Summary of Contents for Jeep WRANGLER 2021

Page 1 202 1 WRAN GL ER OWN ER’S MA N UA L...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................9 GETTING TO KNOW YOUR VEHICLE ................. 16 GETTING TO KNOW YOUR INSTRUMENT PANEL ............107 STARTING AND OPERATING ....................134 MULTIMEDIA ..........................210 SAFETY ............................284 IN CASE OF EMERGENCY ....................344 SERVICING AND MAINTENANCE ..................360 TECHNICAL SPECIFICATIONS .....................431 CUSTOMER ASSISTANCE .....................443 INDEX .............................447...
Page 4 INTRODUCTION MIRRORS ..............44 DOORS ..............25 Manual Door Locks........25 Inside Rearview Mirror ........ 44 Symbols Key............10 Power Door Locks — If Equipped ....26 Illuminated Vanity Mirrors ......44 ROLLOVER WARNING .........10 Keyless Enter-N-Go — Passive Entry (If Outside Mirrors ........... 45 VEHICLE MODIFICATIONS/ALTERATIONS..11 Equipped) ............
Page 5 INTERIOR STORAGE AND EQUIPMENT ..... 62 FOLDING WINDSHIELD ........100 EXTERIOR LIGHTS..........49 Headlight Switch .......... 49 Storage ............62 Lowering The Windshield ......101 Daytime Running Lights (DRLs) — If USB/AUX Control ......... 62 Raising The Windshield......103 Equipped ............. 49 Power Outlets ..........
Page 6 WARNING LIGHTS AND MESSAGES ....122 STARTING THE ENGINE — DIESEL ENGINE (IF FOUR–WHEEL DRIVE OPERATION ....154 Red Warning Lights........122 EQUIPPED) ............137 Four-Position Transfer Case — If Yellow Warning Lights .......125 Equipped ...........154 Automatic Transmission......138 Yellow Indicator Lights.......129 Five-Position Transfer Case — If Extreme Cold Weather ......138 Green Indicator Lights .......130 Equipped ............157...
Page 7 MULTIMEDIA STOP/START SYSTEM — MANUAL TRANSMISSION REFUELING THE VEHICLE — GASOLINE ENGINE (IF (IF EQUIPPED) ............ 166 EQUIPPED) ............187 UCONNECT SYSTEMS ........210 Autostop Mode...........166 Fuel Filler Cap ..........187 CYBERSECURITY ..........210 Possible Reasons The Engine Does Not Loose Fuel Filler Cap Message ....188 UCONNECT SETTINGS ........
Page 8 SAFETY IN CASE OF EMERGENCY CONNECTED SERVICES FAQs ......275 Connected Services SOS FAQs ....275 SAFETY FEATURES..........284 HAZARD WARNING FLASHERS ....... 344 Connected Services Remote Door Lock/ Anti-Lock Brake System (ABS) ....284 ASSIST AND SOS SYSTEM — IF EQUIPPED ..344 Unlock FAQs ..........276 Electronic Brake Control (EBC) System ...285 JACKING AND TIRE CHANGING ......
Page 9 SERVICING AND MAINTENANCE Accessory Drive Belt Inspection ....379 INTERIORS ............424 Air Conditioner Maintenance ....380 Carpet Safety Information......424 SCHEDULED SERVICING — GASOLINE Body Lubrication ........382 Carpet Removal ......... 425 ENGINE ............... 360 Windshield Wiper Blades ......382 Seats And Fabric Parts......429 Maintenance Plan........361 Exhaust System ........384 Plastic And Coated Parts......430...
Page 10 FLUID CAPACITIES ..........437 IF YOU NEED ASSISTANCE .......443 WARRANTY INFORMATION......445 ENGINE FLUIDS AND LUBRICANTS ....438 FCA US LLC Customer Center ....443 MOPAR® PARTS ..........445 FCA Canada Inc. Customer Center ...443 CHASSIS FLUIDS AND LUBRICANTS ....442 REPORTING SAFETY DEFECTS ......
Page 11: Introduction
Dear Customer, Congratulations on the purchase of your new Jeep® vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers differently from many passenger vehicles both on-road and off-road, so take time to become familiar with your vehicle.
Page 12: Symbols Key
SYMBOLS KEY ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of These statements are against operating proce- vehicles. This vehicle has a higher ground clearance and a higher center WARNING! dures that could result in a collision, bodily of gravity than many passenger vehicles.
Page 13: Vehicle Modifications/Alterations
two million annually. In a rollover crash, an unbelted person is significantly Red Warning Lights more likely to die than a person wearing a seat belt. Always buckle up. Door Open Warning Light VEHICLE MODIFICATIONS/ALTERATIONS Ú page 123 WARNING! Electric Power Steering (EPS) Fault Warning Any modifications or alterations to this vehicle could seriously affect its Light roadworthiness and safety and may lead to a collision resulting in seri-...
Page 14 Red Warning Lights Yellow Warning Lights Swing Gate Open Warning Light Low Fuel Warning Light Ú page 124 Ú page 126 Transmission Temperature Warning Light — If Low Washer Fluid Warning Light — If Equipped Equipped Ú page 126 Ú page 124 Engine Check/Malfunction Indicator Warning Vehicle Security Warning Light —...
Page 15 Yellow Warning Lights Yellow Indicator Lights Forward Collision Warning (FCW) OFF Indicator Cruise Control Fault Warning Light Light — If Equipped Ú page 127 Ú page 129 Sway Bar Fault Warning Light Front And Rear Axle Lock Indicator Light Ú page 127 Ú...
Page 16 Yellow Indicator Lights Green Indicator Lights Low Diesel Emissions Additive AdBlue® (UREA) Park/Headlight On Indicator Light Indicator Light — If Equipped Ú page 130 Ú page 130 Stop/Start Active Indicator Light — If Equipped Water In Fuel Indicator Light — If Equipped Ú...
Page 17 Blue Indicator Lights White Indicator Lights Cruise Control Ready Indicator Light — If High Beam Indicator Light Equipped With A Premium Instrument Cluster Ú page 131 Ú page 131 Cruise Control SET Indicator Light — If Equipped Gray Indicator Lights With A Base Instrument Cluster Cruise Control Ready Indicator Light —...
Page 18: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE KEYS NOTE: WARNING! The key fob’s wireless signal may be blocked  Push the Mechanical Key Release Button only if the key fob is located next to a mobile with the key fob facing away from your body, phone, laptop, or other electronic device.
Page 19 GETTING TO KNOW YOUR VEHICLE When the doors are unlocked, the turn signals 1 — Mechanical Key Release Button will flash and the illuminated entry system will 2 — LED Indicator be activated. When the doors are locked, the 3 — Unlock Button turn signals will flash and the horn will chirp.
Page 20: Sentry Key
GETTING TO KNOW YOUR VEHICLE 1. Remove the back cover of the fob by Only key fobs that are programmed to the  vehicle electronics can be used to start and inserting a flat-blade screw driver into the slot on the bottom of the fob. Pry until the operate the vehicle.
Page 21: Ignition Switch
GETTING TO KNOW YOUR VEHICLE or activated. Operation is automatic, regardless CAUTION! of whether the vehicle is locked or unlocked. The Sentry Key Immobilizer system is not The system uses a key fob, keyless push button compatible with some aftermarket remote ignition and a Radio Frequency (RF) receiver to starting systems.
Page 22: Remote Start - If Equipped (Gasoline)
GETTING TO KNOW YOUR VEHICLE WARNING! CAUTION! Driving position.  When exiting the vehicle, always remove An unlocked vehicle is an invitation for  All electrical devices are available.  the key fob from the vehicle and lock your thieves. Always remove key fob from the vehi- START vehicle.
Page 23: How To Use Remote Start
GETTING TO KNOW YOUR VEHICLE NOTE: twice. Pushing the Remote Start button again Brake switch inactive (brake pedal not  will shut the engine off. pushed) The vehicle must be equipped with an auto-  Battery at an acceptable charge level matic transmission to be equipped with ...
Page 24: To Exit Remote Start Mode
GETTING TO KNOW YOUR VEHICLE Button” will display in the instrument cluster The vehicle will adjust the climate control EMOTE TART display until you push the START/STOP igni- settings depending on the outside ambient If applicable, refer to the “Hybrid Supplement” tion button.
Page 25: Remote Start Cancel Message
GETTING TO KNOW YOUR VEHICLE REMOTE START — IF EQUIPPED (DIESEL) For more information on ATC, MTC, and climate WARNING! control settings, see Ú page 54. This system uses the key fob to start Do not start or run an engine in a closed ...
Page 26: Vehicle Security System - If Equipped
GETTING TO KNOW YOUR VEHICLE The park lamps will turn on and remain on Water In Fuel Indicator Light is not illumi- the following audible and visible signals: the   during Remote Start mode. nated horn will pulse, the park lamps and/or turn signals will flash, and the vehicle security light For security, power window operation is Wait To Start Indicator Light is not illuminated...
Page 27: To Disarm The System
GETTING TO KNOW YOUR VEHICLE battery is reconnected; the exterior lights will To unlock the door, push the rocker lever ISARM YSTEM flash, and the horn will sound. If this occurs, rearward. The Vehicle Security system can be disarmed disarm the Vehicle Security system. using any of the following methods: EARMING YSTEM...
Page 28: Power Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) When exiting the vehicle, always switch off Allowing children to be in a vehicle unat-   the ignition and remove the key from the tended is dangerous for a number of vehicle.
Page 29 GETTING TO KNOW YOUR VEHICLE with the key fob’s wireless signal and prevent FOBIK-Safe only executes in vehicles with a the Passive Entry system from locking/ START/STOP ignition. There are three situations unlocking the vehicle. that trigger a FOBIK-Safe search in any passive entry vehicle: Passive Entry Unlock initiates illuminated ...
Page 30 GETTING TO KNOW YOUR VEHICLE The doors are manually locked using the door select between “Unlock Driver Door 1st Press”  lock knobs. and “Unlock All Doors 1st Press” within Uconnect Settings Ú page 211. Three attempts are made to lock the doors ...
Page 31: Automatic Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE If Passive Entry is disabled using the To use the system, open each rear door, use a After engaging the Child-Protection Door Lock   Uconnect Settings, the key protection flat blade screwdriver (or mechanical key) and system, always test the door from the inside described in "Frequency Operated Button to make certain it is in the locked position.
Page 32: Front Door Removal
GETTING TO KNOW YOUR VEHICLE Outside rearview mirrors are mounted on the RONT EMOVAL doors. If you choose to remove the doors, see WARNING! an authorized dealer for a replacement cowl- mounted outside mirror. Federal law requires Do not drive your vehicle on public roads with outside mirrors on vehicles for on-road use.
Page 33 GETTING TO KNOW YOUR VEHICLE NOTE: Do not pry back to open, as this will break the plastic cover. 4. Pull up on the red locking tab to unlock the wiring harness. Open Wiring Harness Door Check (Detached) 1 – Wiring Harness 8.
Page 34: Rear Door Removal (Four-Door Models)
GETTING TO KNOW YOUR VEHICLE EMOVAL WARNING! (Continued) ODELS Do not store detached doors inside of the  WARNING! vehicle, as they may cause personal injury in the event of an accident. Do not drive your vehicle on public roads with the doors removed as you will lose the protec- NOTE: tion they can provide.
Page 35: Steering Wheel
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL 5. Unplug the wiring connector. NOTE: ELESCOPING TEERING OLUMN Squeeze the tab on the base of the wiring This feature allows you to tilt the steering harness. This will unlock the connector tab, column upward or downward.
Page 36: Heated Steering Wheel - If Equipped
GETTING TO KNOW YOUR VEHICLE SEATS wheel outward or push it inward as desired. To Push the heated steering wheel button  lock the steering column in position, push the once to turn the heating element on. Seats are a part of the Occupant Restraint control handle upward until fully engaged.
Page 37: Manual Adjustment Front Seats
GETTING TO KNOW YOUR VEHICLE ANUAL DJUSTMENT RONT EATS WARNING! Manual Front Seat Forward/Rearward Adjusting a seat while driving may be  Adjustment dangerous. Moving a seat while driving could result in loss of control which could The seat can be adjusted forward or rearward cause a collision and serious injury or by using a bar located by the front of the seat death.
Page 38: 60/40 Split Folding Rear Seat - Four Door
GETTING TO KNOW YOUR VEHICLE 60/40 S — Front Passenger Easy Entry Seat — Two PLIT OLDING WARNING! Door Models ODELS Do not ride with the seatback reclined so that Pull upward on the easy entry lever located on To provide additional storage area, each rear the shoulder belt is no longer resting against the outboard side of the seat back, and slide seat can be folded flat to allow for extended...
Page 39: Fold And Tumble Rear Seat - Two Door Models
GETTING TO KNOW YOUR VEHICLE — T To Fold Down The Rear Seat NOTE: UMBLE You may experience deformation in the seat There are two release levers located on each ODELS cushion from the seat belt buckles if the seats upper outboard side of the rear seat.
Page 40: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Using The Retention Straps Removing The Rear Seat WARNING! 1. There are two retention straps located on 1. Push down on the release bar on each It is extremely dangerous to ride in a cargo ...
Page 41: Rear Seat Armrest - If Equipped
GETTING TO KNOW YOUR VEHICLE For information on use with the Remote Start system, see Ú page 22. WARNING! Persons who are unable to feel pain to the  skin because of advanced age, chronic illness, diabetes, spinal cord injury, medica- tion, alcohol use, exhaustion or other phys- ical condition must exercise care when using the seat heater.
Page 42: Head Restraints
GETTING TO KNOW YOUR VEHICLE on the head restraint. The release button does ESTRAINTS WARNING! not need to be pushed to adjust the head Head restraints are designed to reduce the risk restraint. A loose head restraint thrown forward in a ...
Page 43 GETTING TO KNOW YOUR VEHICLE To fold the outboard head restraint, pull on the WARNING! inner release lever, located on the upper part of Do not drive the vehicle without the rear the rear seat.  seat head restraints installed while passen- gers are occupying the rear seat.
Page 44: Uconnect Voice Recognition
GETTING TO KNOW YOUR VEHICLE To raise the center head restraint, lift up on the WARNING! (Continued) head restraint. To lower the center head restraint, push the adjustment button, located A loose head restraint thrown forward in a  at the base of the head restraint, and push collision or hard stop could cause serious down on the head restraint.
Page 45: Basic Voice Commands
GETTING TO KNOW YOUR VEHICLE TARTED VR button is used to activate /deactivate your Voice Recognition system. Helpful hints for using Voice Recognition: Reduce background noise. Wind noise and  passenger conversations are examples of noise that may impact recognition. Speak clearly at a normal pace and volume ...
Page 46: Mirrors
GETTING TO KNOW YOUR VEHICLE MIRRORS Automatic Dimming Mirror — If Equipped The Automatic Dimming feature can be turned on or off through Uconnect Settings The rearview mirror can be adjusted up, down, NSIDE EARVIEW IRROR Ú page 211. left, and right. The mirror should be adjusted to center on the view through the rear window.
Page 47: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE — I (left) or R (right) button to select the mirror that UTSIDE IRRORS EATED IRRORS QUIPPED you want to adjust. The outside mirror(s) can be adjusted to the These mirrors are heated to melt frost Using the mirror control switch, push any of the center of the adjacent lane of traffic to achieve or ice.
Page 48: Before You Begin Programming
GETTING TO KNOW YOUR VEHICLE HomeLink® replaces up to three hand-held Make sure your hand-held transmitter is  DENTIFYING HETHER transmitters that operate devices such as programmed to activate the device you are OLLING OLLING garage door openers, motorized gates, trying to program your HomeLink®...
Page 49: Programming Homelink® To A Garage Door Opener
GETTING TO KNOW YOUR VEHICLE ® T NOTE: Non-Rolling Code Garage Door Opener Final ROGRAMMING Make sure the garage door opener motor is Steps ARAGE PENER plugged in before moving on to the rolling code/ 1. Push and hold the programmed To program any of the HomeLink®...
Page 50: Miscellaneous Device
GETTING TO KNOW YOUR VEHICLE ® T program the HomeLink® button to has a rolling It may be helpful to unplug the device during the ROGRAMMING code or a non-rolling code. cycling process to prevent possible overheating ISCELLANEOUS EVICE of the garage door or gate motor. 1.
Page 51: Reprogramming A Single Homelink
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS NOTE: Rotate the headlight switch clockwise to the first detent for parking light and instrument If the indicator light stays on constantly,  EADLIGHT WITCH panel light operation. Rotate the headlight programming is complete and the garage switch to the second detent for headlight, door/device should activate when the The headlight switch is located on the left side...
Page 52: High/Low Beam Switch
GETTING TO KNOW YOUR VEHICLE — I from high beams to low beams until the WITCH UTOMATIC EADLIGHTS QUIPPED approaching vehicle is out of view. Push the multifunction lever toward the This system automatically turns the headlights instrument panel to switch the headlights to on or off according to ambient light levels.
Page 53: Front Fog Lights - If Equipped
GETTING TO KNOW YOUR VEHICLE — I NOTE: RONT IGHTS QUIPPED If either light remains on and does not flash, or To activate the Front Fog Lights, turn on the there is a very fast flash rate, check for a defec- parking lights or low beam headlights and push tive outside light bulb.
