Page 1 TDS1000B & TDS2000B Series Digital Storage Oscilloscopes Operator Training Kit Manual *P071221901* 071-2199-01...
Page 3 TDS1000B and TDS2000B Series Oscilloscopes Operator Training Kit Manual 071-2199-01 www.tektronix.com...
Page 4 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending.
Page 5: General Safety Summary
General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. To avoid potential hazards, use this product only as specified. While using this product, you may need to access other parts of the system.
Page 6: Safety Terms And Symbols
General Safety Summary Safety Terms and Symbols Terms in This Manual. These terms may appear in this manual: WARNING. Warning statements identify conditions or practices that could result in injury or loss of life. CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.
Page 7: Environmental Considerations
(WEEE). For information about recycling options, check the Support/Service section of the Tektronix Web site (www.tektronix.com). Restriction of Hazardous Substances This product has been classified as Monitoring and Control equipment, and is outside the scope of the 2002/95/EC RoHS Directive.
Page 8 Environmental Considerations TDS1000B and TDS2000B Series Oscilloscopes - - Operator Training Kit...
Page 9: Table Of Contents
Table of Contents Introduction to Oscilloscopes and Probes ........ 1-1 Getting to Know Oscilloscopes..........1-2 Introduction to Oscilloscopes ........... 1-2 Types of Oscilloscopes ............ 1-5 Oscilloscope Terminology ..........1-14 Getting to Know Probes ............. 1-23 Introduction to Probes ............ 1-23 Types of Voltage Probes..........
Page 10 Enhanced Features ............2-92 Help ................2-92 Autoset Feature............2-103 DEFAULT SETUP Feature .......... 2-112 SINGLE SEQ Feature ..........2-112 PRINT / SAVE Feature ..........2-113 Summary................2-114 Using VERTICAL Controls............3-1 VERTICAL Controls.............. 3-2 Setting Up VERTICAL Controls ........3-4 Switching the Input Coupling ...........
Page 11 Using TRIGGER Controls............5-1 Trigger Controls..............5-2 TRIGGER MENU Controls ........... 5-4 Selecting a Trigger Type ..........5-4 Selecting the Signal Coupling for a Trigger ..... 5-8 Using an External Trigger ..........5-12 Triggering on a Specific Pulse Width ......5-17 Capturing a Single-shot Signal ........
Page 12 MEASURE Menu Function Controls ........6-37 Taking Automatic Measurements ........6-37 SAVE/RECALL Menu Function Controls ......6-43 Saving and Recalling a Setup........6-43 Saving and Recalling a Waveform......... 6-48 UTILITY Menu Function Controls........6-51 Displaying the System Status ........6-51 REF MENU Function Controls ...........
Page 13 Symbols Here is a list of symbols used in this Operator Training Kit. These symbols will help you navigate faster and access specific types of information quickly. Icon Description Placed next to text that provides a link to details of the topic being referred.
Page 14 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 15: Introduction To Oscilloscopes And Probes
Introduction to Oscilloscopes and Probes The environment around us contains various energy sources, such as electronic appliances, which generate signals. Oscilloscopes allow you to observe these signals to analyze the performance of their energy sources. This module introduces you to oscilloscopes and the methods to measure electrical signals by using oscilloscopes and associated probes.
Page 16: Getting To Know Oscilloscopes
Introduction to Oscilloscopes and Probes Getting to Know Oscilloscopes This section introduces you to oscilloscopes and describes the different types of oscilloscopes and their functions. The section includes the following topics: • Introduction to Oscilloscopes • Types of Oscilloscopes • Oscilloscope Terminology Introduction to Oscilloscopes You use an oscilloscope to display electrical signals as...
Page 17 Introduction to Oscilloscopes and Probes You can use an oscilloscope to determine the following: • The frequency of an oscillating signal • The malfunctioning component in an electrical circuit • Whether the signal is direct current (DC) or alternating current (AC) •...
