Summary of Contents for Jeep WRANGLER 2024

  • Page 1 WRANGLER 2 0 2 4 O W N E R H A N D B O O K...
  • Page 2 WARNING: Operating, servicing and maintaining ROADSIDE ASSISTANCE a passenger vehicle or off-highway motor vehicle 24 HOURS, 7 DAYS A WEEK AT YOUR SERVICE. CALL can expose you to chemicals including engine 1-800-521-2779 OR VISIT CHRYSLER.RSAHELP.COM (USA). CALL exhaust, carbon monoxide, phthalates, and lead, 1-800-363-4869 OR VISIT FCA.ROADSIDEAID.COM (CANADA) SERVICES: Flat Tire Service, Out Of Gas/Fuel Delivery, Battery which are known to the State of California to cause...
  • Page 3 INTRODUCTION INTERIOR EXTERIOR Page 4 Page 9 Page 38 EMERGENCY SPECIFICATIONS INDEX Page 57 Page 73 Page 97...
  • Page 4: Table Of Contents

    INTRODUCTION Android Auto™ ......14 CRUISE CONTROL SYSTEMS ....31 Uconnect Voice Recognition —...
  • Page 5 SPECIFICATIONS HIGH VOLTAGE CHARGING OPERATION ..48 SAE J1772 Charging Inlet ....48 ENGINE COMPARTMENT OVERVIEW ..73 AC Level 1 Charging (120 Volt, 12 Amp) .
  • Page 6: Introduction

    OWNER HANDBOOK INTRODUCTION SYMBOLS KEY Thank you for choosing Jeep. This Owner Handbook has been prepared These statements apply to operating WARNING! to help you quickly become acquainted with important features of your procedures that could result in a col- vehicle.
  • Page 7: Customer Assistance

    FCA US LLC C CUSTOMER ASSISTANCE USTOMER ENTER OADSIDE SSISTANCE P.O. Box 21–8004 Call 1-800-521-2779 or visit FCA US LLC and its authorized dealers are vitally Auburn Hills, MI 48321–8004 chrysler.rsahelp.com(USA) interested in your satisfaction. We want you to be happy with our products and services. Phone: (877) 426-5337 Call 1-800-363-4869 or visit fca.roadsideaid.com (Canada)
  • Page 8: Service Contract

    the United States, can communicate with FCA contracts. If you purchased a contract other ARRANTY NFORMATION US LLC by dialing 1-800-380-2479. than a genuine FCA Canada Inc. service contract and you have a problem, you will have to To access your warranty Canadian residents with hearing difficulties contact the administrator of that contract for information online, visit...
  • Page 9: Change Of Ownership Or Address

    To order a digital copy of your Service or HANGE WNERSHIP DDRESS ENERAL NFORMATION Diagnostic Procedure manuals, visit: *If you have purchased this vehicle used or The following regulatory statement applies to all www.techauthority.com (US and Canada). have changed your address, please provide the Radio Frequency (RF) devices equipped in this Owner's Manuals following information and mail to:...
  • Page 10 This device complies with part 15 of the FCC Le présent appareil est conforme aux CNR La operación de este equipo está sujeta a las d'Industrie Canada applicables aux appareils siguientes dos condiciones: Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following radio exempts de licence.
  • Page 11: Interior Overview

    INTERIOR OVERVIEW    1 — Garage Door Opener (HomeLink®) page 33 6 — Uconnect Radio Screen Display page 12 10 — Climate Controls page 25    2 — Assist & SOS Buttons page 57 11 — Keyless Push Button Ignition page 10 7 —...
  • Page 12: Starting And Operating

    ‘ ™ — I STARTING AND With a valid Passive Entry key fob on you, push EYLESS NTER GNITION the Passive Entry lock button on the door handle YBRID ODELS OPERATING to lock the vehicle and the swing gate. Pushing the Keyless Push Button Ignition may ‘...
  • Page 13 The Keyless Push Button Ignition has several ● As long as READY appears in the instrument WARNING! operating modes that are labeled and will cluster display, it does not matter if the ● Do not leave the key fob in or near illuminate when in position.
  • Page 14: Stop/Start System

