10. Transfer the USB flash drive (if present) from the original server module to the
enclosure assembly.
Ensure that you install a USB flash drive only in the top slot of the connector. See
"Servicing a USB Flash Drive" on page
Note – Do not move the battery from the original server module. The replacement
enclosure assembly includes a battery.
11. Attach the cover to the enclosure assembly.
See "Replace the Cover" on page
12. Insert the completed enclosure assembly in the same slot as the original server
module.
See "Install the Server Module Into the Modular System" on page
13. Start the server module host.
See "Start the Server Module Host" on page 114
14. Access Oracle ILOM on the SP.
See "Access the SP (Oracle ILOM)" on page
If the replacement service processor detects that the service processor firmware is
not compatible with the existing host firmware, further action is suspended and
the following message is displayed:
Unrecognized Chassis: This module is installed in an unknown or
unsupported chassis. You must upgrade the firmware to a newer
version that supports this chassis.
If you see this message, go to
15. Download the system firmware.
Refer to the Oracle ILOM documentation for instructions.
16. Perform diagnostics to verify the proper operation of the server module.
17. Transfer the serial number and product number to the FRUID of the new
enclosure assembly.
Refer to the SPARC T3-1B knowledge article for specific instructions for updating
FRUID.
Note – The replacement enclosure assembly does not have a label with the serial
number on the front of the system, as was present on the original server module.
101.
111.
15.
Step 15. Otherwise, go to
Replacing the Server Module Enclosure Assembly
112.
Step 16.
