Summary of Contents for Jeep Wrangler 2011

Page 1 Wrangler 2 0 1 1 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and features and equipment that are either standard or op- the name Chrysler Canada Inc.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 5: Table Of Contents
INTRODUCTION CONTENTS Introduction ......4 Warnings And Cautions ....8 Rollover Warning .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION handles on different road surfaces. Your driving skills Congratulations on selecting your new Chrysler Group will improve with experience. When driving off-road or LLC vehicle. Be assured that it represents precision working the vehicle, don’t overload the vehicle or expect workmanship, distinctive styling, and high quality - all the vehicle to overcome the natural laws of physics.
Page 7: Rollover Warning
INTRODUCTION 5 NOTE: After reviewing the owner information, it Do not attempt sharp turns, abrupt maneuvers, or other should be stored in the vehicle for convenient referenc- unsafe driving actions that can cause loss of vehicle ing and remain with the vehicle when sold. control.
Page 8: How To Use This Manual
6 INTRODUCTION Failure to use the driver and passenger seat belts pro- Since the specification of your vehicle depends on the vided is a major cause of severe or fatal injury. In a items of equipment ordered, certain descriptions and rollover crash, an unbelted person is significantly more illustrations may differ from your vehicle’s equipment likely to die than a person wearing a seat belt.
Page 9 INTRODUCTION 7...
Page 10: Warnings And Cautions
8 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 11: Vehicle Modifications/Alterations
INTRODUCTION 9 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a accident resulting in serious injury or death.
Page 13: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....14 To Arm The System ....19 Ignition Key Removal .
Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information ....24 Child-Protection Door Lock System — Rear Doors ......38 Transmitter Battery Replacement .
Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Automatic Locking Retractor Mode (ALR) — Event Data Recorder (EDR) ....70 If Equipped ......55 Child Restraints .
Page 16: A Word About Your Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The keys for your new vehicle are enclosed in a plastic bag with the key code number on it. If you received your keys without the bag, ask your authorized dealer to give you the number.
Page 17: Key-In-Ignition Reminder
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key-In-Ignition Reminder WARNING! Opening the driver’s door when the key is in the ignition sounds a signal to remind you to remove the key. Leaving unattended children in a vehicle is danger- ous for a number of reasons.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A key that has not been programmed is also CAUTION! considered an invalid key, even if it is cut to fit the ignition switch lock cylinder for that vehicle. The Sentry Key Immobilizer system is not compat- ible with some after-market remote starting systems.
Page 19: Customer Key Programming
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Customer Key Programming CAUTION! If you have two valid Sentry Keys , you can program new Sentry Keys to the system by performing the Always remove the Sentry Keys from the vehicle following procedure: and lock all doors when leaving the vehicle unat- tended.
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Insert a blank Sentry Key into the ignition switch. reprogrammed. All vehicle keys must be taken to an Turn the ignition switch to the ON/RUN position within authorized dealer at the time of service to be 60 seconds.
Page 21: Rearming The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 alarming. The horn will sound, the headlights, park To Arm The System lamps and/or turn signals will flash repeatedly for three The Vehicle Security Alarm will set when you use the minutes. If the disturbance is still present (driver’s door, Remote Keyless Entry (RKE) transmitter to lock the doors passenger door, other doors, ignition) after three minutes, and swing gate, or when you use the power door lock...
Page 22: Illuminated Entry - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE your absence, the horn will sound three times and the NOTE: • Unlocking the doors with the manual door lock plung- exterior lights blink three times when you unlock the doors. Check the vehicle for tampering. ers or the driver’s door lock cylinder will not disarm the Vehicle Security Alarm.
Page 23: Remote Keyless Entry (Rke) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 NOTE: • The front courtesy overhead console and door cour- tesy lights do not turn on if the dimmer control is in the Dome ON position (extreme top position). • The Illuminated Entry system will not operate if the dimmer control is in the “Dome defeat”...
Page 24: To Unlock The Doors And Swing Gate
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock The Doors And Swing Gate 3. Release both buttons at the same time. Press and release the RKE transmitter UNLOCK button 4. Test this feature while outside of the vehicle by once to unlock the driver’s door only, or twice to unlock pressing the LOCK/UNLOCK button on the RKE trans- all the doors and swing gate.
Page 25: To Lock The Doors And Swing Gate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 To Lock The Doors And Swing Gate the headlights and park lights will flash, the horn will Press and release the LOCK button on the RKE transmit- pulse on and off and the interior lights will turn on. ter to lock all doors.
Page 26: Programming Additional Transmitters
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. While the UNLOCK button is pressed, (after four Programming Additional Transmitters seconds) press the RKE transmitter LOCK button. Re- Refer to Sentry Key “Customer Key Programming.” lease both buttons. If you do not have a programmed RKE transmitter, 3.
Page 27: Transmitter Battery Replacement
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 If your RKE transmitter fails to operate from a normal distance, check for these two conditions: 1. Weak battery in the RKE transmitter. The expected life of a battery is five years. 2.
Page 28: Remote Starting System - If Equipped
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Hood closed REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry • Hazard switch off (RKE) transmitter to start the engine conve- • Brake switch inactive (brake pedal not pressed) niently from outside the vehicle while still maintaining security.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 • Remote Start Aborted - Fuel Low WARNING! • Do not start or run an engine in a closed garage or The EVIC message stays active until the ignition is turned to the ON/RUN position. confined area.
Page 30: To Exit Remote Start And Drive
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the ignition switch must be cycled to the ON/RUN To Exit Remote Start Mode Without Driving The position before you can repeat the start sequence for a Vehicle third cycle. Press and release the REMOTE START button one time, or allow the engine to run for the entire 15-minute cycle.
Page 31: Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 DOORS CAUTION! Careless handling and storage of the removable door panels may damage the seals, causing water to leak into the vehicle’s interior. Upper Half Door Window Removal — If Equipped Grasp the half door window and pull upward. Upper Half Door Window Upper Half Door Window Installation —...
Page 32: Front Door Removal
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Push down to ensure the half door window is fully seated. Front Door Removal WARNING! Do not drive your vehicle on public roads with the doors removed as you will lose the protection that they can provide.
Page 33: Rear Door Removal (Four-Door Models)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 on one end (right) of the connector. This will unlock the 4. Unhook the door strap from the body hook. Be careful connector tab, allowing the tab to be pressed down and not to allow the door to swing fully open as the mirror enabling the harness to be disconnected.
Page 34: Things To Know Before Starting Your Vehicle 11
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Roll down the glass window to prevent any damage. 3. Slide the front seat(s) fully forward. 2. Remove the hinge pin screws from the upper and 4. Remove the trim access door from the bottom of the lower outside hinges (using a #T50 Torx head driver).
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 NOTE: If the red latch on the connector is locked, push 6. Unhook the door strap from the body hook. the red latch to the right until you can only see the latch 7.
Page 36: Door Locks
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS NOTE: The ignition key that is used to start the vehicle is used to lock or unlock the doors, swing gate, glove Manual Door Locks compartment, and console storage. All doors are equipped with an interior rocker-type door lock lever.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! (Continued) • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Do not leave the key in the ignition.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. The doors were not previously locked using the power 2. Within 15 seconds, cycle the ignition switch between door lock switch or Remote Keyless Entry (RKE) LOCK and ON/RUN and then back to LOCK four times transmitter ending up in the LOCK position (do not start the engine).
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Automatic Unlock Doors On Exit 3. Press the power door unlock switch to unlock the The doors will unlock automatically on vehicles with doors. power door locks if: 4. A single chime will indicate the completion of the 1.
Page 40: Child-Protection Door Lock System - Rear Doors
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. The vehicle speed is above 15 mph (24 km/h). 5. Repeat these steps if you want to return this feature to its previous setting. 6. The doors were not previously locked using the power door lock switch or Remote Keyless Entry (RKE) NOTE: Use the “Automatic Door Locks”...
Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 2. Insert the tip of the ignition key into the lock and WARNING! rotate to the LOCK or UNLOCK position. Avoid trapping anyone in a vehicle in a collision. 3. Repeat steps 1 and 2 for the opposite rear door. Remember that the rear doors can only be opened from the outside when the Child-Protection locks are engaged.
Page 42: Windows
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS The top left switch controls the left front window and the top right switch controls the right front window. Power Windows — If Equipped The power window switches are located on the instru- NOTE: The switches will continue to function for up to ment panel below the radio.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 To stop the window from going all the way down during the Auto-Down operation, pull up on the switch briefly. To partially open the window, press halfway to the first detent and release it when you want the window to stop. Window Lockout Switch —...
Page 44: Wind Buffeting
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rear Power Windows — Four-Door Models Wind Buffeting The rear passenger window switches are located on the Wind buffeting can be described as the perception of back of the center floor console. Press the switch down- pressure on the ears or a helicopter-type sound in the ward to open the window and upward to close the ears.
Page 45: Occupant Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 CAUTION! Do not press on rear wiper blade when closing the rear flip-up window, as damage to the blade will result. WARNING! Driving with the flip-up window open can allow poisonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Advanced Front Air Bags for driver and front passen- Please pay close attention to the information in this section. It tells you how to use your restraint system properly, to keep you and your passengers as safe as possible. •...
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 You should read the instructions provided with your WARNING! child restraint to make sure that you are using it properly. Infants in rear facing child restraints should never 2. All occupants should always wear their lap and ride in the front seat of a vehicle with a passenger shoulder belts properly.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • In an accident, you and your passengers can suffer • Relying on the air bags alone could lead to more much greater injuries if you are not properly severe injuries in a collision.
Page 49: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 of ejection and the risk of injury caused by striking the WARNING! (Continued) inside of the vehicle. Everyone in a motor vehicle should • Do not allow people to ride in any area of your be belted at all times.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Two people should never be belted into a single seat belt. People belted together can crash into one another in an accident, hurting one another badly. Never use a lap/shoulder belt or a lap belt for more than one person, no matter what their size.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Seat Belt Reminder Light will remain on WARNING! (Continued) until the driver and front passenger (if equipped with • A belt that is worn under your arm is dangerous. front passenger BeltAlert ) seat belt is buckled. For Your body could strike the inside surfaces of the further information, refer to “Enhanced Seat Belt Use vehicle in an accident, increasing head and neck...
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed position. • A lap belt worn too high can increase the risk of If necessary, slide the latch plate down the webbing to allow the belt to retract fully.
Page 54: Rear Center Lap/Shoulder Belt Retractor Lockout - Four-Door Models Only
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rear Center Lap/Shoulder Belt Retractor WARNING! Lockout — Four-Door Models Only This feature is designed to lock the retractor whenever The rear center lap/shoulder belt is equipped with a the 60% rear seatback is not fully latched. This prevents lock-out feature to ensure that the rear seatback is in someone from wearing the rear center lap/shoulder belt the fully upright and locked position when occupied.
Page 55: Adjustable Upper Shoulder Belt Anchorage
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate. 3.
Page 56: Seat Belts In Passenger Seating Positions
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE additional information, refer to “Installing Child Re- WARNING! straints Using The Vehicle Seat Belt” under the “Child Restraints” section. The chart below defines the type of Position the shoulder belt height adjusters so that the feature for each seating position.
Page 57: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 out only the amount of webbing necessary to comfort- 3. Allow the belt to retract. As the belt retracts, you will ably wrap around the occupant’s mid-section. Slide the hear a clicking sound. This indicates the safety belt is latch plate into the buckle until you hear a click.
Page 58: Energy Management Feature
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Energy Management Feature Seat Belt Pretensioners This vehicle has a safety belt system with an Energy The seat belts for both front seating positions are Management feature in the front seating positions to help equipped with pretensioning devices that are designed to further reduce the risk of injury in the event of a head-on remove slack from the seat belt in the event of an...
Page 59: Enhanced Seat Belt Use Reminder System (Beltalert )
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Enhanced Seat Belt Use Reminder System The front passenger seat BeltAlert is not active when the (BeltAlert ) front passenger seat is unoccupied. BeltAlert may be BeltAlert is a feature intended to remind the driver and triggered when an animal or heavy object is on the front front passenger (if equipped with front passenger passenger seat or when the seat is folded flat (if...
Page 60: Seat Belts And Pregnant Women
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Turn the ignition switch to the ON/RUN position (do Seat Belts And Pregnant Women not start the engine), and wait for the Seat Belt Reminder We recommend that pregnant women use seat belts Light to turn off.
Page 61: Supplemental Restraint System (Srs) - Air Bags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 WARNING! Using a seat belt extender when not needed can increase the risk of injury in an accident. Only use when the seat belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Air Bags have a multistage inflator Air Bag System Components design. This allows the air bag to have different rates of Your vehicle may be equipped with the following air bag inflation that are based on the severity and type of system components: collision.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Advanced Front Air Bag Features WARNING! (Continued) The Advanced Front Air Bag system has multistage • Do not put anything on or around the air bag driver and front passenger air bags. This system provides covers or attempt to open them manually.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Seat-Mounted Side Air Bags WARNING! (Continued) (SAB) — If Equipped • If your vehicle is equipped with SAB, do not Supplemental Seat-Mounted Side Air Bags may provide attach cupholders or any other objects on or enhanced protection to help protect an occupant during a around the door.
Page 65: Air Bag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 When the air bag deploys, it opens the seam between the Along with seat belts and pretensioners, Advanced Front front and side of the seat’s trim cover. Each air bag Air Bags work with the knee bolsters to provide im- deploys independently;...
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Air Bags are designed to provide addi- Because air bag sensors measure vehicle deceleration tional protection by supplementing the seat belts in over time, vehicle speed and damage by themselves are certain frontal collisions depending on the severity and not good indicators of whether or not an air bag should type of collision.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Also, the ORC turns on the Air Bag Warning WARNING! Light for four to eight seconds for a self-check when the ignition is first turned on. After the Ignoring the Air Bag Warning Light in your instru- self-check, the Air Bag Warning Light will turn ment panel could mean you won’t have the air bags off.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE are possible, based on the collision type and severity. The The ORC determines if a side collision requires the side steering wheel hub trim cover and the upper right side of air bags to inflate, based on the severity and type of the instrument panel separate and fold out of the way as collision.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 • Unlock the doors automatically. Front And Side Impact Sensors In front and side impacts, front and side impact sensors If A Deployment Occurs can aid the ORC in determining the appropriate response The Advanced Front Air Bags are designed to deflate to certain impact events.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Do not drive your vehicle after the air bags have However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor deployed. If you are involved in another collision, the immediately.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Maintaining Your Air Bag System WARNING! (Continued) • Do not attempt to modify any part of your air bag WARNING! system. The air bag may inflate accidentally or • Modifications to any part of the air bag system may not function properly if modifications are could cause it to fail when you need it.
Page 72: Event Data Recorder (Edr)
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light NOTE: If the speedometer, tachometer, or any engine You will want to have the air bags ready to related gauges are not working, the Occupant Restraint inflate for your protection in a collision. The Controller (ORC) may also be disabled.
Page 73: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 • Whether or not the driver and passenger safety belts To read data recorded by an EDR, special equipment is were buckled/fastened; required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, •...
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE There are different sizes and types of restraints for Infants And Child Restraints children from newborn size to the child almost large • Safety experts recommend that children ride enough for an adult safety belt. Always check the child rearward-facing in the vehicle until they are at least seat owner’s manual to ensure you have the correct seat one-year old and weigh at least 20 lbs (9 kg).
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Standards. The manufacturer also recommends that WARNING! you try a child restraint in the vehicle seats where you • Rearward-facing child seats must never be used in will use it before you buy it. the front seat of a vehicle with the front passenger •...
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE retractor and then allow the belt to retract into the WARNING! retractor. For additional information on ALR, refer to “Automatic Locking Mode”. When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the •...
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 • If the shoulder belt contacts the face or neck, move the The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit child closer to the center of the vehicle.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE a hook for attachment to the tether strap anchorage, and WARNING! a means for adjusting the tension of the strap. An incorrectly anchored tether strap could lead to In general, you will first loosen the adjusters on the lower increased head motion and possible injury to the and tether straps so that you can more easily attach the child.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 seat cushion surfaces. Regardless of the specific type of kits or retro-fit kits. You are urged to take advantage of all lower attachment, never install LATCH-compatible child the available attachments provided with your child re- seats such that two seats share a common lower anchor- straint in any vehicle.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE All three rear seating positions of the four-door model the vehicle’s seat belts. Please refer to “Installing Child have lower anchorages that are capable of accommodat- Restraints Using The Vehicle Seat Belt” for typical instal- ing LATCH-compatible child seats having flexible, lation instructions.
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Latch Anchorages (Two-Door Models) Latch Anchorages (Four-Door Models)
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In addition, there are tether strap anchorages behind each rear seating position located on the back of the seat. Tether Strap Mounting (Four-Door Models) Many, but not all, restraint systems will be equipped with separate straps on each side, with each having a hook or Tether Strap Mounting (Two-Door Models) connector for attachment to the lower anchorage and a...
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 a hook for attachment to the tether strap anchorage, and WARNING! a means for adjusting the tension of the strap. Improper installation of a child restraint to the You will first loosen the child seat adjusters on the lower LATCH anchorages can lead to failure of an infant or straps and on the tether strap so that you can more easily child restraint.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE description under “Seat Belts In Passenger Seating Posi- Installing a Child Restraint with an ALR: tions” section. The chart below defines the seating posi- 1. To install a child restraint with ALR, first, pull enough tions with an Automatic Locking Retractor (ALR) or a of the seat belt webbing from the retractor to route it cinching latch plate.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 To attach a Child Restraint tether strap: Tether Strap Mounting (Four-Door Models) Route the tether strap over the seatback and attach the Tether Strap Mounting (Two-Door Models) hook to the tether anchor located on the back of the seat. For the outboard seating positions, route the tether under the head restraint, and attach the hook to the tether anchor located on the back of the seat.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If the belt still can’t be tightened, or if pulling and WARNING! pushing on the restraint loosens the belt, disconnect the latch plate from the buckle, turn the buckle An incorrectly anchored tether strap could lead to around, and insert the latch plate into the buckle increased head motion and possible injury to the again.
