Servicing The Battery; Replace The Battery - Sun Oracle SPARC T3-1B Service Manual

Servicing the Battery

The battery operates the clock for the server module.
"Replace the Battery" on page 105
■
Related Information
"Detecting and Managing Faults" on page 5
■
"Preparing for Service" on page 51
■

▼ Replace the Battery

The battery maintains system time when the server module is powered off. If the
server module fails to maintain the proper time when it is powered off, replace the
battery.
1. Prepare for service by performing the following tasks:
"Shut Down the Oracle Solaris OS" on page 56
■
"Prepare the Server Module for Removal" on page 58
■
"Remove the Server Module From the Modular System" on page 59
■
"Remove the Cover" on page 62
■
"ESD Safety Measures" on page 52
■
2. Remove a FEM card using connector FEM 1 (if present).
See "Remove a FEM" on page
3. Push the top of the battery forward, then lift the battery from the holder (panel
1).
89.
105