    TART YSTEM The Stop/Start function is designed to save fuel and reduce emissions. The system will stop the engine automatically during a vehicle stop if the required conditions are met. Releasing Scan me the brake pedal, pressing the Uconnect 5/5 NAV Display accelerator pedal, or releasing the 1 —...
  • Page 15: Pair/Delete A Device

    Warning features? Within the Safety/Driving ELETE EVICE Assistance setting, you can customize both Did you know pairing your the warning and sensitivity for your Forward smartphone with your vehicle is Collision Warning detection. quick and easy? Pairing your ● Phone/Bluetooth® — Do you have your phone smartphone with your vehicle will paired to your Uconnect system yet? Press the open even more possibilities for...
  • Page 16: Apple Carplay

    with the system. You have no need to plug Connect your iPhone® to one of the media your device in if it is paired with the system. USB ports in your vehicle, or pair your iPhone® with the system. You have no need Once the device is connected and to plug your device in if it is paired with the recognized, the Phone icon on the menu bar...
  • Page 17: Off-Road

    To access the Off-Road Pages: Push the VR button or, for the Uconnect 5/5 NAV, say the vehicle’s “Wake Up” word, “Hey, Press the Apps button on the touchscreen. Uconnect”. After the beep, say: Press “Off-Road Pages”. ● “Cancel” to stop a current voice session. ●...
  • Page 18: Usb

    WARNING! CAUTION! Only use these intermittently and with ● Do not touch with wet hands. greater caution. ● Close the lid when not in use and while ● After the use of high power draw driving the vehicle. accessories, or long periods of the vehicle ●...
  • Page 19 Plugging in a mobile device to a USB port below the Uconnect screen may activate the Android Auto™ or Apple CarPlay® features. To disable Android Auto™ or Apple CarPlay®, navigate to “Device Manager” in the “Phone/ Bluetooth®” section of your Uconnect settings. For further information, refer to “Android Auto™”...
  • Page 20: Instrument Cluster

    INSTRUMENT CLUSTER ETTING NSTRUMENT LUSTER Tachometer: Temperature Gauge: Instrument Cluster Display: Indicates the engine speed in revolutions per The temperature gauge shows engine When the appropriate conditions exist, this minute (RPM x 100). coolant temperature. Any reading within the display shows the instrument cluster display normal range indicates that the engine is messages.
  • Page 21: Getting To Know Your Instrument Cluster - Hybrid Only

    Fuel Gauge: The fuel pump symbol points to the Speedometer: side of the vehicle where the fuel The gauge shows the level of fuel in the Indicates vehicle speed. door is located. fuel tank when the Keyless Push Button Ignition is in the ON/RUN position. —...
  • Page 22: Instrument Cluster Display Location And Controls

    The green outer ring represents the High Tachometer: ● Up Arrow Button Voltage (HV) battery output during Push and release the up arrow button to Indicates the engine speed in revolutions per acceleration and input power during scroll upward through the Main Menu items. minute (RPM x 1000).
  • Page 23 Warning & Indicator Lights If any of the Warning Lights illuminate in your cluster, a condition may need to be corrected or your vehicle may require service. In these situations it is recommended that you contact your local authorized dealer to schedule service. The Indicator Lights illuminate in your cluster to indicate a feature is active.
  • Page 24 Warning Lights Anti-Lock Brake System (ABS) Cruise Control Fault Electric Park Brake (EPB) Electronic Stability Control (ESC) Ac- Engine Check/Malfunction) Fuel Level Sensor Failure tive Warning LaneSense Loose Fuel Filler Cap Low Fuel Service Forward Collision Warning Low Washer Fluid Service 4WD (FCW) Service LaneSense...
  • Page 25 Hybrid Warning Lights Service Hybrid System Warning Torque Limited Warning Plug Status Fault Warning Traction Battery Fault Warning Indicator Lights 4WD Indicator Light 4WD Low Indicator Light 4WD Part Time Indicator Light Axle Locker Fault Indicator Light Electronic Stability Control (ESC) Off Forward Collision Warning (FCW) Off Front And Rear Axle Lock Indicator Gear Shift Indicator Light...
  • Page 26 Indicator Lights Stop/Start Active Cruise Control Set Turn Signal Adaptive Cruise Control (ACC) Set Adaptive Cruise Control (ACC) Set Front Fog Lights With Target With No Target Detected Parking/Headlights On LaneSense Cruise Control Ready Indicator Light 2WD High Indicator Light Adaptive Cruise Control (ACC) Ready Cruise Control Ready Hill Descent Control (HDC)
  • Page 27: Drowsy Driver Detection (Ddd) - If