Page 18 Introduction to Oscilloscopes and Probes An oscilloscope contains various controls that help you analyze waveforms displayed on a graphical grid called a graticule. The vertical or Y-axis of the graticule typically represents voltage while the horizontal or X-axis typically represents time. Figure 1.1 shows how an oscilloscope displays voltage and time.
Page 19: Types Of Oscilloscopes
Introduction to Oscilloscopes and Probes Types of Oscilloscopes Electronic equipment can be categorized into two types, analog and digital. Analog equipment use variable voltages while digital equipment use binary numbers that represent voltage samples. Similarly, oscilloscopes are categorized into analog and digital. Figure 1.2 shows an analog and a digital oscilloscope.
Page 20 Introduction to Oscilloscopes and Probes Analog Oscilloscopes Let us look at how analog oscilloscopes work. Figure 1.3 shows a block diagram of an analog oscilloscope. Figure 1.3: Block diagram of an analog oscilloscope When you connect an analog oscilloscope to a circuit, the voltage signal from the circuit travels to the vertical deflection plates of the oscilloscope screen, which is a phosphor-coated cathode-ray tube (CRT).
Page 21 Introduction to Oscilloscopes and Probes A positive voltage causes the dot to move up while a negative voltage causes the dot to move down. The signal also travels to a trigger system, which initiates a horizontal sweep. The trigger causes the time base on the X-axis of the display grid to move the glowing dot from left to right across the screen within a specified time interval.
Page 22 Introduction to Oscilloscopes and Probes In analog oscilloscopes, the CRT limits the range of sine wave frequencies that the oscilloscope can display. At low frequencies, the signal appears as a bright, slow-moving dot that does not display the waveform. When signal frequencies exceed the display speed of the CRT, the displayed signal is distorted, attenuated, or both.
Page 23 Introduction to Oscilloscopes and Probes Digital Oscilloscopes In contrast to analog oscilloscopes, digital oscilloscopes use an analog-to-digital converter (ADC). An ADC converts the voltage being measured into a digital format. A digital oscilloscope acquires a waveform as a series of signal samples, which are stored in its memory and then reassembled for viewing on the screen.
Page 24 Introduction to Oscilloscopes and Probes Digital Storage Oscilloscopes In a DSO, an ADC takes samples of a signal at discrete points in time and converts the voltage at these points to digital values called sample points. The DSO contains a sample clock that determines the frequency at which the ADC takes samples.
Page 25 Introduction to Oscilloscopes and Probes Figure 1.5 shows the block diagram of a DSO. Figure 1.5: Block diagram of a DSO A DSO contains a microprocessor (represented by uP in the figure above) that processes the signal, manages display activities, and interprets front panel controls. TDS1000B and TDS2000B Series Oscilloscopes –...
Page 26 Introduction to Oscilloscopes and Probes Digital Phosphor Oscilloscopes A DPO uses electronic Digital Phosphor to display waveforms on the screen. Digital Phosphor is a database that uses separate cells to store information corresponding to each pixel of the oscilloscope display screen. Every time a waveform triggers, the cells that map to the display path of the waveform are updated with intensity information.
Page 27 Introduction to Oscilloscopes and Probes Figure 1.6 shows how a DPO works. Figure 1.6: Block diagram of DPO Similar to a DSO, a DPO also uses a microprocessor for display management, measurement automation, and analysis of the displayed waveforms. TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 1-13...
Page 28: Oscilloscope Terminology
Introduction to Oscilloscopes and Probes Oscilloscope Terminology This topic discusses the terminology related to the following categories: • Types of waves • Waveform measurements • Performance terms Types of Waves You use waveform shapes to analyze a signal. Different types of waveforms represent different types of signals. Waveforms are classified into the following groups: •...