Page 54: Dimmer Controls
GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS IMMER ONTROLS The dimmer controls are part of the headlight The windshield wiper/washer control lever is switch and are located on the left side of the located on the right side of the steering column. instrument panel.
Page 55: Rear Window Wiper/Washer - If
GETTING TO KNOW YOUR VEHICLE — I NOTE: INDOW IPER ASHER WARNING! The wiper delay times depend on vehicle speed. QUIPPED If the vehicle is moving less than 10 mph Sudden loss of visibility through the wind- A rotary switch on the center portion of the (16 km/h), delay times will be doubled.
Page 56: Climate Controls
GETTING TO KNOW YOUR VEHICLE NOTE: MAX A/C Button UTOMATIC LIMATE ONTROL As a protective measure, the washer will stop if Press and release the MAX A/C button ESCRIPTIONS UNCTIONS the switch is held for more than 20 seconds. on the touchscreen to change the Once the switch is released the washer will current setting to the coldest output resume normal operation.
Page 57 GETTING TO KNOW YOUR VEHICLE The A/C button allows the operator to manually AUTO Button defogging. When toggling the front defrost activate or deactivate the A/C system. When the mode button, the climate system returns to the Set your desired temperature and A/C system is turned on, cool dehumidified air previous setting.
Page 58 GETTING TO KNOW YOUR VEHICLE SYNC Button speed decreases as you turn the blower CAUTION! (Continued) control knob counterclockwise. Press the SYNC button on the Do not use scrapers, sharp instruments, or Touchscreen: Use the small blower icon to  touchscreen to toggle the SYNC ...
Page 59: Manual Climate Control Descriptions And Functions
GETTING TO KNOW YOUR VEHICLE Bi-Level Mode Climate Control OFF Button A/C Button Air comes from the instrument panel Press and release the OFF button on Push the A/C button to engage the Air outlets and floor outlets. A slight the touchscreen, or push the OFF Conditioning (A/C).
Page 60 GETTING TO KNOW YOUR VEHICLE outside conditions such as smoke, odors, dust, temperature settings for best windshield and CAUTION! (Continued) or high humidity are present. Recirculation can side window defrosting and defogging. be used in all modes except for Defrost. Keep all objects a safe distance from the ...
Page 61: Automatic Temperature Control (Atc) - If
GETTING TO KNOW YOUR VEHICLE Blower Control located below the air vanes to shut off or adjust Climate Control OFF the amount of airflow from these outlets. Blower Control regulates the amount To turn the Climate Controls off, turn of air forced through the climate the blower control knob to the OFF (O) Bi-Level Mode system.
Page 62: Equipped
GETTING TO KNOW YOUR VEHICLE automatically adjusts the temperature, Did You Know: Voice Command for Climate may Vacation/Storage mode, and blower speed to provide comfort only be used to adjust the interior temperature For information on maintaining the Climate as quickly as possible. of your vehicle.
Page 63 GETTING TO KNOW YOUR VEHICLE Stop/Start System — If Equipped climate control functions will resume their CONTROL previous operation except, if the de-icer is WEATHER While in an Autostop, the Climate Control SETTINGS active, the de-icer timer and operation will system may automatically adjust airflow to continue.
Page 64: Interior Storage And Equipment
GETTING TO KNOW YOUR VEHICLE INTERIOR STORAGE AND EQUIPMENT Console Storage Compartment The center console has both an upper and lower TORAGE storage compartment. To open the upper storage compartment, lift the Glove Compartment top latch. To access the lower storage The glove compartment is located on the compartment, lift the bottom latch.
Page 65 GETTING TO KNOW YOUR VEHICLE The Smart Charging USB ports provide power to your device up to an hour after the vehicle is turned off. NOTE: Two devices can be plugged in at the same  time and both ports will provide charging capabilities.
Page 66: Power Outlets
GETTING TO KNOW YOUR VEHICLE WARNING! Do not plug in or remove the external device while driving. Failure to follow this warning could result in a collision. OWER UTLETS There are two 12 Volt (13 Amp) auxiliary power outlets that can provide power for accessories designed for use with the standard power outlet Front Power Outlet Power Outlets Fuse Locations...
Page 67: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE — I OWER NVERTER QUIPPED CAUTION! CAUTION! (Continued) There is a 115 Volt, 150 Watt inverter outlet Many accessories that can be plugged in Power outlets are designed for accessory   located on the back of the center console to draw power from the vehicle's battery, even plugs only.
Page 68: Auxiliary Switches - If Equipped
GETTING TO KNOW YOUR VEHICLE The power inverter is designed with built-in All switches can be configured as follows: overload protection. If the power rating of Switch type operation: Latching or Momen-  150 Watts is exceeded, the power inverter tary automatically shuts down.
Page 69: Power Windows - If Equipped
GETTING TO KNOW YOUR VEHICLE Wire Color Chart Circuit Function Fuse Wire Color Locations Interior (passenger side under instrument panel) & Aux Switch 1 F93 – 40 Amp Beige/Pink Underhood (right side near battery) Interior (passenger side under instrument panel) & Aux Switch 2 F92 –...
Page 70: Auto-Down Feature
GETTING TO KNOW YOUR VEHICLE To open the window part way (manually), push UFFETING WARNING! the window switch down briefly and release. Wind buffeting can be described as the There is no anti-pinch protection when the perception of pressure on the ears or a NOTE: window is almost closed.
Page 71: Lowering The Soft Top Into Sunrider
GETTING TO KNOW YOUR VEHICLE OWERING CAUTION! ® P UNRIDER OSITION The soft top is not designed to carry any addi- Use this QR code to access your tional loads such as roof racks, spare tires, digital experience. building, hunting, or camping supplies, and/ or luggage, etc.
Page 72 GETTING TO KNOW YOUR VEHICLE CAUTION! CAUTION! (Continued) CAUTION! (Continued) Do not run a fabric top through an auto- Do not fully lower the top with the windows Failure to follow these cautions may cause   matic car wash. Window scratches and wax installed.
Page 73 GETTING TO KNOW YOUR VEHICLE Four Door Side View Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Rear Quarter Window 3 — #3 Bow 8 — Lower Window Retainer 4 — #4 Bow 9 —...
Page 74 GETTING TO KNOW YOUR VEHICLE Two Door Side View Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Rear Quarter Window 3 — #3 Bow 8 — Lower Window Retainer 4 — #4 Bow 9 —...
Page 75 GETTING TO KNOW YOUR VEHICLE Two And Four Door Rear Components 1 — Rear Window Retainer Attachment Points 2 — Quarter Window Pillars 3 — Swing Gate Bar Retainers...
Page 76 GETTING TO KNOW YOUR VEHICLE NOTE: All lowering and raising the soft top instruc-  tions are applicable to both two and four door model vehicles. Images shown are of four door models, and  appearance of two door model components may differ.
Page 77 GETTING TO KNOW YOUR VEHICLE NOTE: the rear window. Store in soft window bag (if equipped), or a safe location. The vehicle can be driven in the Sunrider®  position with the rear window and quarter panel assemblies fully installed or completely removed.
Page 78 GETTING TO KNOW YOUR VEHICLE 5. While keeping the rear window level, slide to window moving toward the front of the the left until it is completely separate from vehicle. its retainer. Do not pull downward while removing the rear window. Damage to the retainer could result.
Page 79 GETTING TO KNOW YOUR VEHICLE 5. While keeping the window level, slide NOTE: rearward until it is completely separate from The swing gate bar, once removed from the rear its retainer. Do not pull downward while window, does not store in the soft window removing the window.
Page 80 GETTING TO KNOW YOUR VEHICLE 3. Lay the second quarter window on top of the 6. Close the storage bag and store in a safe first divider all the way to the left side with location. the inside of the window facing downward and the window pillar to the outside.
Page 81 GETTING TO KNOW YOUR VEHICLE 3. Locate the Sunrider® latch beneath the #6 CAUTION! Bow of the soft top on the left side. Failure to follow the next steps could result in damage to the Soft Top or vehicle. 5. While pushing downward slightly on the folded soft top, slide the lock lever on the left and right side lift assist mechanisms to the “lock”...
Page 82: Raising The Soft Top
GETTING TO KNOW YOUR VEHICLE 4. Gently pull rearward on the #6 Bow to AISING ensure the top is locked in the Sunrider® Use this QR code to access your position. digital experience. 5. Using the side link, lift and push the soft top toward the front of the vehicle manually guiding the top into the closed position.
Page 83 GETTING TO KNOW YOUR VEHICLE 6. From inside the vehicle, pull the handle on Installing The Soft Top Windows the header latch downward to engage the Install The Right And Left Quarter Windows hook into its receiver. Repeat on the other 1.
Page 84 GETTING TO KNOW YOUR VEHICLE 3. Engage the retainers on the front of the 2. Insert the swing gate bar into the retainers windows, ensuring they are fully engaged, at the bottom of the window from left to the followed by the retainers along the bottom right.
Page 85: Removing The Soft Top
GETTING TO KNOW YOUR VEHICLE 4. Line up the rear window to the right side NOTE: 2. Make sure the lift assist mechanism on quarter window first, and engage the plastic For information on removing your soft top, refer both the left and right sides are in the “lock” retainers.
Page 86 GETTING TO KNOW YOUR VEHICLE 3. Using the provided #40 Torx head driver and ratchet, unscrew the two Torx head screws on each lift assist mechanism, then lift the mechanism up and away from the vehicle. Step Four Step Six 7.
Page 87: Installing The Soft Top
GETTING TO KNOW YOUR VEHICLE NSTALLING CAUTION! 1. If currently installed, remove the hard top Do not over tighten Torx screws. Damage to Ú page 91. the retainers will occur. 2. Install the door rails, starting with the front, followed by the rear on each side. For Torque Speci- instructions and appropriate torque specifi- fication For...
Page 88 GETTING TO KNOW YOUR VEHICLE 5. Using the provided #40 Torx head driver Torque Speci- and ratchet, tighten the Torx screws by fication For Maximum Minimum turning them clockwise. Secure them until Torx Screws they are snug (refer to the table below for 119.5 in-lbs 150.5 in-lbs 106.2 in-lbs...
Page 89: Hard Top Front Panel(S) Removal
GETTING TO KNOW YOUR VEHICLE RONT ANEL EMOVAL CAUTION! (Continued) CAUTION! (Continued) Use this QR code to access your Failure to follow these cautions may cause Careless handling and storage of the  digital experience. interior water damage, stains or mildew: removable roof panels may damage the seals, causing water to leak into the It is recommended that the top be free of...
Page 90 GETTING TO KNOW YOUR VEHICLE Four Door Hard Top Components 1 — Right Side Panel 2 — Left Side Panel 3 — Hard Top...
Page 91 GETTING TO KNOW YOUR VEHICLE Two Door Hard Top Components 1 — Right Side Panel 2 — Left Side Panel 3 — Hard Top...
Page 92 GETTING TO KNOW YOUR VEHICLE NOTE: 3. Unlatch the left side header panel latch Lay the bag for the Freedom Top panels down located at the top of the windshield. so the loops and hooks are facing upward. All hard top removal and installation instruc- ...
Page 93: Hard Top Front Panel(S) Installation
GETTING TO KNOW YOUR VEHICLE 4. Unfold the outer flap and zip the hard top RONT ANEL bag closed. NSTALLATION 1. Set the right side panel on the windshield frame with the locating pin in the front receiver mounting hole followed by the left side panel, making sure there is no overhang.
Page 94 GETTING TO KNOW YOUR VEHICLE 5. Open the swing gate all the way to ensure 7. Release the locking tab by pushing it clearance of the rear window glass. Lift the downward. rear window glass. Step Eight 9. To remove the washer hose, push the release button on hose connector, and pull Step Seven downward.
Page 95: Installing The Hard Top
GETTING TO KNOW YOUR VEHICLE 10. Secure the wire harness to the body side by NSTALLING plugging it into the receptacle and If the door frames are installed from soft top reengaging the locking tab. usage, they must be removed prior to installation of the hard top.
Page 96: Power Sliding Top - If Equipped
GETTING TO KNOW YOUR VEHICLE — I NOTE: OWER LIDING QUIPPED WARNING! The Power Top is non-removable. If desired,  CAUTION! Never leave children unattended in a the rear quarter windows can be removed  vehicle, or with access to an unlocked and stored in the provided storage bag Lowering of the windshield is NOT recom- vehicle.
Page 97 GETTING TO KNOW YOUR VEHICLE Opening And Closing The Power Top Pinch Protect Feature Power Top Maintenance Express Open/Close This feature will detect an obstruction in the Use only a non-abrasive cleaner and a soft cloth opening of the power top during Express Close to clean the quarter window glass panel.
Page 98 GETTING TO KNOW YOUR VEHICLE 2. Ensure the power top is in the fully closed 3. Locate the rear quarter window latches NOTE: position. (two on each window) on the interior of the Do not pull down or apply any weight to the windows.
Page 99: Door Frame
GETTING TO KNOW YOUR VEHICLE 7. Store the rear quarter windows in the 2. Place the second window into the foam the forward most cargo hook on the load provided storage bag and keep in a safe insert with the latches facing outward. Fully floor.
Page 100: Door Frame Removal
GETTING TO KNOW YOUR VEHICLE 3. Lift the frame upward, removing it from the CAUTION! vehicle. Failure to follow these cautions may cause interior water damage, stains or mildew: Opening a door or lowering a window while  the top is wet may allow water to drip into the vehicle's interior.
Page 101: Door Frame Installation Four Door
GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) Do not drive your vehicle on public roads  with the doors removed as you will lose the protection that they can provide. This procedure is furnished for use during off-road operation only. RAME NSTALLATION —...
Page 102: Models - If Equipped
GETTING TO KNOW YOUR VEHICLE 6. Swing the frame bracket around the side of RAME NSTALLATION Target Torque the rail, and insert the screws from — I Specification ODELS QUIPPED Maximum Minimum underneath. Tighten with #40 Torx head For Torx Fas- 1.
Page 103: Lowering The Windshield
GETTING TO KNOW YOUR VEHICLE Do not drive your vehicle on-road with the OWERING INDSHIELD WARNING! (Continued) windshield down, as you lose the protection this 1. Before completing the steps below: structural element can provide. Do not drive your vehicle unless the wind- ...
Page 104 GETTING TO KNOW YOUR VEHICLE 2. Manually remove the protective caps over the windshield wiper hex bolts. Step Five Step Six 1 — Outside Torx Screws 1 — Washer Nozzle 2 — Inside Torx Screws 2 — Bumper Step Two 3 —...
Page 105: Raising The Windshield
GETTING TO KNOW YOUR VEHICLE ACC/FCW Sensor Protective Cover — If reinstall the hex nut and tighten until snug. AISING INDSHIELD Be careful not to over-tighten. Repeat for Equipped 1. Release the strap that secured the the other arm. Your vehicle may be equipped with a protective windshield in the lowered position.
Page 106: Hood
GETTING TO KNOW YOUR VEHICLE HOOD REAR SWING GATE LOSING If applicable, refer to the “Hybrid Supplement” The rear swing gate can be unlocked by using PENING for additional information. one of the following methods: If applicable, refer to the “Hybrid Supplement” To close the hood, remove the support rod from Mechanical key (with mechanical lock —...
Page 107: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE NOTE: Lift the loop to use. ARGO EATURES Close the rear flip-up window before attempting Trail Rail Cargo Organizer — If Equipped to close the swing gate (hard top models only). If your vehicle is equipped with the Trail Rail WARNING! system, a rail will be found built into the floor on either side of the cargo area.
Page 108 GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! CAUTION! (Continued) Crossbars can be purchased at an authorized dealer through Mopar parts. To avoid damage to the roof rack and Travel at reduced speeds and turn corners   vehicle, do not exceed the maximum roof carefully when carrying large or heavy loads External racks do not increase the total load rack load capacity.
Page 109: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster — Gasoline...
Page 110 GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster — Gasoline...
Page 111 GETTING TO KNOW YOUR INSTRUMENT PANEL Base Instrument Cluster — Diesel...
Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster — Diesel...
Page 113: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL NSTRUMENT LUSTER ESCRIPTIONS WARNING! 1. Tachometer A hot engine cooling system is dangerous. Indicates the engine speed in revolutions  You or others could be badly burned by steam per minute (RPM x 1000). or boiling coolant.
Page 114: Instrument Cluster Display Location And Controls
GETTING TO KNOW YOUR INSTRUMENT PANEL total miles, or kilometers, in the odometer. Your The system allows the driver to select Left And Right Arrow Buttons: instrument cluster display is designed to display information by pushing the following buttons Using the left or right arrow button allows important information about your vehicle’s...
Page 115: Oil Change Reset - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL — I Secondary Method For Oil Change Reset Push and release the OK button to toggle HANGE ESET QUIPPED Procedure between MPH and km/h. Your vehicle may be equipped with an engine oil 1. Without pushing the brake pedal, place the change indicator system.
Page 116 GETTING TO KNOW YOUR INSTRUMENT PANEL speed for the feature to become available will Push the SET + or the SET - button (located on release the left or right arrow button to also display. the steering wheel), and the following will scroll through the information submenus.
Page 117 GETTING TO KNOW YOUR INSTRUMENT PANEL Range – The display shows the estimated The Trip A and Trip B information will display the NOTE:  distance (mi or km) that can be traveled with following: The call status will temporarily replace the the fuel remaining in the tank.