    Hybrid Indicator Lights Max Regeneration Indicator Light Plug Status Indicator Ready To Drive Indicator Light (DDD) ROWSY RIVER ETECTION WARNING! — I QUIPPED driving the vehicle. If you experience fatigue while driving, pull over safely for a break DDD detects when the driver is feeling without waiting for the DDD warnings.
  • Page 28 A/C Button SYNC Button CAUTION! Push the button to engage the Air Press the SYNC button on the Failure to follow these cautions can cause Conditioning (A/C) system. touchscreen to synchronize the driver damage to the heating elements: and front passenger temperature ●...
  • Page 29: Automatic Temperature Control (Atc)

    Mix Mode Manual Operation Override WARNING! Your Climate Control system includes manual ● Persons who are unable to feel pain override features. The AUTO symbol in the front to the skin because of advanced age, ATC display will turn off when the system is in Climate Control OFF Button chronic illness, diabetes, spinal cord injury, the manual mode.
  • Page 30: Head Restraints

    Head restraints are designed to reduce the risk Rear Head Restraints - Two Door Vehicles of injury by restricting head movement in the The rear seat is equipped with non-adjustable, event of a rear impact. Head restraints should be but foldable head restraints. adjusted so that the top of the head restraint is located above the top of your ear.
  • Page 31: Lighting Operation

    Outboard Head Restraints To install the head restraint, hold the release button while pushing downward on the head restraint. WARNING! ● All occupants, including the driver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.
  • Page 32: Automatic Headlights

    The Automatic High Beam Headlight Control can NOTE: be turned on or off by selecting “ON” under The mist feature does not activate the washer “Auto High Beam” within your Uconnect pump; therefore, no washer fluid will be sprayed Settings, as well as turning the headlight on the windshield.
  • Page 33: Cruise Control Systems

    (ACC) CRUISE CONTROL DAPTIVE RUISE ONTROL WARNING! SYSTEMS ○ Does not always fully recognize complex WARNING! driving conditions, which can result in Your vehicle may be equipped wrong or missing distance warnings. ● Adaptive Cruise Control (ACC) is a with the Cruise Control system, or convenience system.
  • Page 34 1 — Distance Setting Increase WARNING! WARNING! 2 — SET (+)/Accel complex driving situations (i.e., in highway 3 — CANC/Cancel In Fixed Speed Cruise Control mode, the construction zones). 4 — RES/Resume system will not react to vehicles ahead. In 5 —...
  • Page 35: Garage Door Opener (Homelink®)

    GARAGE DOOR OPENER antenna. If you have one of these, you have a WARNING! Rolling Code garage door opener. (HOMELINK®) or too low for prevailing traffic and road While the car is ON, hold the handheld conditions could cause the vehicle to garage door transmitter 1-3 inches from the accelerate or decelerate too sharply for The HomeLink®...
  • Page 36: Troubleshooting Tips

    PARKING ASSISTANCE ● Push the LEARN button on the garage door Push and hold the two outside HomeLink® opener to complete the training for a rolling buttons (I and III) for up to 20 seconds, or code. until the HomeLink® indicator light flashes. ENSE SSIST ●...
  • Page 37: Offroad Features

    WARNING! CAUTION! including small obstacles. Parking curbs ● Drivers must be careful when backing up might be temporarily detected or not even when using ParkSense. Always check detected at all. Obstacles located above or carefully behind your vehicle, look behind below the sensors will not be detected when you, and be sure to check for pedestrians, they are in close proximity.
  • Page 38: If Equipped

    Axle Lock will disengage if the vehicle is taken Axle Lock will disengage if the vehicle is taken out of 4H, Off Road+ is turned off by the driver, out of 4L, or the ignition switch is turned to the OFF position. The Axle Lock disengages ESC “Full Off”...
  • Page 39: Off Road+ - If Equipped