Page 87: Engine Break-In Recommendations
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 ENGINE BREAK-IN RECOMMENDATIONS “Maintenance Procedures” in “Maintaining Your Ve- A long break-in period is not required for the engine and hicle”. NON-DETERGENT OR STRAIGHT MINERAL drivetrain (transmission and axle) in your vehicle. OILS MUST NEVER BE USED.
Page 88: Exhaust Gas
86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! (Continued) • It is extremely dangerous to ride in a cargo area, WARNING! inside or outside of a vehicle. In a collision, people Exhaust gases can injure or kill. They contain carbon riding in these areas are more likely to be seri- monoxide (CO), which is colorless and odorless.
Page 89: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 If you are required to drive with the trunk/liftgate open, Safety Checks You Should Make Inside The make sure that all windows are closed and the climate Vehicle control BLOWER switch is set at high speed. DO NOT Seat Belts use the recirculation mode.
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Defroster WARNING! (Continued) Check operation by selecting the defrost mode and place • Always make sure that floor mats are properly the blower control on high speed. You should be able to attached to the floor mat fasteners.
Page 91: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 lodged in the tread or sidewall. Inspect the tread for cuts WARNING! (Continued) and cracks. Inspect sidewalls for cuts, cracks and bulges. • Always make sure that objects cannot fall into the Check the wheel nuts for tightness.
Page 93: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......96 Uconnect™ Phone Features ... . . 112 Inside Day/Night Mirror .
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seats ......135 Replacing The Rear Seat — Two-Door Models .
Page 95 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 Front Fog Lights ..... 152 To Deactivate ..... . . 161 Instrument Panel Dimmer .
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dual Top — If Equipped ....170 Door Frame Installation — Two-Door Models ....190 Removing The Soft Top .
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Sunrider (Two-Door Models) — Folding Windshield ....253 If Equipped ......247 Lowering The Windshield And Removing Opening The Sunrider .
Page 98: Mirrors
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical adjustment of the mirror. The mirror should be adjusted to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 99: Outside Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 Outside Mirrors WARNING! To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight Vehicles and other objects seen in the passenger side overlap of the view obtained on the inside mirror. convex mirror will look smaller and farther away than they really are.
Page 100: Power Mirrors - If Equipped
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors — If Equipped After selecting a mirror, move the knob in the same The power mirror switch is located on the center of the direction you want the mirror to move. Use the center off instrument panel, below the climate controls.
Page 101: Uconnect™ Phone - If Equipped
• www.chrysler.com/uconnect • www.dodge.com/uconnect Vanity Mirror Uconnect™ Phone — IF EQUIPPED • www.jeep.com/uconnect Uconnect™ Phone is a voice-activated, hands-free, in- • or call 1–877–855–8400 vehicle communications system. Uconnect™ Phone al- lows you to dial a phone number with your mobile phone using simple voice commands (e.g., “Call”...
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone allows you to transfer calls between WARNING! the system and your mobile phone as you enter or exit your vehicle and enables you to mute the system’s Any voice commanded system should be used only microphone for private conversation.
Page 103: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Voice Command Button Operation Actual button location may vary with the ra- Voice commands can be used to operate the Uconnect™ dio. The individual buttons are described in the Phone and to navigate through the Uconnect™ Phone “Operation”...
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE example, you can use the compound form voice Cancel Command command “Phonebook New Entry”, or you can break At any prompt, after the beep, you can say “Cancel” and the compound form command into two voice com- you will be returned to the main menu.
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 • When prompted, after the beep, say “Pair a Phone” phone to use if multiple mobile phones are in the and follow the audible prompts. vehicle at the same time. For example, if priority three and priority five phones are present in the vehicle, the •...
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone will confirm the phone number • The Uconnect™ system will confirm the name and and then dial. The number will appear in the display then dial the corresponding phone number, which of certain radios.
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 • When prompted, enter the number designation (e.g., Phonebook Download – Automatic Phonebook “Home”, “Work”, “Mobile”, or “Other”). This will Transfer From Mobile Phone allow you to store multiple numbers for each phone- If equipped and specifically supported by your phone, book entry, if desired.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- Phonebook Download — Single Entry loaded, there may be a short delay before the latest If equipped and supported by your phone, Uconnect™ downloaded names can be used. Until then, if avail- Phone also allows the user to download entries one at a able, the previous downloaded phonebook is available time from their phone via Bluetooth .
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 • You will then be asked for the name of the phonebook first disconnect or drop the Bluetooth connection to the Uconnect™ phone, and then send the address entry that you wish to edit. book entry via Bluetooth .
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the name, the Uconnect™ Phone will Delete Uconnect™ Phonebook Entry ask you which designation you wish to delete: home, NOTE: Editing phonebook entries is recommended work, mobile, other, or all. Say the designation you when the vehicle is not in motion.
Page 111: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 • Note that only the phonebook in the current language NOTE: The user can also exercise “Edit” or “Delete” is deleted. operations at this point. • Automatic downloaded phonebook entries cannot be • The Uconnect™ Phone will then prompt you as to the deleted or edited.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer or Reject an Incoming Call - No Call NOTE: The Uconnect™ Phone compatible phones in the Currently in Progress market today do not support rejecting an incoming call When you receive a call on your mobile phone, the when another call is in progress.
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Toggling Between Calls Call Termination If two calls are in progress (one active and one on hold), To end a call in progress, momentarily press the press the button until you hear a single beep, indicat- button.
Page 114: Uconnect™ Phone Features
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Uconnect™ Phone Features Call continuation is the progression of a phone call on the Language Selection Uconnect™ Phone after the vehicle ignition key has been To change the language that the Uconnect™ Phone is switched to OFF.
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Emergency Assistance Canada and 060 for Mexico). The number dialed may If you are in an emergency and the mobile phone is not be applicable with the available mobile service and reachable: area. •...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Towing Assistance Paging If you need towing assistance: To learn how to page, refer to “Working with Automated Systems”. Paging works properly except for pagers of • Press the button to begin. certain companies, which time out a little too soon to •...
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 When calling a number with your Uconnect™ Phone that The Uconnect™ Phone will then send the corresponding normally requires you to enter in a touch-tone sequence phone number associated with the phonebook entry, as on your mobile phone keypad, you can press the tones over the phone.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts On/Off Dialing Using the Mobile Phone Keypad Turning confirmation prompts off will stop the system You can dial a phone number with your mobile phone from confirming your choices (e.g., the Uconnect™ keypad and still use the Uconnect™...
Page 119: Advanced Phone Connectivity
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Mute/Un-Mute (Mute OFF) from your Uconnect™ Phone paired mobile phone to the When you mute the Uconnect™ Phone, you will still be Uconnect™ Phone or vice versa, press the button able to hear the conversation coming from the other and say “Transfer Call”.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say “List Phones”. • The selected phone will be used for the next phone call. If the selected phone is not available, the • The Uconnect™ Phone will play the phone names of Uconnect™...
Page 121: Things You Should Know About Your Uconnect™ Phone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Things You Should Know About Your Uconnect™ You can either press the Uconnect™ Phone button to Phone restore the factory setting or repeat the words and phrases when prompted by the Uconnect™ Phone. For Uconnect™...
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, Voice Command • For best performance, adjust the rearview mirror to • dry weather condition. provide at least ⁄ in (1 cm) gap between the overhead • Even though the system is designed for users speaking console (if equipped) and the mirror.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 • Numbers must be spoken in single digits. “800” must • fully closed windows, be spoken “eight-zero-zero” not “eight hundred”. • dry weather conditions, and • You can say “O” (letter “O”) for “0” (zero). •...
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Send Messages: Uconnect™ Phone can read or send new messages on You can send messages using Uconnect™ Phone. To send your phone. a new message: • Press the Read Messages: button. If you receive a new text message while your phone is •...
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 List of Preset Messages: 11. See You in 15 minutes 1. Yes 12. I am on my way 2. No 13. I’ll be late 3. Where are you? 14. Are you there yet? 4.
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn SMS Incoming Announcement ON/OFF Bluetooth Communication Link Turning the SMS Incoming Announcement OFF will stop Mobile phones have been found to lose connection to the the system from announcing the new incoming mes- Uconnect™...
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127...
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 132: General Information
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...
Page 133: Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 If you ever wish to interrupt the system while it lists The system will best recognize your speech if the win- options, press the Voice Command button, listen dows are closed, and the heater/air conditioning fan is set to low.
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Say a command (e.g., “Help”). Radio AM To switch to the AM band, say “AM” or “Radio AM”. In 3. Use the ON/OFF VOLUME rotary knob to adjust the this mode, you may say the following commands: volume to a comfortable level while the Voice Command •...
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 • “Menu Radio” (to switch to the radio menu) Disc To switch to the disc mode, say “Disc”. In this mode, you • “Main Menu” (to switch to the main menu) may say the following commands: Satellite Radio •...
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Switch to system setup” − “Continue” (to continue recording) • “Change to setup” − “Delete” (to delete the recording) • “Play Memos” (to play previously recorded memos) • “Main menu setup” or —...
Page 137: Voice Training
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Voice Training WARNING! For users experiencing difficulty with the system recog- • It is dangerous to ride in a cargo area, inside or nizing their voice commands or numbers the Uconnect™ Voice “Voice Training” feature may be used. outside of a vehicle.
Page 138: Manual Seat Height Adjustment - If Equipped
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE position. Then, using body pressure, move forward and WARNING! rearward on the seat to be sure that the seat adjusters • Adjusting a seat while driving may be dangerous. have latched. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.
Page 139: Front Seatback Recline
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Seat Height Adjustment Recline Lever Front Seatback Recline WARNING! Lean forward before lifting the handle, then lean back to the desired position and release the handle. Lift the Do not ride with the seatback reclined so that the handle to return the seatback to an upright position.
Page 140: Front Passenger Easy Entry Seat - Two-Door Models
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Passenger Easy Entry Seat — Two-Door Models Pull upward on the recline lever (toward the rear of the vehicle) and slide the entire seat forward. Easy Entry Seat To return the seat to a sitting position, rotate the seatback upright until it locks and push the seat rearward until the track locks.
Page 141: Tip N' Slide Seats - Two-Door Models
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 NOTE: Driver’s Seat • The front passenger seats have a track memory, which Pull upward on the recline lever and bring the seatback returns the seat to just past the halfway point of the to its full forward position.
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rotate the entire seat assembly toward the instrument Pull upward on the recline lever and slide the entire seat panel. forward (Easy Entry). Tip n’ Slide Easy Entry Lever With the seat forward, pull the entire seat assembly Passenger Seat In addition to Easy Entry, the front passenger seat is also toward the instrument panel.
Page 143: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 controls for each seat are located on a switch bank near the bottom center of the instrument panel. You can choose from HIGH, LOW or OFF heat settings. Amber indicator lights in each switch indicate the level of heat in use.
Page 144: Head Restraints
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE two to one, indicating the change. The LOW-level setting WARNING! (Continued) will turn OFF automatically after approximately 30 min- • Do not place anything on the seat that insulates utes. against heat, such as a blanket or cushion. This NOTE: When a heat setting is selected, heat will be felt may cause the seat heater to overheat.
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 WARNING! The head restraints for all occupants must be prop- erly adjusted prior to operating the vehicle or occu- pying a seat. Head restraints should never be ad- justed while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.
Page 146: Fold And Tumble Rear Seat - Two-Door Models
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold And Tumble Rear Seat — Two-Door Models NOTE: • Prior to folding the rear seat, it may be necessary to reposition the front seats. • Be sure that the front seats are fully upright and positioned forward.
Page 147: Removing The Rear Seat - Two-Door Models
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Removing The Rear Seat — Two-Door Models WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed.
Page 148: Replacing The Rear Seat - Two-Door Models
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Press down on the release bar on each side, and pull Replacing The Rear Seat — Two-Door Models the seat out and away from the lower bracket. Reverse the steps for removing the seat. 3.
Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 NOTE: To Fold Down The Rear Seat • Prior to folding the rear seat, it may be necessary to Locate the pull strap (lower outboard side of seat), and reposition the front seat to its mid-track position. pull it toward you until the seatback releases.
Page 150: To Open And Close The Hood
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Raise The Rear Seat TO OPEN AND CLOSE THE HOOD Raise the seatback and lock it into place. If interference Release both the hood latches. from the cargo area prevents the seatback from fully locking, you will have difficulty returning the seat to its proper position.
Page 151: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 down slightly on the hood before pushing the safety passing light, fog lights, instrument panel light dimming latch. Insert the support rod into the slot on the hood. and turn signals. The lever is located on the left side of the steering column.
Page 152: Headlights And Parking Lights
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights And Parking Lights NOTE: Lens fogging can occur under certain weather Turn the end of the multifunction lever to the first detent conditions. Turning the headlights on will usually accel- for parking lights and instrument panel lights. Turn to erate the clearing process.
Page 153: Turn Signals
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Headlight Switch Turn Signal Operation NOTE: The engine must be running before the head- NOTE: • If either light remains on and does not flash, or there is lights will turn on in the Automatic mode. a very fast flash rate, check for a defective outside light Turn Signals bulb.
Page 154: Lane Change Assist
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • A tone will chime if the turn signals are left on for Flash-To-Pass more than 1 mile (2 km). You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward the steer- Lane Change Assist ing wheel.
Page 155: Instrument Panel Dimmer
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Instrument Panel Dimmer Rotate the center portion of the lever to the extreme bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened. Rotate the center portion of the lever up to increase the brightness of the instrument panel lights when the park- ing lights or headlights are on.
Page 156: Interior Lights
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The Daytime Running Lights will turn off The sports bar reading lights (available on four-door automatically when a turn signal is in operation and turn models) can be turned on by pressing the switches, on again when the turn signal is not operating.
Page 157: Windshield Wipers And Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 WINDSHIELD WIPERS AND WASHERS The windshield wiper/washer control lever is located on the right side of the steering column. The front wipers are operated by rotating a switch, located at the end of the lever.
Page 158: Windshield Wiper Operation
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Wiper Operation CAUTION! Rotate the end of the lever upward to the second detent past the intermittent settings for low-speed wiper opera- In cold weather, always turn off the wiper switch and tion.
Page 159: Windshield Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Windshield Washers To use the washer, pull the lever toward you and hold while spray is desired. If the lever is pulled while in the delay range, the wiper will start and continue to operate for two or three wipe cycles after the lever is released, and then resume the intermittent interval previously selected.
Page 160: Mist Feature
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mist Feature Push down on the wiper lever to activate a single wipe to clear off road mist or spray from a passing vehicle. As long as the lever is held down, the wipers will continue to operate.
Page 161: Electronic Speed Control - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 Push down on the lever to unlock the steering column. WARNING! With one hand firmly on the steering wheel, move the steering column up or down, as desired. Pull upwards on Do not adjust the steering column while driving. the lever to lock the column firmly in place.
Page 162: To Activate
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Electronic Speed Control buttons are located on the the same time. If this occurs, the Electronic Speed Control right side of the steering wheel. System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed.
Page 163: To Set A Desired Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 To Set A Desired Speed To Resume Speed Turn the Electronic Speed Control ON. When the vehicle To resume a previously set speed, push the RES (+) has reached the desired speed, press the SET (-) button button and release.
Page 164: To Accelerate For Passing
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE decrease until the button is released. Release the button On steep hills, a greater speed loss or gain may occur so when the desired speed is reached, and the new set speed it may be preferable to drive without Electronic Speed will be established.
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 The front power outlet is powered from the ignition automatically when ready for use. To preserve the heat- switch. Power is available when the ignition switch is in ing element, do not hold the lighter in the heating the ON or ACC position.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On vehicles equipped with a rear subwoofer, there is a third power outlet located in the right rear cargo area. Power Outlet Fuse Locations 1 — M7 Fuse 20 A Yellow Power Outlet Rear with Sub Woofer (Opt.) Rear Power Outlet —...
Page 167 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery, even when not in use (i.e., mobile phones, etc.).
Page 168: Power Inverter - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not hang any type of accessory or acces- sory bracket from the plug. POWER INVERTER — IF EQUIPPED There is a 115 Volt, 150 Watt inverter outlet located on the front of the center console to convert DC current to AC current.
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 may have to be reset manually. To reset the inverter WARNING! manually press the power inverter button OFF and ON. To avoid overloading the circuit, check the power ratings To avoid serious injury or death: on electrical devices prior to using the inverter.
Page 170: Cupholders
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Rear Cupholders The rear cupholders are located on the back of the center Front Cupholders console. The front cupholders are located in the center console. Rear Cupholders Front Cupholders...
Page 171: Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 STORAGE Rear Storage Compartment The rear cargo area storage compartment cover is held by Console Storage Compartment a spring-loaded latch. In order to remove the rear storage To lock or unlock the storage compartment, insert the compartment cover, use the following procedure: ignition key and turn.
Page 172: Dual Top - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Open the rear compartment cover. factory for shipping purposes only. The soft top and the hard top are to be used independently. Removal is mandatory to prevent any possible wear and tear on the soft top.