Page 118 GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup Driver Selectable Items Upper Right Driver Assist – If Equipped (show/hide)  Upper Left None Fuel Economy (show/hide)   Trip Info (Show/Hide) None Compass    Compass Outside Temp Stop/Start ...
Page 119: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL When the speed warning is set, the icon should vehicle may stall due to lack of electrical supply, Loss of the battery charge may indicate one or more of the following conditions: remain visualized for the same duration time of or will not restart after the current drive cycle.
Page 120: Diesel Displays
GETTING TO KNOW YOUR INSTRUMENT PANEL What to do when an electrical load reduction manages engine combustion to allow the IESEL ISPLAYS action message is present (“Battery Saver On” exhaust system’s catalyst to trap and burn When the appropriate conditions exist, the or “Battery Saver Mode”) Particulate Matter (PM) pollutants, with no input following messages display in the instrument...
Page 121: Fuel System Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has the ability to alert you to Exhaust System Regeneration in Process a dealer service is not performed, extensive  additional maintenance required on your Continue Driving — This message indicates exhaust after-treatment damage can occur. that the DPF is self-cleaning.
Page 122 GETTING TO KNOW YOUR INSTRUMENT PANEL MESSAGE DESCRIPTION Diesel Emissions Additive AdBlue® (UREA) Warning Messages: The first low level warning will be given at around a 1,490 miles (2,400 km) range, and is determined according to the current consumption rate. The “UREA Low Level” warning light and message will display on the instrument panel.
Page 123 GETTING TO KNOW YOUR INSTRUMENT PANEL MESSAGE DESCRIPTION Diesel Emissions Additive AdBlue® (UREA) Fault Warning Messages: This message will display if the AdBlue® (UREA) system issue detected is not serviced during the allowed period. Your engine will not restart unless your vehicle is serviced by an authorized dealer. If the level is not Engine Will Not Restart Service resolved, an additional warning appears whenever a certain threshold is reached until it will no longer be AdBlue®...
Page 124: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES If the light is not on during startup, stays on, or The dual brake system provides a reserve turns on while driving, have the system braking capacity in the event of a failure to a The warning/indicator lights will illuminate in inspected at an authorized dealer as soon as portion of the hydraulic system.
Page 125 GETTING TO KNOW YOUR INSTRUMENT PANEL Vehicles equipped with the Anti-Lock Brake RUN position and if the driver’s seat belt is Electric Power Steering (EPS) Fault System (ABS) are also equipped with Electronic unbuckled, a chime will sound and the light will Warning Light Brake Force Distribution (EBD).
Page 126 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: vehicle. If the temperature reading does not recommended to take the vehicle to an This light may turn on if the accelerator and return to normal, turn the engine off authorized dealer as soon as possible. brake pedals are pressed at the same time.
Page 127: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL strenuous usage such as trailer towing. If this ACC/ON/RUN position, and when ESC is ELLOW ARNING IGHTS light turns on, stop the vehicle and run the activated. It should go out with the engine Anti-Lock Brake System (ABS) Warning engine at idle or slightly faster, with the running.
Page 128 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) OFF Low Washer Fluid Warning Light — If When the engine is running, the MIL may flash to alert serious conditions that could lead to Warning Light — If Equipped Equipped immediate loss of power or severe catalytic This warning light indicates the ESC is...
Page 129 GETTING TO KNOW YOUR INSTRUMENT PANEL AdBlue® (UREA) Injection System Failure Service Forward Collision Warning (FCW) Tire Pressure Monitoring System (TPMS) Warning Light — If Equipped Light — If Equipped Warning Light This warning light will illuminate along This warning light will illuminate to The warning light switches on and a with a dedicated message on the indicate a fault in the Forward...
Page 130 GETTING TO KNOW YOUR INSTRUMENT PANEL indicated on the vehicle placard or tire inflation Your vehicle has also been equipped with a CAUTION! pressure label, you should determine the TPMS malfunction indicator to indicate when proper tire inflation pressure for those tires. the system is not operating properly.
Page 131: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Axle Locker Fault Indicator Light Service Adaptive Cruise Control Warning ELLOW NDICATOR IGHTS Light — If Equipped This light indicates when the front 4WD Indicator Light — If Equipped and/or rear axle locker fault has been This light will turn on when a ACC is This light alerts the driver that the detected.
Page 132: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Low Diesel Emissions Additive AdBlue® 4WD Auto Indicator Light — If Equipped CAUTION! (UREA) Indicator Light — If Equipped This light alerts the driver that the The presence of water in the fuel system cir- vehicle is in the four-wheel drive auto The Low Diesel Exhaust Emissions cuit may cause severe damage to the injec-...
Page 133: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Stop/Start Active Indicator Light — If 2WD High Indicator Light — If Equipped NOTE: If the vehicle is not in 4WD Low, “To Enter Equipped With a Premium Instrument Cluster Selec-Speed Shift to 4WD Low” will appear in This indicator light will illuminate This light alerts the driver that the the instrument cluster display.
Page 134: Gray Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL turn off the high beams. If the high beams are vehicle will usually be drivable and not need WARNING! off, pull the lever toward you for a temporary towing, see an authorized dealer for service as high beam on, "flash to pass"...
Page 135 GETTING TO KNOW YOUR INSTRUMENT PANEL For states that require an Inspection 2. As soon as you cycle the ignition switch to If your OBD II system is not ready, you should and Maintenance (I/M), this check the ON position, you will see the see an authorized dealer or repair facility.
Page 136: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE — GASOLINE — I UTOMATIC RANSMISSION WARNING! (Continued) QUIPPED ENGINE (IF EQUIPPED) Do not leave children or animals inside  Start the vehicle with the gear selector in the parked vehicles in hot weather. Interior Before starting your vehicle, adjust your seat, PARK position (vehicle can also be started in heat build-up may cause serious injury or...
Page 137: Autopark
STARTING AND OPERATING NOTE: remain in the ACC mode (NOT the OFF mode) 4. Push the ENGINE START/STOP button a Normal starting of either a cold or a warm if the engine is turned off when the third time to return the ignition to the OFF engine is obtained without pumping or pressing transmission is not in PARK.
Page 138 STARTING AND OPERATING If the vehicle is not in PARK and the driver exits If the driver shifts into PARK while moving, the WARNING! (Continued) the vehicle with the engine running, the vehicle vehicle may AutoPark. may AutoPark. AutoPark is a supplemental feature. It is not ...
Page 139: Extreme Cold Weather (Below -22°F Or −30°C)
STARTING AND OPERATING The message “AutoPark Not Engaged” will be FTER TARTING WARNING! displayed in the instrument cluster. A warning The idle speed is controlled automatically and chime will continue until you shift the vehicle Never pour fuel or other flammable liquid ...
Page 140: Automatic Transmission
STARTING AND OPERATING required for cold starts with temperatures CAUTION! WARNING! (Continued) under -20°F (-28°C). The engine is allowed to crank as long as Never leave children alone in a vehicle, or   NOTE: 30 seconds. If the engine fails to start with access to an unlocked vehicle.
Page 141: Starting Fluids
STARTING AND OPERATING NOTE: TARTING LUIDS WARNING! (Continued) A delay of the start of up to five seconds is The engine is equipped with a glow plug possible under very cold conditions. The "Wait Do not leave the key fob in or near the ...
Page 142: Cold Weather Precautions
STARTING AND OPERATING EATHER RECAUTIONS Operation in ambient temperature below 32°F (0°C) may require special considerations. The following charts suggest these options: Fuel Operating Range NOTE: Use “Ultra Low Sulfur Diesel Fuels (ULSD)” ONLY. Fuel Operating Range Chart *Number 1 ULSD Fuel should only be used where extended arctic conditions 0°F (-18°C) exist.
Page 143: Engine Idling
STARTING AND OPERATING NOTE: Winter Front Cover NGINE DLING Use of Climatized ULSD Fuel or Number A Winter front or cold weather cover can be  Avoid prolonged idling, long periods of idling 1 ULSD Fuel results in a noticeable decrease used in ambient temperatures below 32°F may be harmful to your engine because in fuel economy.
Page 144: Cooling System Tips - Automatic Transmission
STARTING AND OPERATING Idle Time (min.) Before Engine Driving Condition Load Turbocharger Temperature Shutdown Stop and Go Empty Cool None Stop and Go Medium Highway Speeds Medium Warm City Traffic Maximum GCWR Highway Speeds Maximum GCWR Uphill Grade Maximum GCWR NOTE: Up Steep Hills —...
Page 145: Engine Block Heater - If Equipped
STARTING AND OPERATING Do Not Operate The Engine With Failed WARNING! Parts Remember to disconnect the engine block All engine failures give some warning before the heater cord before driving. Damage to the parts fail. Be on the alert for changes in 110-115 Volt AC electrical cord could cause performance, sounds, and visual evidence that electrocution.
Page 146: Engine Break-In Recommendations
STARTING AND OPERATING For the recommended viscosity and quality Check the coolant and oil levels frequently. parking brake, pull the lever up slightly, push  grades see Ú page 438. the center button, then lower the lever Vary throttle position at highway speeds ...
Page 147: Manual Transmission - If Equipped
STARTING AND OPERATING When parking on a hill, it is important to turn the CAUTION! WARNING! (Continued) front wheels toward the curb on a downhill grade and away from the curb on an uphill If the “Brake Warning Light” remains on with Never leave children alone in a vehicle, or ...
Page 148: Shifting
STARTING AND OPERATING NOTE: NOTE: During cold weather, you may experience A certain amount of noise from the transmis- increased effort in shifting until the transmis- sion is normal. This noise can be most notice- sion fluid warms up. This is normal. able when the vehicle is idling in NEUTRAL with the clutch engaged (clutch pedal released), but it may also be heard when driving.
Page 149: Downshifting
STARTING AND OPERATING Manual Transmission Shift Speeds in MPH (KM/H) Engine Speeds 1 to 2 2 to 3 3 to 4 4 to 5 5 to 6 Accel. 15 (24) 24 (39) 50 (80) 65 (104) 70 (112) 3.6L Cruise 10 (16) 19 (31) 40 (64)
Page 150: Automatic Transmission - If Equipped
STARTING AND OPERATING Maximum Recommended Downshift Speeds CAUTION! Failure to follow the maximum recommended downshifting speeds may cause the engine to overspeed and/or damage the clutch disc, even if the clutch pedal is pressed. Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4...
Page 151: Ignition Park Interlock
STARTING AND OPERATING NOTE: WARNING! (Continued) WARNING! (Continued) The transmission is NOT locked in PARK when the ignition is in the ACC mode (even though the It is dangerous to shift out of PARK or Never leave children alone in a vehicle, or ...
Page 152 STARTING AND OPERATING shift from NEUTRAL into DRIVE or REVERSE The transmission gear selector provides PARK, (1, 2, 3, etc.) is displayed in the instrument when the vehicle is stopped or moving at low REVERSE, NEUTRAL, DRIVE and MANUAL cluster. Move the gear selector to the right (into speeds.
Page 153 STARTING AND OPERATING When exiting the vehicle, always: WARNING! (Continued) WARNING! (Continued) Apply the parking brake.  The transmission may not engage PARK if Unintended movement of a vehicle could   Shift the transmission into PARK.  the vehicle is moving. Always bring the injure those in or near the vehicle.
Page 154 STARTING AND OPERATING Look at the transmission gear position  CAUTION! WARNING! (Continued) display and verify that it indicates the PARK position (P), and is not blinking. Towing the vehicle, coasting, or driving for Do not leave the key fob in or near the ...
Page 155 STARTING AND OPERATING During extremely cold temperatures (-22°F restarted. The Malfunction Indicator Light (MIL) 3. Push and hold the ignition switch until the [-30°C] or below), transmission operation may may be illuminated. A message in the engine turns off. be modified depending on engine and instrument cluster will inform the driver of the 4.
Page 156: Four-Wheel Drive Operation
STARTING AND OPERATING FOUR–WHEEL DRIVE OPERATION selector (in the MANUAL position) to manually Holding the gear selector in the (-) position  will downshift the transmission to the lowest shift the transmission. gear possible at the current speed. WARNING! AutoStick mode has the following operational Transmission shifting will be more noticeable benefits: ...
Page 157 STARTING AND OPERATING The transfer case provides four mode positions: N (Neutral) The transfer case is intended to be driven in the 2WD High position for normal street and 2H (2WD High) — Two-Wheel Drive High  WARNING! highway conditions, such as hard-surfaced Range roads.
Page 158 STARTING AND OPERATING Proper operation of four-wheel drive vehicles NOTE: position. Do not pause with the transfer case in depends on tires of equal size, type, and N (Neutral). Once the shift is completed, place Do not attempt to make a shift while only the ...
Page 159: Five-Position Transfer Case - If Equipped
STARTING AND OPERATING — I For additional information on the appropriate N (Neutral) OSITION RANSFER use of each transfer case mode position, see QUIPPED WARNING! the information below: 2WD High You or others could be injured or killed if you leave the vehicle unattended with the transfer Two-Wheel Drive High Range —...
Page 160 STARTING AND OPERATING This transfer case is designed to be driven in The instrument cluster alerts the driver that the motion, the transfer case will engage/ the two-wheel drive position (2WD) or vehicle is in four-wheel drive, and the front and disengage faster if you momentarily release the four-wheel drive position (4WD AUTO) for rear driveshafts are locked together.
Page 161: Trac-Lok Rear Axle - If Equipped
STARTING AND OPERATING Delayed shifts out of four-wheel drive may be required for clutch teeth alignment and shift  WARNING! experienced due to uneven tire wear, low or completion to occur. The preferred method is with uneven tire pressures, excessive vehicle the vehicle rolling at 1 to 3 mph (2 to 5 km/h).
Page 162: Equipped
STARTING AND OPERATING — I This feature will only activate when the following Ignition in RUN position, vehicle in 4WD High.  conditions are met: The vehicle must be in Off Road+ active QUIPPED  Ú page 162. Ignition in RUN position, vehicle in 4WD Low. ...
Page 163: Electronic Sway Bar Disconnect - If Equipped
STARTING AND OPERATING — met. The stabilizer/sway bar should remain in NOTE: LECTRONIC ISCONNECT on-road mode during normal driving conditions. The stabilizer/sway bar may be torque locked QUIPPED due to left and right suspension height differ- Your vehicle may be equipped with an WARNING! ences.
Page 164: Off Road+ - If Equipped
STARTING AND OPERATING + — I When Off Road+ is active, the following features 4H (4WD High) QUIPPED will activate: Engine/Transmission Calibration: Improved  sand performance/ wheel slip focus, change The Off Road+ telltale will illuminate in the  in shift schedule for sport mode, pedal cali- instrument cluster display bration set to aggressive, operates at A mode specific message will display the...
Page 165: Electro-Hydraulic Power Steering
STARTING AND OPERATING ELECTRO-HYDRAULIC POWER STEERING STOP/START SYSTEM — AUTOMATIC If the “POWER STEERING HOT” message and an icon are displayed on the instrument cluster TRANSMISSION (IF EQUIPPED) Your vehicle is equipped with an screen, it indicates that extreme steering electro-hydraulic power steering system that maneuvers may have occurred, which caused The Engine Stop/Start (ESS) function is...
Page 166: Autostop Mode
STARTING AND OPERATING Secondary Battery UTOSTOP OSSIBLE EASONS NGINE Your vehicle may be equipped with a secondary UTOSTOP WARNING! battery used to power the Stop/Start system Prior to engine shut down, the system will check and the 12 Volt vehicle electrical system. The Vehicles with the Stop/Start system will be ...
Page 167: To Start The Engine While In Autostop Mode
STARTING AND OPERATING Hood is open. Conditions That Will Cause The Engine To Start ANUALLY  Automatically While In Autostop Mode: Transfer case is in 4WD Low or N (Neutral).  TART YSTEM The transmission selector is moved out of Brake pedal is not pressed with sufficient ...
Page 168: To Manually Turn On The Stop/Start System
STARTING AND OPERATING a vehicle stop if the required conditions are ANUALLY met. Pressing the clutch pedal will TART YSTEM automatically restart the vehicle. Push the Stop/Start OFF switch (located on the ESS vehicles have been upgraded with a heavy switch bank).
Page 169: Possible Reasons The Engine Does Not Autostop
STARTING AND OPERATING The Stop/Start feature is enabled after every Driver’s seat belt is not buckled. TART NGINE HILE  driver ignition start. It will remain in STOP/ Outside temperature is less than 10°F  UTOSTOP START NOT READY until you drive forward with a (–12°C) or greater than 109°F (43°C).
Page 170: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING CRUISE CONTROL SYSTEMS — IF EQUIPPED 5. The Stop/Start system will reset itself back ANUALLY to an ON condition every time the ignition is TART YSTEM Your vehicle may be equipped with the Cruise turned off and back on. 1.
Page 171 STARTING AND OPERATING To Set A Desired Speed WARNING! Turn the Cruise Control on. Cruise Control can be dangerous where the NOTE: system cannot maintain a constant speed. The vehicle should be traveling at a steady Your vehicle could go too fast for the condi- speed and on level ground before pushing the tions, and you could lose control and have an SET (+) or SET (-) button.