    NOTE: ● A mode-specific message will display the The stabilizer/sway bar may be torque locked instrument cluster display due to left and right suspension height ● Off-Road Pages will launch on the radio head- differences. This condition is due to driving unit if selected in radio settings surface differences or vehicle loading.
  • Page 40: Exterior

    EXTERIOR OVERVIEW ð ð ð ð 1 — Exterior Camera Locations page 39 3 — Fuel Door page 40 page 41 5 — Emergency Tow Hook page 70 ð 2 — Charging Inlet page 48 4 — Swing Gate Release Button EXTERIOR...
  • Page 41: Exterior Camera Views

    EXTERIOR CAMERA VIEWS CAUTION! Raise the hood slightly, and place a hand palm-side down in the center of the hood ● opening. Locate the safety latch in the AMERA To avoid vehicle damage, ParkView should middle, and push the latch to the right to only be used as a parking aid.
  • Page 42: To Close The Hood

    NOTE: NOTE: For Hybrid Models: For Hybrid models: If the vehicle stopped charging the high voltage battery when the ● Electric drive mode will not be available while hood was opened, the vehicle will resume the hood is open. A message will show in the charging when the hood closes.
  • Page 43: Refueling The Vehicle - Hybrid

    NOTE: CAUTION! ● When the fuel nozzle “clicks” or shuts off, could let impurities into the fuel system. the fuel tank is full. Also, a poorly fitting aftermarket cap can ● Wait five seconds before removing the cause the Malfunction Indicator Light (MIL) fuel nozzle to allow excess fuel to drain to illuminate, due to fuel vapors escaping from the nozzle.
  • Page 44 ● ● If the fuel door does not re-latch upon If it is loose, and not secured to the filler CAUTION! closure, push the fuel door release button tube, reinstall and tighten again about a again to reset the latch. If pushing the fuel quarter turn until you hear the click.
  • Page 45: High Voltage Battery

    High Voltage Battery Service Disconnect WARNING! Remove the release cap from the quarter trim panel. The high voltage battery service disconnect is dealership for any service or maintenance located under the load floor of the cargo area, at on these high voltage components. After removing the release cap, pull it the front left side.
  • Page 46: Battery Conditioning

    NOTE: If the ambient temperature is 5°F (-15°C) or WARNING! below at vehicle shut down, the instrument During start up and shut down, a clicking noise death. If you discover these leaks, contact cluster will display the message “Plug In Vehicle may be heard from within the vehicle.
  • Page 47: Power Box - If Equipped

    ● It is recommended that the vehicle be WARNING! WARNING! plugged in overnight when possible to Refer to the warning labels on the side of the ● Do not overload electrical extension cords maximize the electric range of the vehicle. Power Box and on the charging cables.
  • Page 48 1 — Power Outlet Blended Mode 2 — Power Indicator Light Blended Mode will use the engine and battery to 3 — Vehicle Indicator Light power the Power Box. It is very efficient and will 4 — AC On Button keep your Power Box going for the longest time.
  • Page 49: Regenerative Braking System (Rbs)

    braking conditions by recapturing energy that ELEC CAUTION! would otherwise be lost while braking. IMPORTANT SAFETY INSTRUCTONS Max Regeneration PERTAINING TO POWER BOX USE AND Max Regeneration is a supplemental feature of OPERATION: It is important to follow these the RBS. When activated, it will use the RBS to Power Box instructions and cautions for overall help slow the vehicle when the driver releases use and operation.
  • Page 50: High Voltage Charging Operation