Page 29 Introduction to Oscilloscopes and Probes Sine Waves A sine wave is a basic waveform that represents voltage change with time. Signals produced by the oscillator circuit in a signal generator are sine waves. Most AC power sources produce sine waves. Figure 1.7 shows a sine wave. Figure 1.7: Sine wave TDS1000B and TDS2000B Series Oscilloscopes –...
Page 30 Introduction to Oscilloscopes and Probes Square and Rectangular Waves A square wave represents voltage signals that turn on and off at regular intervals. It is a standard wave used for testing amplifiers, televisions, radios, and computer circuits. A rectangular wave represents high and low time periods of a square wave that are unequal.
Page 31 Introduction to Oscilloscopes and Probes Step and Pulse Waves Step and pulse waves are generated only once from a circuit. These signals are also called single-shot or transient signals. A step wave indicates a sudden change in voltage, which may be the result of turning on an electric switch. A pulse wave represents a sudden change in signal level followed by a return to the original level.
Page 32 Introduction to Oscilloscopes and Probes Sawtooth and Triangle Waves Sawtooth and triangle waves represent a linearly changing voltage required to control a device. A sawtooth wave has a rising rate of change, which differs from its falling rate of change. A triangle wave has a rising rate of change equal to its falling rate of change.
Page 33 Introduction to Oscilloscopes and Probes Complex Waves Some waveforms, formed by a combination of the characteristics of sines, squares, steps, and pulses, are called complex waves. Complex waves can represent signal information embedded in the form of amplitude, phase, and/or frequency variations. Figure 1.11 shows a complex wave.
Page 34 Introduction to Oscilloscopes and Probes Waveform Measurements You use waveform measurements to determine specific characteristics of waveforms. Frequency and Period Frequency represents the number of times a signal repeats itself in one second. The frequency of a signal is measured in Hertz (Hz).
Page 35 Introduction to Oscilloscopes and Probes Phase and Phase Shift A sine wave moves through 360° in one cycle. You can use this phase information to calculate the time elapsed since the reference or beginning point of the sine wave. Figure 1.13 shows phase along a sine wave.
Page 36 Introduction to Oscilloscopes and Probes Performance Terms Some terms and concepts related to how oscilloscopes work are discussed below. Bandwidth Bandwidth is the sine wave frequency range of an oscilloscope. By convention, bandwidth specifies the frequency at which the amplitude of the displayed sine wave reduces to 70.7% of the amplitude of the applied sine wave signal.
Page 37: Getting To Know Probes
Introduction to Oscilloscopes and Probes Getting to Know Probes This section describes the different types of probes and their applications. It includes the following topics: • Introduction to Probes • Types of Voltage Probes • How Probes Affect Measurements Introduction to Probes A probe is an input device for an oscilloscope.
Page 38: Types Of Voltage Probes
Introduction to Oscilloscopes and Probes Types of Voltage Probes There are two types of voltage probes, passive and active. Most probes are packaged with standard accessories. These accessories usually include a ground lead clip that you can attach to a ground signal source, a compensation adjustment tool, and one or more probe tip accessories to help connect the probe to test points.
Page 39 Introduction to Oscilloscopes and Probes Passive Voltage Probes Passive voltage probes consist of wires, connectors, resistors, and capacitors. Passive voltage probes typically have attenuation factors of 1X, 10X, and 100X for different voltage ranges. Attenuation factor represents the number of times a probe attenuates a signal.
Page 40 Introduction to Oscilloscopes and Probes Active Voltage Probes Active voltage probes contain active components such as transistors. Often, the active device is a field-effect transistor (FET). An active FET voltage probe can provide a very low input capacitance. As a result, active FET probes have predefined bandwidths ranging from 500 MHz to more than 4 GHz.
Page 41: How Probes Affect Measurements
Introduction to Oscilloscopes and Probes How Probes Affect Measurements To display a signal on an oscilloscope, the signal is diverted to the oscilloscope input circuit. Depending on the relative impedance values, the addition of a probe to a test point can cause loading of the signal source.