Page 172: Adaptive Cruise Control (Acc) - If
STARTING AND OPERATING Metric Speed (km/h) Engine overspeed occurs  WARNING! Pushing the SET (+), or SET (-) button once Clutch pedal is pressed (manual transmis-   Cruise Control can be dangerous where the will result in a 1 km/h speed adjustment. sion only) system cannot maintain a constant speed.
Page 173 STARTING AND OPERATING mance of the Adaptive Cruise Control and WARNING! (Continued) WARNING! (Continued) Forward Collision Warning system. Cannot take street, traffic, and weather You should switch off the ACC system: Fixed Speed Cruise Control alone (an ACC   ...
Page 174 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Adaptive Cruise Control Off When the system is turned on and in the ready state, the instrument cluster displays “ACC When ACC is deactivated, the display will read The buttons on the right side of the steering Ready.”...
Page 175 STARTING AND OPERATING To Activate/Deactivate different modes, push the ACC on/off button On vehicles equipped with a manual which turns the ACC and the Fixed Speed Cruise transmission, the ACC system cannot be set Push and release the Adaptive Cruise Control Control off.
Page 176 STARTING AND OPERATING The vehicle parking brake is applied To Resume To Vary The Speed Setting  The braking temperature exceeds normal If there is a set speed in the memory, push the To Increase Or Decrease The Set Speed ...
Page 177 STARTING AND OPERATING NOTE: Setting The Following Distance In ACC To increase the distance setting, push the When you override and push the SET (+) button Distance Setting Increase button and release. The specified following distance for ACC can be or SET (-) buttons, the new set speed will be the Each time the button is pushed, the distance set by varying the distance setting between four...
Page 178 STARTING AND OPERATING The maximum braking applied by ACC is limited; is triggered when the driver utilizes the left turn WARNING! however, the driver can always apply the brakes signal and will only be active when passing on manually, if necessary. the left hand side.
Page 179 STARTING AND OPERATING The ACC system will recover after the vehicle Do not attach or install any accessories near display “ACC/FCW Limited Functionality Clean  has left these areas. Under rare conditions, the sensor, including transparent material or Front Windshield” and the system will have aftermarket grilles.
Page 180 STARTING AND OPERATING “Service ACC/FCW” Warning The offset vehicle may move in and out of the line of travel, which can cause your vehicle to If the system turns off, and the instrument brake or accelerate unexpectedly. cluster displays “ACC/FCW Unavailable Service Required”...
Page 181: Parksense Rear Park Assist - If
STARTING AND OPERATING Lane Changing Narrow Vehicles ACC may not detect a vehicle until it is Some narrow vehicles, such as motorcycles, completely in the lane in which you are traveling near the outer edges of the lane or traveling. In the lane changing example below, merging into the lane are not detected until they have moved to the center of the lane.
Page 182: Parksense Sensors
STARTING AND OPERATING ParkSense can be active only when the gear If an obstacle is detected in the center rear ENSE ARNING ISPLAY selector is in REVERSE. If ParkSense is enabled region, the display will show a single solid arc in The ParkSense Warning screen is located within at this gear selector position, the system will the center rear region and will produce a...
Page 183 STARTING AND OPERATING Rear ParkSense Arcs 1 — Continuous Tone/Flashing Arc 4 — Slow Tone/Solid Arc 2 — Fast Tone/Flashing Arc 5 — Slow Tone/Solid Arc 3 — Fast Tone/Flashing Arc 6 — Single 1/2 Second Tone/Solid Arc...
Page 184: Enabling And Disabling Parksense
STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Greater than Less than Rear Distance...
Page 185: Service The Parksense Rear Park Assist System
STARTING AND OPERATING If “PARKSENSE UNAVAILABLE SERVICE ParkSense, when on, will reduce the volume ERVICE ENSE  REQUIRED” appears in the instrument cluster of the radio when it is sounding a tone. SSIST YSTEM display, see an authorized dealer. Clean the ParkSense sensors regularly, ...
Page 186: Parkview Rear Back Up Camera
STARTING AND OPERATING Manual Activation Of The Rear View Camera WARNING! CAUTION! 1. Press the “Controls” button located on the Drivers must be careful when backing up ParkSense is only a parking aid and it is   bottom of the Uconnect display. even when using ParkSense.
Page 187: Trailcam System - If Equipped
STARTING AND OPERATING NOTE: The following table shows the approximate CAUTION! distances for each zone: If the vehicle speed remains below 8 mph  To avoid vehicle damage, ParkView should (13 km/h), the Rear View Camera image will  Distance To The Rear Zone only be used as a parking aid.
Page 188 STARTING AND OPERATING The TrailCam view can also be activated by NOTE: pressing the icon on the Backup Camera If the vehicle speed remains below 8 mph  view. The Backup Camera view can also be (13 km/h) while in 2WD or 4WD High, the activated by pressing the icon on the TrailCam image will be displayed continu-...
Page 189: Refueling The Vehicle - Gasoline Engine (If Equipped)
STARTING AND OPERATING REFUELING THE VEHICLE — GASOLINE CAUTION! ENGINE (IF EQUIPPED) Damage to the fuel system or emission  control system could result from using an ILLER improper fuel filler cap. A poorly fitting cap The fuel filler cap is located on the driver's side could let impurities into the fuel system.
Page 190: Loose Fuel Filler Cap Message
STARTING AND OPERATING NOTE: OOSE ILLER ESSAGE When the fuel nozzle “clicks” or shuts off, the  After fuel has been added, the vehicle fuel tank is full. diagnostic system can determine if the fuel filler Tighten the fuel filler cap about a quarter turn cap is possibly loose, improperly installed, or ...
Page 191: Bulk Fuel Storage - Diesel Fuel
STARTING AND OPERATING — D The purpose of the SCR system is to reduce Temperature sensors TORAGE IESEL  levels of NOx (oxides of nitrogen emitted from SCR catalyst  If you store quantities of fuel, good engines) that are harmful to our health and the The DEF injection system and SCR catalyst maintenance of the stored fuel is also essential.
Page 192 STARTING AND OPERATING DEF is subject to freezing at the lowest DEF Fill Procedure you have a fault related to the DEF system, the gauge may not update to the new level. temperatures. For example, DEF may freeze at NOTE: temperatures at or below 12°F (-11°C).
Page 193 STARTING AND OPERATING Refilling With Containers CAUTION! (Continued) CAUTION! (Continued) Proceed as follows: DO NOT OVERFILL. DEF will freeze below Never add anything other than DEF to the   Check the expiration date.  12ºF (-11ºC). The DEF system is designed tank –...
Page 194: Vehicle Loading
STARTING AND OPERATING VEHICLE LOADING Payload Inflation Pressure The payload of a vehicle is defined as the This is the cold tire inflation pressure for your ERTIFICATION ABEL allowable load weight a truck can carry, vehicle for all loading conditions up to full As required by National Highway Traffic Safety including the weight of the driver, all GAWR.
Page 195: Trailer Towing
STARTING AND OPERATING exceeded but the total load is within the towing a trailer, carefully review this information The recommended way to measure GTW is to specified GVWR. If so, weight must be shifted to tow your load as efficiently and safely as put your fully loaded trailer on a vehicle scale.
Page 196 STARTING AND OPERATING Tongue Weight (TW) Weight-Carrying Hitch stability. Trailer sway control and a weight distributing (load equalizing) hitch are The TW is the downward force exerted on the A weight-carrying hitch supports the trailer recommended for heavier Tongue Weights (TW) hitch ball by the trailer.
Page 197: Trailer Hitch Classification
STARTING AND OPERATING RAILER ITCH LASSIFICATION The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.
Page 198: Trailer And Tongue Weight
STARTING AND OPERATING NOTE: NOTE: WARNING! (Continued) The trailer tongue weight must be considered as Remember that everything put into or on the part of the combined weight of occupants and trailer adds to the load on your vehicle. Also, When hauling cargo, or towing a trailer, do ...
Page 199 STARTING AND OPERATING Towing Requirements — Tires WARNING! WARNING! (Continued) Proper tire inflation pressures are essential  Do not connect trailer brakes to your Total weight must be distributed between   to the safe and satisfactory operation of your vehicle's hydraulic brake lines.
Page 200: Towing Tips
STARTING AND OPERATING Towing Requirements — Trailer Lights And 3 — Right Stop/Turn Wiring 4 — Electric Brakes 5 — Ground Whenever you pull a trailer, regardless of the 6 — Left Stop/Turn trailer size, stoplights and turn signals on the trailer are required for motoring safety.
Page 201: Recreational Towing (Behind Motorhome)
STARTING AND OPERATING This action will also provide better engine shifts. For example, choose “5” if the desired Cruise Control — If Equipped braking. speed can be maintained. Choose “4” or “3” Do not use in hilly terrain or with heavy loads. ...
Page 202: Recreational Towing Four -Wheel Drive Models
STARTING AND OPERATING — ECREATIONAL OWING WARNING! CAUTION! (Continued) HEEL RIVE ODELS You or others could be injured or killed if you Before recreational towing, perform the  procedure outlined under “Shifting Into (N) leave the vehicle unattended with the transfer NOTE: Neutral”...
Page 203: Driving Tips
STARTING AND OPERATING 11. Firmly apply the parking brake. 6. Turn the engine off. CAUTION! 12. Shift the transmission into PARK or place 7. Shift the transfer case lever to the desired It is necessary to follow these steps to be cer- manual transmission in gear (NOT in position.
Page 204: Off-Road Driving Tips
STARTING AND OPERATING applications. Specific design characteristics give them a higher center of gravity than conventional passenger cars. An advantage of the higher ground clearance is a better view of the road, allowing you to anticipate problems. They are not designed for cornering at the same speeds as conventional passenger cars any more than low-slung sports cars are designed to perform satisfactorily in...
Page 205 STARTING AND OPERATING The Basics Of Off-Road Driving WARNING! CAUTION! You will encounter many types of terrain driving Always wear your seat belt and firmly tie down Do not use 4WD Low when operating the off-road. You should be familiar with the terrain cargo.
Page 206 STARTING AND OPERATING still applying throttle. This will allow the tires to Sand Crossing Obstacles (Rocks And Other High get a fresh "bite" and help maintain your Points) Soft sand is very difficult to travel through with momentum. full tire pressure. When crossing soft, sandy While driving off-road, you will encounter many spots in a trail, maintain your vehicle's types of terrain.
Page 207 STARTING AND OPERATING where they can see the obstacle, watch your crossing large obstacles with steep sides. Do Then ease the vehicle off the log using your tires and undercarriage, and guide you through. not attempt to cross any large obstacle with brakes.
Page 208 STARTING AND OPERATING Hill Climbing Driving Up Hill WARNING! Once you have determined your ability to Hill climbing requires good judgment and a Never attempt to climb a hill at an angle or proceed and have shifted into the appropriate good understanding of your abilities and your turn around on a steep grade.
Page 209 STARTING AND OPERATING Driving Across An Incline transmission), with the transfer case in the WARNING! 4WD Low position and proceed very slowly with If at all possible, avoid driving across an incline. If the engine stalls or you lose headway or a constant slow speed of {3 to 5 mph (5 to If it is necessary, know your vehicle's abilities.
Page 210 STARTING AND OPERATING Before You Cross Any Type Of Water to entering. This makes for a faster, cleaner and the large surface area of the vehicle's body. easier vehicle recovery. If you are able to Before you proceed, determine the speed of the As you approach any type of water, you need to determine you can safely cross, than proceed current, the water's depth, approach angle,...
Page 211 STARTING AND OPERATING Check threaded fasteners for looseness, NOTE: If you experience unusual vibration after   particularly on the chassis, drivetrain compo- Inspect the clutch vent holes in the manual driving in mud, slush or similar conditions, nents, steering, and suspension. Retighten check the wheels for impacted material.
Page 212: Multimedia
MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain WARNING! security features to reduce the risk of For detailed information about your Uconnect unauthorized and unlawful access to vehicle It is not possible to know or to predict all of ...
Page 213: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS NOTE: USTOMER ROGRAMMABLE EATURES FCA US LLC or an authorized dealer may  The Uconnect system uses a combination of contact you directly regarding software buttons on the touchscreen and buttons on the updates. faceplate located on the center of the To help further improve vehicle security and ...
Page 214 MULTIMEDIA NOTE: When making a selection, only press one button press the X button on the touchscreen to close at a time to enter the desired menu. Once in the out of the settings screen. Pressing the Up or Depending on the vehicle’s options, feature ...
Page 215 MULTIMEDIA Setting Name Description This setting will allow you to set the brightness when the headlights are Display Brightness With Headlights OFF/Brightness off. To access this setting, Display Mode must be set to Manual. The “+” setting will increase the brightness; the “-” will decrease the brightness. Theme This setting will allow you to change the display theme.
Page 216 MULTIMEDIA Voice When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature. Setting Name Description This setting will change the response length for the Voice Recognition system. The “Brief” setting provides a shortened audio description from Voice Response Length the system.
Page 217 MULTIMEDIA Setting Name Description This setting will allow you to set the minutes. Sync Time With GPS must Set Time Minutes be off for this setting to be available. The “+” setting will increase the minutes. The “-” setting will decrease the minutes. Show Time in Status Bar/Show Time Status This setting will place the time in the radio’s status bar.
Page 218 MULTIMEDIA Safety & Driving Assistance When the Safety & Driving Assistance button is selected on the touchscreen, the system displays the options related to the vehicle’s safety settings. These options will differ depending on the features equipped on the vehicle. The settings may display in list form or within subfolders on the screen. To access a subfolder, select the desired folder;...
Page 219 MULTIMEDIA Setting Name Description This setting will change the type of alert provided when an object is detected in a vehicle’s blind spot. The “Off” setting will turn off Blind Spot Blind Spot Alert Alert. The “Lights” setting will activate the Blind Spot Alert lights on the outside mirrors.
Page 220 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchased.
Page 221 MULTIMEDIA Setting Name Description This setting will unlock the doors when any of the doors are opened from Auto Unlock On Exit the inside. This setting will allow you to turn the flashing of the lights when the Lock Flash Lights With Lock button is pushed on the key fob on or off.
Page 222 MULTIMEDIA Seats & Comfort/Auto-On Comfort Systems When Seats & Comfort/Auto-On Comfort Systems button is pressed on the touchscreen, the system displays the option related to the vehicle’s comfort systems when remote start has been activated or the vehicle has been started. Setting Name Description This setting will activate the vehicle’s comfort system and heated seats (if...
Page 223 MULTIMEDIA Key Off Options/Engine Off Options After pressing the Key Off Options/Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Description This setting will keep certain electrical features running after the engine Doors On Key Off Power Delay/Doors On Power Delay is turned on.
Page 224 MULTIMEDIA Setting Name Description This setting will adjust audio volume as speeds increase. At a higher set- Speed Adjusted Volume ting, the volume will increase more as the vehicle speeds up. The avail- able settings are “Off”, “1”, “2”, and “3”. This setting will tune the audio levels from a device connected through AUX Volume Offset the AUX port.
Page 225 MULTIMEDIA Setting Name Description This setting will activate phone message pop-ups in the Instrument Clus- Phone Pop-ups Displayed In Cluster ter Display. This setting will activate your smartphone to be projected on the vehicle’s Smartphone Projection Manager — If Equipped touchscreen.
Page 226 MULTIMEDIA Reset/Restore Settings When the Reset/Restore Settings button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can clear personal data and reset selected settings from other menus. Setting Name Description Reset App Drawer To Default Order...
Page 227: Uconnect Introduction
MULTIMEDIA UCONNECT INTRODUCTION NOTE: Uconnect screen images are for illustration YSTEM VERVIEW purposes only and may not reflect exact soft- ware for your vehicle. Uconnect 4 With 7-inch Display Uconnect 3 With 5-inch Display 1 — Radio Button 2 — Media Button 1 —...
Page 228 MULTIMEDIA Feature Description Press the Radio button or Media button to enter Radio Mode/Media Radio/Media Mode and access the radio functions and external audio sources Ú page 228. Press the Phone button to enter Phone Mode and access the hands-free Phone phone system Ú...
Page 229: Drag & Drop Menu Bar
MULTIMEDIA Feature Description Press the Controls button to access vehicle-specific features like heated Controls seats and steering wheel. Apps Press the Apps button to access a list of the available Uconnect apps. Press the Climate button to enter Climate Mode and access the climate Climate control functions Ú...
Page 230: Uconnect Modes
MULTIMEDIA Ensure the volume level of the system is set Care And Maintenance  to a level that still allows you to hear outside Do not press the touchscreen with any hard  traffic and emergency vehicles. or sharp objects (pen, USB stick, jewelry, etc.), which could scratch the surface.
Page 231: Radio Mode
MULTIMEDIA The following describes the left-hand control ADIO operation in each mode: Radio Controls Radio Operation Pushing the top of the switch will Seek Up for the next available station and pushing the bottom of the switch will Seek Down for the next available station.
Page 232 MULTIMEDIA Press the Radio button on the touchscreen to Seek Info — If Equipped enter the Radio Mode. The different tuner The Seek Up and Down functions are activated Press the Info button to display information modes, AM, FM, and SXM, can then be selected by pressing the double arrow buttons on the related to the currently playing song and radio by pressing the corresponding buttons in Radio...