    AC L (120 V , 12 HIGH VOLTAGE CHARGING EVEL HARGING WARNING! OPERATION ● When unplugging the Portable Charging Cordset (EVSE) from the wall outlet, be sure Your vehicle is equipped with a 120 Volt AC, SAE SAE J1772 C to pull by the plug, and not the cord.
  • Page 51 To access this area, lift the handle of the load WARNING! floor cover, and remove the Portable Charging Failure to follow these warnings and Cordset (EVSE) from the storage bag in the rear instructions can result in electrical shock and cargo area on the right side.
  • Page 52 Portable Charging Cordset WARNING! WARNING! (EVSE) drip onto the vehicle connection end of the ● There are no user serviceable parts inside J1772 EVSE connector. If water penetrates the Portable Charging Cordset (EVSE). The Portable Charging Cordset (EVSE) is the electrical device, the risk of electrical Do not attempt to repair or service the compliant with SAE J1772, and applicable for shock increases.
  • Page 53 Check to see if the Portable Charging Grounding Instructions Portable Charging Cordset Cordset (EVSE) is ready to charge by (EVSE) Installation And reviewing the indicator lights. For A Grounded, Cord-Connected Product: Operating Instructions The Portable Charging Cordset (EVSE) must be grounded. If it should malfunction or break Always insert the AC plug prongs of the down, grounding provides a path of least Portable Charging Cordset (EVSE) into a 15...
  • Page 54 To disengage the vehicle coupler, push the If the Portable Charging Cordset (EVSE) button on the connector. is ready to charge, ensure the vehicle is in PARK, and then connect the charge connector to the vehicle’s charge inlet. You will hear a “click” when the charge connector is inserted correctly and coupled with the vehicle’s charge inlet.
  • Page 55: Ac Level 2 Charging (240 Volt, 40 Amp)

    ● EHICLE HARGE NDICATORS Remove the connector from the vehicle WARNING! charge inlet. Instrument Cluster High Voltage Battery Display INSTRUCTIONS PERTAINING TO A RISK OF ● Plug the charge handle into the Level 2 EVSE FIRE OR ELECTRIC SHOCK: Do not use the There is a battery display indicator located on station and coil the charging cord onto its Portable Charging Cordset (EVSE) with an...
  • Page 56: Hybrid Electric

    The SOC indicator provides a visual indication of the high voltage battery’s charge status during LED Charging Inlet charging. LED Light NOTE: Status Color The lights scroll one at a time when the vehicle is plugged in outside of its charging schedule Blue Indicates that the system is time/day of the week, and it is waiting on the...
  • Page 57 Charging Schedule To set a charging schedule, select the Hybrid Electric App on the touchscreen and follow these steps: Select “Schedules”. Set Charge Schedule Power Flow Screen When done, press the back arrow. The active Driving History schedule will be indicated by the check mark to the right of the schedule event line.
  • Page 58: E-Save

    — I HARGE ETTINGS QUIPPED The fifth screen within the Hybrid Electric App is The fourth screen within the Hybrid Electric App the Charge Setting screen. From this screen, you is the e-Save screen. From this screen, you can can select the rate at which your vehicle specify the behavior of the e-Save drive mode: charges.
  • Page 59: Emergency

    SOS AND ASSIST SYSTEM NOTE: The LED light located next to the SOS ● button on the overhead console will turn Your vehicle may be transmitting data as — IF EQUIPPED authorized by the subscriber. green once a connection to an SOS operator has been made.
  • Page 60 Other Uconnect DURING OR AFTER AN ACCIDENT), Air Bag Warning Light is illuminated, have services will only be operable if your Jeep THE UCONNECT FEATURES, APPS AND an authorized dealer service the Occupant Connect service is active and you are SERVICES, AMONG OTHERS, WILL NOT Restraint Control system immediately.
  • Page 61: Jacking And Tire Changing

    JACKING AND TIRE OCATION CHANGING The jack and lug wrench are located in the rear cargo area. To remove jack and tools proceed as follows: REPARATIONS ACKING Lift the load floor in the cargo area. Park on a firm, level surface (avoid ice or slippery areas).
  • Page 62: Spare Tire Removal

    Remove the hardware storage cover by PARE EMOVAL pinching the latch on the left side and pulling upward. To remove the spare tire from the carrier, remove the tire cover, if equipped. Remove the Rear Camera Cover by turning the lock bolt counterclockwise with the #T40 torx head driver and ratchet from the supplied tool kit.
  • Page 63 WARNING! ● Never start or run the engine with the vehicle on a jack. ● Do not let anyone sit in the vehicle when it is on a jack. ● Do not get under the vehicle when it is on a jack.
  • Page 64 NOTE: Keep the jack and tools aligned while raising the vehicle to prevent tool damage. CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated. Jack Lift Box Usage Rear Lifting Point Operate the jack from the front or the rear of the vehicle.
  • Page 65: Jump Starting - Gas Models