Page 42 Introduction to Oscilloscopes and Probes To minimize this loading effect, you can try the following remedies: • Use a higher impedance probe. • Measure the signal at a test point where the impedance is lower. For example, cathodes, emitters, and sources, have lower impedances than plates, collectors, and drains.
Page 43 Introduction to Oscilloscopes and Probes Capacitive Loading An increase in signal frequency or transition speed decreases the reactive impedance of a capacitive element. Consequently, capacitive loading increases the rise and fall times on fast transition waveforms and decreases the amplitude of high frequency details in waveforms. When the output of a pulse generator is tested, the probe input capacitance and resistance will interact with the pulse generator impedance.
Page 44 Introduction to Oscilloscopes and Probes Bandwidth Consideration Bandwidth measurement system issues include the bandwidth of both the probe and the oscilloscope. Bandwidth is a sine wave specification. Bandwidth specifies the maximum frequency of a sine wave that can appear on the oscilloscope display with a maximum of 29.3% decrease in amplitude.
Page 45: Summary
Introduction to Oscilloscopes and Probes Summary In this module, you learned the following: • An oscilloscope displays a waveform that represents voltage change with time. • Oscilloscopes are available in analog and digital types. • Digital oscilloscopes are of two types, digital storage oscilloscopes (DSO) and digital phosphor oscilloscopes (DPO).
Page 46 Introduction to Oscilloscopes and Probes • Waveforms are classified as: Sine waves Square and rectangular waves Step and pulse waves Sawtooth and triangle waves Complex waves • You use a probe to physically connect a signal source to an oscilloscope. •...
Page 47: Getting Started With The Tds1000B And Tds2000B Series Oscilloscopes
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes This module describes the TDS1000B and TDS2000B series of digital storage oscilloscopes. You will learn how to functionally check these oscilloscopes for general operation, and verify the probes for correct calibration. You will also learn how to power and use the Training 1 signal board that will be used in operational procedures later in this manual.
Page 48 • Identify the enhanced features of a TDS1000B/TDS2000B oscilloscope TDS1000B refers to all models in the TDS1000B series of oscilloscopes, and TDS2000B refers to all models in the TDS2000B series of oscilloscopes. TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 49: Introduction To Tds1000B And Tds2000B Series Oscilloscopes
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Introduction to TDS1000B and TDS2000B Series Oscilloscopes The TDS1000B and TDS2000B Series consist of nine models: TDS1001B, TDS1002B, TDS1012B, TDS2002B, TDS2012B, TDS2014B, TDS2022B, and TDS2024B. All the models are digital real-time oscilloscopes and share most of the features and characteristics that will be covered in this operator training manual.
Page 50 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.1 shows a TDS1001B digital storage oscilloscope. Figure 2.1: The TDS1001B digital storage oscilloscope TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 51 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.2 shows a TDS2024B digital storage oscilloscope. Figure 2.2: The TDS2024B digital storage oscilloscope TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 52: Features Of The Tds1000B And Tds2000B Series Oscilloscopes
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Features of the TDS1000B and TDS2000B Series Oscilloscopes The TDS1000B and TDS2000B Series Oscilloscopes are versatile and flexible DSOs. They have a low price/performance ratio, which makes them very popular with educational institutions and companies designing consumer-oriented computing and communication devices.
Page 53 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Ease of use The features listed below enable you to use the oscilloscopes with ease. • Context sensitive HELP menu • Color display in all the TDS2000B models • Multilanguage on-screen menus •...
Page 54 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes • DEFAULT SETUP button that recalls the factory settings in a single step • Trigger frequency readout • Delayed time base • Advanced video trigger capability • Removable data storage via USB flash drive port •...
Page 55 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes High bandwidth and sample rate The models in the TDS1000B and TDS2000B series range in bandwidth from 40 MHz to 200 MHz. In addition, they have a bandwidth limit selection of 20 MHz. The bandwidth and sample rate of the various models are listed: Model Channels...