Page 233 MULTIMEDIA like to hear. (Subscription or included All fees and programming subject to change. SiriusXM® Satellite Radio trial required.) SiriusXM® satellite service is available only to those at least 18 and older in the 48 contiguous Push the VR button on the steering wheel USA and D.C.
Page 234 MULTIMEDIA Acquiring SiriusXM® Subscription In addition to the tuning operation functions common to all radio modes, the replay, Traffic/ To activate the SiriusXM® Satellite Radio Weather button, and Favorite button functions subscription, US residents visit siriusxm.com/ are available in SiriusXM® Mode. getallaccess or call: 1-800-643-2112 Canadian residents visit https:// www.siriusxm.ca/ or call: 1-888-539-7474.
Page 235 MULTIMEDIA Press the Replay button on the touchscreen. The play/pause, rewind/forward and live buttons will display at the top of the screen, along with the replay time. You can exit by pressing the Replay button on the touchscreen any time during the Replay Mode. Press the Pause/Play button on the touchscreen to pause the playing of live or Play/Pause rewound content at any time.
Page 236 MULTIMEDIA Browse In SXM Channel List Press the Channel List to display Favorites  all the SiriusXM® Channel Numbers. You can Press the Favorites button on the Browse scroll the Channel List by pressing the Up and screen. Down arrows, located on the right side of the The Favorites menu provides a means to edit screen.
Page 237 MULTIMEDIA Game Zone Alert Settings Press the Game Zone button, located at the left Press the Alert Setting tab at the top of the of the Browse screen. This feature provides you screen. The Alert Settings menu allows you to with the ability to select teams, edit the choose from “Alert me to on-air games upon start”...
Page 238 MULTIMEDIA Preset Features — If Equipped Audio Settings Browse In AM/FM Press the Audio button within the settings main menu to activate the Audio Settings screen. When in either AM or FM, the Browse Screen provides a means to edit the Presets List and is The audio settings can also be accessed on the entered by pushing the Enter/Browse button.
Page 239 MULTIMEDIA Audio Setting Description Press the Balance/Fade button on the touchscreen to balance audio between the front speakers or fade the audio between the rear and front Balance/Fade speakers. Press the Front, Rear, Left or Right buttons or press and drag the red Speaker icon to adjust the Balance/Fade.
Page 240: Media Mode
MULTIMEDIA select the Browse button on the touchscreen to EDIA be given these options: Operating Media Mode Now Playing  Artists  Albums  Genres  Songs  Playlists  Folders  You can press the Source, Pause/Play, or the Uconnect 4 With 7-inch Display Operating Media Mode Info button on the touchscreen for artist 1 —...
Page 241 MULTIMEDIA On the Uconnect 3 With 5-inch Display, if you Controlling The Auxiliary Device insert a USB device with the ignition ON, the unit The control of the Auxiliary device (e.g., will switch to USB Mode and begin to play. The selecting playlists, play, fast forward, etc.) display will show the track number and index cannot be provided by the radio;...
Page 242 MULTIMEDIA touchscreen to return to the beginning of the In Bluetooth® Mode, press the Media button on Info current selection, or return to the beginning of the touchscreen to select the desired audio In both Disc and USB Modes, press the Info the previous selection if the Bluetooth®...
Page 243: Phone Mode
MULTIMEDIA Media Voice Commands The feature supports the following: Reviewing your recent Incoming SMS  Messages. Uconnect offers connections via USB, Voice Activated Features Pairing up to 10 phones/audio devices for Bluetooth®, and auxiliary (AUX) ports. Voice  Hands-Free dialing via Voice (“Call John ...
Page 244 MULTIMEDIA button you will hear a BEEP. The BEEP is your You will be prompted for a specific command WARNING! signal to give a command. and then guided through the available options. ALWAYS drive safely with your hands on the Voice Command Button Prior to giving a voice command, one must ...
Page 245 MULTIMEDIA Natural Speech To activate the Uconnect Phone from idle, Please visit UconnectPhone.com for complete mobile phone compatibility information. simply push the Phone button (if active) on your Your Uconnect Phone Voice system uses a steering wheel and say a command or say Natural Language Voice Recognition (VR) engine.
Page 246 MULTIMEDIA Follow the steps below to pair your phone: sure the PIN on the touchscreen matches the system automatically when entering the PIN from the pop-up on your mobile phone. vehicle. Only one mobile phone and/or one 1. Place the ignition in the ACC or ON/RUN Bluetooth®...
Page 247 MULTIMEDIA Bluetooth® connection. If this happens, simply 6. Uconnect Phone will display an in-process 2. Press the Paired Phones/Audio Sources repeat the pairing process. However, first make screen while the system is connecting. buttons. sure to delete the device from the list of phones 7.
Page 248 MULTIMEDIA 6. Press the X to exit out of the Settings Selecting “Ok” or “Allow” will sync your contacts screen. with the Uconnect system. See the Uconnect website, Making A Phone Or Audio Device A Favorite UconnectPhone.com, for supported phones. 1.
Page 249 MULTIMEDIA phone. The changes are transferred and favorites. This will bring up the options for Call Controls updated to Uconnect Phone on the next that Favorite contact. The touchscreen allows you to control the phone connection. following call features: 3. Deselect the Star icon to delete the Favorite.
Page 250 MULTIMEDIA 4. Use the numbered buttons on the touchscreens to enter the number and press “Dial/Call”. Recent Calls — If Equipped You may browse a list of the most recent of each of the following call types: All Calls  Incoming Calls or Calls Received Uconnect 4 With 7-inch Display ...
Page 251 MULTIMEDIA Answer Or Ignore An Incoming Call — Call Automatic reply messages can be: your mobile phone), recent calls, SMS Inbox or Currently In Progress from the phonebooks. “I am driving right now, I will get back to you  If a call is currently in progress and you have shortly”.
Page 252 MULTIMEDIA If two calls are in progress (one active and one Call Continuation Ensure that no one other than you is  speaking during a voice command period on hold), press the Swap Calls button on the Call continuation is the progression of a phone phone main screen.
Page 253 MULTIMEDIA Number and name recognition rate is optimized mobile phone compatibility and pairing Listen to the Uconnect prompts. After the when the entries are not similar. You can say instructions. beep, repeat one of the predefined messag- “O” (letter “O”) for “0” (zero). es and follow the system prompts.
Page 254: Android Auto™ & Apple Carplay® - If Equipped
MULTIMEDIA Did You Know: Your mobile phone must have steering wheel. After you hear a double beep, display. Android Auto™ brings you useful the full implementation of the Message Access you can ask Siri to play podcasts and music, get information, and organizes it into simple cards Profile (MAP) to take advantage of this feature.
Page 255 MULTIMEDIA NOTE: NOTE: Navigation  Be sure to use the factory-provided USB cable Android Auto™ is set to launch immediately Live traffic information  that came with your phone, as aftermarket once a compatible device is connected. You can Lane guidance ...
Page 256: Apple Carplay
MULTIMEDIA NOTE: Android Auto™ Voice Command Text Messages  To see the track details for the music playing Additional Apps  NOTE: through Android Auto™, select the Uconnect Feature availability depends on your carrier and NOTE: system’s media screen. mobile phone manufacturer. Some Android Requires compatible smartphone running For further information, refer to https:// Auto™...
Page 257 MULTIMEDIA To use Apple CarPlay®, make sure you are Messages  using iPhone® 5 or later, have Siri enabled in Maps  Settings, ensure your iPhone® is unlocked for Phone the very first connection only, and then use the following procedure: With Apple CarPlay®, push and hold the VR button on the steering wheel to 1.
Page 258: Android Auto™ And Apple Carplay® Tips And Tricks
MULTIMEDIA Messages Refer to http://www.apple.com/ios/carplay/ Phone  (US) or https://www.apple.com/ca/ios/ Music Push and hold the VR button on the  carplay/ (Canada) to see the latest list of steering wheel to activate a Siri voice Messages  available apps for Apple CarPlay®. recognition session.
Page 259: Connected Vehicle Services - If
MULTIMEDIA connections to function. The connected device these buttons are present in your vehicle, you NOTE: is unavailable to other devices when connected have a connected radio and can take SiriusXM Guardian™ involves the collection, using Android Auto™ or Apple CarPlay®. advantage of the many connected vehicle transmission and use of data from your vehicle Ú...
Page 260 MULTIMEDIA What Is SiriusXM Guardian™? Other factors outside the control of SiriusXM The ASSIST and SOS Call Buttons On Your  Guardian™ that may limit or prevent service Rearview Mirror Or Overhead Console SiriusXM Guardian™ uses an embedded device delivery are hills, structures, buildings, The ASSIST Button is used for contacting in the Uconnect system installed in your vehicle, tunnels, weather, damage to the electrical...
Page 261: Getting Started With Connected Vehicle Services
MULTIMEDIA Included Trial Period For New Vehicles Download the Uconnect app to your mobile  device. Your new vehicle may come with an included Use your Owner Account login and password trial period for use of the SiriusXM Guardian™  to open the app and then set up a PIN.
Page 262 MULTIMEDIA d. After clicking the email link, it will take Start, and activate your horn and lights For customers in Canada, press the My Vehicle remotely, if equipped. you to a website and prompt you to button. Select from “Dashboard”, “Vehicle assign your account with a password.
Page 263: Using Siriusxm Guardian
MULTIMEDIA text message, push notification, and/or E-mail Access To Emergency Services At The Push Of A NOTE: to notify you of the event. To set up the Button Certain SiriusXM Guardian™ services are notifications, please follow these instructions. dependent on an operational Uconnect system, Center Light Status Description cellular network availability that is compatible...
Page 264 MULTIMEDIA 2. Once a connection between the vehicle and An in-vehicle audio message will state Requirements  “Vehicle phone requires service. Please a SiriusXM Guardian™ Customer Care agent This feature is available only on vehicles sold  is made, the agent will stay on the line with contact your dealer.”...
Page 265 MULTIMEDIA WARNING! (Continued) WARNING! (Continued) WARNING! (Continued) Do not add any aftermarket electrical The Occupant Restraint Controller (ORC) If anyone in the vehicle could be in danger    equipment to the vehicle’s electrical turns on the Air Bag Warning Light on the (e.g., fire or smoke is visible, dangerous system.
Page 266 MULTIMEDIA 4. A message will let you know if the command 3 — Horn & Lights: Press this button to sound the was received by your vehicle. horn and activate your lights. 4 — Unlock: Press this button to unlock your vehicle. Using A Remote Command Through Your 5 —...
Page 267 MULTIMEDIA 5. A message will appear on the screen to let Working Vehicle Conditions NOTE: you know if the command was received by All other remote services should be performed The vehicle must in PARK or at a standstill.  your vehicle.
Page 268 MULTIMEDIA Working Vehicle Conditions NOTE: rules and ordinances in the location of your The SiriusXM Guardian™ Customer Care agents vehicle when using Remote Horn & Lights. The vehicle must be off or in ACC mode.  are not authorized for Remote Vehicle Start The vehicle has been started with the key fob ...
Page 269 MULTIMEDIA SiriusXM Guardian™ In-Vehicle Assistance Disclaimers Features If Roadside Assistance Call is provided to your With SiriusXM Guardian™, your vehicle has vehicle, you agree to be responsible for any onboard assistance features located on the additional roadside assistance service costs rearview mirror or overhead console designed that you may incur.
Page 270 MULTIMEDIA How It Works 4. Confirm your destination inside your vehicle by pressing the Send To Vehicle option on 1. Use the Uconnect App to find the the pop-up that appears on the radio destination. touchscreen. There are multiple ways to find a destina- tion.
Page 271 MULTIMEDIA Vehicle must have an operable LTE (voice/ Vehicle Finder  data) or 3G or 4G (data) network connection Description compatible with your device. The Vehicle Finder feature of the Uconnect App allows you to find the location of your stationary vehicle.
Page 272 MULTIMEDIA 3. You can also select the “Person” icon to see Vehicle must be registered with SiriusXM  WARNING! Guardian™ and have an active subscription your location. that includes the applicable feature. The driver should NEVER use the 4G Wi-Fi 4.
Page 273 MULTIMEDIA Use one of these three ways to purchase a The SiriusXM Guardian™ Customer Care WARNING! subscription to the 4G Wi-Fi Hotspot: Agent will ask for the stolen vehicle report Always drive safely with your hands on the number (as issued by your local law enforce- 1.
Page 274 MULTIMEDIA Requirements SiriusXM Guardian™ and to FCA, such as your NOTE: vehicle’s health and performance, your Vehicle Health Alert emails require you to Vehicle must be properly equipped with the  vehicle’s location, your utilization of the register and activate services. During this Uconnect system.
Page 275 MULTIMEDIA Amazon Alexa® Skill — If Equipped An active subscription to SiriusXM Guardian™ is Google Assistant — If Equipped required. To use Amazon Alexa®, first, register Enjoy the convenience of using your voice to With the Google Assistant, you can get help and for SiriusXM Guardian™...
Page 276 MULTIMEDIA To link your Uconnect account with Google Monitor vehicle vitals, such as tire press, fuel SmartWatch Integration — If Equipped  level and oil life Assistant, follow these steps: Description And more! 1. Download and install the Google Assistant ...
Page 277: Manage M Y Sirius Xm Guardian Account
MULTIMEDIA Uconnect Market 6. Accept the Uconnect market Terms of ASSIST button and then select SiriusXM Guardian™ Call on your in-vehicle touchscreen Service. With Uconnect Market, you can enjoy seamless to contact SiriusXM Guardian™. Your call will be 7. Enter your credit card information, and and secure transactions from the comfort of directed to a SiriusXM Guardian™...
Page 278: Connected Services Remote Door Lock/Unlock Faqs
MULTIMEDIA & G remotely command your vehicle. Other ONNECTED ERVICES EMOTE ONNECTED ERVICES operating systems may be supported in the NLOCK future. 1. How long does it take to unlock or lock the 1. How long does it take to send the route and 5.
Page 279: Connected Services Stolen Vehicle
MULTIMEDIA your responsibility to guard your PIN do so. We will also provide the service for ONNECTED ERVICES EMOTE EHICLE accordingly. See the Uconnect and FCA entities to locate a vehicle that you TART SiriusXM Guardian™ terms of service for have purchased through them.
Page 280: Connected Services Remote Horn & Lights Faqs
MULTIMEDIA Remote Start feature simply starts the 2. Which is faster, my key fob or the Uconnect Push the Assist button. A call will be  engine to warm up or cool down the interior App? Your key fob will sound the horn and placed to an agent who can assist in before you arrive.
Page 281 MULTIMEDIA 3. How do I create a SiriusXM Guardian™ Guardian™ Security PIN can be updated in advance of your expiration date to remind security PIN? Set up your SiriusXM online on your Owner’s Site. Log in to your you that your subscription is ending soon. Guardian™...
Page 282: Data Collection & Privacy
MULTIMEDIA from the date of cancellation for annual 18. What will happen if an operable LTE (voice/ Connected Vehicle Services Inc. and shared plans or longer. Please see the Uconnect and data), 4G (data), or 5G (data) network with FCA US LLC for the purposes stated in the SiriusXM Guardian™...
Page 283: Radio Operation And Mobile Phones
MULTIMEDIA RADIO OPERATION AND MOBILE PHONES The radio manufacturer believes the internal wireless radio is safe for use by consumers. The Under certain conditions, the mobile phone level of energy emitted is far less than the being on in your vehicle can cause erratic or electromagnetic energy emitted by wireless noisy performance from your radio.
Page 284: Off-Road Pages Status Bar
MULTIMEDIA AGES TATUS RIVETRAIN The Off-Road Pages Status Bar is located along The Drivetrain page displays information the bottom of Off-Road Pages and is present in concerning the vehicle’s drivetrain. each of the three selectable page options. It The following information is displayed: provides continually updating information for Steering angle in degrees ...
Page 285: Accessory Gauge
MULTIMEDIA & R — I CCESSORY AUGE ITCH RAIL QUIPPED The Accessory Gauge page displays the current The Pitch & Roll page displays the vehicle’s Your vehicle may be equipped with a TrailCam status of the vehicle’s Coolant Temperature, Oil current pitch (angle up and down) and roll that allows you to see an on-screen image of the Temperature, Oil Pressure (Gas Vehicles Only),...
Page 286: Safety
SAFETY SAFETY FEATURES Brake pedal pulsations  WARNING! (Continued) A slight drop of the brake pedal at the end of  (ABS) RAKE YSTEM The ABS cannot prevent the natural laws of the stop  physics from acting on the vehicle, nor can The ABS provides increased vehicle stability ABS is designed to function with the Original it increase braking or steering efficiency...
Page 287: Electronic Brake Control (Ebc) System
SAFETY and that service is required. However, the Brake System Warning Light braking is no longer desired. Once the brake conventional brake system will continue to pedal is released, the BAS is deactivated. The red Brake System Warning Light will turn on operate normally if the ABS Warning Light is on.
Page 288 SAFETY that the rate of change of the steering wheel Electronic Stability Control (ESC) Indicator Light begins to flash during angle and vehicle’s speed are sufficient to acceleration, ease up on the accelerator and ESC enhances directional control and stability potentially cause wheel lift, it then applies the apply as little throttle as possible.