    10. Finish tightening the wheel bolts. Push down Raise the vehicle by turning the jack screw clockwise. Raise the vehicle only until the on the wrench while at the end of the handle tire just clears the surface and enough for increased leverage.
  • Page 66: Preparations For Jump Starting - Gas

    WARNING! WARNING! Do not attempt jump starting if the battery is ● Do not allow vehicles to touch each other frozen. It could rupture or explode and cause as this could establish a ground connection personal injury. and personal injury could result. ●...
  • Page 67 Disconnecting The Jumper Cables CAUTION! Disconnect the negative (-) end of the Failure to follow these procedures could result jumper cable from the engine ground of the in damage to the charging system of the vehicle with the discharged battery. booster vehicle or the discharged vehicle.
  • Page 68: Models

    JUMP STARTING — HYBRID charging process. Once the vehicle When the vehicle is at the charging location, charging has begun (indicated by the shift the transmission back to PARK, apply the MODELS charge status indicator on top of the Electric Park Brake, and start the high voltage vehicle's instrument panel), the jumper battery charging.
  • Page 69: Preparations For Jump Starting

    — — Pull upward and remove the protective cover REPARATIONS TARTING TARTING ROCEDURE over the positive (+) battery post. YBRID ODELS YBRID ODELS If using another vehicle to jump start the 12 The battery in your vehicle is located in the right WARNING! Volt electrical system, park the vehicle within rear of the engine compartment.
  • Page 70: Freeing A Stuck Vehicle

    minutes, and then start the engine in the CAUTION! Connect the opposite end of the negative vehicle with the discharged battery. (-) jumper cable to a good engine ground. etc.). Eventually, if plugged in long enough A “ground” is an exposed metallic/unpainted After a couple minutes (depending on the without engine operation, the vehicle’s battery part of the engine, frame or chassis, such...
  • Page 71: Towing A Disabled Vehicle

    NOTE: WARNING! CAUTION! ● For vehicles with automatic transmission: cause damage, or even failure, of the axle and do not spin the wheels faster than 15 mph Shifts between DRIVE (D) and REVERSE tires. A tire could explode and injure someone. (24 km/h), or drivetrain damage may result.
  • Page 72: Towing In An Emergency

    Towing Condition Wheels OFF The Ground 4WD MODELS • Automatic Transmission in PARK (P) • Manual Transmission in gear (NOT in NEUTRAL) Flat Tow NONE • Transfer Case in NEUTRAL (N) • Tow in Forward direction Front NOT ALLOWED Wheel Lift Or Dolly Tow Rear NOT ALLOWED Flatbed...
  • Page 73 Manual Park Release Pull the tether strap up until the release lever locks into place in the vertical position. The In order to move the vehicle in cases where the vehicle is now out of PARK (P) and can be transmission will not shift out of PARK (P) (such moved.
  • Page 74 risk of damage to the vehicle. Always use an WARNING! Lower the Manual Park Release lever appropriately rated tow strap. downward and to the left, into its original position. ● Do not use a chain for freeing a stuck vehicle. Chains may break, causing serious injury or death.
  • Page 75: Engine Compartment Overview

    ENGINE COMPARTMENT OVERVIEW 2.0L E NGINE 1 — Power Distribution Center (Fuses) 5 — Brake Fluid Reservoir Cap 9 — Power Steering Reservoir Cap 2 — Engine Oil Dipstick 6 — Washer Fluid Reservoir Cap 10 — Intercooler Coolant Reservoir Cap 3 —...
  • Page 76: L Hybrid Engine

    2.0L H YBRID NGINE 1 — Power Distribution Center (Fuses) 5 — Brake Fluid Reservoir Cap 9 — Power Steering Fluid Reservoir Cap 2 — Engine Oil Dipstick 6 — Battery Coolant Reservoir Cap 10 — Washer Fluid Reservoir Cap 3 —...
  • Page 77: L Engine

    3.6L E NGINE 1 — Power Distribution Center (Fuses) 5 — Engine Coolant Pressure Cap 9 — Power Steering Reservoir Cap 2 — Battery 6 — Brake Fluid Reservoir Cap 10 — Motor Generator Unit Coolant Pressure Cap — If Equipped 3 —...
  • Page 78: L Engine