Page 173 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 • Two Sunrider secure straps (if equipped) • Two rear swing gate brackets 2. Remove the hard top. Refer to “Freedom Top Three- Piece Modular Hard Top — Front/Rear Panel Removal” in this section. 3.
Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: To aid in disconnecting the knuckles, you may carefully tap on the knuckles using a rubber mallet. 6. Reinstall the hard top. Refer to “Freedom Top Three- Piece Modular Hard Top — Front/Rear Panel Installa- tion”...
Page 175: Installing The Soft Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 • Rear window Installing The Soft Top NOTE: The following procedures are for first time set 2. Remove the hard top. Refer to “Freedom Top Three- up only. For future soft top procedures, refer to “Soft Piece Modular Hard Top —...
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE a. If the pivot brackets have been removed, unzip the b. Lay the soft top into the rear of the vehicle with the sport bar covers and attach the pivot brackets to the bows pointing forward and the curved portion of the sports bar with the four screws that were removed bows facing upward.
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 d. Screw the pivot screws back into place using a #T30 CAUTION! Torx head driver. Secure them until they are snug, being careful not to cross-thread the screws or over- Do not overtighten the screws. You can strip the tighten.
Page 178: Freedom Top™ Three-Piece Modular Hard Top - If Equipped
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE FREEDOM TOP™ THREE-PIECE MODULAR CAUTION! HARD TOP — IF EQUIPPED Failure to follow these cautions may cause interior CAUTION! water damage, stains or mildew: • It is recommended that the top be free of water •...
Page 179: Front Panel(S) Removal
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Front Panel(s) Removal NOTE: Left panel must be removed before removing right panel. 1. Fold down the sun visor, and move it to the side. 2. Turn the rear fasteners (knobs) (located on the over- head speaker bar assembly) counterclockwise until they can be removed.
Page 180 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Turn the center L-shaped locks (two) from the center of the roof panel. 5. Unlatch the header panel latch located at the top of the windshield. 4. Turn the rear L-shaped lock (located above the shoul- der belt anchorage).
Page 181: Freedom Top™ Storage Bag
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Freedom Top™ Storage Bag Your vehicle comes with a Freedom Top™ storage bag that allows you to store your Freedom Top™ panels. The storage bag contains two compartments and fits behind the rear seat. Lay the Freedom bag down so the loops and hooks are facing downward.
Page 182 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Insert the right side Freedom panel into the bag with the Unfold the black panel divider (ensure the divider is latches facing downward. laying flat). Secure the Velcro, located at the center of the divider.
Page 183 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 Insert the left-side Freedom panel into the bag with the Unfold the outer flap and zip the Freedom bag closed. latches facing upward. NOTE: Ensure the front Freedom panel latch is closed prior to inserting the panel into the bag.
Page 184 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Install the seat attachment strap (at the top of the bag) through the loops. Wrap the upper strap around the rear head restraints and loop the strap through the buckle. Pull on the strap to tighten the Freedom bag securely against the rear seat.
Page 185: Front Panel(S) Installation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Front Panel(s) Installation With Rear Hard Top Removed 1. Turn the left and right panels over and move the spacer block (located on the rear of the panel) upward 90 degrees. Front Panel(s) Installation NOTE: Set the panels on the windshield frame so that there is no overhang.
Page 186: Rear Hard Top Removal
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The front panel(s) must be positioned properly 4. Remove the six Torx head screws that secure the hard to ensure sealing. Set the panels on the windshield frame top to the vehicle (along the interior bodyside) using a so that there is no overhang.
Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 6. Locate the wire harness on the left rear inside corner of 7. Release the red locking tab by pulling outward. the vehicle. Red Locking Tab Wire Harness Connector...
Page 188 186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 8. To remove the wiring harness press the tab and pull downward to disconnect. Pinch Grip On Hose 10. Close the swing gate. Press Tab To Disconnect 11. Remove the hard top from the vehicle. Place the hard 9.
Page 189: Rear Hard Top Installation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 NOTE: CAUTION! • The Torx fasteners that attach the hard top to the body should be torqued to 66 in lb +/- 22 in lb (7.5 N·m +/- The removal of the Freedom Top requires four adults 2.5 N·m) located on each corner.
Page 190: Door Frame Removal
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Failure to follow these cautions may cause interior water damage, stains or mildew: • Opening a door or lowering a window while the top is wet may allow water to drip into the vehicle’s interior.
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 2. Place one hand on the upper rear and one hand on the front of the door frame. 3. Pull the frame toward you with your rearward hand to remove the frame from the vehicle. WARNING! Never store the door frames in your vehicle.
Page 192: Door Frame Installation - Two-Door Models
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Frame Installation — Two-Door Models 3. After the door frame pin has been set into the body side hole, carefully set the front of the door frame into the 1. Unfold door frame and unscrew thumbscrews. rubber seal at the top of the windshield.
Page 193: Door Frame Installation - Four-Door Models
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 5. Starting with the front knob, screw in and tighten both Door Frame Installation — Four-Door Models knobs. Repeat on the other side. 1. Install the rear door frame first. 2. Set the door frame pin into the hole on top of the body side, just behind the rear door opening.
Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Position the top of the door frame against the metal 5. Carefully set the front of the front door frame in the sport bar and press onto the side bar making sure not to rubber seal at the top of the windshield.
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 7. Position the rear of the front door frame to lay on top 9. Tighten the front knob, then the rear most knob, and of the front of the rear door frame. Ensure the seals are then the middle knob.
Page 196: Soft Top - Two-Door Models
SOFT TOP — TWO-DOOR MODELS Place the vehicle in a warm area. Pull steadily on the top Please visit the owners section of Jeep.com for instruc- fabric. The vinyl will stretch back to its original size and the top can then be installed. If the temperature is 41°F tional videos.
Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 CAUTION! (Continued) WARNING! (Continued) • Refer to “Appearance Care For Fabric Top Models” • The fabric upper doors and fabric top are designed in “Maintaining Your Vehicle” for further infor- only for protection against the elements. Do not mation.
Page 198: Quick Steps To Lowering The Soft Top
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Careless handling and storage of the soft top may damage the seals, causing water to leak into the vehicle’s interior. • The soft top must be positioned properly to ensure sealing.
Page 199 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 3. Release the Sunrider latch (both sides). 4. Open the swing gate and lower the top.
Page 200: Quick Steps To Raising The Soft Top
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Ensure fabric does not overhang the sides of the 1. Open the swing gate and raise the top, engaging the vehicle. Sunrider latches (another person may be needed to help with this operation). Quick Steps To Raising The Soft Top Refer to “Raising The Soft Top”...
Page 201 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 2. Engage header latches.
Page 202 200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Install rear corner panels. 4. Install side and back windows.
Page 203: Lowering The Soft Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 Lowering The Soft Top 1 — Header Bow 6 — Quarter Window 2 — 2–Bow 7 — Check Strap 3 — 3–Bow 8 — Front Retainer — Quarter Window 4 — Sail Panel 9 —...
Page 204 202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1 — Zipper Start 2 — Zipper Finish 3 — Swing Gate Bar 4 — Swing Gate Brackets 5 — Sail Panels...
Page 205 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 NOTE: Clean side and rear windows before removal to assist in preventing scratching during removal of the soft top. If zippers are difficult to operate due to road dust, etc., clean them with a mild soap solution and a small brush.
Page 206 204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Before unzipping the rear window, release the first 3 in will stay on the rear window. Pull down on the rear (7.6 cm) of both sail panels from the channel. Remove the window to disengage it from the zipper on the top swing gate bar by pulling it straight rearward out of the cover.
Page 207 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 7. Stow the windows carefully to avoid scratching. 10. Once unzipped, remove the side window retainers from the door channel and body side channel. Repeat this 8. Undo the Velcro that runs along the top and rear step on the opposite side.
Page 208 206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 11. Finish releasing the sail panel retainers from the body 12. As you begin to lower the top, fold the sail panels so side channel at the rear corners of the vehicle. that they rest on top of the soft top. NOTE: When releasing the sail panel retainers, it is helpful to pull down on the rear roof bow.
Page 209 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 13. The swing gate brackets do not need to be removed 14. Completely release the latches from the loops on the unless the hard top is being installed. To remove the windshield frame. If your vehicle is not equipped with swing gate brackets, pull the front of the bracket forward the Sunrider package, proceed to Step 15.
Page 210 208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 15. Make sure the plastic sleeves are slid rearward over the Sunrider link (Sunrider Models only). 17. Before lowering the top, open the swing gate to prevent possible damage to the rear center high-mounted brake light.
Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 18. Tuck the fabric and the check straps between the 19. Close the front header latches. bows and as far inward as possible. This will keep any 20. Remove the door frames, if desired. Refer to “Door portion of the top from flapping outside of the vehicle.
Page 212: Raising The Soft Top
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Raising The Soft Top 4. Standing on the side of the vehicle, lift the top by the side bow and the 2–bow (middle bow) up and over the 1. Unclip and move the sun visors to the side. sports bar until the header rests on the top of the 2.
Page 213 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 5. Make sure the Sunrider bracket on the side bows 6. Open the header latches and engage the hook on each latches to the door rails (Sunrider Models only). side onto the windshield loops (do not close the latches).
Page 214 212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. If the swing gate brackets were removed, install them 8. Move to the rear of the vehicle and gently pull the sail by hooking the rear edge of the bracket on the interior panels over the rear roof bow.
Page 215 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 9. Partially install the sail panel retainers into the body 10. To install the side windows, affix the window tem- side channel, leaving the last 3 in (7.6 cm) toward the rear porarily by attaching to the Velcro in the rear corner. window loose (on both sides).
Page 216 214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 11. Insert the front retainer of the window into the door channel, making sure the retainer is fully seated and properly positioned on the door frame. Failure to do so can result in wind and water leaks or damage to the window.
Page 217 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 12. Insert the retainer along the bottom edge of the window into the bottom side channel, beginning at the front and working to the rear of the vehicle. Finish by closing the zipper completely and attaching the Velcro along the top and rear of the window.
Page 218 216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 13. Locate the black swing gate bar. Slide the swing gate 14. Install the rear window by starting both zipper ends bar over the receiver at the bottom inside of the rear at the lower left corner of the rear window opening. window.
Page 219 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 16. Grasp the swing gate bar and position it into the swing gate brackets. 15. Run the zipper fully around to the right side of the window.
Page 220 218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 17. Insert the rear window retainer into the swing gate 19. Close the header latches and return the sun visors to bracket on both the left and right sides. their secured position. 18. Apply downward pressure on the top corner of the rear soft top bow (3–bow), then complete attaching the sail panel retainers into the body side channel.
Page 221: Soft Top - Four-Door Models
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 SOFT TOP — FOUR-DOOR MODELS Place the vehicle in a warm area. Pull steadily on the top Please visit the owner’s section of Jeep.com for instruc- fabric. The vinyl will stretch back to its original size and tional videos.
Page 222 220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) WARNING! • Do not lower the top with the windows installed. • Do not drive the vehicle with the rear window Window and top damage may occur. curtain up unless the side curtains are also open. •...
Page 223 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 NOTE: Do not remove any of the three attachment CAUTION! knobs unless you are planning on installing the hard top. Failure to follow these cautions may cause interior water damage, stains or mildew on the top material: •...
Page 224: Quick Steps For Lowering The Soft Top
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Quick Steps For Lowering The Soft Top 1. Remove the side and back windows. 3. Fold header rearward, pulling the fabric to the rear. 2. Release header latches from the windshield frame.
Page 225 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223...
Page 226 224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Release Sunrider latch (both sides). NOTE: Ensure the fabric does not overhang the sides of the vehicle. 5. Open the swing gate and lower the top.
Page 227: Quick Steps For Raising The Soft Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 Quick Steps For Raising The Soft Top 1. Open the swing gate and raise the top, engaging the Sunrider latches (another person may be needed to help with this operation).
Page 228 226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Install rear corner panels. 3. Rotate the header forward.
Page 229 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 4. Engage the header latches. 5. Install the side and back windows.
Page 230: Folding Down The Soft Top
228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Down The Soft Top 1 — Header Bow 6 — Body Side Retainer 2 — 2–Bow 7 — Quarter Window 3 — 3–Bow 8 — Check Strap 4 — 4–Bow 9 — Front Retainer — Quarter Window 5 —...
Page 231 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 1 — Zipper Start 2 — Zipper Finish 3 — Swing Gate Bar 4 — Swing Gate Brackets 5 — Sail Panels...
Page 232 230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Clean side and rear windows before removal to assist in preventing scratching during removal of the soft top. If zippers are difficult to operate due to road dust, etc., clean them with a mild soap solution and a small brush.
Page 233 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 will stay on the rear window. Pull down on the rear window to disengage it from the zipper on the top cover. • Unzip the rear window starting at the right lower corner of the window. Pull the zipper up, across the top and down to the left lower corner.
Page 234 232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Remove the rear window retainer from the swing gate 9. Beginning from the rear lower corner, completely bracket on both the left and right sides. unzip the window. 7. Stow the windows carefully to avoid scratching. 10.
Page 235 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 11. Finish releasing the sail panel retainers from the body 12. Fold the sail panels so that they rest on top of the soft side channel at the rear corners of the vehicle. top.
Page 236 234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 13. The swing gate brackets do not need to be removed 14. Grasp the front side bow behind the header, and lift unless the hard top is being installed. To remove the the top. swing gate brackets, pull the front of the bracket forward while rolling the entire bracket back in toward the vehicle to disengage.
Page 237 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 15. Fold back the front section of the top, pulling the 16. Fold the top so that the material forms a W as fabric rearward. Gently rest the header on top of the rear shown.
Page 238 236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 17. Release the side bows by pressing down on the latch above the front of the rear door. Push the top rearward to disengage. Repeat this step on the other side. 19. Gently slide the side bows off the door frame track and lower the top down into the vehicle.
Page 239 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 20. Tuck the fabric and the check straps between the 22. Close the front header latches. bows as far inside as possible. This will keep any portion 23. Remove the door frames, if desired. Refer to “Door of the top from flapping outside of the vehicle.
Page 240: Putting Up The Soft Top
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Putting Up The Soft Top NOTE: Be extremely careful when putting up the soft top to prevent the doors from getting scratched. It may be helpful to open the rear doors. 1. Install the door frames, if removed. Refer to “Door Frame”...
Page 241 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 6. Ensure that the top locks into the Sunrider locking 7. Unclip and move the sun visors to the side. mechanisms that are located above the front of the rear doors.
Page 242 240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 8. Standing on the side of the vehicle, lift the top by the 9. Open the header latches and engage the hook on each side bow until it rests on the windshield frame. side onto the windshield loops (do not close the latches).
Page 243 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 10. If the swing gate brackets were removed, install them 11. Ensure that the straps are positioned correctly before by hooking the rear edge of the bracket on the interior pulling the sail panels over the rear roof bow (4–bow). side of the body channel.
Page 244 242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Partially install the sail panel retainers into the body side 12. To install the side windows, affix the window tem- channel, leaving the last 3 in (7.6 cm) toward the rear porarily by attaching it to the Velcro in the upper rear window loose (on both sides).
Page 245 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 13. Insert the front retainer of the window into the door channel, making sure the retainer is fully seated and properly positioned on the door frame. Failure to do so can result in wind and water leaks or damage to the window.
Page 246 244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 14. Insert the retainer along the bottom edge of the window into the bottom side channel, beginning at the front and working to the rear of the vehicle. Finish by closing the zipper completely and attaching the Velcro along the top and rear of the window.
Page 247 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 16. Install the rear window by starting both zipper ends 17. Run the first zipper fully around to the right side of at the lower left corner of the rear window opening. the window. Ensure that the zippers are properly started and aligned before zipping to prevent damage.
Page 248 246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 18. Grasp the swing gate bar and position it into the swing gate brackets. 20. Complete the installation of the sail panel by insert- ing the rest of the retainer into the body channel. 19.
Page 249: Sunrider (Two-Door Models) - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 SUNRIDER (TWO-DOOR MODELS) — IF EQUIPPED CAUTION! Operating the top, opening a door or lowering a window while the top is wet may allow water to drip into the vehicle’s interior. NOTE: If you are going to be driving faster than 40 mph (64 km/h) with the Sunrider feature open, it is recom- mended that you remove the rear window of the vehicle.
Page 250: Opening The Sunrider
248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening The Sunrider 1. Unclip and move the sun visors to the side. 2. Release the header latches from the loops on the windshield frame. 4. Grasp the header and lift the top back. Make sure the material is folded back as shown.
Page 251: Closing The Sunrider
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 5. Locate the straps to secure the side bows. Wrap the 6. Reposition the sun visors. straps around the bows as shown. Repeat on the other Closing The Sunrider side. 1. Remove the straps from the side bows. 2.
Page 252: Sunrider (Four-Door Models) - If Equipped
250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Grasp the front header and pull it to the front of the (64 km/h) with the Sunrider feature open, it is recom- vehicle. mended that you remove the rear window of the vehicle. 4.
Page 253 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 3. Grasp the front side bow behind the header, and lift 4. Fold back the front section of the top and gently rest the top. the header on top of the rear portion of the deck.
Page 254: Closing The Sunrider
252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Fold the top so that the material forms a W as shown. Enter the vehicle and move the material into two folds. Closing The Sunrider Perform the above steps in the opposite order. 6.
Page 255: Folding Windshield
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 FOLDING WINDSHIELD Raise the windshield and reinstall the side bars as soon as The fold-down windshield and removable side bars on the task that required their removal is completed and your vehicle are structural elements that can provide before you return to on-road driving.
