Servicing a FEM

The server module supports the installation of one FEM. To see a list of supported
FEMs for this server module, refer to the SPARC T3-1B Server Module Product Notes.
Description
Replace a FEM.
Install a FEM.
Related Information
"Detecting and Managing Faults" on page 5
■
"Preparing for Service" on page 51
■

▼ Remove a FEM

In addition to when you replace a FEM, you might need to remove a FEM in the
FEM-1 connector to access the clock battery.
1. Prepare for service. See:
"Shut Down the Oracle Solaris OS" on page 56
■
"Prepare the Server Module for Removal" on page 58
■
"Remove the Server Module From the Modular System" on page 59
■
"Remove the Cover" on page 62
■
"ESD Safety Measures" on page 52
■
2. Lift the lever to eject the card (panel 1).
Links
"Remove a FEM" on page 89
"Install a FEM" on page 90
"Install a FEM" on page 90