    6.4L E NGINE 1 — Battery 4 — Brake Fluid Reservoir 7 — Power Steering Fluid Reservoir 2 — Engine Oil Fill 5 — Washer Fluid Reservoir Cap 8 — Engine Oil Dipstick 3 — Engine Coolant Reservoir 6 — Power Distribution Center (Fuses) 9 —...
  • Page 79: Fluid Capacities

    FLUID CAPACITIES Metric Fuel (Approximate) 4Xe Models 17.2 gal 65 L Two Door Models 17.5 gal 66 L Four Door Models 21.5 gal 81 L Engine Oil with Filter 2.0L Engine 5 qt 4.73 L 3.6L Engine 5 qt 4.73 L 6.4L Engine 7.5 qt 7.1 L...
  • Page 80 Cooling System * Metric 2.0L Engine 12 qt 11.4 L 2.0L Engine Intercooler 3.7 qt 3.5 L 2.0L Hybrid Battery Coolant (Contact an authorized dealer for service) 5.6 qt 5.3 L 2.0L Hybrid Power Electronics Coolant (Contact an authorized dealer for service) 5.7 qt 5.4 L 3.6L Engine...
  • Page 81: Engine Fluids And Lubricants

    ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km) Formula OAT (Organic Additive Technology) or equiva- Engine Coolant lent meeting the requirements of the manufacturer Material Standard MS.90032. We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km) Formula OAT (Organic Additive Technology) or equiva- Intercooler lent meeting the requirements of the manufacturer Material Standard...
  • Page 82 Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® API SP/GF-6A Certified SAE 5W-30 Full Syn- thetic Engine Oil which meets the requirements of the manufacturer Mate- rial Standard MS-13340. Equivalent full synthetic 5W-30 API SP engine oil can be used but must have the API Donut trademark. Engine Oil —...
  • Page 83: Chassis Fluids And Lubricants

    Component Fluid, Lubricant, or Genuine Part Fuel Selection — 3.6L Engine 87 Octane (R+M)/2 Method, 0-15% Ethanol. Premium Unleaded 91 Octane Only or Higher (R+M)/2 Method, 0-15% Etha- Fuel Selection — 6.4L Engine nol (Do Not Use E-85). CAUTION! ● Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.
  • Page 84 Component Fluid, Lubricant, or Genuine Part Manual Transmission - If Equipped We recommend using Mopar® ATF+4 Automatic Transmission Fluid. Transfer Case We recommend using Mopar® ATF+4 Automatic Transmission Fluid. We recommend using Mopar® Gear & Axle Lubricant (SAE 75W85)(API Front Axle Differential GL-5).
  • Page 85: Servicing And Maintenance

    SERVICING AND On non-instrument cluster display equipped run or idle time is generally only a concern for vehicles, “Change Oil” will flash in the instrument fleet customers. MAINTENANCE cluster odometer and a single chime will sound, Once A Month Or Before A Long Trip: indicating that an oil change is necessary.
  • Page 86 Maintenance Plan Refer to the maintenance plan for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System ● Change oil and filter. ● Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. ●...
  • Page 87 Mileage Or Time Passed (Whichever Comes First): Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, rear suspension, and replace if neces- sary. Inspect the front and rear axle fluid. Inspect the brake linings, replace as necessary.
  • Page 88 Mileage Or Time Passed (Whichever Comes First): Or Years: Or Kilometers: Additional Maintenance Replace engine air cleaner filter. Replace cabin air filter. To be replaced every 12,000 miles (19,000 km). Replace Spark Plugs - 2.0L Engine. Replace spark plugs – 3.6L Engine. Flush and replace the engine, inter- cooler (if equipped), power electron- ics (if equipped), and battery (if...
  • Page 89 Mileage Or Time Passed (Whichever Comes First): Or Years: Or Kilometers: Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plow- ing, heavy loading, taxi, police, de- livery service (commercial service), off-road, desert operation or more than 50% of your driving is at sus- tained high speeds during hot weath- er, above 90°F (32°C).
  • Page 90: Scheduled Servicing - 6.4L