Page 256: Lowering The Windshield And Removing Side Bars
254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lowering The Windshield And Removing Side WARNING! (Continued) Bars • Do not drive your vehicle unless the windshield is 1. Lower the fabric top or remove the hard top following securely fastened, either up or down. the instructions in this manual.
Page 257 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 7. Remove the one hex bolt (13 mm) visible through the plastic trim on the bottom side of the side bar, one hex bolt (13 mm) on the side of the side bar, and one hex bolt (13 mm) on top of the side bar.
Page 258 256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! WARNING! Do not remove the head impact foam from the side You or others could be injured if you carry the side bars, as damage to the foam may result. bars loose in your vehicle. Remove the side bars from the vehicle or securely store them as described or NOTE: Store all of the mounting bolts in their original they may cause personal injury if an accident occurs.
Page 259: Raising The Windshield And Replacing Side Bars
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 11. Remove the lower windshield plates by removing the 12. Lower the windshield gently until it contacts the six black round-headed Torx head screws (using a #40 rubber hood bumpers. Torx head driver) on each side of the base of the 13.
Page 260 258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Install the top two hex bolts (13 mm) first, then the 2. Loosely attach the rear of the side bar to the sport bar. Refer to Step 4 of “Lowering Windshield And Removing lower side hex bolt (13 mm).
Page 261: Rear Window Features - Hard Top Only
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 6. Reinstall the wiper arms. Rear Wiper/Washer Control Rotate the switch upward to the first detent posi- REAR WINDOW FEATURES — HARD TOP ONLY tion for rear wiper operation. Rear Window Wiper/Washer — If Equipped Rotate the switch upward past the first detent to A rotary switch on the center portion of the control lever activate the rear washer.
Page 262: Rear Window Defroster - If Equipped
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE wiper will continue to operate as long as the switch is NOTE: To prevent excessive battery drain, use the rear held. Upon release, the wiper will cycle two to three window defroster only when the engine is operating. times before returning to the set position.
Page 263: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....264 Electronic Vehicle Information Center (EVIC) — If Equipped ......286 Instrument Cluster .
Page 264 262 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 230 (REQ) — AM/FM Stereo Media Center 730N/430/430N (RHR/RER/ Radio And 6–Disc CD/DVD Changer RBZ/RHB) CD/DVD/HDD/NAV — (MP3/WMA AUX Jack) ....298 If Equipped .
Page 265 UNDERSTANDING YOUR INSTRUMENT PANEL 263 Media Center 130 With Satellite Radio Play Mode ......344 (Sales Code RES+RSC)....326 List Or Browse Mode .
Page 266: Instrument Panel Features
264 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 7 — Climate Controls 2 — Instrument Cluster 8 — Power Outlet 3 — Radio 9 — Lower Switch Bank 4 — Assist Handle 10 — Power Mirror Switch — If Equipped 5 —...
Page 267: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 265 INSTRUMENT CLUSTER...
Page 268: Instrument Cluster Descriptions
266 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 3. Front Fog Light Indicator — If Equipped This indicator will illuminate when the front fog 1. Fuel Gauge lights are on. The pointer shows the level of fuel in the fuel tank. 4.
Page 269 UNDERSTANDING YOUR INSTRUMENT PANEL 267 the driver’s seat belt is unbuckled, a chime will sound. checked by an authorized dealer. If the light turns on After the bulb check or when driving, if the driver seat while driving, stop the vehicle and shut off the engine as belt remains unbuckled, the Seat Belt Reminder Light soon as possible.
Page 270 268 UNDERSTANDING YOUR INSTRUMENT PANEL 11. Brake Warning Light The dual brake system provides a reserve braking capac- This light monitors various brake functions, ity in the event of a failure to a portion of the hydraulic including brake fluid level and parking brake system.
Page 271 UNDERSTANDING YOUR INSTRUMENT PANEL 269 The light also will turn on when the parking brake is WARNING! applied with the ignition switch in the ON/RUN posi- tion. Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. NOTE: This light shows only that the parking brake is It will take longer to stop the vehicle.
Page 272 270 UNDERSTANDING YOUR INSTRUMENT PANEL 13. Air Bag Warning Light CAUTION! This light will turn on for four to eight seconds as a bulb check when the ignition switch is first Do not operate the engine with the tachometer turned to ON/RUN. If the light is either not on pointer in the red area.
Page 273 UNDERSTANDING YOUR INSTRUMENT PANEL 271 17. Vehicle Security Light — If Equipped CAUTION! This light will flash at a fast rate for approxi- mately 15 seconds, when the vehicle security Driving with a hot engine cooling system could alarm is arming, and then will flash slowly damage your vehicle.
Page 274 272 UNDERSTANDING YOUR INSTRUMENT PANEL 21. Odometer / Trip Odometer / ECO WARNING! (Fuel Saver Indicator) Button Press this button to change the display from odometer to A hot engine cooling system is dangerous. You or either of the two trip odometer settings or the “ECO” others could be badly burned by steam or boiling display.
Page 275 UNDERSTANDING YOUR INSTRUMENT PANEL 273 has tires of a different size than the size indicated on the maintain correct tire pressure, even if under-inflation has vehicle placard or tire inflation pressure label, you should not reached the level to trigger illumination of the TPMS determine the proper tire inflation pressure for those low tire pressure telltale.
Page 276 274 UNDERSTANDING YOUR INSTRUMENT PANEL tires or wheels on your vehicle, to ensure that the 24. Odometer / Trip Odometer Display Area replacement or alternate tires and wheels allow the TPMS The odometer display shows the total distance the vehicle to continue to function properly.
Page 277 UNDERSTANDING YOUR INSTRUMENT PANEL 275 Vehicle Odometer Messages depending on driving habits and vehicle usage. Press the When the appropriate conditions exist, the following Odometer / Trip Odometer / ECO (Fuel Saver Indicator) odometer messages will display: button to change the display from odometer to either of the two trip odometer settings or the “ECO”...
Page 278 276 UNDERSTANDING YOUR INSTRUMENT PANEL (e.g., snow plowing, off-road operation). If this “HOT- gASCAP OIL” message turns on, stop the vehicle and run the If the vehicle diagnostic system determines that the fuel engine at idle or faster with the transmission in NEU- filler cap is loose, improperly installed, or damaged, a TRAL until the message turns off.
Page 279 UNDERSTANDING YOUR INSTRUMENT PANEL 277 in the instrument cluster odometer for approximately 3. Turn the ignition switch to the OFF/LOCK position. 12 seconds after a single chime has sounded to indicate NOTE: If the indicator message illuminates when you the next scheduled oil change interval. The engine oil start the vehicle, the oil change indicator system did not change indicator system is duty-cycle based, which reset.
Page 280 278 UNDERSTANDING YOUR INSTRUMENT PANEL When the engine is running, the MIL may flash to alert WARNING! serious conditions that could lead to immediate loss of power or severe catalytic converter damage. The vehicle A malfunctioning catalytic converter, as referenced should be serviced as soon as possible if this occurs.
Page 281 UNDERSTANDING YOUR INSTRUMENT PANEL 279 system. If this light remains on after several ignition WARNING! cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see The Electronic Stability Control (ESC) cannot pre- your authorized dealer as soon as possible to have the vent the natural laws of physics from acting on the problem diagnosed and corrected.
Page 282 280 UNDERSTANDING YOUR INSTRUMENT PANEL 28. Sway Bar Indicator Light — If Equipped position. The light should turn off. If the light remains on This indicator will illuminate when the front with the engine running, your vehicle will usually be sway bar is disconnected.
Page 283: Compass And Trip Computer - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 281 31. Electronic Vehicle Information Center (EVIC) Display / Compass Mini-Trip Computer Display — If Equipped When the appropriate conditions exist, this display shows the Electronic Vehicle Information Center (EVIC) messages. For further information, refer to “Electronic Vehicle Information Center”.
Page 284: Control Buttons
282 UNDERSTANDING YOUR INSTRUMENT PANEL Control Buttons NOTE: The system will display the last known outside The Compass/Temperature control buttons are located temperature when starting the vehicle and may need to on the left spoke of the steering wheel. be driven several minutes before the updated tempera- ture is displayed.
Page 285: Trip Conditions
UNDERSTANDING YOUR INSTRUMENT PANEL 283 Trip Conditions Trip Odometer (ODO) / ECO (Fuel Saver Indicator) — If Equipped This display shows the distance traveled since the last reset. Press and release the right button (on the instru- ment cluster) to switch from odometer to Trip A or Trip B or to ECO.
Page 286: Compass/Temperature Display
284 UNDERSTANDING YOUR INSTRUMENT PANEL ECO (Fuel Saver Indicator) — If Equipped Compass Variance The ECO-ON indicator will illuminate when you are Compass Variance is the difference between Magnetic driving in a fuel efficient manner and can be used to North and Geographic North.
Page 287 UNDERSTANDING YOUR INSTRUMENT PANEL 285 button to increase the variance one step. Repeat as necessary until the desired variance is achieved. NOTE: The factory default zone is 8. During program- ming, the zone value will wrap around from zone 15 to zone 1.
Page 288: Electronic Vehicle Information Center (Evic) - If Equipped
286 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Release the RESET button, then press and hold again for approximately 10 seconds, until the direction is displayed, with the CAL indicator on continuously in the display. 4. To complete the compass calibration, drive the vehicle in one or more complete 360–degree circles, under 5 mph (8 km/h) in an area free from power lines and large metallic objects, until the CAL indicator turns off.
Page 289 UNDERSTANDING YOUR INSTRUMENT PANEL 287 • Vehicle Information Warning Message Displays • Tire Pressure Monitor System (if equipped) • Personal Settings (Customer-Programmable Features) • Compass Display • Outside Temperature Display • Trip Computer Functions • Uconnect™ gps system screens (if equipped) •...
Page 290: Electronic Vehicle Information Center (Evic) Displays
288 UNDERSTANDING YOUR INSTRUMENT PANEL COMPASS Button Electronic Vehicle Information Center (EVIC) Press and release the COMPASS button to Displays display one of eight compass readings and the When the appropriate conditions exist, the EVIC displays outside temperature or to exit sub-menus. the following messages: •...
Page 291: Oil Change Required
UNDERSTANDING YOUR INSTRUMENT PANEL 289 • Right Rear Turn Signal Light Out (with a single chime) • Door(s) Ajar (with a single chime if vehicle is in motion) • Key Fob Battery Low (with a single chime) • Gate Ajar (with a single chime) •...
Page 292: Trip Functions
290 UNDERSTANDING YOUR INSTRUMENT PANEL indicator system is duty cycle based, which means the Trip Functions engine oil change interval may fluctuate dependent upon Press and release the MENU button until one of the your personal driving style. following Trip Functions displays in the EVIC: •...
Page 293 UNDERSTANDING YOUR INSTRUMENT PANEL 291 history information will be erased, and the averaging will significant amount of fuel to the vehicle will turn off the continue from the last fuel average reading before the LOW FUEL text and a new DTE value will display. reset.
Page 294: Compass Display / Eco (Fuel Saver Mode) - If Equipped
292 UNDERSTANDING YOUR INSTRUMENT PANEL three seconds of resetting the currently displayed func- ECO (Fuel Saver Mode) — If Equipped tion (reset ALL will display during this three-second The ECO message will display below the outside tem- window). perature in the EVIC display. This message will appear whenever you are driving in a fuel efficient manner.
Page 295 UNDERSTANDING YOUR INSTRUMENT PANEL 293 NOTE: A good calibration requires a level surface and 4. Press and release the SELECT button to start the an environment free from large metallic objects such as calibration. The “CAL” indicator will display in the buildings, bridges, underground cables, railroad tracks, EVIC.
Page 296: Personal Settings (Customer-Programmable Features)
294 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Magnetic materials should be kept away from 3. Press the DOWN button until “Compass Variance” the top of the instrument panel; this is where the compass message and the last variance zone number displays in sensor is located.
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 Use the DOWN button to display one of the following NEUTRAL position and the driver’s door is opened. To choices: make your selection, press and release the SELECT button until “On” or “Off” appears. Language When in this display you may select one of five lan- Remote Key Unlock guages for all display nomenclature, including the trip...
Page 298 296 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Key Lock feature. To make your selection, press Delay Power Off to Accessories Until Exit and release the SELECT button until “On” or “Off” When this feature is selected, the power window appears. switches, radio, hands–free system (if equipped), DVD video system (if equipped), power sunroof (if equipped), Flash Lights with Remote Key Lock and power outlets will remain active for up to 10 minutes...
Page 299 UNDERSTANDING YOUR INSTRUMENT PANEL 297 Nav–Turn By Turn Display Fuel Saver — If Equipped When this feature is selected, the navigation system The “ECO” message is located in the Compass/ utilizes voice commands, guiding through the drive Temperature display; this message can be turned on or route, mile by mile, turn-by-turn until the final destina- off.
Page 300: Operating Instructions - Radio Mode
298 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 230 (REQ) — AM/FM STEREO Operating Instructions - Radio Mode RADIO AND 6–DISC CD/DVD CHANGER NOTE: The ignition switch must be in the ON or ACC (MP3/WMA AUX JACK) position to operate the radio. NOTE: The radio sales code is located on the lower right Power Switch/Volume Control (Rotary) side of the radio faceplate.
Page 301 UNDERSTANDING YOUR INSTRUMENT PANEL 299 to seek up and the left switch to seek down. The radio If your vehicle is not equipped with or this feature is not will remain tuned to the new station until you make available on your vehicle, a “Not Equipped With another selection.
Page 302 300 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure INFO Button Press the INFO button for an RDS station (one with call 1. Press and hold the TIME button until the hours blink. letters displayed). The radio will return a Radio Text 2.
Page 303 UNDERSTANDING YOUR INSTRUMENT PANEL 301 Push the rotary TUNE/SCROLL control knob a second MUSIC TYPE Button time and MID will display. Turn the TUNE/SCROLL Pressing this button once will turn on the Music Type control knob to the right or left to increase or decrease the mode for five seconds.
Page 304 302 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type 16-Digit Character Display Program Type 16-Digit Character Display Information Inform Top 40 Top 40 Jazz Jazz Weather Weather News News By pressing the SEEK button when the Music Type icon Nostalgia Nostalga is displayed, the radio will be tuned to the next frequency Oldies Oldies station with the same selected Music Type name.
Page 305 UNDERSTANDING YOUR INSTRUMENT PANEL 303 • DVD Enter - When the disc is in DVD Menu mode, • Angle – Repeatedly pressing SELECT will change selecting DVD Enter will allow you to play the current the viewing angle if supported by the DVD disc (if highlighted selection.
Page 306 304 UNDERSTANDING YOUR INSTRUMENT PANEL • Set Home Clock - Pressing the SELECT button allows Audio Language — If Equipped you to set the clock. Turn the TUNE/SCROLL control Selecting this item allows you to choose a default audio knob to adjust the hours and then press and turn the language (effective only if the language is supported by TUNE/SCROLL control knob to adjust the minutes.
Page 307 UNDERSTANDING YOUR INSTRUMENT PANEL 305 Audio DRC — If Equipped a disc is loaded, changes will not be effective. Also, the Selecting this item allows you to limit maximum audio defaults are effective only if the disc supports the dynamic range. The default is set to High, and under customer-preferred settings.
Page 308: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
306 UNDERSTANDING YOUR INSTRUMENT PANEL both AM and FM. This allows a total of 12 AM, 12 FM, Operation Instructions - (DISC MODE for CD and and 12 Satellite (if equipped) stations to be stored into MP3/WMA Audio Play, DVD-VIDEO) pushbutton memory.
Page 309 UNDERSTANDING YOUR INSTRUMENT PANEL 307 NOTE: The ignition switch must be in the ON or ACC Eject Button — Ejecting Compact Disc(s) position to operate the radio. Press the EJECT button and the pushbutton with the corresponding number (1-6) where the LOAD Button —...
Page 310: Notes On Playing Mp3/Wma Files
308 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (CD MODE) Notes On Playing MP3/WMA Files Press the SCAN button to scan through each track on the The radio can play MP3/WMA files; however, acceptable CD currently playing. MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the TIME Button (CD MODE) following restrictions.
Page 311 UNDERSTANDING YOUR INSTRUMENT PANEL 309 The radio uses the following limits for file systems: If a disc contains multi-formats, such as CD audio and MP3/WMA tracks, the radio will only play the MP3/ • Maximum number of directory levels: 8 WMA tracks on that disc.
Page 312 310 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3/WMA Files MPEG Specifi- Sampling Fre- Bit Rate (kbps) When a medium containing MP3/WMA data is loaded, cation quency (kHz) the radio checks all files on the medium. If the medium 320, 256, 224, contains a lot of folders or files, the radio will take more MPEG-1 Audio 192, 160, 128,...
Page 313: List Button (Disc Mode For Mp3/Wma Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 311 LIST Button (DISC Mode for MP3/WMA Play) Press and hold the INFO button again for three seconds Pressing the LIST button will bring up a list of all folders to return to elapsed time display. on the disc.
Page 314 312 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (Auxiliary Mode) Operating Instructions — Voice Command System No function. (If Equipped) For the radio, Refer to “Voice Command” in the EJECT Button (Auxiliary Mode) Uconnect™ User Manual located on the DVD for further No function.
Page 315: If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 313 Macrovision NOTE: Sirius service is not available in Hawaii and has This product incorporates copyright protection technol- limited coverage in Alaska. ogy that is protected by U.S. patents and other intellec- System Activation tual property rights. Use of this copyright protection Sirius Satellite Radio service is pre-activated, and you technology must be authorized by Macrovision, and is may begin listening immediately to the one year of audio...
