NAV With 8.4-Inch Display Climate Uconnect 4 With 7-inch Display Climate...
Page 628 626 MULTIMEDIA Navigation (4C NAV) — If Equipped The Uconnect navigation feature helps you save time and become more productive when the system shows you exactly how to get to where you want to go. 1. To enter a destination, push the VR button on the steering wheel.
Page 629 MULTIMEDIA SOS Call SiriusXM Guardian™ (4C/4C NAV) — If Equipped Remote Door Lock/Unlock CAUTION! Some SiriusXM Guardian™ services, including SOS Send & Go Call and Roadside Assistance Call will NOT work without an operable LTE (voice/data) or 4G (data) Vehicle Finder network connection.
Page 630 628 MULTIMEDIA Register (4C/4C NAV) Mobile App (4C/4C NAV) To unlock the full potential of SiriusXM Guardian™ in your You’re only a few steps away from a connected car experi- vehicle, you must activate your SiriusXM Guardian™ services. ence. 1. Press the Apps icon on the bottom of your in-vehicle touchscreen.
Page 631 MULTIMEDIA 2. Once on the “Remote” screen, you can begin using SiriusXM® Travel Link (4C NAV) Remote Door Lock/Unlock, Remote Vehicle Start, and Need to find a gas station, view local movie listings, check a activate your horn and lights remotely, if equipped. sports score or the 5-day weather forecast? SiriusXM®...
Page 632 630 MULTIMEDIA TIP: Siri® Eyes Free Traffic alerts are not accessible with Voice Command. Traffic Available on iPhone® 4s and later alerts provide you with an alternate route to help you avoid construction or delays from reported traffic incidents. Use Siri lets you use your voice to send text messages, schedule your touchscreen to accept or decline the recommended meetings, select media, place phone calls and much more.
Page 633 MULTIMEDIA To begin, ensure Siri is enabled on your iPhone®. Pair your Siri-enabled device to your Uconnect System. Push and hold, then release the Uconnect Voice Recognition (VR) button on the steering wheel. After you hear a double beep you can ask Siri to play podcasts and music, get directions, read text messages, and many other useful requests.
Page 634 632 MULTIMEDIA Using Do Not Disturb Android Auto™ — If Equipped With Do Not Disturb, you can disable notifications from NOTE: incoming calls and texts, allowing you to keep your eyes on Feature availability depends on your carrier and mobile the road and hands on the wheel.
Page 635 MULTIMEDIA • Phone • Text Messages • Additional Apps Android Auto™ On 8.4-inch Display Android Auto™ On 7-inch Display Refer to your Uconnect Owner’s Manual Supplement for further information. NOTE: Requires compatible smartphone running Android™ 5.0 (Lollipop) or higher and download app on Google Play. Android™, Android Auto™, and Google Play are trade- marks of Google Inc.
Page 636 634 MULTIMEDIA • Messages Apple CarPlay® — If Equipped • Maps NOTE: Feature availability depends on your carrier and mobile • Additional Apps phone manufacturer. Some Apple CarPlay® features may or may not be available in every region and/or language. Apple CarPlay®...
Page 637 MULTIMEDIA General Information The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: This device complies with Part 15 of the FCC Rules and with Innovation, Science, and Economic Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1.
Page 638 636 MULTIMEDIA La operación de este equipo está sujeta a las siguientes dos Google Inc. SiriusXM® and all related marks and logos are condiciones: trademarks of SiriusXM® Radio Inc. 1. es posible que este equipo o dispositivo no cause interfer- Uconnect System Support: encia perjudicial y •...
Page 639: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with the service Prepare For The Appointment advisor and list the items in order of priority.
Page 640 638 CUSTOMER ASSISTANCE This is why you should always talk to an authorized dealer FCA Canada Inc. Customer Center service manager first. Most matters can be resolved with this P.O. Box 1621 process. • If for some reason you are still not satisfied, talk to the Windsor, Ontario N9A 4H6 general manager or owner of the authorized dealer.
Page 641 CUSTOMER ASSISTANCE Owner Identification Card in the mail within three weeks of Customer Assistance For The Hearing Or Speech the vehicle delivery date. If you have any questions about the Impaired (TDD/TTY) service contract, call the manufacturer's Service Contract To assist customers who have hearing difficulties, the manu- National Customer Hotline at 1-800-521-9922 (Canadian resi- facturer has installed special Telecommunication Devices for dents, call (800) 465-2001 English / (800) 387-9983 French).