Page 289 SAFETY Partial Off WARNING! (Continued) WARNING! (Continued) This mode may be useful if the vehicle becomes Vehicle modifications, or failure to properly Trailer Sway Control (TSC) is disabled when  stuck. This mode may modify TCS and ESC  maintain your vehicle, may change the the ESC system is in the “Partial Off”...
Page 290 SAFETY at any speed and will remain in "Full Off" mode ESC Activation/Malfunction Indicator Light The ESC OFF Indicator Light indicates until Off Road+ is exited or ESC is re-enabled by the customer has elected to have the And ESC OFF Indicator Light the driver.
Page 291 SAFETY HDC has three states: using the gear shift +/-. The following Driver Override summarizes the HDC set speeds: 1. Off (feature is not enabled and will not The driver may override HDC activation with activate). HDC Target Set Speeds throttle or brake application at any time.
Page 292 SAFETY The vehicle is driven greater than 20 mph The vehicle must be on a sufficient grade.   WARNING! (32 km/h) for greater than 70 seconds. The gear selection must match vehicle uphill  HDC is only intended to assist the driver in The vehicle is driven greater than 40 mph direction (i.e., vehicle facing uphill is in ...
Page 293 SAFETY Disabling And Enabling HSA Rain Brake Support (RBS) 2. Enabled (feature is enabled and ready but activation conditions are not met, or driver This feature can be turned on or turned off. To RBS may improve braking performance in wet is actively overriding with brake or throttle change the current setting, refer to Ú...
Page 294 SAFETY The set speed for SSC is selectable by the mission will shift appropriately for the The vehicle is driven greater than 20 mph  driver-selected set speed and corresponding (32 km/h) for greater than 70 seconds. driver, and can be adjusted by using the gear shift +/-.
Page 295: Auxiliary Driving Systems
SAFETY AUXILIARY DRIVING SYSTEMS Trailer Sway Control (TSC) WARNING! TSC uses sensors in the vehicle to recognize an (BSM) — I LIND ONITORING SSC is only intended to assist the driver in excessively swaying trailer and will take the controlling vehicle speed when driving in QUIPPED appropriate actions to attempt to stop the sway.
Page 296 SAFETY The BSM detection zone covers approximately when a motorcycle or any small object The BSM system notifies the driver of objects in remains at the side of the vehicle for one lane width on both sides of the vehicle 12 ft the detection zones by illuminating the BSM (3.8 m).
Page 297 SAFETY Entering From The Side Vehicles that move into your adjacent lanes from either side of the vehicle. Rear Monitoring Overtaking/Approaching Overtaking Traffic If you pass another vehicle slowly with a relative speed less than 15 mph (24 km/h) and the Side Monitoring vehicle remains in the blind spot for Entering From The Rear...
Page 298 SAFETY The BSM system will not alert you of objects that Rear Cross Path (RCP) When RCP is on and the vehicle is in REVERSE, are traveling in the opposite direction of the the driver is alerted using both the visual and RCP is intended to aid the driver when backing vehicle in adjacent lanes Ú...
Page 299: Forward Collision Warning (Fcw) With
SAFETY Blind Spot Modes NOTE: jerk, to warn the driver when it detects a Whenever an audible alert is requested by the potential frontal collision. The warnings are Blind Spot has three selectable modes of BSM system, the radio is also muted. intended to provide the driver with enough time operation that are available in the Uconnect to react, avoid or mitigate the potential collision.
Page 300 SAFETY If a FCW with Mitigation event begins at a speed NOTE: WARNING! below 32 mph (52 km/h), the system may The minimum speed for FCW activation is  provide the maximum braking possible to miti- Forward Collision Warning (FCW) is not 3 mph (5 km/h).
Page 301 SAFETY NOTE: More dynamic or aggressive drivers that   want to avoid frequent warnings may When the FCW is “on”, this allows the system When the sensitivity of FCW is set to the   prefer this setting. to warn the driver of a possible collision with “Far”...
Page 302: Tire Pressure Monitoring System (Tpms)
SAFETY The TPMS will warn the driver of a low tire For example, your vehicle may have a RESSURE ONITORING YSTEM pressure if the tire pressure falls below the recommended cold (parked for more than three (TPMS) low-pressure warning limit for any reason, hours) placard pressure of 33 psi (227 kPa).
Page 303 SAFETY NOTE: pressure levels. Sensors, mounted to each CAUTION! wheel as part of the valve stem, transmit tire The TPMS is not intended to replace normal  The TPMS has been optimized for the orig- pressure readings to the receiver module. ...
Page 304 SAFETY Tire Pressure Monitoring Low Pressure Warn- "Inflate to XX" message. Once the system the system fault no longer exists, the TPMS ings receives the updated tire pressures, the system Warning Light will no longer flash, and the will automatically update, the pressure values “SERVICE TIRE PRESSURE SYSTEM”...
Page 305 SAFETY a chime to sound, an Inflate to XX message Beginning with the next ignition cycle, the TPMS NOTE: to appear in the instrument cluster, and the will no longer chime or display the “SERVICE Only one tire can be filled at a time when ...
Page 306 SAFETY When Tire Fill Alert mode is entered, the tire Uconnect system, you will be able to select a hazard lamps will come on to confirm the pressure display screen will be displayed in the pressure setting for both the front and rear axle vehicle is in Tire Fill Alert mode.
Page 307: Occupant Restraint Systems
SAFETY OCCUPANT RESTRAINT SYSTEMS 2. A child who is not big enough to wear the 9. If the air bag system in this vehicle needs to vehicle seat belt properly must be secured be modified to accommodate a disabled Some of the most important safety features in in the appropriate child restraint or person, see Ú...
Page 308 SAFETY in a collision. Some of the worst injuries happen BeltAlert is not active when an outboard front sequence will begin until the seat belts are when people are thrown from the vehicle. Seat passenger seat is unoccupied. buckled again. belts reduce the possibility of ejection and the BeltAlert Warning Sequence The outboard front passenger seat BeltAlert is...
Page 309 SAFETY Lap/Shoulder Belts WARNING! (Continued) WARNING! (Continued) All seating positions in your vehicle are It is dangerous to ride in a cargo area, Two people should never be belted into a   equipped with lap/shoulder belts. inside or outside of a vehicle. In a collision, single seat belt.
Page 310 SAFETY WARNING! (Continued) WARNING! (Continued) A seat belt that is buckled into the wrong A shoulder belt placed behind you will not   buckle will not protect you properly. The lap protect you from injury during a collision. portion could ride too high on your body, You are more likely to hit your head in a possibly causing internal injuries.
Page 311 SAFETY 4. Position the lap belt so that it is snug and necessary, slide the latch plate down the and move it up or down to the position that lies low across your hips, below your webbing to allow the seat belt to retract serves you best.
Page 312 SAFETY verify the shoulder belt anchorage is latched, (if equipped) is in its lowest position, an Seat Belts And Pregnant Women pull downward on the shoulder belt anchorage authorized dealer can provide you with a Seat until it is locked into position. Belt Extender.
Page 313 SAFETY performance of the seat belt by removing slack used to secure a child restraint system. The If the passenger seating position is equipped from the seat belt early in a collision. figure below illustrates the locking feature for with an ALR and is being used for normal usage, Pretensioners work for all size occupants, each seating position Ú...
Page 314: Supplemental Restraint Systems (Srs)
SAFETY How To Disengage The Automatic Locking Mode UPPLEMENTAL ESTRAINT YSTEMS WARNING! Unbuckle the combination lap/shoulder belt (SRS) Never place a rear-facing child restraint in  and allow it to retract completely to disengage Some of the safety features described in this front of an air bag.
Page 315 SAFETY Front and Side Impact Sensors single chime will sound to alert you if the light  WARNING! comes on again after initial startup. Seat Belt Pretensioners  Ignoring the Air Bag Warning Light in your The ORC also includes diagnostics that will Seat Track Position Sensors ...
Page 316 SAFETY Front Air Bags the Occupant Restraint Controller (ORC), which WARNING! may receive information from the front impact This vehicle has front air bags and lap/shoulder Being too close to the steering wheel or sensors (if equipped) or other system ...
Page 317 SAFETY category other than a properly seated adult. On the other hand, depending on the type and WARNING! (Continued) This could be a child, teenager, or even an location of impact, front air bags may deploy in adult. crashes with little vehicle front-end damage but Do not put anything on or around the air ...
Page 318 SAFETY Occupant Classification System (OCS) — Occupant Classification Module (OCM) And Sensor Front Passenger Seat The Occupant Classification Module (OCM) is The Occupant Classification System (OCS) is located underneath the front passenger seat. part of a Federally regulated safety system for The Sensor is located beneath the passenger this vehicle.
Page 319 SAFETY Passenger Air Bag Disable (PAD) System Front Passenger Advanced Air Bag Front Passenger Seat Occupant Status Front Passenger Air Bag Status Disabled Indicator Light (“PAD”) Status Unoccupied seat* Unbuckled NOT ILLUMINATED DEACTIVATED Unoccupied seat*Buckled “PASSENGER AIR BAG OFF” DEACTIVATED Grocery bags, heavy briefcases, and other rela- “PASSENGER AIR BAG OFF”...
Page 320 SAFETY Front Air Bag will not deploy during a collision. Indicator Light. NEVER assume the Passenger comfortably on or near the floor, and with When the front passenger seat is empty or Advanced Front Air Bag is deactivated unless their back against the seatback. when very light objects are placed on the seat the PAD Indicator Light is illuminated with the 5.
Page 321 SAFETY AIR BAG OFF” when an adult is in the front activation of the Passenger Advanced Front Air WARNING! (Continued) passenger seat, have the passenger reposition Bag. Examples of improper front passenger his or her body in the seat until the PAD seating include: Never install a rear-facing child restraint in ...
Page 322 SAFETY The OCS determines the front passenger’s most WARNING! probable classification. If an occupant in the front passenger seat is seated improperly, the If a child restraint system, child, small teen-  ager or adult in the front passenger seat is occupant may provide an output signal to the OCS that is different from the occupant’s seated improperly, the occupant may...
Page 323 SAFETY The following requirements must be strictly The Air Bag Warning Light will illuminate WARNING! (Continued) followed: whenever the OCS is unable to classify the front If there is a fault present in the OCS, both passenger seat status.  Do not modify the front passenger seat ...
Page 324 SAFETY WARNING! WARNING! Unapproved modifications or service proce- Do not drill, cut, or tamper with the knee   dures to the passenger seat assembly, its impact bolsters in any way. related components, seat cover, or cushion Do not mount any accessories to the knee ...
Page 325 SAFETY Side Impacts Side Air Bags are a supplement to the seat belt WARNING! restraint system. Side Air Bags deploy in less The Side Air Bags are designed to activate in time than it takes to blink your eyes. Side Air Bags need room to inflate. Do not certain side impacts.
Page 326 SAFETY Air Bag System Components NOTE: the garment manufacturer’s instructions for cleaning. Front and/or side air bags will not deploy in all NOTE: collisions. This does not mean something is Do not drive your vehicle after the air bags have The Occupant Restraint Controller (ORC) moni- wrong with the air bag system.
Page 327 SAFETY determine whether to have the Enhanced Automatic transmission gear selector START or ON/RUN to ignition OFF. Carefully  Accident Response System perform the check the vehicle for fuel leaks in the engine Horn  following functions: compartment and on the ground near the Front wiper engine compartment and fuel tank before ...
Page 328: Child Restraints
SAFETY understanding how a vehicle’s systems To read data recorded by an EDR, special WARNING! (Continued) performed. The EDR is designed to record data equipment is required, and access to the related to vehicle dynamics and safety systems vehicle or the EDR is needed. In addition to the It is dangerous to try to repair any part of ...
Page 329 SAFETY There are different sizes and types of restraints applicable Safety Standards. You should also WARNING! for children from newborn size to the child make sure that you can install it in the vehicle In a collision, an unrestrained child can almost large enough for an adult safety belt.
Page 330 SAFETY Infant And Child Restraints Children should remain in a forward-facing child WARNING! seat with a harness for as long as possible, up Safety experts recommend that children ride Never place a rear-facing child restraint in to the highest weight or height allowed by the ...
Page 331 SAFETY Children Too Large For Booster Seats If the answer to any of these questions was WARNING! (Continued) “no”, then the child still needs to use a booster Children who are large enough to wear the seat in this vehicle. If the child is using the lap/ After a child restraint is installed in the ...
Page 332 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of LATCH – Lower Restraint Type the Child + Child LATCH – Lower Seat Belt + Top Seat Belt Only Anchors + Top Tether Restraint Anchors Only Tether Anchor...
Page 333 SAFETY LATCH Positions For Installing Child Restraints In This Vehicle LATCH Positions (Four-Door Models) Lower Anchorage Symbol (2 Anchorages Per Seating Position) LATCH Positions (Two-Door Models) Top Tether Anchorage Symbol Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol...
Page 334 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the com- What is the weight limit (child’s weight + weight bined weight of the child and the child restraint of the child restraint) for using the LATCH 65 lbs (29.5 kg) is 65 lbs (29.5 kg).
Page 335 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH The child seat may touch the back of the front Can the rear-facing child restraint touch the passenger seat if the child restraint manufac- back of the front passenger seat? turer also allows contact.
Page 336 SAFETY Locating The Upper Tether Anchorages Two-Door Models: There are tether strap anchorages behind each rear seating position located on the back of the seat, near the floor. LATCH Anchorages (Two-Door Models) Tether Strap Anchorages (Four-Door Models) LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side.
Page 337 SAFETY Center Seat LATCH move it to its rear-most position to make WARNING! (Continued) room for the child seat. You may also move Two-Door Models: the front seat forward to allow more room Please see Ú page 335 for typical installa- WARNING! for the child seat.
Page 338 SAFETY being used to secure child restraints. An unused Installing Child Restraints Using The Refer to the “Automatic Locking Mode” belt could injure a child if they play with it and description in “Switchable Automatic Locking Vehicle Seat Belt accidentally lock the seat belt retractor. Before Retractors (ALR)”...
Page 339 SAFETY Automatic Locking Retractor Locations (Four-Door Models) ALR — Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight Always use the tether anchor when using the of the child restraint) for using the Tether Anchor seat belt to install a forward facing child Weight limit of the Child Restraint...
Page 340 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts Two Door — None Four Door — The center head restraint can be Two Door Models – No Can the rear head restraints be removed? removed if it interferes with the installation of Four Door Models –...
Page 341 SAFETY 1. Place the child seat in the center of the 6. Try to pull the webbing out of the retractor. Installing Child Restraints Using The Top seating position. If the second row seat can If it is locked, you should not be able to pull Tether Anchorage be reclined, you may recline the seat and/ out any webbing.
Page 342 SAFETY no top tether anchorage for that seating WARNING! (Continued) position, move the child restraint to another position in the vehicle if one is If your vehicle is equipped with a split rear  available. seat, make sure the tether strap does not slip into the opening between the seat- 2.
Page 343: Safety Tips
SAFETY 3. Attach the tether strap hook of the child position. If the light is either not on during RANSPORTING restraint to the center tether anchorage starting, stays on, or turns on while driving, have Air Bags deploying in the front seat could harm located on the back of the seat.
Page 344: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY WARNING! WARNING! (Continued) WARNING! (Continued) An improperly attached, damaged, folded, or ONLY use the driver’s side floor mat on the If the vehicle carpet has been removed and   stacked floor mat, or damaged floor mat fas- driver’s side floor area. To check for inter- re-installed, always properly attach carpet teners may cause your floor mat to interfere ference, with the vehicle properly parked...
Page 345: Exhaust Gas
SAFETY Lights the vehicle is raised for lubrication or oil WARNING! (Continued) change. Replace as required. Have someone observe the operation of brake If you are required to drive with the trunk/  lights and exterior lights while you work the ARBON ONOXIDE ARNINGS...
Page 346: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS motion. Use it when your vehicle is disabled and If equipped, the overhead console contains an it is creating a safety hazard for other motorists. ASSIST and an SOS button. The Hazard Warning Flashers switch is located When you must leave the vehicle to seek WARNING! on the instrument panel below the climate...
Page 347 IN CASE OF EMERGENCY ASSIST Call SOS call button on the overhead console or WARNING! press the cancellation button on the Device The ASSIST Button is used to automatically Screen. Termination of the SOS Call will turn off ALWAYS obey traffic laws and pay attention to connect you to any one of the following support the green LED light on the overhead console.
Page 348 IN CASE OF EMERGENCY 5. The SOS operator may attempt to contact SOS Call System Limitations WARNING! (Continued) appropriate emergency responders and Vehicles sold in Mexico DO NOT have SOS Call provide them with important vehicle The SOS Call system is embedded into the ...
Page 349 IN CASE OF EMERGENCY LTE (voice/data) or 4G (data) network NOTE:  WARNING! (Continued) congestion Your vehicle may be transmitting data as  The Occupant Restraint Control module Weather  authorized by the subscriber.  turns on the air bag Warning Light on the Buildings, structures, geographic terrain, or Never place anything on or near the vehicle’s ...
Page 350: Jacking And Tire Changing
IN CASE OF EMERGENCY JACKING AND TIRE CHANGING NOTE: WARNING! Passengers should not remain in the vehicle Do not attempt to change a tire on the side of when the vehicle is being lifted or raised. WARNING! the vehicle close to moving traffic. Pull far OCATION Do not attempt to change a tire on the side ...