Page 316 314 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Your Vehicle Identification Number. placed within the line of sight of the antenna will cause decreased performance. Larger luggage items such as To access the ESN/SID, refer to the following steps: bikes should be placed as far rearward as possible, within ESN/SID Access the loading design of the rack.
Page 317 UNDERSTANDING YOUR INSTRUMENT PANEL 315 Operating Instructions - Uconnect™ Multimedia INFO Button (Satellite) Mode Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- NOTE: The ignition switch must be in the ON/RUN or able).
Page 318 316 UNDERSTANDING YOUR INSTRUMENT PANEL or turning the TUNE/SCROLL control knob within five SET Button – To Set the Pushbutton Memory seconds will allow the program format type to be selected. When you are receiving a channel that you wish to commit to pushbutton memory, press the SET button.
Page 319: If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 317 Buttons 1 - 6 MEDIA CENTER 130 (SALES CODE RES) These buttons tune the radio to the channels that you NOTE: The radio sales code is located on the lower right commit to pushbutton memory (12 Satellite stations). side of the radio faceplate.
Page 320: Operating Instructions - Radio Mode
318 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode SEEK Buttons Press and release the SEEK buttons to search for the next NOTE: The ignition switch must be in the ON/RUN or listenable station in AM/FM mode. Press the right switch ACC position to operate the radio.
Page 321 UNDERSTANDING YOUR INSTRUMENT PANEL 319 4. Adjust the minutes using the right side TUNE/ Push the rotary TUNE/SCROLL control knob a second SCROLL control knob. Press the TUNE/SCROLL control time and MID will display. Turn the TUNE/SCROLL knob to save time change. control knob to the right or left to increase or decrease the mid-range tones.
Page 322 320 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob again to SET 2 in both AM and FM. This allows a total of 12 AM exit setting tone, balance, and fade. and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by AM/FM Button pressing the pushbutton twice.
Page 323: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 321 Operation Instructions — CD MODE For CD And If you insert a disc with the ignition ON/RUN and the MP3 Audio Play radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display NOTE: will show the track number, and index time in minutes •...
Page 324 322 UNDERSTANDING YOUR INSTRUMENT PANEL EJECT Button - Ejecting a CD the current selection. Pressing and holding the SEEK Press the EJECT button to eject the CD. button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD If you have ejected a disc and have not removed it within...
Page 325: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 323 SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
Page 326 324 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of characters in file/folder names: When using the MP3 encoder to compress audio data to an MP3 file, the bit rate and sampling frequencies in the • Level 1: 12 (including a separator . and a three- following table are supported.
Page 327: Operation Instructions - Auxiliary Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 325 Playlist files are not supported. MP3 Pro files are not To increase the speed of disc loading, it is recommended supported. to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option Playback of MP3 Files before writing to the disc.
Page 328: Media Center 130 With Satellite Radio (Sales Code Res+Rsc)
326 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when ignition is OFF). MEDIA CENTER 130 WITH SATELLITE RADIO (SALES CODE RES+RSC) NOTE: The radio sales code is located on the lower right side of the radio faceplate.
Page 329 UNDERSTANDING YOUR INSTRUMENT PANEL 327 Power Switch/Volume Control (Rotary) Voice Command System (Radio) — If Equipped Push the ON/VOLUME control knob to turn on the Refer to “Voice Command” in “Understanding The Fea- radio. Push the ON/VOLUME control knob a second tures If Your Vehicle”.
Page 330 328 UNDERSTANDING YOUR INSTRUMENT PANEL If your vehicle is not equipped with or this feature is not 5. To exit, press any button/knob or wait five seconds. available on your vehicle, a “Not Equipped With Uconnect The clock can also be set by pressing the SETUP button. Phone”...
Page 331 UNDERSTANDING YOUR INSTRUMENT PANEL 329 TUNE Control Push the rotary TUNE/SCROLL control knob a fourth Turn the rotary TUNE/SCROLL control knob clockwise time and BALANCE will display. Turn the TUNE/ to increase or counterclockwise to decrease the frequency. SCROLL control knob to the right or left to adjust the sound level from the right or left side speakers.
Page 332 330 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following Program Type 16-Digit Character Display format types: Public Public Program Type 16-Digit Character Display Rhythm and Blues R & B No program type or Religious Music Rel Musc None undefined...
Page 333 UNDERSTANDING YOUR INSTRUMENT PANEL 331 If a preset button is activated while in the Music Type SET/RND Button — To Set the Pushbutton (Program Type) mode, the Music Type mode will be Memory exited and the radio will tune to the preset station. When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND SETUP Button...
Page 334: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
332 UNDERSTANDING YOUR INSTRUMENT PANEL • This radio is capable of playing compact discs (CD), Every time a preset button is used, a corresponding button number will display. recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and Buttons 1 - 6 multisession compact discs with CD and MP3 tracks.
Page 335 UNDERSTANDING YOUR INSTRUMENT PANEL 333 If you have ejected a disc and have not removed it within CAUTION! 10 seconds, it will be reloaded. If the CD is not removed, • This CD player will accept 4–3/4 in (12 cm) discs the radio will reinsert the CD but will not play it.
Page 336: Notes On Playing Mp3 Files
334 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Notes On Playing MP3 Files Press and hold FF (Fast Forward) and the CD player will The radio can play MP3 files; however, acceptable MP3 begin to fast forward until FF is released or RW or file recording media and formats are limited.
Page 337 UNDERSTANDING YOUR INSTRUMENT PANEL 335 • Maximum number of files: 255 Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of • Maximum number of folders. (The radio display of file multisession for CD audio or MP3 playback may result in names and folder names is limited.
Page 338 336 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files MPEG Sampling Fre- Bit Rate (kbps) When a medium containing MP3 data is loaded, the Specification quency (kHz) radio checks all files on the medium. If the medium 320, 256, 224, contains a lot of folders or files, the radio will take more MPEG-1 Audio 192, 160, 128,...
Page 339: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 337 LIST Button (CD Mode for MP3 Play) Press and hold the INFO button again for three seconds Pressing the LIST button will bring up a list of all folders to return to elapsed time display. on the disc.
Page 340: Uconnect™ Multimedia (Satellite Radio) - If Equipped
338 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) radio system in your vehicle. Sirius will supply a wel- Press this button to change the display to time of day. The come kit that contains general information, including time of day will display for five seconds (when the how to setup your on-line listening account.
Page 341 UNDERSTANDING YOUR INSTRUMENT PANEL 339 using the TUNE/SCROLL control knob until Sirius ID is Reception Quality selected. Press the TUNE/SCROLL control knob and the Satellite reception may be interrupted due to one of the Sirius ID number will display. The Sirius ID number following reasons: display will time out in two minutes.
Page 342 340 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons RW/FF Press and release the SEEK buttons to search for the next Pressing the RW (Rewind) or FF (Fast Forward) buttons channel in Satellite mode. Press the right switch to seek causes the tuner to search for the next channel in the up and the left switch to seek down.
Page 343 UNDERSTANDING YOUR INSTRUMENT PANEL 341 By pressing the SEEK button when the Music Type Select the button (1-6) you wish to lock onto this channel function is active, the radio will be tuned to the next and press and release that button. If a button is not channel with the same selected Music Type name.
Page 344: Ipod /Usb/Mp3 Control - If Equipped
342 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Uconnect™ Phone iPod control supports Mini, 4G, Photo, Nano, 5G iPod (If Equipped) and iPhone devices. Some iPod software versions may Refer to “Uconnect™ Phone” in “Understanding The not fully support the iPod control features. Please visit Features If Your Vehicle”.
Page 345: Using This Feature
UNDERSTANDING YOUR INSTRUMENT PANEL 343 NOTE: If the audio device battery is completely dis- charged, it may not communicate with the iPod /USB/ MP3 control system until a minimum charge is attained. Leaving the audio device connected to the iPod /USB/ MP3 control system may charge it to the required level.
Page 346: Controlling The Ipod Or External Usb Device Using Radio Buttons
344 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it clockwise (forward) by one click, while Controlling The iPod Or External USB Device Using Radio Buttons playing a track, skips to the next track or press the To get into the iPod /USB/MP3 control mode and access VR button and say Next Track .
Page 347: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 345 during play mode will jump to the next track in the SCAN button again. During Scan mode, pressing the list, or press the VR button and say Next or Previous << SEEK and SEEK >> buttons will select the previ- Track .
Page 348 346 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it clockwise (forward) and counterclock- • Preset 2 – Artists wise (backward) scrolls through the lists, displaying • Preset 3 – Albums the track detail on the radio display. Once the track • Preset 4 – Genres to be played is highlighted on the radio display, press the TUNE control knob to select and start •...
Page 349: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 347 device, then follow the same steps to go to the desired WARNING! track in that list. Not all iPod or external USB device sub-menu levels are available on this system. Do not plug in or remove the iPod or external USB device while driving.
Page 350: Steering Wheel Audio Controls
348 UNDERSTANDING YOUR INSTRUMENT PANEL phone system. Seven devices can be paired to the Previous Track Uconnect™ phone system, but just one can be selected Use the SEEK DOWN button, or press the VR button on and played. the radio and say “Previous Track” to jump to the previous track music on your cellular phone.
Page 351: Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 349 Pressing the center button will make the radio switch between the various modes available (AM/FM/SAT/ CD/HDD/AUX/VES, etc.). The left-hand control is a rocker-type switch with a pushbutton in the center. The function of the left-hand control is different depending on which mode you are in.
Page 352: Cd Player
350 UNDERSTANDING YOUR INSTRUMENT PANEL CD Player 2. If the disc is stained, clean the surface with a soft cloth, Pressing the top of the switch once will go to the next wiping from center to edge. track on the CD. Pressing the bottom of the switch once 3.
Page 353: Radio Operation And Mobile Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 351 RADIO OPERATION AND MOBILE PHONES Manual Heating And Air Conditioning Under certain conditions, the mobile phone being on in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the mobile phone antenna.
Page 354 352 UNDERSTANDING YOUR INSTRUMENT PANEL Blower Control NOTE: If your air conditioning performance seems Rotate this control to regulate the lower than expected, check the front of the A/C con- amount of air forced through the ven- denser located in front of the radiator for an accumula- tilation system in any mode.
Page 355 UNDERSTANDING YOUR INSTRUMENT PANEL 353 Panel Floor Air is directed through the outlets in the instrument Air is directed through the floor outlets with a panel. These outlets can be adjusted to direct airflow. small amount flowing through the defrost and side window demist outlets.
Page 356 354 UNDERSTANDING YOUR INSTRUMENT PANEL Conditioning (A/C) button is not pressed. This dehu- because of moisture buildup inside the vehicle. Select midifies the air to help dry the windshield. To improve the outside air position for maximum defogging. fuel economy, use these modes only when necessary. •...
Page 357: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 355 temperatures, while rotating right into the red area Automatic Temperature Control (ATC) — indicates warmer temperatures. If Equipped NOTE: The air conditioning compressor will not engage until the engine has been running for about 10 seconds. •...
Page 358 356 UNDERSTANDING YOUR INSTRUMENT PANEL Operation of the system is quite simple. You will experience the greatest efficiency by simply allowing the system to function automatically. Selecting 1. Turn the Mode Control knob (on the right) and the the “O” (OFF) position on the blower control stops the Blower Control knob (on the left) to AUTO.
Page 359 UNDERSTANDING YOUR INSTRUMENT PANEL 357 • If your air conditioning performance seems lower than Manual Operation expected, check the front of the A/C condenser located This system offers a full complement of manual override in front of the radiator for an accumulation of dirt or features, which consist of Blower Preferred Automatic, insects.
Page 360 358 UNDERSTANDING YOUR INSTRUMENT PANEL...
Page 361 UNDERSTANDING YOUR INSTRUMENT PANEL 359 • Floor The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and side window demist outlets.
Page 362 360 UNDERSTANDING YOUR INSTRUMENT PANEL • Air Conditioner Control NOTE: • When the ignition switch is turned to the LOCK Press this button to turn on the air conditioning during manual operation position, the recirculation feature will be cancelled. only. When the air conditioning is •...
Page 363: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 361 • Most of the time, when in Automatic Operation, you Summer Operation can temporarily put the system into Recirculation The engine cooling system in air-conditioned vehicles mode by pressing the Recirculation button. However, must be protected with a high-quality antifreeze coolant under certain conditions, while in Automatic mode, to provide proper corrosion protection and to protect the system is blowing air out the defrost vents.
Page 364 362 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Outside Air Intake Interior fogging on the windshield can be quickly re- Make sure the air intake, located directly in front of the moved by turning the mode selector to Defrost. The windshield, is free of obstructions such as leaves. Leaves Defrost/Floor mode can be used to maintain a clear collected in the air intake may reduce airflow, and if they windshield and provide sufficient heating.
Page 365 UNDERSTANDING YOUR INSTRUMENT PANEL 363 Control Setting Suggestions For Various Weather Conditions...
Page 367 STARTING AND OPERATING CONTENTS Starting Procedures ....370 Manual Transmission — If Equipped ..373 Manual Transmission –...
Page 368 366 STARTING AND OPERATING Four–Wheel Drive Operation Simultaneous Brake And Throttle (Command-Trac I Or Rock-Trac ) ..383 Operation ......394 Operating Instructions/Precautions .
Page 369 STARTING AND OPERATING 367 Brake Assist System (BAS) ....411 Tires — General Information ... . . 436 Hill Start Assist (HSA) .
Page 370 368 STARTING AND OPERATING Replacement Tires ....443 Fuel System Cautions ....455 Tire Chains .
Page 371 STARTING AND OPERATING 369 Trailer And Tongue Weight ... . . 470 Recreational Towing (Behind Motorhome, Etc.) ....478 Towing Requirements .
Page 372: Starting Procedures
370 STARTING AND OPERATING STARTING PROCEDURES Four-Wheel Drive Models Only Before starting your vehicle, adjust your seat, adjust both In 4L mode, this vehicle will start regardless of whether inside and outside mirrors, and fasten your seat belts. or not the clutch pedal is pressed to the floor. This feature enhances off-road performance by allowing the vehicle to WARNING! start when in 4L without having to press the clutch pedal.
Page 373: Extreme Cold Weather (Below -20°F Or -29°C)
STARTING AND OPERATING 371 Turn the ignition switch to the START position and If Engine Fails To Start release when the engine starts. If the engine fails to start WARNING! within 10 seconds, turn the ignition switch to the LOCK position, wait 10 to 15 seconds, then repeat the “Normal •...
Page 374 372 STARTING AND OPERATING Without Tip Start – Manual Transmission Only If the engine shows no sign of starting after two 15– If the engine fails to start after you have followed the second periods of cranking with the accelerator pedal “Normal Starting”...
Page 375: After Starting
STARTING AND OPERATING 373 CAUTION! WARNING! To prevent damage to the starter, wait 10 to 15 sec- Remember to disconnect the engine block heater onds before trying again. cord before driving. Damage to the 110-115 Volt AC electrical cord could cause electrocution. After Starting The idle speed will automatically decrease as the engine MANUAL TRANSMISSION —...
Page 376: Shifting
374 STARTING AND OPERATING CAUTION! Never drive with your foot resting on the clutch pedal, or attempt to hold the vehicle on a hill with the clutch pedal partially engaged, as this will cause abnormal wear on the clutch. NOTE: During cold weather, you may experience in- creased effort in shifting until the transmission fluid warms up.
Page 377: Downshifting
STARTING AND OPERATING 375 You should always use 1st gear when starting from a Downshifting standing position if under heavy load or when pulling a Moving from a high gear down to a lower gear is trailer. recommended to preserve brakes when driving down Recommended Vehicle Shift Speeds steep hills.
Page 378: Reverse Shifting
376 STARTING AND OPERATING Manual Transmission Downshift Speeds in MPH CAUTION! (KM/H) When descending a hill, be very careful to downshift Gear one gear at a time to prevent overspeeding the engine Selec- 6 to 5 5 to 4 4 to 3 3 to 2 2 to 1 which can cause valve damage, and/or clutch disc...
Page 379: Automatic Transmission - If Equipped
STARTING AND OPERATING 377 The “knock-over” prevents the driver from accidentally CAUTION! (Continued) entering the REVERSE shift area and warns the driver • Do not shift from REVERSE, PARK, or NEUTRAL that they are about to shift the transmission into RE- into any forward gear when the engine is above VERSE.
Page 380: Key Ignition Park Interlock
378 STARTING AND OPERATING Key Ignition Park Interlock Automatic Transmission With Overdrive This vehicle is equipped with a Key Ignition Park Inter- Shifting from DRIVE to PARK or REVERSE (or from P or lock which requires the shift lever to be placed in PARK R to D) should be done only after the accelerator pedal is prior to rotating the key to the LOCK position.
Page 381 STARTING AND OPERATING 379 Gear Ranges WARNING! NOTE: Under extreme cold temperatures (-10°F (-23°C) • Never use the PARK position as a substitute for and when in DRIVE, transmission operation may be the parking brake. Always apply the parking briefly limited to only second gear operation. Normal brake fully when parked to guard against vehicle operation will resume once the transmission temperature movement and possible injury or damage.
Page 382 380 STARTING AND OPERATING • The O/D OFF switch has not been activated. NEUTRAL This range is used when vehicle is standing for pro- • Vehicle speed is above approximately 30 mph longed periods with engine running. Engine may be (48 km/h).
