Introduction to Oscilloscopes and Probes
Figure 1.5 shows the block diagram of a DSO.
Figure 1.5: Block diagram of a DSO
A DSO contains a microprocessor (represented by uP in the
figure above) that processes the signal, manages display
activities, and interprets front panel controls.
TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit
1-11