Page 642 640 CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS WARNING! Engine exhaust (internal combustion engines only), In The 50 United States And Washington, D.C. some of its constituents, and certain vehicle components If you believe that your vehicle has a defect that could contain, or emit, chemicals known to the State of cause a crash or cause injury or death, you should imme- California to cause cancer and birth defects, or other...
Page 643 CUSTOMER ASSISTANCE Diagnostic Procedure Manuals In Canada If you believe that your vehicle has a safety defect, you Diagnostic Procedure Manuals are filled with diagrams, charts and detailed illustrations. These practical manuals should contact the Customer Service Department imme- make it easy for students and technicians to find and fix diately.
Page 644 INDEX Air Conditioning Filter.............92, 491 About Your Brakes ..............551 Air Conditioning System ............90 Adaptive Cruise Control (ACC) (Cruise Control) .....372 Air Conditioning, Operating Tips ..........90 Adding Engine Coolant (Antifreeze) ........502 Air Filter ...................487 Adding Fuel ................403 Air Pressure Additives, Fuel ................554 Tires..................521 Air Bag Alarm...
Page 645 Automatic Headlights ..............70 Brake Control System .............234 Automatic High Beams ............69 Brake Fluid ...............506, 561 Automatic Temperature Control (ATC) ........90 Brake System..............506, 551 Automatic Transmission............341 Anti-Lock (ABS)..............551 Adding Fluid ...............511 Fluid Check ................506 Fluid And Filter Change ............511 Master Cylinder..............506 Fluid Change................511 Parking..................333 Fluid Level Check ............509, 510...
Page 646 Cellular Phone .................613 Compact Spare Tire ..............528 Center High Mounted Stop Light.........442 Connector Certification Label..............405 UCI ..................609 Chains, Tire................531 Universal Consumer Interface (UCI)........609 Changing A Flat Tire ..............511 Console ..................191 Chart, Tire Sizing ..............512 Floor ..................191 Check Engine Light (Malfunction Indicator Light) ...231 Contract, Service..............639 Checking Your Vehicle For Safety........322 Cooling Pressure Cap (Radiator Cap)........503...
Page 647 Drag And Drop Menu ............562 Daytime Running Lights ............68 Driver’s Seat Back Tilt ............48, 50 Dealer Service ................484 Driving..................418 Defroster, Windshield ............323 Dual Top..................95 Delay (Intermittent) Wipers ............74 Diagnostic System, Onboard..........230 Electric Brake Control System ..........234 Dimmer Switch Anti-Lock Brake System .............233 Headlight................69 Electronic Roll Mitigation ..........236, 246 Dipsticks...
Page 648 Break-In Recommendations ..........332 Compartment...............480, 481 Fabric Care ................538 Compartment Identification........480, 481 Fabric Top.................538 Coolant (Antifreeze) ............558 Filters Cooling .................500 Air Cleaner ................487 Exhaust Gas Caution ..........322, 556 Air Conditioning ............92, 491 Fails To Start ................331 Engine Oil..............486, 558 Flooded, Starting ..............331 Engine Oil Disposal ............486 Fuel Requirements ............553, 557 Flashers...
Page 649 Fog Lights, Service..............439 Specifications ...............558 Fold And Tumble Rear Seat ............54 Tank Capacity ..............557 Fold-Flat Seats ................48 Fueling ..................403 Folding Rear Seats ..............53 Fuses..................442 Folding Windshield ..............174 Forward Collision Warning ..........254 Garage Door Opener (HomeLink)........183 Four Wheel Drive..............349 Gas Cap (Fuel Filler Cap)..........403, 404 Operation................
Page 650 Heated Mirrors................67 Interior And Instrument Lights ..........71 Heated Steering Wheel.............63 Interior Appearance Care ............540 High Beam/Low Beam Select (Dimmer) Switch ....69 Interior Lights ................71 Hill Descent Control ...............240 Intermittent Wipers (Delay Wipers)........74 Hill Descent Control Indicator..........240 Introduction ................13 Hill Start Assist................243 Inverter Hitches Power ..................196...
Page 651 Hill Descent Control Indicator ..........240 Lane Change Assist ..............71 Interior ..................71 Lap/Shoulder Belts ..............269 Lights On Reminder..............71 Latches..................325 Malfunction Indicator (Check Engine)......223 Hood ..................179 Park..................228 Leaks, Fluid................325 Passing ..................70 Life Of Tires ................525 Rear Servicing ..............440 Light Bulbs ...............325, 436 Rear Tail Lamps..............440 Lights ..................325 Seat Belt Reminder ..............221...
