2. Slide the cover forward until it latches into place (panel 2).
3. Install the server module into the modular system chassis.
See
Related Information
"Install the Server Module Into the Modular System" on page 112
■
"Remove the Cover" on page 62
■
▼ Install the Server Module Into the
Modular System
Caution – Insert a filler panel into an empty modular system slot within 60 seconds
of server module removal to ensure proper chassis cooling.
Caution – Hold the server module firmly with both hands so that you do not drop
it. The server module weighs approximately 17 pounds (8.0 kg).
1. Remove the rear connector cover from the server module before inserting it in
the modular system.
112
SPARC T3-1B Server Module Service Manual • July 2012
"Install the Server Module Into the Modular System" on page
112.
