The slots are color coded to indicate which slots to use to install different quantities
of DIMMs.
4 DIMMs: Blue slots
■
8 DIMMs: White and blue slots
■
16 DIMMs: Black, white, and blue slots
■
The following table summarizes details on using each of the 16 DIMM slots.
DIMM
*
Location Slot Color
1 Blue
2 Black
3 White
4 Black
5 Black
6 White
7 Black
8 Blue
9 Blue
10 Black
11 White
12 Black
13 Black
14 White
15 Black
16 Blue
* From top to bottom when viewed with the front panel of the server module on your left.
Related Information
"Memory Faults" on page 69
■
"Locate a Faulty DIMM (LEDs)" on page 70
■
"Remove a DIMM" on page 73
■
"Install a Replacement DIMM" on page 74
■
Slot Is Used For
This Quantity of FRU Name (all start with
DIMMs
/SYS/MB/CMP0/)
4, 8, 16
BOB0/CH1/D0
16
BOB0/CH1/D1
8, 16
BOB0/CH0/D0
16
BOB0/CH0/D1
16
BOB1/CH0/D1
8, 16
BOB1/CH0/D0
16
BOB1/CH1/D1
4, 8, 16
BOB1/CH1/D0
4, 8, 16
BOB3/CH1/D0
16
BOB3/CH1/D1
8, 16
BOB3/CH0/D0
16
BOB3/CH0/D1
16
BOB2/CH0/D1
8, 16
BOB2/CH0/D0
16
BOB2/CH1/D1
4, 8, 16
BOB2/CH1/D0