Page 383 STARTING AND OPERATING 381 time restores the Overdrive function. The lockout feature is useful when towing a trailer or carrying a heavy load. If the transmission overheats, a “HOTOIL” message may be displayed in the odometer (accompanied by a chime sound).
Page 384 382 STARTING AND OPERATING CAUTION! CAUTION! • Before moving the shift lever out of PARK, you Continuing to drive with the Transmission Tempera- ture “HOTOIL” Warning Message illuminated will must turn the ignition from LOCK so the steering eventually cause severe transmission damage or wheel and shift lever are released.
Page 385: Four-Wheel Drive Operation (Command-Trac I Or Rock-Trac )
STARTING AND OPERATING 383 Transmission Limp Home Mode PARK, REVERSE, and NEUTRAL will continue to oper- Transmission function is monitored for abnormal condi- ate. Only second gear will operate in the DRIVE position. tions. If a condition is detected that could result in Have the transmission checked at your authorized dealer transmission damage, the Transmission Limp Home as soon as possible.
Page 386 384 STARTING AND OPERATING • 4H (Four-wheel drive high range) The transfer case is intended to be driven in the 2H position for normal street and highway conditions such • N (Neutral) as hard-surfaced roads. • 4L (Four-wheel drive low range) In the event that additional traction is required, the transfer case 4H and 4L positions can be used to lock the front and rear driveshafts together, forcing the front and...
Page 387: Shift Positions
STARTING AND OPERATING 385 NOTE: Do not attempt to shift when only the front or WARNING! rear wheels are spinning. The transfer case is not equipped with a synchronizer, and the front and rear You or others could be injured if you leave the driveshaft speeds must be equal for a shift to take place.
Page 388: Shifting Procedure
386 STARTING AND OPERATING 4H Position speed. This range (4L) provides additional traction and This range locks the front and rear driveshafts together, maximum pulling power for loose, slippery road surfaces forcing the front and rear wheels to rotate at the same only.
Page 389: Trac-Lok Rear Axle - If Equipped
STARTING AND OPERATING 387 4H to 4L or 4L to 4H WARNING! With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift an automatic transmission into NEUTRAL (N), or press Failure to engage a position completely can cause the clutch pedal on a manual transmission.
Page 390: Axle Lock (Tru-Lok ) - Rubicon Models
388 STARTING AND OPERATING WARNING! On vehicles equipped with a limited-slip differen- tial, never run the engine with one rear wheel off the ground. The vehicle may drive through the rear wheel remaining on the ground and cause you to lose control of your vehicle.
Page 391: Electronic Sway Bar Disconnect - If Equipped
STARTING AND OPERATING 389 To activate the system, press the bottom of the AXLE Axle lock will disengage if the vehicle is taken out of 4L LOCK switch once to lock the rear axle only (the “Rear (Low) range, or the ignition switch is turned to the OFF Axle Lock Indicator Light”...
Page 392 390 STARTING AND OPERATING This system is controlled by the SWAY BAR switch Indicator Light” will flash during activation transition, or located on the instrument panel (to the left of the steering when activation conditions are not met. The stabilizer/ column).
Page 393: On-Road Driving Tips
STARTING AND OPERATING 391 To disconnect the stabilizer/sway bar, shift to either 4H WARNING! or 4L and press the SWAY BAR switch to obtain the off-road position. Refer to “Four-Wheel Drive Operation” If the stabilizer/sway bar will not return to on-road in “Starting and Operating”...
Page 394: Off-Road Driving Tips
392 STARTING AND OPERATING An advantage of the higher ground clearance is a better view of the road, allowing you to anticipate problems. They are not designed for cornering at the same speeds as conventional two-wheel drive vehicles any more than low-slung sports cars are designed to perform satisfacto- rily in off-road conditions.
Page 395: The Basics Of Off-Road Driving
STARTING AND OPERATING 393 your vehicle’s steering, handling and traction. Control- ling your vehicle is one of the keys to successful off-road driving, so always keep a firm grip on the steering wheel and maintain a good driving posture. Avoid sudden accelerations, turns or braking.
Page 396: When To Use 4L (Low) Range
394 STARTING AND OPERATING using light brake pressure with light throttle will keep the WARNING! vehicle from jerking or lurching. This technique is also used when you need to stop and restart a vehicle on a Always wear your seat belt and firmly tie down steep incline.
Page 397 STARTING AND OPERATING 395 entering any mud hole, get out and determine how deep CAUTION! it is, if there are any hidden obstacles and if the vehicle can be safely recovered if stuck. On icy or slippery roads, do not downshift at high engine RPM or vehicle speeds, because engine brak- Sand ing may cause skidding and loss of control.
Page 398: Crossing Obstacles (Rocks And Other High Points)
396 STARTING AND OPERATING forward until it makes contact with the object. Apply the CAUTION! throttle lightly while holding a light brake pressure and ease the vehicle up and over the object. Reduced tire pressures may cause tire unseating and total loss of air pressure.
Page 399 STARTING AND OPERATING 397 Crossing Large Rocks Crossing A Ravine, Gully, Ditch, Washout Or Rut When approaching large rocks, choose a path which When crossing a ravine, gully, ditch, washout or a large ensures you drive over the largest of them with your rut, the angled approach is the key to maintaining your tires.
Page 400: Hill Climbing
398 STARTING AND OPERATING Crossing Logs and place a few rocks under the tires so the weight is off To cross a log, approach it at a slight angle (approxi- of the high point when you let the vehicle down. You can mately 10 to 15 degrees).
Page 401 STARTING AND OPERATING 399 Before Climbing A Steep Hill slightly to bring all four tires back on the ground. As you As you approach a hill, consider its grade or steepness. approach the crest of the hill, ease off the throttle and Determine if it is too steep.
Page 402 400 STARTING AND OPERATING Driving Downhill Driving Across An Incline Before driving down a steep hill, you need to determine If at all possible, avoid driving across an incline. If it is if it is too steep for a safe descent. What is the surface necessary, know your vehicle’s abilities.
Page 403: Driving Through Water
STARTING AND OPERATING 401 engine braking to control the descent and apply your designated and approved. You should tread lightly and brakes, if necessary, but do not allow the tires to lock. avoid damage to the environment. You should know your vehicle’s abilities and be able to recover it if WARNING! something goes wrong.
Page 404 402 STARTING AND OPERATING muddy waters; check for hidden obstacles. Make sure CAUTION! you will not be intruding on any wildlife, and you can • Water ingestion into the axles, transmission, trans- recover the vehicle if necessary. The key to a safe crossing is the water depth, current and bottom conditions.
Page 405: After Driving Off-Road
STARTING AND OPERATING 403 the slowest current can push the heaviest vehicle down- CAUTION! stream and out of control if the water is deep enough to push on the large surface area of the vehicle’s body. Muddy waters can reduce the cooling system effec- Before you proceed, determine the speed of the current, tiveness by depositing debris onto the radiator.
Page 406 404 STARTING AND OPERATING • After extended operation in mud, sand, water, or always a good idea to check for damage. That way you can get any problems taken care of right away and have similar dirty conditions, have the radiator, fan, brake your vehicle ready when you need it.
Page 407: Power Steering
STARTING AND OPERATING 405 • Upon initial start-up in cold weather, the power steer- POWER STEERING The standard power steering system will give you good ing pump may make noise for a short amount of time. vehicle response and increased ease of maneuverability This is due to the cold, thick fluid in the steering in tight spaces.
Page 408: Power Steering Fluid Check
406 STARTING AND OPERATING Power Steering Fluid Check WARNING! Checking the power steering fluid level at a defined service interval is not required. The fluid should only be Fluid level should be checked on a level surface and checked if a leak is suspected, abnormal noises are with the engine off to prevent injury from moving apparent, and/or the system is not functioning as antici- parts and to ensure accurate fluid level reading.
Page 409 STARTING AND OPERATING 407 The parking brake lever is located in the center console. When the parking brake is applied with the ignition To apply the parking brake, pull the lever up as firmly as switch ON, the “Brake Warning Light” in the instrument possible.
Page 410 408 STARTING AND OPERATING difficult to move the shift lever out of PARK. The parking WARNING! (Continued) brake should always be applied whenever the driver is • Be sure the parking brake is fully disengaged not in the vehicle. before driving; failure to do so can lead to brake failure and a collision.
Page 411: Anti-Lock Brake System
STARTING AND OPERATING 409 ANTI-LOCK BRAKE SYSTEM The Anti-Lock Brake System conducts a low speed self- The Anti-Lock Brake System (ABS) is designed to aid the test at about 12 mph (20 km/h). If for any reason your driver in maintaining vehicle control under adverse foot is on the brake when the vehicle reaches 12 mph braking conditions.
Page 412: Electronic Brake Control System
410 STARTING AND OPERATING WARNING! (Continued) CAUTION! • The Anti-Lock Brake System (ABS) cannot prevent The Anti-Lock Brake System is subject to possible the natural laws of physics from acting on the detrimental effects of electronic interference caused vehicle, nor can they increase braking or steering by improperly installed aftermarket radios or tele- efficiency beyond that afforded by the condition phones.
Page 413: Traction Control System (Tcs)
STARTING AND OPERATING 411 vehicle stability and control in various driving condi- pressure is applied to the slipping wheel(s) to provide tions, and are commonly referred to as ESC. enhanced acceleration and stability. A feature of the TCS system functions similar to a limited slip differential and WARNING! controls the wheel spin across a driven axle.
Page 414: Hill Start Assist (Hsa)
412 STARTING AND OPERATING quickly results in the best BAS assistance. To receive the Hill Start Assist (HSA) benefit of the system, you must apply continuous brak- The HSA system is designed to assist the driver when ing pressure during the stopping sequence. Do not starting a vehicle from a stop on a hill.
Page 415 STARTING AND OPERATING 413 • Gear selection matches vehicle uphill direction (i.e., WARNING! vehicle facing uphill is in forward gear; vehicle back- ing uphill is in REVERSE gear). If the clutch pedal (manual transmission only) re- mains pressed during the application of the throttle, WARNING! the HSA will disengage allowing the vehicle to roll down the incline.
Page 416 414 STARTING AND OPERATING HSA On Automatic Transmission Vehicles Towing With HSA The system will work in REVERSE, and all forward gears HSA will provide assistance when starting on a grade on vehicles equipped with an automatic transmission. when pulling a trailer. The system will not activate if the vehicle is placed in WARNING! NEUTRAL.
Page 417 STARTING AND OPERATING 415 HSA Off WARNING! (Continued) If you wish to turn off the HSA system, follow this • HSA is not a parking brake. If you stop the vehicle procedure: on a hill without putting the transmission in 1.
Page 418: Electronic Roll Mitigation (Erm)
416 STARTING AND OPERATING 7. If the sequence was completed properly, the “ESC driving maneuvers. It cannot prevent wheel lift due to Activation/Malfunction Indicator Light” will blink sev- other factors such as road conditions, leaving the road- eral times to confirm HSA is off. way or striking objects or other vehicles.
Page 419: Electronic Stability Control (Esc)
STARTING AND OPERATING 417 • Understeer - when the vehicle is turning less than Electronic Stability Control (ESC) appropriate for the steering wheel position. This system enhances directional control and stability of the vehicle under various driving conditions. The ESC The “ESC Activation/Malfunction Indicator Light”...
Page 420 418 STARTING AND OPERATING The ESC system has three available operating modes in WARNING! 4H range. The system has one operating mode in 4L range. Two-wheel drive vehicles and four-wheel drive The Electronic Stability Control (ESC) cannot pre- vehicles in 2H range have two operating modes. vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by 4H Range (4WD Models) Or 2WD Models...
Page 421 STARTING AND OPERATING 419 All other stability features of ESC function normally. This mode is intended to be used if the vehicle is in deep snow, sand, or gravel conditions and more wheel spin than ESC would normally allow is required to gain traction.
Page 422 420 STARTING AND OPERATING returns but TCS remains off. When the vehicle speed WARNING! drops below 35 mph (56 km/h), the ESC system shuts off. The ESC is off at low vehicle speeds in 4L range so that it With the ESC switched off, the enhanced vehicle will not interfere with off-road driving, but the ESC stability offered by ESC and ERM are unavailable.
Page 423 STARTING AND OPERATING 421 ESC and defeat the functionality of the ESC switch. WARNING! Repeating the procedure will return the system to normal ESC operation and restore ESC switch functionality al- With the ESC switched off, the enhanced vehicle lowing ESC “Partial” or “Off” modes. stability offered by ESC and ERM are unavailable.
Page 424: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
422 STARTING AND OPERATING The following procedure will disable (or re-enable) ESC 9. Turn the steering wheel back to center. functionality in the vehicle: 10. Press and hold the ESC OFF button for seven sec- 1. Shift the transfer case into the 4H range position. onds.
Page 425: Trailer Sway Control (Tsc)
STARTING AND OPERATING 423 • Each time the ignition is turned ON, the ESC system malfunction has been detected in the ESC system. If this light remains on after several ignition cycles, and the will be ON even if it was turned off previously. vehicle has been driven several miles (kilometers) at •...
Page 426: Hill Descent Control (Hdc) - If Equipped
424 STARTING AND OPERATING swaying trailer is recognized. No driver action is re- Hill Descent Control (HDC) – If Equipped quired. Note that TSC cannot stop all trailers from HDC is only intended for low speed off-road driving. swaying. Always use caution when towing a trailer and HDC maintains vehicle speed while descending hills in follow the tongue weight recommendations.
Page 427 STARTING AND OPERATING 425 2. Press the “Hill Descent” button. The “Hill Descent Gear Approximate HDC Set Control Indicator Light” in the instrument cluster will Speed turn on solid. 1 mph (1.5 km/h) 2.5 mph (4 km/h) NOTE: If the transfer case is not in 4WD LOW range, the “Hill Descent Control Indicator Light”...
Page 428: Tire Safety Information
426 STARTING AND OPERATING TIRE SAFETY INFORMATION NOTE: • P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 429 STARTING AND OPERATING 427 • High flotation tire sizing is based on U.S. design compact spare tires have the letter “T” or “S” molded into the sidewall preceding the size designation. Ex- standards, and it begins with the tire diameter molded ample: T145/80D18 103M.
Page 430 428 STARTING AND OPERATING EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 431: Tire Identification Number (Tin)
STARTING AND OPERATING 429 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 432: Tire Terminology And Definitions
430 STARTING AND OPERATING Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after the Cold Tire Inflation Pressure vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 433: Tire Loading And Tire Pressure
STARTING AND OPERATING 431 Tire Loading And Tire Pressure Tire Placard Location Tire Placard Location (Four-Door Models) Tire Placard Location (Two-Door Models)
Page 434: Starting And Operating
432 STARTING AND OPERATING Tire And Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle 4) cold tire inflation pressures for the front, rear, and spare tires.
Page 435 STARTING AND OPERATING 433 NOTE: Under a maximum loaded vehicle condition, Steps For Determining Correct Load Limit gross axle weight ratings (GAWRs) for the front and rear 1. Locate the statement “The combined weight of occu- axles must not be exceeded. For further information on pants and cargo should never exceed XXX kg or XXX lbs”...
Page 436 434 STARTING AND OPERATING 5. Determine the combined weight of luggage and cargo NOTE: • The following table shows examples on how to calcu- being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity late total load, cargo/luggage, and towing capacities calculated in Step 4.
Page 437 STARTING AND OPERATING 435...
Page 438: Tires - General Information
436 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Under-inflation increases tire flexing and can re- increase your stopping distance. Use tires of the sult in over-heating and tire failure. recommended load capacity for your vehicle.
Page 439: Tire Inflation Pressures
STARTING AND OPERATING 437 Economy CAUTION! Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal After inspecting or adjusting the tire pressure, al- wear patterns will reduce tread life resulting in a need for ways reinstall the valve stem cap.
Page 440: Tire Pressures For High-Speed Operation
438 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per Tire Pressures For High-Speed Operation 12° F (7° C) of air temperature change. Keep this in mind The manufacturer advocates driving at safe speeds when checking tire pressure inside a garage, especially in within posted speed limits.
Page 441: Radial-Ply Tires
STARTING AND OPERATING 439 Radial-Ply Tires vehicle. If your vehicle has this option refer to an authorized tire dealer for the recommended tire rotation WARNING! pattern. If your vehicle is not equipped with an original equip- Combining radial ply tires with other types of tires ment tire and wheel as a spare, a non-matching tempo- on your vehicle will cause your vehicle to handle rary emergency use spare may be equipped with your...
Page 442: Compact Spare Tire - If Equipped
440 STARTING AND OPERATING Compact Spare Tire – If Equipped WARNING! The compact spare is for temporary emergency use only. You can identify if your vehicle is equipped with a Compact spares are for temporary emergency use compact spare by looking at the spare tire description on only.
Page 443: Limited-Use Spare - If Equipped
STARTING AND OPERATING 441 your original equipment tire, replace (or repair) the WARNING! original equipment tire and reinstall on the vehicle at the first opportunity. Limited-use spares are for emergency use only. In- stallation of this limited-use spare tire affects vehicle Limited-Use Spare –...
Page 444: Tread Wear Indicators
442 STARTING AND OPERATING WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) when you are stuck, and do not let anyone near a spinning wheel no matter what the speed.
Page 445: Life Of Tire
STARTING AND OPERATING 443 Life Of Tire Replacement Tires The service life of a tire is dependent upon varying The tires on your new vehicle provide a balance of many factors including but not limited to: characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure.
