Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes
Menu
Option
Main
Window
Zone
Window
Set
Trigger
Holdoff
Refer to Using HORIZONTAL Controls, starting on page
4-1, for procedures involving the use of the HORIZONTAL
controls.
2-44 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit
Description
You use this menu option to display the
main horizontal time base setting for
the displayed waveform.
You use this menu option to adjust the
position and width of the window zone
with the horizontal POSITION and
SEC/DIV knobs. A window zone is an
area defined by two vertical dotted line
cursors on the oscilloscope display.
You use this menu option to magnify
the section of the waveform visible
within the window zone to full
horizontal screen size.
You use this menu option to specify the
trigger holdoff time (in seconds).
