Figure 6.4: A noisy variable amplitude signal acquired with the
You will observe that the signal noise is reduced when you
shift from the Sample to the Average acquisition mode.
DISPLAY Menu Function Controls
You use the DISPLAY Menu Function Controls to control
how waveforms are displayed. You can use various menu
options of the DISPLAY menu, such as Type, Persist, and
Format, to change the appearance of the oscilloscope
display.
TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit
Average acquisition mode
Using Menu Function Controls
6
6-15