Page 446 444 STARTING AND OPERATING It is recommended you contact your original equipment WARNING! (Continued) or an authorized tire dealer with any questions you may • Never use a tire with a smaller load index or have on tire specifications or capability. Failure to use capacity, other than what was originally equipped equivalent replacement tires may adversely affect the on your vehicle.
Page 447: Tire Chains
STARTING AND OPERATING 445 TIRE CHAINS CAUTION! (Continued) Tire chains may be installed on all models except the • Because of restricted chain clearance between tires Sahara and Rubicon. Install chains on rear tires only. and other suspension components, it is important Follow these recommendations to guard against damage that only chains in good condition are used.
Page 448: Tire Rotation Recommendations
446 STARTING AND OPERATING TIRE ROTATION RECOMMENDATIONS CAUTION! (Continued) The tires on the front and rear of your vehicle operate at • Observe the tire chain manufacturer’s instructions different loads and perform different steering, handling, on the method of installation, operating speed, and braking functions.
Page 449: Tire Pressure Monitor System (Tpms)
STARTING AND OPERATING 447 when the outside temperature decreases, the tire pressure will decrease. Tire pressure should always be set based on cold inflation tire pressure. This is defined as the tire pressure after a vehicle has not been driven for more than three hours, or driven less than 1 mile (1.6 km) after a three-hour period.
Page 450 448 STARTING AND OPERATING cold placard pressure. Once the “Tire Pressure Monitor- 30 psi (207 kPa), but the “Tire Pressure Monitoring ing Telltale Light” has been illuminated, the tire pressure Telltale Light” will still be ON. In this situation, the “Tire must be increased to the recommended cold placard Pressure Monitoring Telltale Light”...
Page 451: Base System
STARTING AND OPERATING 449 • The TPMS is not a substitute for proper tire mainte- CAUTION! (Continued) nance, and it is the driver’s responsibility to maintain • After inspecting or adjusting the tire pressure, correct tire pressure, even if under-inflation has not always reinstall the valve stem cap.
Page 452 450 STARTING AND OPERATING The Tire Pressure Monitor System (TPMS) consists of the inflation pressure of each tire on your vehicle, and inflate following components: each tire to the vehicle’s recommended cold placard pressure value. The system will automatically update •...
Page 453 STARTING AND OPERATING 451 2. Installing some form of aftermarket window tinting OFF the “Tire Pressure Monitoring Telltale Light” as that affects radio wave signals. long as none of the road tires are below the low pressure warning threshold. 3. Lots of snow or ice around the wheels or wheel •...
Page 454: General Information
452 STARTING AND OPERATING vehicle in place of the spare tire, the TPMS will update The tire pressure sensors are covered under one of the automatically and the “Tire Pressure Monitoring Tell- following licenses: tale Light” will turn OFF, as long as no tire pressure is below the low-pressure warning limit in any of the United States .
Page 455: Reformulated Gasoline
STARTING AND OPERATING 453 Poor quality gasoline can cause problems such as hard The manufacturer supports the use of reformulated gaso- starting, stalling and hesitations. If you experience these line. Properly blended reformulated gasoline will pro- symptoms, try another brand of gasoline before consid- vide excellent performance and durability for the engine ering service for the vehicle.
Page 456: E-85 Usage In Non-Flex Fuel Vehicles
454 STARTING AND OPERATING Problems that result from using gasoline containing To fix a Non-FFV vehicle inadvertently fueled once with Methanol or gasoline containing more than 10% Ethanol E-85 perform the following: are not the responsibility of the manufacturer and may •...
Page 457: Materials Added To Fuel
STARTING AND OPERATING 455 vehicle. The MMT content of gasoline may not be indi- Fuel System Cautions cated on the gasoline pump, therefore, you should ask CAUTION! your gasoline retailer if the gasoline contains MMT. It is even more important to look for gasoline without Follow these guidelines to maintain your vehicle’s MMT in Canada, because MMT can be used at levels performance:...
Page 458: Carbon Monoxide Warnings
456 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives which are now being WARNING! sold as octane enhancers is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Most of these products contain high concentra- Follow the precautions below to prevent carbon tions of methanol.
Page 459: Adding Fuel
STARTING AND OPERATING 457 ADDING FUEL WARNING! (Continued) Fuel Filler Cap (Gas Cap) • Guard against carbon monoxide with proper The gas cap is located on the driver’s side of the vehicle. maintenance. Have the exhaust system inspected If the gas cap is lost or damaged, be sure the replacement every time the vehicle is raised.
Page 460 458 STARTING AND OPERATING CAUTION! WARNING! (Continued) • Never add fuel when the engine is running. This is • Damage to the fuel system or emission control in violation of most state and federal fire regula- system could result from using an improper fuel tions and may cause the MIL to turn on.
Page 461: Loose Fuel Filler Cap Message
STARTING AND OPERATING 459 Loose Fuel Filler Cap Message This label contains the month and year of manufacture, After fuel has been added, the vehicle diagnostic system Gross Vehicle Weight Rating (GVWR), Gross Axle Weight can determine if the fuel filler cap is possibly loose, Rating (GAWR) front and rear, and Vehicle Identification improperly installed, or damaged.
Page 462 460 STARTING AND OPERATING Payload Rim Size The payload of a vehicle is defined as the allowable load This is the rim size that is appropriate for the tire size weight a truck or any given vehicle can carry, including listed.
Page 463: Trailer Towing
STARTING AND OPERATING 461 The entire vehicle should first be weighed on a commer- CAUTION! cial scale to ensure that the GVWR has not been ex- ceeded. The weight on the front and rear of the vehicle Do not load your vehicle any heavier than the GVWR should then be determined separately to be sure that the or the maximum front and rear GAWR.
Page 464: Common Towing Definitions
462 STARTING AND OPERATING Common Towing Definitions Gross Combination Weight Rating (GCWR) The following trailer towing-related definitions will as- The GCWR is the total permissible weight of your vehicle sist you in understanding the following information: and trailer when weighed in combination. Gross Vehicle Weight Rating (GVWR) NOTE: The GCWR rating includes a 150 lbs (68 kg) The GVWR is the total allowable weight of your vehicle.
Page 465 STARTING AND OPERATING 463 Trailer Tongue Weight (TW) hitch is the most popular on the market today and is The trailer tongue weight is the downward force exerted commonly used to tow small and medium-sized trailers. on the hitch ball by the trailer. In most cases it should not Weight-Distributing Hitch be less than 10% or more than 15% of the trailer load.
Page 466: Trailer Hitch Classification
464 STARTING AND OPERATING Trailer Hitch Classification Definitions WARNING! Class Max. Trailer Hitch Industry • An improperly adjusted weight-distributing hitch Standards system may reduce handling, stability, braking Class I - Light Duty 2,000 lbs (907 kg) performance, and could result in a collision. Class II - Medium 3,500 lbs (1 587 kg) •...
Page 467: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 465 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/ Axle Model GCWR (Gross Frontal Area Max. GTW Max. Trailer Transmis- Combined Wt. (Gross Trailer Tongue Wt.
Page 468 466 STARTING AND OPERATING Engine/ Axle Model GCWR (Gross Frontal Area Max. GTW Max. Trailer Transmis- Combined Wt. (Gross Trailer Tongue Wt. sion Rating) Wt.) (See Note) 3.8L/ 3.21 Two–Door 5,430 lbs (2 463 kg) 25 sq ft (2.32 sq m) 1,000 lbs (453 kg) 100 lbs (45 kg) Manual Sahara Model...
Page 469 STARTING AND OPERATING 467 Engine/ Axle Model GCWR (Gross Frontal Area Max. GTW Max. Trailer Transmis- Combined Wt. (Gross Trailer Tongue Wt. sion Rating) Wt.) (See Note) 3.8L/ 4.10 Two–Door 6,533 lbs (2 963 kg) 25 sq ft (2.32 sq m) 2,000 lbs (907 kg) 200 lbs (91 kg) Auto- Rubicon matic...
Page 470 468 STARTING AND OPERATING Engine/ Axle Model GCWR (Gross Frontal Area Max. GTW Max. Trailer Transmis- Combined Wt. (Gross Trailer Tongue Wt. sion Rating) Wt.) (See Note) 3.8L/ 3.21 Four–Door 5,782 lbs (2 623 kg) 32 sq ft (2.97 sq m) 1,000 lbs (453 kg) 100 lbs (45 kg) Manual Sahara Model...
Page 471 STARTING AND OPERATING 469 Engine/ Axle Model GCWR (Gross Frontal Area Max. GTW Max. Trailer Transmis- Combined Wt. (Gross Trailer Tongue Wt. sion Rating) Wt.) (See Note) 3.8L/ 4.10 Four–Door 8,406 lbs (3 813 kg) 32 sq ft (2.97 sq m) 3,500 lbs 350 lbs Manual...
Page 472: Trailer And Tongue Weight
470 STARTING AND OPERATING Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 473: Towing Requirements
STARTING AND OPERATING 471 NOTE: Remember that everything put into or on the CAUTION! trailer adds to the load on your vehicle. Also, additional • Do not tow a trailer at all during the first 500 miles factory-installed options, or authorized dealer-installed options, must be considered as part of the total load on (805 km) the new vehicle is driven.
Page 474 472 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Make certain that the load is secured in the trailer • Vehicles with trailers should not be parked on a and will not shift during travel. When trailering grade. When parking, apply the parking brake on cargo that is not fully secured, dynamic load shifts the tow vehicle.
Page 475 STARTING AND OPERATING 473 − When replacing tires, refer to “Tires – General Infor- WARNING! (Continued) mation” in “Starting and Operating” for information 4. Tongue weight rating for the trailer hitch utilized on replacement tires and for proper tire replacement (This requirement may limit the ability to always procedures.
Page 476 474 STARTING AND OPERATING − Trailer brakes are recommended for trailers over WARNING! 1,000 lbs (454 kg) and required for trailers in excess of • Do not connect trailer brakes to your vehicle’s 2,000 lbs (907 kg). hydraulic brake lines. It can overload your brake CAUTION! system and cause it to fail.
Page 477 STARTING AND OPERATING 475 The Trailer Tow Package will include a four–pin wiring harness. Use a factory-approved trailer harness and connector. NOTE: Do not cut or splice wiring into the vehicles wiring harness. The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector.
Page 478: Towing Tips
476 STARTING AND OPERATING Towing Tips The automatic transmission fluid and filter should be Before setting out on a trip, practice turning, stopping changed if you REGULARLY tow a trailer for more than and backing the trailer in an area away from heavy 45 minutes of continuous operation.
Page 479 STARTING AND OPERATING 477 Electronic Speed Control – If Equipped Cooling System To reduce potential for engine and transmission over- − Do not use in hilly terrain or with heavy loads. heating, take the following actions: − When using the speed control, if you experience speed −...
Page 480: Starting And Operating
478 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Four-Wheel Drive Models Ground See Instructions • Automatic transmission in PARK • Manual transmission in gear Flat Tow NONE (NOT in NEUTRAL (N) •...
Page 481: Recreational Towing - Four-Wheel Drive Models
STARTING AND OPERATING 479 Recreational Towing – Four-Wheel Drive Models CAUTION! (Continued) NOTE: The transfer case must be shifted into N (Neu- • Manual transmissions must be placed in gear (not tral), automatic transmission must be shifted into PARK, in Neutral) for recreational towing. and manual transmission must be placed in gear (NOT in •...
Page 482 480 STARTING AND OPERATING Shifting Into Neutral (N) CAUTION! Use the following procedure to prepare your vehicle for recreational towing. It is necessary to follow these steps to be certain that the transfer case is fully in N (Neutral) before recre- WARNING! ational towing to prevent damage to internal parts.
Page 483 STARTING AND OPERATING 481 8. Release the brake pedal (and clutch pedal on manual 13. Attach the vehicle to the tow vehicle using a suitable transmissions) for five seconds and ensure that there is tow bar. no vehicle movement. 14. Release the parking brake. 9.
Page 484 482 STARTING AND OPERATING 5. Turn the ignition key/fob to the ON/RUN position, 10. Release the brake pedal. but do not start the engine. 11. Disconnect vehicle from the tow vehicle. 6. Press and hold the brake pedal. 12. Start the engine. 7.
Page 485: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....484 Jump-Starting Procedure ....493 If Your Engine Overheats .
Page 486: Hazard Warning Flashers
484 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel below the climate controls. potential for overheating by taking the appropriate ac- tion.
Page 487: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES 485 NOTE: There are steps that you can take to slow down JACKING AND TIRE CHANGING an impending overheat condition: WARNING! • If your air conditioner (A/C) is on, turn it off. The A/C • Do not attempt to change a tire on the side of the system adds heat to the engine cooling system and turning the A/C off can help remove this heat.
Page 488: Jack Location
486 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
Page 489: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 487 NOTE: If you have added aftermarket accessories to the 4. Shift the automatic transmission into PARK, or a spare tire mounted carrier, it cannot exceed a gross manual transmission into REVERSE. weight of 50 lbs (23 kg) including the weight of the spare 5.
Page 490: Jacking Instructions
488 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. Carefully follow these tire changing warnings to • Do not get under the vehicle when it is on a jack. help prevent personal injury or damage to your •...
Page 491 WHAT TO DO IN EMERGENCIES 489 CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. 1. Remove the spare tire, jack and tools from the stored location.
Page 492 490 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable and cause a collision. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6.
Page 493: Jump-Starting Procedures
WHAT TO DO IN EMERGENCIES 491 8. Lower the vehicle by turning the jack screw to the left, WARNING! and remove the jack. A loose tire or jack, thrown forward in a collision or 9. Finish tightening the lug nuts. Push down on the hard stop, could endanger the occupants of the ve- wrench while tightening for increased leverage.
Page 494: Preparations For Jump-Start
492 WHAT TO DO IN EMERGENCIES Preparations For Jump-Start CAUTION! The battery in your vehicle is located in the right rear of the engine compartment, behind the Power Distribution Do not use a portable battery booster pack or any Center. other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur.
Page 495: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 493 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
Page 496 494 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 497: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 495 8. Disconnect the opposite end of the positive (+) jumper FREEING A STUCK VEHICLE cable from the positive (+) post of the booster battery. If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion.
Page 498: Emergency Tow Hooks - If Equipped
496 WHAT TO DO IN EMERGENCIES NOTE: If your vehicle is equipped with Traction Con- WARNING! trol or Electronic Stability Control (ESC), turn the system OFF before attempting to “rock” the vehicle. Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause damage, or CAUTION! even failure, of the axle and tires.
Page 499: Shift Lever Override
WHAT TO DO IN EMERGENCIES 497 SHIFT LEVER OVERRIDE WARNING! If a malfunction occurs and the shift lever cannot be • Chains are not recommended for freeing a stuck moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: vehicle.
Page 500: Towing A Disabled Vehicle
498 WHAT TO DO IN EMERGENCIES 3. Using a screwdriver or similar tool, carefully remove 5. Using the screwdriver or similar tool, reach into the the shift lever override access cover, located on the opening and press and hold the shift lever override. PRNDL bezel.
Page 501 WHAT TO DO IN EMERGENCIES 499 Towing Condition Wheels OFF the Ground 4WD MODELS See instructions under “Recreational Towing” • Automatic Transmission in PARK • Manual Transmission in gear ( NOT in Neutral) Flat Tow NONE • Transfer Case in NEUTRAL •...
Page 502: Towing Without The Ignition Key Fob
500 WHAT TO DO IN EMERGENCIES Towing Without The Ignition Key Fob CAUTION! Special care must be taken when the vehicle is towed • Do not attempt to use sling type equipment when with the ignition in the LOCK/OFF position. The only approved method of towing without the ignition key is towing.
Page 503 WHAT TO DO IN EMERGENCIES 501 If flatbed equipment is not available and the transfer case CAUTION! is operable, the vehicle may be towed (in the forward • Front or rear wheel lifts should not be used. direction, with ALL wheels on the ground), IF the transfer case is in NEUTRAL and the transmission is in Internal damage to the transmission or transfer PARK (for automatic transmissions) or in gear ( NOT in...
Page 505: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.8L ... . . 505 Engine Oil Filter ..... 512 Onboard Diagnostic System —...
Page 506 504 MAINTAINING YOUR VEHICLE Brake System ..... . . 525 Bulb Replacement ..... 546 Automatic Transmission –...
Page 507: Engine Compartment - 3.8L
MAINTAINING YOUR VEHICLE 505 ENGINE COMPARTMENT — 3.8L 1 — Integrated Power Module (Fuses) 7 — Engine Coolant Reservoir 2 — Battery 8 — Engine Oil Fill 3 — Automatic Transmission Dipstick 9 — Air Cleaner Filter 4 — Engine Oil Dipstick 10 —...
Page 508: Onboard Diagnostic System - Obd Ii
506 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
Page 509: Emissions Inspection And Maintenance Programs
MAINTAINING YOUR VEHICLE 507 the message will appear the next time the vehicle is Normally, the OBD II system will be ready. The OBD II started. This might indicate a damaged cap. If the prob- system may not be ready if your vehicle was recently lem is detected twice in a row, the system will turn on the serviced, recently had a dead battery or a battery replace- MIL.
Page 510: Replacement Parts
508 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.
Page 511: Dealer Service
MAINTAINING YOUR VEHICLE 509 DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 512: Engine Oil
510 MAINTAINING YOUR VEHICLE Checking the oil while the vehicle is on level ground will CAUTION! (Continued) improve the accuracy of the oil level readings. Always • Your vehicle has been built with improved fluids maintain the oil level within the SAFE zone on the that protect the performance and durability of dipstick.