Page 351: Spare Tire Removal
IN CASE OF EMERGENCY 2. Remove the hardware storage cover by PARE EMOVAL pinching the latch on the left side and 1. To remove the spare tire from the carrier, pulling upward. remove the tire cover, if equipped. 2. Remove the Rear Camera Cover by turning the lock bolt counterclockwise with the #T40 torx head driver and ratchet from the supplied tool kit.
Page 352 IN CASE OF EMERGENCY WARNING! (Continued) Block the wheel diagonally opposite the  wheel to be raised. Never start or run the engine with the  vehicle on a jack. Do not let anyone sit in the vehicle when it ...
Page 353 IN CASE OF EMERGENCY 8. Install the lug nuts with the cone-shaped end toward the wheel. Lightly tighten the lug nuts clockwise. WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the wheel nuts fully until the vehicle has been lowered.
Page 354: Jump Starting
IN CASE OF EMERGENCY 12. Remove the jack assembly and wheel WARNING! CAUTION! blocks. A loose tire or jack thrown forward in a colli- Do not use a portable battery booster pack or 13. Secure the jack and tools in their proper sion or hard stop, could endanger the occu- any other booster source with a system volt- locations.
Page 355 IN CASE OF EMERGENCY If your vehicle is equipped with a Stop/Start WARNING! system, it will be equipped with two batteries Only use the positive battery post on the Ú page 163.  main battery to jump start your vehicle. See below steps to prepare for jump starting: Serious injury or death could result if you 1.
Page 356: Jump Starting Procedure
IN CASE OF EMERGENCY an accessory bracket or large bolt. The CAUTION! WARNING! (Continued) ground must be away from the battery and Failure to follow these procedures could the fuel injection system. Remove any metal jewelry such as rings,  watch bands and bracelets that could result in damage to the charging system of WARNING!
Page 357: If Your Engine Overheats
IN CASE OF EMERGENCY Disconnecting The Jumper Cables CAUTION! CAUTION! 1. Disconnect the negative (-) end of the Accessories plugged into the vehicle power Driving with a hot cooling system could dam- jumper cable from the engine ground of outlets draw power from the vehicle’s battery, age your vehicle.
Page 358: Manual Park Release
IN CASE OF EMERGENCY In order to push or tow the vehicle in cases WARNING! where the transmission will not shift out of You or others can be badly burned by hot PARK (P) (such as a depleted battery), a Manual engine coolant (antifreeze) or steam from Park Release is available.
Page 359: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY FREEING A STUCK VEHICLE vehicle Ú page 286. Once the vehicle has CAUTION! (Continued) been freed, push the ESC OFF switch again to If your vehicle becomes stuck in mud, sand or restore “ESC On” mode. When “rocking”...
Page 360: Four Wheel Drive Models
IN CASE OF EMERGENCY Towing Condition Wheels OFF The Ground 4WD MODELS Automatic Transmission in PARK (P)  Manual Transmission in gear (NOT in NEUTRAL)  Flat Tow NONE Transfer Case in NEUTRAL (N)  Tow in forward direction  Front NOT ALLOWED Wheel Lift Or Dolly Tow...
Page 361: Without The Key Fob
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM WARNING! CAUTION! (Continued) (EARS) Do not use a chain for freeing a stuck Towing this vehicle in violation of the above   vehicle. Chains may break, causing serious requirements can cause severe transmis- This vehicle is equipped with an Enhanced sion and/or transfer case damage.
Page 362: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING — GASOLINE On non-instrument cluster display equipped Once A Month Or Before A Long Trip: vehicles, “Change Oil” will flash in the Check the engine oil level.  ENGINE instrument cluster odometer and a single chime Check the windshield washer fluid level.
Page 363: Maintenance Plan
SERVICING AND MAINTENANCE AINTENANCE Refer to the maintenance plan for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter  Rotate the tires  NOTE: Rotate at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. Inspect battery and clean and tighten terminals as required ...
Page 364 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first): Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints Inspect front suspension, tie rod ends, rear suspension, and replace if necessary Inspect the front and rear axle fluid Inspect the brake linings, replace as necessary Adjust parking brake on vehicles equipped with four wheel disc brakes Inspect transfer case fluid...
Page 365 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first): Or Years: Or Kilometers: Flush and replace the engine, intercooler (if equipped) coolant at 10 years or 150,000 miles (240,000 km) whichever comes first Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more than 50% of your driving is at sustained high speeds during hot...
Page 366: Scheduled Servicing - Diesel Engine
SERVICING AND MAINTENANCE ambient temperatures will influence when the remove the filter and use a suction gun to WARNING! “Oil Change Required” message is displayed. remove any residual oil left in the housing or You can be badly injured working on or Have your vehicle serviced as soon as possible, wait about 30 minutes for the oil to drain back ...
Page 367: Maintenance Plan - Diesel Fuel Up To B5 Biodiesel
SERVICING AND MAINTENANCE — D B5 B AINTENANCE IESEL IODIESEL Refer to the maintenance plan for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter.  Completely fill the Diesel Exhaust Fluid tank. ...
Page 368 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Completely fill the Diesel Exhaust Fluid tank. Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, and replace if neces- sary. Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer tow- ing.
Page 369 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150, 000 miles (240,000 km) whichever comes first. Replace accessory drive belt(s). Change transfer case fluid. —...
Page 370: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 2.0L G ASOLINE NGINE 1 — Battery 6 — Brake Fluid Reservoir Cap 2 — Power Distribution Center (Fuses) 7 — Washer Fluid Reservoir Cap 3 — Engine Oil Dipstick 8 — Intercooler Coolant Reservoir Cap 4 —...
Page 371: L Gasoline Engine
SERVICING AND MAINTENANCE 3.6L G ASOLINE NGINE 1 — Power Distribution Center (Fuses) 7 — Power Pack Unit Pressure Cap — If Equipped 2 — Battery 8 — Washer Fluid Reservoir Cap 3 — Engine Oil Dipstick 9 — Motor Generator Unit Coolant Pressure Cap— If Equipped 4 —...
Page 372: L Diesel Engine
SERVICING AND MAINTENANCE 3.0L D IESEL NGINE 1 — Battery 6 — Engine Air Cleaner Filter 2 — Engine Oil Fill 7 — Engine Oil Dipstick 3 — Engine Coolant Pressure Reservoir 8 — Power Steering Reservoir Cap 4 — Brake Fluid Reservoir Cap 9 —...
Page 373: Checking Oil Level
SERVICING AND MAINTENANCE HECKING EVEL AINTENANCE ATTERY CAUTION! To ensure proper engine lubrication, the engine Your vehicle is equipped with a Overfilling or underfilling the crankcase will oil must be maintained at the correct level. maintenance-free battery. You will never have cause aeration or loss of oil pressure.
Page 374: Pressure Washing
SERVICING AND MAINTENANCE perform all service operations in an expert WARNING! (Continued) CAUTION! (Continued) manner. Service Manuals are available which include detailed service information for your Vehicles with the Stop/Start system will be Vehicles with the Stop/Start system will be ...
Page 375: Engine Oil Filter
SERVICING AND MAINTENANCE requirements of FCA Material Standard American Petroleum Institute (API) Engine Materials Added To Engine Oil MS-13340. An equivalent full synthetic engine Oil Identification Symbol FCA strongly recommends against the addition oil can be used if it meets API SP/GF-6 of any additives (other than leak detection dyes) This symbol means that the oil has Certification.
Page 376: Engine Air Cleaner Filter
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and NGINE LEANER ILTER Replacement — Gasoline Engine For the proper maintenance intervals Follow the recommended maintenance Ú page 361 for gasoline engines or Ú page 365 for diesel engines. intervals as shown in the Maintenance Schedule in this section.
Page 377: Draining Fuel/Water Separator Filter - Diesel Engine
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and RAINING ATER EPARATOR Replacement — Diesel Engine — D ILTER IESEL NGINE Follow the recommended maintenance The fuel/water separator housing is located intervals as shown in the Maintenance inside the left frame rail in front of the fuel tank. Schedule in this section.
Page 378: Fuel Filter Replacement - Diesel Engine
SERVICING AND MAINTENANCE NOTE: Care should be taken in disposing of used fluids from your vehicle. Used fluids, indiscriminately discarded, can present a problem to the envi- ronment. Contact an authorized dealer, service station, or government agency for advice on recycling programs and for where used fluids and filters can be properly disposed of in your area.
Page 379 SERVICING AND MAINTENANCE 3. Place drain pan under the fuel filter CAUTION! (Continued) assembly. Do not prefill the fuel filter when installing a  4. Open the water drain valve, and let any new fuel filter. There is a possibility debris accumulated water and fuel drain.
Page 380: Priming If The Engine Has Run Out Of Fuel - Diesel Engine
SERVICING AND MAINTENANCE 11. Install the new fuel filter cartridge onto the In addition, commercially available fuel addi-  CAUTION! tives are not necessary for the proper opera- cap. The starter motor will engage for approxi- tion of your diesel engine. 12.
Page 381: Diesel Exhaust Fluid
SERVICING AND MAINTENANCE WARNING! WARNING! (Continued) A hot exhaust system can start a fire if you When working near the radiator cooling fan,  park over materials that can burn. Such mate- disconnect the fan motor lead. The fan is rials might be grass or leaves coming into temperature controlled and can start at any contact with your exhaust system.
Page 382: Air Conditioner Maintenance
SERVICING AND MAINTENANCE Some conditions can be caused by a faulty CAUTION! WARNING! (Continued) component such as a belt pulley. Belt pulleys should be carefully inspected for damage and Do not use chemical flushes in your air condi- The air conditioning system contains refrig- ...
Page 383 SERVICING AND MAINTENANCE Cabin Air Filter 5. Remove the air filter from the HVAC air inlet housing. Pull the filter elements out WARNING! pinching them to the right for clearance. Do not remove the cabin air filter while the vehicle is running, or while the ignition is in the ACC or ON/RUN mode.
Page 384: Body Lubrication
SERVICING AND MAINTENANCE 8. Rotate the glove compartment door back easy operation and to protect against rust and Avoid using the wiper blades to remove frost or into position ensuring you have properly wear. Prior to the application of any lubricant, ice from the windshield.
Page 385 SERVICING AND MAINTENANCE Wiper Blade Removal/Installation 2. To disengage the wiper blade from the wiper Installing The Front Wipers arm, push the release tab on the wiper 1. Lift the wiper arm off of the glass, until the CAUTION! blade and while holding the wiper arm with wiper arm is in the full up position.
Page 386: Exhaust System
SERVICING AND MAINTENANCE 2. Lift wiper arm off of the glass and rotate detected inside the vehicle; or when the wiper blade outward to disengage the wiper underside or rear of the vehicle is damaged; blade from the wiper arm. have an authorized technician inspect the complete exhaust system and adjacent body areas for broken, damaged, deteriorated, or...
Page 387: Cooling System
SERVICING AND MAINTENANCE NOTE: OOLING YSTEM CAUTION! Intentional tampering with emissions control WARNING! The catalytic converter requires the use of systems can result in civil penalties being  unleaded fuel only. Leaded gasoline will assessed against you. You or others can be badly burned by hot ...
Page 388 SERVICING AND MAINTENANCE freezing weather, where applicable). If the If the engine coolant (antifreeze) is dirty or products, as they may not be compatible with the radiator engine coolant and may plug the engine, battery (if equipped), intercooler (if contains visible sediment, have an authorized equipped), and MGU (if equipped) coolant is dealer clean and flush with OAT coolant radiator.
Page 389 SERVICING AND MAINTENANCE Please review these recommendations for according to the temperatures occurring in WARNING! using Organic Additive Technology (OAT) engine the area where the vehicle is operated. coolant that meets the requirements of FCA Do not open hot engine cooling system. Some vehicles require special tools to add ...
Page 390 SERVICING AND MAINTENANCE Coolant Level Engine Coolant Level — 2.0L The radiator normally remains completely full, so there is no need to remove the radiator/ The coolant bottle provides a quick visual WARNING! coolant pressure cap unless checking for method for determining that the coolant level is engine coolant freeze point or replacing adequate.
Page 391: Brake System
SERVICING AND MAINTENANCE If an examination of your engine compartment factory engine cooling performance, poor gas wear. Brake fluid level should be checked when shows no evidence of radiator or hose leaks, mileage, and increased emissions. pads are replaced. If the brake fluid is the vehicle may be safely driven.
Page 392: Front/Rear Axle Fluid
SERVICING AND MAINTENANCE Adding Fluid Drain And Refill WARNING! (Continued) Add lubricant only at the fill hole and only to the For the proper maintenance intervals Overfilling the brake fluid reservoir can  level specified above. Ú page 361. result in spilling brake fluid on hot engine Selection Of Lubricant Selection Of Lubricant parts, causing the brake fluid to catch fire.
Page 393: Automatic Transmission - If Equipped
SERVICING AND MAINTENANCE Selection Of Lubricant dipstick. An authorized dealer can check your Selection Of Lubricant transmission fluid level using special service Use only FCA recommended manual It is important to use the proper transmission tools. If you notice fluid leakage or transmission transmission fluid Ú...
Page 394: Fuses
SERVICING AND MAINTENANCE The fuses protect electrical systems against Power Distribution Center (PDC) USES excessive current. The Power Distribution Center is located in the General Information When a device does not work, you must check engine compartment near the battery. This center the fuse element inside the blade fuse for a contains cartridge fuses, mini fuses, and relays.
Page 395 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description – – Spare 40 Amp Green – Starter – 5 Amp Tan Intelligent Battery Sensor (IBS) – 20 Amp Yellow Fuel Pump MTR/FPCM – 5 Amp Tan Security Gateway – – Spare –...
Page 396 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink – Central Body Controller (CBC) 1-INTERIOR LIGHTS – 20 Amp Yellow REAR WIPER Engine Control Module (ECM)/Powertrain Control Module – 10 Amp Red (PCM)/Motor Generator Unit (MGU) WAKE UP/Power Pack Unit (PPU) WAKE UP Powertrain Control Module (PCM)/Engine Control Module –...
Page 397 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description Electronic Stability Control (ESC)/Electric Hydraulic Power – 10 Amp Red Steering (EHPS)/Smart Bar Control Module (SBCM) WAKE 30 Amp Pink – BRAKE VAC PMP — If Equipped 30 Amp Pink – TRAILER TOW MOD —...
Page 398 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description Digital TV (DSRC)/USB/InSide RearView Mirror (ISRVM)/ – 10 Amp Red Compass Module (CSGM) – 20 Amp Yellow CIGAR LTR – – Spare – – Spare – 10 Amp Red Central Vision Processing Module (CVPM) –...
Page 399 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description Motor Generator Unit MGU Belt Starter Generator (BSG) — – 5 Amp Tan If Equipped – 25 Amp Clear INJ/IGN COIL (GAS)/GLO PLUG MOD (DSL) – – Spare – 10 Amp Red HD ELEC ACC PKG —...
Page 400 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description – 10 Amp Red SUPPLY/PURGING PMP — If Equipped 20 Amp Blue – NOx SENSOR #1/ #2 — IF Equipped Steering Column Control Module (SCCM)/ Cruise Control – 10 Amp Red (CRUISE CTL)/Digital TV (DTV) 20 Amp Blue –...
Page 401 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description F106 50 Amp Red – Cruise Control -PUMP MTR F107 – 20 Amp Yellow TRAILER TOW STOP/TURN LT — If Equipped F108 – 15 Amp Blue HD ACCY #4 — If Equipped F109 –...
Page 402: Bulb Replacement
SERVICING AND MAINTENANCE EPLACEMENT Replacement Bulbs NOTE: See an authorized dealer for LED bulb replacement. Interior Bulbs Bulb Name Bulb Number Automatic Transmission Indicator Lamp Heater Control Lamps (2) Rocker Switch Indicator Lamp (Rear Window Defogger, and Rear Wash/ Wipe) Soundbar Dome Lamp ** Bulbs only available from an authorized dealer.
Page 403 SERVICING AND MAINTENANCE Exterior Bulbs Bulb Name Bulb Number Front Side Marker Lamps (2) LED – (Serviced at an authorized dealer) Base Fog Lamps PSX24W Premium Fog Lamps LED – (Serviced at an authorized dealer) Rear Premium LED Tail Lamps LED –...
Page 404 SERVICING AND MAINTENANCE 9. Push connector locking tab to the unlock Halogen Front Fog Lamp position. See below steps to replace: 10. Remove connector from bulb. 1. Reach under the vehicle to access the back of the front fog lamp. 11.
Page 405 SERVICING AND MAINTENANCE Rear Tail, Stop, Turn Signal, And Backup Lamp 4. Rotate the appropriate socket a quarter turn counterclockwise, then remove it from See below steps to replace: the housing. 1. Remove interior trim panel cap to access 5. Pull the bulb straight from the socket to single retaining screw for tail lamp replace.
Page 406: Tires
SERVICING AND MAINTENANCE License Plate Lamps Tire Markings European — Metric tire sizing is based on  European design standards. Tires designed See an authorized dealer to replace LED lamps. to this standard have the tire size molded NOTE: into the sidewall beginning with the section To install a new bulb, reverse the procedure width.
Page 407 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 408 SERVICING AND MAINTENANCE EXAMPLE: H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions  The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle ...