    Mileage Or Time Passed (Whichever Comes First): Or Years: Or Kilometers: Change front and rear axle fluid if us- ing your vehicle for police, taxi, fleet, off-road or frequent trailer towing. — 6.4L The instrument cluster display will display an CHEDULED ERVICING WARNING!
  • Page 91 NOTE: Severe Duty All Models ● Check the fluid levels of the coolant reservoir, engine oil, brake master cylinder, and add as Vehicles that are operated in a dusty and off- ● The oil change indicator message will not needed. road environment, or predominately at idle or monitor the time since the last oil change.
  • Page 92 Maintenance Plan Miles: Or Months: Or Kilometers: Change the engine oil and engine oil filter. Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before scheduled mainte- nance. If using your vehicle for any of the following: dusty or off-road condi- tions.
  • Page 93 Miles: Or Months: Or Kilometers: Inspect the exhaust system. Adjust the parking brake on ve- hicles equipped with four wheel disc brakes. Drain the transfer case and refill. Inspect the accessory drive belts, replace if necessary. Inspect the front and rear axle flu- id.
  • Page 94 Miles: Or Months: Or Kilometers: Inspect front suspension, tie rod ends, and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Replace the engine air cleaner fil- ter. Replace cabin air filter. To be replaced every 12,000 miles (19,000 km).
  • Page 95: Oil Change Reset

    Miles: Or Months: Or Kilometers: Flush and replace the engine cool- ant at 120 months if not done at 150,000 miles (240,000 km). To reset the oil change indicator after HANGE ESET WARNING! performing the scheduled maintenance, refer to the following procedure: ●...
  • Page 96: Engine Break-In Recommendations

    NGINE REAK ECOMMENDATIONS NGINE REAK ECOMMENDATIONS ● Maintain vehicle speed below 70 mph (112 km/h) and observe local speed limits. — 6.4L E NGINE A long break-in period is not required for the 300 to 500 miles (483 to 805 km): engine and drivetrain (transmission and axle) in This breaking in occurs mainly during the first your vehicle.
  • Page 97: Trailer Towing

    TRAILER TOWING To maintain the New Vehicle Limited Warranty coverage, follow the requirements and recommendations in your Owner’s Manual concerning vehicles used for trailer towing. Trailer Towing Weights (Maximum Trailer Weight Ratings) Engine Model GCWR Frontal Area Maximum GTW Maximum Trailer TW (See Note) 8,016 lb (3,636 Two-Door 20 ft2 (1.86 m2)
  • Page 98 Engine Model GCWR Frontal Area Maximum GTW Maximum Trailer TW (See Note) 8,016 lb (3,636 Two-Door 20 ft2 (1.86 m2) 2,000 lb (907 kg) 200 lb (91 kg) 3,500 lb (1,587 Four-Door 8,117 lb (3,682 kg) 30 ft2 (2.79 m2) 350 lb (158 kg) 3.6L Four-Door Ru-...
  • Page 99 Capacities, Fuel ..........3, 78 Compartment ........3, 75, 77 Caps, Filler Compartment Identification ..3, 75, 77 Fuel ............. 2, 40 Coolant (Antifreeze) ......3, 79 Adaptive Cruise Control (ACC) Oil (Engine) ..........3, 73 Fuel Requirements .........3, 78 (Cruise Control) ..........2, 31 Charging ............3, 48 Jump Starting ........
  • Page 100 Gas Cap (Fuel Filler Cap) ....2, 40, 41 Keyless Enter 'n Go™ ........2, 10 Oil Change Indicator Reset ............3, 93 Oil, Engine ............3, 79 Capacity .............3, 78 Filter ............3, 79 Headlights Lights Recommendation ........3, 78 Switch ............2, 29 Exterior ............2, 29 Viscosity .............3, 78 Heavy-Duty Use ...........3, 88...
  • Page 101 To Open Hood ..........2, 39 Tow Hooks Emergency .............72 Schedule, Maintenance ......3, 83 Warning Lights And Messages ....2, 20 Towing ............. 3, 69, 94 Scheduled Servicing ........3, 88 Windshield Washers ........2, 30 Disabled Vehicle ........3, 69 Seats Windshield Wipers ........
  • Page 103 ® common questions. Not all features shown in this manual may apply to your vehicle. For additional information, visit mopar.com/om (USA), owners.mopar.ca (Canada) or your local Jeep brand dealer. ®...
  • Page 104 ©2024 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée Third Edition de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.