Page 513 MAINTAINING YOUR VEHICLE 511 Engine Oil Selection CAUTION! For best performance and maximum protection for all engines under all types of operating conditions, the Do not use chemical flushes in your engine oil as the manufacturer recommends engine oils that are API Cer- chemicals can damage your engine.
Page 514: Engine Oil Filter
512 MAINTAINING YOUR VEHICLE Synthetic Engine Oils Engine Oil Filter Synthetic engine oils can be used if the recommended oil The engine oil filter should be replaced with a new filter quality requirements are met, and the recommended at every engine oil change. maintenance intervals for oil and filter changes are Engine Oil Filter Selection followed.
Page 515: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 513 WARNING! WARNING! • Battery fluid is a corrosive acid solution and can The air cleaner can provide protection in the case of engine backfire. Do not remove the air cleaner unless burn or even blind you. Do not allow battery fluid it is necessary for repair or maintenance.
Page 516: Air Conditioner Maintenance
514 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance CAUTION! For best possible performance, your air conditioner • It is essential when replacing the cables on the should be checked and serviced by an authorized dealer at the start of each warm season. This service should battery that the positive cable is attached to the include cleaning of the condenser fins and a performance positive post and the negative cable is attached to...
Page 517: Body Lubrication
MAINTAINING YOUR VEHICLE 515 Refrigerant Recovery And Recycling WARNING! R-134a Air Conditioning Refrigerant is a hydrofluoro- • Use only refrigerants and compressor lubricants carbon (HFC) that is endorsed by the Environmental Protection Agency (EPA) and is an ozone-saving product. approved by the manufacturer for your air condi- However, the manufacturer recommends that air condi- tioning system.
Page 518: Windshield Wiper Blades
516 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. remove frost or ice from the windshield. Keep the blade When performing other underhood services, the hood rubber out of contact with petroleum products such as latch, release mechanism and safety catch should be engine oil, gasoline, etc.
Page 519: Exhaust System
MAINTAINING YOUR VEHICLE 517 some washer fluid and apply it to a cloth or towel and Exhaust System wipe clean the wiper blades; this will help blade perfor- The best protection against carbon monoxide entry into mance. the vehicle body is a properly maintained engine exhaust system.
Page 520 518 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Exhaust gases can injure or kill. They contain • The catalytic converter requires the use of un- carbon monoxide (CO), which is colorless and leaded fuel only. Leaded gasoline will destroy the odorless. Breathing it can make you unconscious effectiveness of the catalyst as an emissions con- and can eventually poison you.
Page 521 MAINTAINING YOUR VEHICLE 519 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 522: Cooling System
520 MAINTAINING YOUR VEHICLE Cooling System equipped) or radiator for any accumulation of bugs, leaves, etc. If dirty, clean by gently spraying water from a WARNING! garden hose vertically down the face of the A/C con- denser (if equipped) or the back of the radiator core. You or others can be badly burned by hot engine Check the engine cooling system hoses for brittle rubber, coolant (antifreeze) or steam from your radiator.
Page 523 MAINTAINING YOUR VEHICLE 521 Cooling System – Drain, Flush, And Refill CAUTION! If the engine coolant (antifreeze) is dirty and contains a • Mixing of engine coolant (antifreeze) other than considerable amount of sediment, clean and flush with reliable cooling system cleaner. Follow with a thorough the specified HOAT engine coolant (antifreeze) rinsing to remove all deposits and chemicals.
Page 524 522 MAINTAINING YOUR VEHICLE Please review these recommendations for using Hybrid CAUTION! (Continued) Organic Additive Technology (HOAT) engine coolant • This vehicle has not been designed for use with (antifreeze). When adding engine coolant (antifreeze): Propylene Glycol based engine coolant (anti- •...
Page 525 MAINTAINING YOUR VEHICLE 523 Please note that it is the owner’s responsibility to main- WARNING! tain the proper level of protection against freezing ac- cording to the temperatures occurring in the area where The warning words DO NOT OPEN HOT on the the vehicle is operated.
Page 526 524 MAINTAINING YOUR VEHICLE to remain in puddles on the ground. If ingested by a child When additional engine coolant (antifreeze) is needed to or pet, seek emergency assistance immediately. Clean up maintain the proper level, it should be added to the any ground spills immediately.
Page 527: Brake System
MAINTAINING YOUR VEHICLE 525 • Do not change the thermostat for Summer or Winter engine coolant (antifreeze) needs to be added, the contents of the coolant recovery bottle must also be operation. If replacement is ever necessary, install protected against freezing. ONLY the correct type thermostat.
Page 528 526 MAINTAINING YOUR VEHICLE Power Disc Brakes WARNING! Disc brakes do not require adjustment; however, several • Use only manufacturer’s recommended brake hard stops during the break-in period are recommended to seat the linings and wear off any foreign material. fluid.
Page 529: Automatic Transmission - If Equipped
MAINTAINING YOUR VEHICLE 527 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contami- moisture, use only new brake fluid or fluid that nate the brake fluid. Brake seal components could has been in a tightly closed container.
Page 530 528 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! Using a transmission fluid other than the manufac- Do not use chemical flushes in your transmission as turer’s recommended fluid may cause deterioration the chemicals can damage your transmission compo- in transmission shift quality and/or torque converter nents.
Page 531 MAINTAINING YOUR VEHICLE 529 3. Fully apply the parking brake. the fluid at approximately 70° F (21° C) (room tempera- ture). If the fluid level is correctly established at room 4. Place the shift lever momentarily into each gear posi- temperature, it should be between the HOT (upper) tion ending with the shift lever in PARK.
Page 532: Hydraulic Clutch Fluid - Manual Transmission
530 MAINTAINING YOUR VEHICLE normal for the dipstick cap to spring back slightly from Fluid Level Check its fully seated position, as long as its seal remains Check the fluid level by removing the fill plug. The fluid engaged in the dipstick tube. level should be between the bottom of the fill hole and a point not more than 3/16 in (4.76 mm) below the bottom Hydraulic Clutch Fluid –...
Page 533: Transfer Case
MAINTAINING YOUR VEHICLE 531 Transfer Case Drain First remove the fill plug (B), then the drain plug (C). The Fluid Level Check recommended tightening torque for the drain and fill The fluid level should be to the bottom edge of the fill plugs is 15 to 25 ft lbs (20 to 34 N·m).
Page 534: Appearance Care And Protection From Corrosion
532 MAINTAINING YOUR VEHICLE fluid level. Refer to “Fluids, Lubricants, and Genuine trees and road surfaces during other seasons, are highly Parts” in “Maintaining Your Vehicle” for further informa- corrosive to the metal in your vehicle. Outside parking, tion. which exposes your vehicle to airborne contaminants, road surfaces on which the vehicle is operated, extreme Fluid Level Check hot or cold weather and other extreme conditions will...
Page 535 MAINTAINING YOUR VEHICLE 533 • Insects, tree sap and tar. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint • Salt in the air near sea-coast localities. finish. • Atmospheric fallout/industrial pollutants. CAUTION! •...
Page 536 534 MAINTAINING YOUR VEHICLE • It is important that the drain holes in the lower edges • Use MOPAR Touch-Up Paint or equivalent on of the doors, rocker panels and tailgate are kept clear scratches or chips as soon as possible. Your authorized and open.
Page 537 MAINTAINING YOUR VEHICLE 535 Interior Care CAUTION! Use MOPAR Total Clean or equivalent to clean fabric upholstery and carpeting. When installing hanging air fresheners in your ve- hicle, read the installation instructions carefully. Interior Trim should be cleaned starting with a damp Some air fresheners will damage the finish of cloth, a damp cloth with MOPAR Total Clean or equiva- painted or decorated parts if allowed to directly...
Page 538 536 MAINTAINING YOUR VEHICLE Cleaning Plastic Instrument Cluster Lenses Replace the belts if they appear frayed or worn or if the The lenses in front of the instruments in this vehicle are buckles do not work properly. molded in clear plastic. When cleaning the lenses, care Appearance Care For Fabric Top Models must be taken to avoid scratching the plastic.
Page 539 MAINTAINING YOUR VEHICLE 537 • Be especially careful when washing the windows by CAUTION! (Continued) following the directions for “Care of Fabric Top • Avoid high-pressure car washes, as they can dam- Windows.” age the top material. Also, increased water pres- WASHING —...
Page 540 MOPAR Jeep Soft Glass Window should be cleaned and lubricated regularly. Use Cleaner or equivalent will safely clean all plastic win-...
Page 541: Fuses
MAINTAINING YOUR VEHICLE 539 zipper teeth. If a stuck zipper slide is experienced, work the MOPAR Soft Top Zipper Cleaner and Lubricant or equivalent into the zipper slide. Several applications may be required before the zipper comes free. 6. Never paste stickers, gummed labels or any tape to the windows.
Page 542 540 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 25 Amp Driver Door Node 30 Amp Headlamp Wash Natural Pink Relay/Manifold Tun- ing Valve 25 Amp Passenger Door Node Natural 30 Amp Sway Bar Pink 40 Amp Anti-Lock Brake Sys-...
Page 543 MAINTAINING YOUR VEHICLE 541 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 60 Amp Radiator Fan — — Yellow 25 Amp Power Inverter – If 30 Amp Front Wiper LO/HI Natural Equipped Pink 20 Amp Power Outlet #1/Rain 20 Amp Front/Rear Washer Yellow...
Page 544 542 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 15 Amp Ignition Off Draw – 20 Amp Ignition Off Draw – Blue Vehicle Entertainment Yellow Cabin Compartment System, Satellite Digi- Node, Wireless Con- tal Audio Receiver trol Module, SIREN, (SDARS), DVD,...
Page 545 MAINTAINING YOUR VEHICLE 543 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 10 Amp Airbag Module 10 Amp Left Horn (HI/LOW) 15 Amp Left Tail/License/ 25 Amp Rear Wiper Blue Park Lamp Natural 15 Amp Right Tail/Park/Run 20 Amp Fuel Pump, Diesel Blue...
Page 546 544 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 20 Amp Backup Lamps 10 Amp Anti-Lock Brake Sys- Yellow tem, Electronic Stabil- ity Control, Stop 10 Amp Airbag Controller, TT Lamp Switch, Fuel EUROPE Pump Relay 10 Amp...
Page 547: Vehicle Storage
MAINTAINING YOUR VEHICLE 545 • Anytime you store your vehicle, or keep it out of CAUTION! (Continued) service (i.e., vacation) for two weeks or more, run the • When replacing a blown fuse, it is important to air conditioning system at idle for about five minutes use only a fuse having the correct amperage rating.
Page 548: Bulb Replacement
546 MAINTAINING YOUR VEHICLE conditions change to allow the condensation to change Exterior Lights Bulb Type back into a vapor. Turning the lamps on will usually Backup Lamps (2) ..... . . 3157 accelerate the clearing process.
Page 549: Front Park/Turn Signal
MAINTAINING YOUR VEHICLE 547 8. Pull the bulb from the housing. 2. Pull the bottom of the grille away starting at one side and working toward the other. 9. Push connector locking tab to the unlock position. 3. Turn the socket assembly 1/4 turn counterclockwise 10.
Page 550: Rear Tail, Stop, Turn Signal, And Backup Lamp
548 MAINTAINING YOUR VEHICLE 3. Firmly grasp the bulb by the two latch features and squeeze them together to unlock the bulb from the back of the front fog lamp housing. 4. Pull the bulb straight out from the keyed opening in the housing and then connect the replacement bulb.
Page 551: Center High-Mounted Stop Lamp (Chmsl)
MAINTAINING YOUR VEHICLE 549 Center High-Mounted Stop Lamp (CHMSL) 2. Remove the four screws holding the lens/cover in The stop lamp is mounted on a bracket that extends place on the spare tire carrier. upward from the tailgate behind the spare tire. If service 3.
Page 552: Fluids, Lubricants And Genuine Parts
550 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. Engine Oil Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 553: Chassis
MAINTAINING YOUR VEHICLE 551 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission – If MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Equipped ATF+4 product. Manual Transmission – If MOPAR Manual Transmission Lubricant or equivalent (meeting the re- Equipped quirements of Chrysler Material Standard MS-9224).
Page 555 MAINTENANCE SCHEDULES CONTENTS Maintenance Schedule ....554 Required Maintenance Intervals ..555...
Page 556 554 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE NOTE: • The oil change indicator message will not monitor the The Scheduled Maintenance services listed in this manual must be done at the times or mileages specified time since the last oil change. Change your vehicle’s to protect your vehicle warranty and ensure the best oil if it has been six months since your last oil change vehicle performance and reliability.
Page 557 MAINTENANCE SCHEDULES 555 • Check all lights and other electrical items for correct At Each Stop For Fuel operation. • Check the engine oil level about five minutes after a fully warmed engine is shut off. Checking the oil level At Each Oil Change while the vehicle is on level ground will improve the •...
Page 558 556 MAINTENANCE SCHEDULES 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 559: Service Schedule
MAINTENANCE SCHEDULES 557 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 560 558 MAINTENANCE SCHEDULES 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 561 MAINTENANCE SCHEDULES 559 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). ❏...
Page 562 560 MAINTENANCE SCHEDULES 64,000 Miles (104,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64,000 miles (104 000 km). ❏...
Page 563 MAINTENANCE SCHEDULES 561 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 564 562 MAINTENANCE SCHEDULES 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). ❏...
Page 565 MAINTENANCE SCHEDULES 563 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
Page 566 564 MAINTENANCE SCHEDULES 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 567 MAINTENANCE SCHEDULES 565 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
Page 568 566 MAINTENANCE SCHEDULES 128,000 Miles (208,000 km) or 96 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 128,000 miles (208 000 km). ❏...
Page 569 MAINTENANCE SCHEDULES 567 136,000 Miles (221,000 km) or 144,000 Miles (234,000 km) or 108 Months Maintenance Service 102 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 570 568 MAINTENANCE SCHEDULES 152,000 Miles (247,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 152,000 miles (247 000 km). ❏...
Page 571 MAINTENANCE SCHEDULES 569 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 573: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Customer Assistance For The Hearing Or Vehicle......573 Speech Impaired (TDD/TTY) .
Page 574 572 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....577 Traction Grades ..... 579 Department Of Transportation Uniform Tire Temperature Grades .
Page 575: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 573 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 576: Chrysler Group Llc Customer Center
574 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (877) 426–5337 •...
Page 577: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 575 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 578: Warranty Information
576 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 579: In Canada
IF YOU NEED CONSUMER ASSISTANCE 577 If NHTSA receives similar complaints, it may open an In Canada investigation, and if it finds that a safety defect exists in If you believe that your vehicle has a safety defect, you a group of vehicles, it may order a recall and remedy should contact the Customer Service Department imme- campaign.
Page 580 578 IF YOU NEED CONSUMER ASSISTANCE • Service Manuals • Owner’s Manuals These comprehensive Service Manuals provide the These Owner’s Manuals have been prepared with the information that students and professional technicians assistance of service and engineering specialists to need in diagnosing/troubleshooting, problem solving, acquaint you with specific Chrysler Group LLC ve- maintaining, servicing, and repairing Chrysler Group hicles.
Page 581: Traction Grades
IF YOU NEED CONSUMER ASSISTANCE 579 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 582 580 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 583 INDEX...
Page 584 582 INDEX ABS (Anti-Lock Brake System) ... . 269,409 Alarm Light ......271 Adding Engine Coolant (Antifreeze) .
Page 585 INDEX 583 Special Additives ..... 528 Bulb Replacement ..... 545,546 Torque Converter .
Page 586 584 INDEX Check Engine Light Console ......169 (Malfunction Indicator Light) ... . . 277,507 Console, Floor .
Page 587 INDEX 585 Data Recorder, Event ..... . 70 Driver’s Seat Back Tilt ....137 Daytime Running Lights .
Page 588 586 INDEX Emergency Brake ......406 Oil Change Interval ....289 Emergency, In Case of Oil Disposal .
Page 589 INDEX 587 Fabric Care ......535,536 Fog Light Service ......547 Fabric Top .
Page 590 588 INDEX Requirements ..... . . 549 Gross Vehicle Weight Rating ... . . 459,462 Tank Capacity .
Page 591 INDEX 589 Hill Descent Control ..... 424 Instrument Panel and Controls ....264 Hill Descent Control Indicator .
Page 592 590 INDEX Keys ....... . . 14 Brake Warning ..... . 268 Bulb Replacement .
Page 593 INDEX 591 Instrument Cluster ....150 Loading Vehicle ......459 Interior .
Page 594 592 INDEX Shift Speeds ......375 Occupant Restraints ..... . . 43 Manual, Service .
Page 595 INDEX 593 Onboard Diagnostic System ....506,507 Power Operator Manual (Owner’s Manual) ... . 6 Door Locks .
Page 596 594 INDEX Rearview Mirrors ......96 Reporting Safety Defects ....576 Recorder, Event Data .
Page 597 INDEX 595 Child Restraint ..... 71,81 Security Against Theft ..... 18 Extender .
Page 598 596 INDEX Shoulder Belt Upper Anchorage ....53 Remote ......26 Shoulder Belts .
Page 599 INDEX 597 Tachometer ......270 Inflation Pressures ....437 Temperature Control, Automatic (ATC) .
Page 600 598 INDEX Towing ......461,498 Transfer Case ......531 24-Hour Towing Assistance .
Page 601 INDEX 599 UCI Connector ......342 Warranty Information ..... 576 Uconnect™...
Page 602 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 603 Chrysler Group LLC 11JK72-126-AF Sixth Edition Printing in U.S.A.

Save PDF