Page 409 SERVICING AND MAINTENANCE EXAMPLE: ABCD = Code used by the tire manufacturer (one to four digits) 03 = Number representing the week in which the tire was manufactured (two digits) 03 means the 3rd week  01 = Number representing the year in which the tire was manufactured (two digits) 01 means the year 2001 ...
Page 410 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure 3. Tire size designed for your vehicle. 4. Cold tire inflation pressures for the front, NOTE: rear, and spare tires. The proper cold tire inflation pressure is listed on the driver’s side B-pillar or the rear edge of Loading the driver's side door.
Page 411 SERVICING AND MAINTENANCE Steps For Determining Correct Load (5) Determine the combined weight of NOTE: Limit— luggage and cargo being loaded on the If your vehicle will be towing a trailer, load  from your trailer will be transferred to your vehicle.
Page 412: Tires - General Information
SERVICING AND MAINTENANCE — G Four primary areas are affected by improper tire IRES ENERAL NFORMATION WARNING! pressure: Tire Pressure Overloading of your tires is dangerous. Over- Safety  loading can cause tire failure, affect vehicle Proper tire inflation pressure is essential to the Fuel Economy ...
Page 413 SERVICING AND MAINTENANCE Safety Both underinflation and overinflation affect the Tire Inflation Pressures stability of the vehicle and can produce a feeling The proper cold tire inflation pressure is listed WARNING! of sluggish response or over responsiveness in on the driver's side B-pillar or rear edge of the the steering.
Page 414 SERVICING AND MAINTENANCE after sitting for a minimum of three hours. The inflation pressure is very important. Increased Tire Repair cold tire inflation pressure must not exceed the tire pressure and reduced vehicle loading may If your tire becomes damaged, it may be maximum inflation pressure molded into the be required for high-speed vehicle operation.
Page 415 SERVICING AND MAINTENANCE replaced immediately. A Run Flat tire is not These indicators are molded into the bottom of WARNING! repairable. When a run flat tire is changed after the tread grooves. They will appear as bands driving with underinflated tire condition, please Fast spinning tires can be dangerous.
Page 416 SERVICING AND MAINTENANCE paragraph on “Tread Wear Indicators” in this WARNING! WARNING! section. Refer to the Tire and Loading Tires and the spare tire should be replaced Information placard or the Vehicle Certification Do not use a tire, wheel size, load rating, or ...
Page 417: Tire Types
SERVICING AND MAINTENANCE For more information, contact an authorized Snow tires generally have lower speed ratings CAUTION! dealer. than what was originally equipped with your Replacing original tires with tires of a differ- vehicle and should not be operated at Summer tires do not contain the all season sustained speeds over 75 mph (120 km/h).
Page 418 SERVICING AND MAINTENANCE driver’s side door opening or on the sidewall of Full Size Spare — If Equipped CAUTION! the tire. Compact spare tire descriptions begin The full size spare is for temporary emergency Because of the reduced ground clearance, do with the letter “T”...
Page 419: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE Your wheels are susceptible to deterioration Chrome Cleaner or their equivalent is WARNING! caused by salt, sodium chloride, magnesium recommended or select a non-abrasive, Limited use spares are for emergency use chloride, calcium chloride, etc., and other road non-acidic cleaner for aluminum or chrome chemicals used to melt ice or control dust on wheels.
Page 420: Snow Traction Devices
SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or No other tire sizes are recommended for use RACTION EVICES  with the snow traction device. Low Gloss Clear Coat Wheels Use of traction devices require sufficient Please follow the table below for the recom- ...
Page 421: Tire Rotation Recommendations
SERVICING AND MAINTENANCE and wet traction levels, and contribute to a WARNING! CAUTION! (Continued) smooth, quiet ride. Using tires of different size and type (M+S, Drive cautiously and avoid severe turns and  For the proper maintenance intervals Snow) between front and rear axles can large bumps, especially with a loaded Ú...
Page 422: Department Of Transportation Uniform Tire Quality Grades
SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION significantly from the norm due to its ability to dissipate heat, when tested variations in driving habits, service under controlled conditions on a UNIFORM TIRE QUALITY GRADES practices, and differences in road specified indoor laboratory test wheel. The following tire grading categories characteristics and climate.
Page 423: Storing The Vehicle
SERVICING AND MAINTENANCE STORING THE VEHICLE CAUTION! WARNING! If the negative battery cables are not isolated properly it can cause a potential power spike Take care to avoid the radiator cooling fan  or surge in the system, resulting in damage to whenever the hood is raised.
Page 424: Bodywork
SERVICING AND MAINTENANCE BODYWORK Insects, tree sap and tar If insects, tar, or other similar deposits have   accumulated on your vehicle, use Mopar Salt in the air near seacoast localities  ROTECTION TMOSPHERIC Super Kleen Bug and Tar Remover to remove. Atmospheric fallout/industrial pollutants ...
Page 425 SERVICING AND MAINTENANCE If you detect any stone chips or scratches in Avoid leaving your vehicle unattended with   CAUTION! the paint, touch them up immediately. The the top down, as exposure to sun or rain may cost of such repairs is considered the respon- damage interior trim.
Page 426: Interiors
Clean them with a mild soap solution and a washed off immediately and thoroughly as and down. Mopar Jeep Soft Glass Window small brush. Cleaning products are available the acid they contain is particularly aggres- Cleaner or equivalent will safely clean all through an authorized dealer.
Page 427: Carpet Removal
SERVICING AND MAINTENANCE ARPET EMOVAL WARNING! WARNING! (Continued) Front Carpets (Two And Four Door Models): If operating the vehicle without carpet in ONLY install carpet designed to fit your   1. Remove the front grommets. place the floor may become hot, and there vehicle.
Page 428 SERVICING AND MAINTENANCE 3. Remove the grommets under the front seat. First for the rear carpet and then the front carpet. Rear Underside Of Front Seat Front Seat And Floor 1 — Harness 1 — Grommets 2 — Carpet Split 2 —...
Page 429 SERVICING AND MAINTENANCE Rear Carpet (Four Door Models): 4. Pull the carpet out to the front and open the Rear Carpet (Two Door Models): carpet split around the rear seats brackets. 1. Remove the grommets under the front seat 1. Remove the rear seats. (one left and one right).
Page 430 SERVICING AND MAINTENANCE 4. Then pull the carpet out to the rear and 4. When reinstalling carpet please perform open the carpet split around the front seats these steps in reverse order making sure brackets. that the carpet is tucked under the scuffs, B-pillar, console, and refasten grommets.
Page 431: Seats And Fabric Parts
SERVICING AND MAINTENANCE 3. When reinstalling carpet please perform 3. When reinstalling carpet please perform Seat Belt Maintenance these steps in reverse order making sure these steps in reverse order making sure Do not bleach, dye or clean the belts with that the carpet is tucked under the scuffs, that the carpet is tucked under the scuffs, chemical solvents or abrasive cleaners.
Page 432: Plastic And Coated Parts
SERVICING AND MAINTENANCE LASTIC OATED ARTS EATHER URFACES CAUTION! Use Mopar Total Clean to clean vinyl upholstery. Mopar Total Clean is specifically recommended Do not use Alcohol and Alcohol-based and/or for leather upholstery. Ketone based cleaning products to clean CAUTION! Your leather upholstery can be best preserved by leather upholstery, as damage to the uphol- Direct contact of air fresheners, insect...
Page 433: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER some loss of overall braking effectiveness. You ORQUE PECIFICATIONS may notice increased pedal travel during Lug Nut/Bolt **Lug Nut/ Lug Nut/Bolt The Vehicle Identification Number (VIN) is found application, greater pedal force required to slow Torque Bolt Size Socket Size...
Page 434: Fuel Requirements - Gasoline Engine
TECHNICAL SPECIFICATIONS 2.0L E Spare tire torque is for the spare tire carrier After 25 miles (40 km), check the lug nut/bolt NGINE located on the swing gate. torque to be sure that all the lug nuts/bolts are This engine is designed to meet all properly seated against the wheel.
Page 435: Reformulated Gasoline
TECHNICAL SPECIFICATIONS www.toptiergas.com for a list of TOP TIER Problems that result from using gasoline EFORMULATED ASOLINE Detergent Gasoline Retailers. containing more than 15% ethanol (E-15) or Many areas of the country require the use of gasoline containing methanol are not the Indiscriminate use of fuel system cleaning cleaner burning gasoline referred to as responsibility of FCA and may void or not be...
Page 436: Cng And Lp Fuel System Modifications
TECHNICAL SPECIFICATIONS CNG A LP F MMT is prohibited in Federal and California YSTEM CAUTION! (Continued) reformulated gasoline. ODIFICATIONS The use of fuel additives, which are now  YSTEM AUTIONS Modifications that allow the engine to run on being sold as octane enhancers, is not Compressed Natural Gas (CNG) or Liquid recommended.
Page 437: Diesel Fuel Specifications
TECHNICAL SPECIFICATIONS Testing and Materials) specification D-975 Commercially available fuel additives are not  CAUTION! Grade S15 will provide good performance. If the necessary for the proper operation of your diesel engine. vehicle is exposed to extreme cold (below 20°F If the “Water in Fuel Indicator Light”...
Page 438 TECHNICAL SPECIFICATIONS meet Biodiesel blend B6 – B20 fuel meeting CAUTION! CAUTION! ASTM specification D-7467: Failure to comply with Oil Change require- In the event that the vehicle is filled with bio- Petrodiesel fuel meeting ASTM specification  ments for vehicles operating on biodiesel diesel and not used for more than a month, D-975 and Biodiesel fuel (B100) meeting blends between 6% and 20% (B6–B20) will...
Page 439: Fluid Capacities
TECHNICAL SPECIFICATIONS regular use of biodiesel between 6% and 20% biodiesel between 6% and 20%, fuel filter 16,000 miles (25,750 km), if regular operation requires intervals shorter than the outlined replacement intervals should be every second occurs with 6% - 20% biodiesel blends. Failure 10,000 miles (16,000 km)and must not exceed oil change, and must not exceed 16,000 miles to comply with these Oil Change and fuel filter...
Page 440: Engine Fluids And Lubricants
TECHNICAL SPECIFICATIONS Metric Cooling System * 2.0L Engine 10.3 Quarts 9.7 Liters 2.0L Engine Intercooler 3.2 Quarts 3.0 Liters 3.6L Engine 11.2 Quarts 10.6 Liters 3.6L Motor Generator Unit (MGU) 1.9 Quarts 1.8 Liters 3.6L Battery Coolant 2.5 Quarts 2.4 Liters 3.0L Diesel Engine 12 Quarts 11.4 Liters...
Page 441 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar API SP/GF-6 Certified SAE 5W-30 Full Synthetic Engine Oil which meets the requirements of FCA Material Stan- dard MS-13340. Equivalent full synthetic SAE 5W-30 engine oil can be used if it meets API SP/GF-6 Certification.
Page 442 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) Mixing of engine coolant (antifreeze) other This vehicle has not been designed for use   than specified Organic Additive Technology with propylene glycol-based engine coolant (OAT) engine coolant (antifreeze), may (antifreeze). Use of propylene glycol-based result in engine damage and may decrease engine coolant (antifreeze) is not recom- corrosion protection.
Page 443 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant (240,000 km) Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of FCA Material Standard MS.90032. We recommend you use 5W-40 synthetic engine oil such as Mopar that Engine Oil —...
Page 444: Chassis Fluids And Lubricants
TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar ZF 8&9 Speed Automatic Transmission Fluid (ATF) or Automatic Transmission – If Equipped equivalent. Failure to use the correct fluid may affect the function or per- formance of your transmission.
Page 445: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE IF YOU NEED ASSISTANCE Owner's name and address  Owner's telephone number (mobile, home  FOR YOUR VEHICLE FCA US LLC and its authorized dealers are vitally and office) interested in your satisfaction. We want you to Authorized dealer name REPARE PPOINTMENT...
Page 446: Puerto Rico And Us Virgin Islands
CUSTOMER ASSISTANCE US V We appreciate that you have made a major UERTO IRGIN SLANDS ERVICE ONTRACT investment when you purchased the vehicle. An FCA Caribbean LLC You may have purchased a service contract for authorized dealer has also made a major a vehicle to help protect you from the high cost P.O.
Page 447: Warranty Information
CUSTOMER ASSISTANCE WARRANTY INFORMATION Safety Administration (NHTSA) in immediately. Canadian customers who addition to notifying FCA US LLC. wish to report a safety defect to the See the Warranty Information for the terms and Canadian government should contact If NHTSA receives similar complaints, it provisions of FCA US LLC warranties applicable Transport Canada, Motor Vehicle Defect may open an investigation, and if it finds...
Page 448: General Information
CUSTOMER ASSISTANCE GENERAL INFORMATION troubleshooting and drivability procedures, 1. l'appareil ne doit pas produire de proven diagnostic tests and a complete list of all brouillage, et The following regulatory statement applies to all tools and equipment. 2. l'utilisateur de l'appareil doit accepter tout Radio Frequency (RF) devices equipped in this Owner's Manuals brouillage radioélectrique subi, même si le...
Page 449 INDEX  ..... 87 ....325 ........252 Hard Top Front Panel(s) Removal Maintaining Your Air Bag System Apple CarPlay  ..........325 ..........290 Lowering The Soft Top Into Sunrider® Maintenance Assist, Hill Start ............69 ..... 313 ..........236 Position Redundant Air Bag Warning Light Audio Settings...
Page 450 ......... 433 Caps, Filler Clean Air Gasoline ..........123 ............187 Battery Fuel Cleaning .......123 ..........368 ............417 Charging System Light Oil (Engine) Wheels ....17 ..... 387 Keyless Key Fob Replacement Radiator (Coolant Pressure) Climate Control .............341 ........... 422 ............54 Belts, Seat Car Washes...
Page 451 Radiator Cap ..........387 Disposal Emergency Selection Of Coolant Antifreeze (Engine Coolant) ...... 387 In Case Of ..........344 (Antifreeze) ......386 Disturb ............249 SOS Emergency Call ......... 344 Corrosion Protection ........422 Door Ajar ..........123 Emergency Brake .......... 144 Cruise Control (Speed Control) ....
Page 452 ..........355 ........433 Overheating Fluid Level Materials Added .............134 ....... 390 ..........433 Starting Manual Transmission Methanol ........390 ........432 Enhanced Accident Response Fluid Level Checks Octane Rating ..........324 ............389 ........434 Feature Brake Requirements ............433 ..........371 ........
Page 453 Cleaning ............422 Instrument Panel Lens Cleaning ....430 High Beam/Low Beam Select Switch ..50 Integrated Power Module (Fuses) ....392 Lane Change Assist ..........51 Lights On Reminder ........50 Interior And Instrument Lights ......51 Lap/Shoulder Belts ........307 Passing ............
Page 454 ..126 Malfunction Indicator (Check Engine) Lowering The Soft Top Into Sunrider® Modifications/Alterations  ............130 .............69 ............11 Park Position Vehicle ............50 .......... 382 ...... 300 Passing Lubrication, Body Monitor, Tire Pressure System ...........403 ..........431 ..........445 Rear Servicing Lug Nuts/Bolts Mopar Parts ........403 ..........
Page 455 Recommendation ....372 Operation ............94 Shifting Out Of Transfer Case Synthetic ...........373 Pinch Protect ..........94 Neutral (N) ..........201 Viscosity ............437 Quarter Window Removal ......96 Reformulated Gasoline ......... 433 Onboard Diagnostic System ......132 Power Steering Fluid ........442 Refrigerant ............ 380 Operating Precautions ........132 Power Top Quarter Windows...
Page 456 ........400 ........326 ........18 Replacement Bulbs Child Restraints Sentry Key (Immobilizer) ........... 18 ....311 ........18 Replacement Keys Energy Management Feature Sentry Key Replacement .........414 ........... 310 ........443 Replacement Tires Extender Service Assistance .......445 ....... 305 ..........444 Reporting Safety Defects Front Seat Service Contract ..........326...
Page 457 Spark Plugs ...........438 Storage ..........62 Inflation Pressure ........411 Specifications Behind the Seat ...........62 Life Of Tires ..........413 Fuel (Gasoline) ..........438 Storage, Vehicle ..........421 Load Capacity ........... 408 ..............438 Store Radio Presets ........235 Pressure Monitoring System Speed Control Storing Your Vehicle ........
Page 458 ......199 ....... 246 Towing Behind A Motorhome Things You Should Know About Your Uconnect Phonebook Download ........... 250 ....249 Trac-Lok Phone Place/Retrieve A Call From Hold ...........159 ........22 ..........252 Rear Axle Uconnect Settings Power-Up ..........293 ..........259 ..........248 Traction Control Uconnect App Recent Calls...
Page 459 Vehicle Modifications/Alterations ....11 Water Separator Windshield Defroster ........341 Vehicle Notifications ........272 Diesel Fuel ..........375 Windshield Washers ......52 Vehicle Storage ..........421 Wheel And Wheel Tire Care ......417 Fluid ............371 Voice Command ......42 Wheel And Wheel Tire Trim ......
Page 463 Some states or provinces prohibit the use of cellular telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a ®...
Page 464 © 2020 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep WRANGLER 2021 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Jeep WRANGLER 2021

Summary of Contents for Jeep WRANGLER 2021