Page 652 Locks Electric Powered..............67 Automatic Door..............41 Electric Remote ..............67 Child Protection ..............40 Heated..................67 Power Door ................34 Outside..................66 Low Tire Pressure System .............258 Rearview.................64 Lowering ................118, 145 Vanity..................67 Lowering Four Door............118, 145 Modifications/Alterations Lowering Two Door ............118, 145 Vehicle..................15 Lubrication, Body ..............494 Monitor, Tire Pressure System ..........258 Lug Nuts/Bolts ...............551 Mopar Parts................640...
Page 653 Change Interval ..............484 Placard, Tire And Loading Information ......516 Dipstick.................482 Power Disposal ................486 Brakes..................551 Filter ................486, 558 Door Locks ................34 Filter Disposal..............486 Inverter..................196 Identification Logo..............485 Mirrors ..................67 Materials Added To............486 Steering .................359 Pressure Warning Light .............220 Windows.................93 Recommendation ............485, 557 Power Sliding Top ..............167 Synthetic ................486 Operation................167...
Page 654 Rear Camera ................400 Rear..................45 Rear Cross Path ...............251 Removable Top................167 Rear ParkSense System ............393 Removal..................103 Rear Swing Gate..............180 Removing ...................95 Rear Wiper/Washer ..............76 Replacement Bulbs..............436 Recreational Towing...............415 Replacement Keys...............21, 30 Shifting Into Transfer Case Neutral (N) ......416 Replacement Tires..............525 Shifting Out Of Transfer Case Neutral (N) .....417 Reporting Safety Defects............640 Reformulated Gasoline ............554 Restraints, Child ..............300...
Page 655 Automatic Locking Retractor (ALR) ........275 Disarm The System ...............32 Child Restraints ..............300 Selection Of Coolant (Antifreeze) .........558 Energy Management Feature ..........275 Sentry Key (Immobilizer)............29 Extender................274 Sentry Key Replacement ............21, 30 Front Seat..............267, 269, 271 Service Assistance ..............637 Inspection ................323 Service Contract...............639 Lap/Shoulder Belt Operation ...........
Page 656 Specifications Stop/Start.................360, 364 Fuel (Gasoline)..............558 Storage ..............105, 132, 171, 190 Oil ..................558 Behind the Seat ..............192 Speed Control Storage, Vehicle ..............91, 534 Accel/Decel................371 Storing Your Vehicle...............534 Accel/Decel (ACC Only) ........... 377 Stuck, Freeing ................468 Cancel..................371 Sun Roof ...................167 Resume .................371 Sway Bar Disconnect Speed Control (Cruise Control) ........368, 372 Electronic ................358...
Page 657 Compact Spare..............528 Removable................167 General Information ...........520, 528 Soft.................118, 145 High Speed................522 Tow Hooks Inflation Pressure ..............521 Emergency................470 Jacking ..................511 Towing..............407, 410, 469 Life Of Tires .................525 Disabled Vehicle ..............469 Load Capacity..............516, 517 Recreational................415 Pressure Monitoring System (TPMS).......225, 258 Weight...................410 Quality Grading ..............533 Towing Behind A Motorhome ..........415 Radial ..................522...
Page 658 Automatic..............341, 509 Fluid ..................561 Vanity Mirrors ................67 Maintenance.................509 Vehicle Identification Number (VIN) ........550 Manual..................335 Vehicle Loading...............405, 517 Shifting..................339 Vehicle Modifications/Alterations.........15 Transmitter, Garage Door Opener (Homelink)....183 Vehicle Storage ..............91, 534 Transporting Pets..............322 Vehicle User Guide Tread Wear Indicators............524 In Vehicle Help ..............16 Turn Signals.............228, 439, 440 Navigation................16 Operating Instructions............16...
Page 659 Washing Vehicle ..............537 Windshield Wheel And Wheel Tire Care ..........530 Folding ..................174 Wheel And Wheel Tire Trim ..........530 Windshield Defroster .............323 Wind Buffeting ..............94, 169 Windshield Washers............73, 482 Window Fogging ..............91 Fluid ..................482 Window Storage..............132 Windshield Wiper Blades ............495 Windows ..................93 Windshield Wipers ..............73 Power ..................93...
Page 660 Mobile radio equipment with output power greater than INSTALLATION OF RADIO TRANSMITTING normal may require special precautions. EQUIPMENT Special design considerations are incorporated into this All installations should be checked for possible interference between the communications equipment vehicle’s electronic system to provide immunity to radio and the vehicle’s electronic systems.
Page 661 ©2019 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.