Page 56 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Enhanced Triggering Features The following trigger capabilities are offered on all models: • Pulse Width Triggering (width from 33 ns to 10 sec) • External trigger on all models • Improved video triggering with line selectable triggering •...
Page 57: Safety Precautions
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes This saves you the effort of calculating the values off of the screen, and eliminates human errors while taking readings. This capability will be featured in a later section of this manual.
Page 58 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes • Ensure that the oscilloscope is properly grounded to the power mains before you connect the various accessories, such as probes, to the input or output terminals of the oscilloscope. • Connect the probe ground lead only to the ground potential.
Page 59: Preliminary Functional Check
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Preliminary Functional Check To set up a TDS1000B or TDS2000B oscilloscope to verify that it is functioning properly, follow these steps: 1. Connect your TDS1000B or TDS2000B oscilloscope to an AC supply by using the appropriate power cord and adapters.
Page 60 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes 6. Attach the probe tip to the 5V@1kHz connector on the front panel, and the probe ground lead to the ground connector on the front panel. 7. On the top of the front panel, push the AUTOSET button.
Page 61 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes 8. Push the CH1 MENU button twice to switch channel 1 off and push the CH2 MENU button to activate channel 2. Move the probe to CH2 (CH3 or CH4) on the front panel, and repeat steps 7 and 8 for CH2 (CH3 or CH4).
Page 62: Introduction To The Training 1 Signal Board
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Introduction to the Training 1 Signal Board You will use the Training 1 signal board for most procedures in this Operator Training Kit. Figure 2.4 shows the Training 1 signal board. Figure 2.4: The Training 1 signal board 2-16 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 63 9-volts, 1A, to power the Training 1 signal board. A 9-volt battery is supplied with your Training 1 signal board. However, for long-term use you can also order the appropriate wall transformer with the recommended output for your country from Tektronix. Part Numbers Wall Transformer Accessories...
Page 64 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes When using a wall transformer for power, you should remove the 9-volt battery from the Training 1 signal board. You should also disconnect the wall transformer from the Training 1 signal board when the signal board is not in use.
Page 65 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Now that we have discussed the power switch of the signal board, let us look at the various pins of the Training 1 signal board. Pins 2 to 6 of the Training 1 signal board provide digital signals, while pins 9 to 13 provide analog signals.
Page 66: Probe Compensation
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Probe Compensation When you attach a passive voltage attenuation probe to an oscilloscope, the capacitances of both the probe cable and the oscilloscope’s input combine. This combined capacitance must match the capacitance of the input attenuation circuit of the probe.
Page 67 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes The following procedure enables you to balance the capacitive and resistive effects of a probe and an oscilloscope by compensating the probe. This procedure assumes that the oscilloscope retains the settings from the previous preliminary functional check procedure (page 2-13).
Page 68 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You should observe a square waveform displayed on the oscilloscope similar to the waveform shown in Figure 2.5. Figure 2.5: CH1 probe compensation signal 2-22 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 69 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes However, the waveform could also have distorted corners similar to the waveforms shown in Figure 2.6 or Figure 2.7. Figure 2.6: Probe undercompensated TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-23...
Page 70 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.7: Probe overcompensated An undercompensated or overcompensated probe can cause errors in measurements. To compensate the probe correctly, use the probe adjustment tool provided with the probe. The probe adjustment tool resembles a small screwdriver.
Page 71: Primary Controls
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Primary Controls The TDS1000B and TDS2000B Series Oscilloscopes provide different controls to modify different components of the displayed waveform. This section describes the following primary controls on the front panel: • VERTICAL Controls •...
Page 72: Vertical Controls
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes VERTICAL Controls You use the VERTICAL controls to set or modify the waveform vertical scale, position, input coupling, bandwidth, and other signal conditioning. These controls are needed to scale, position, and combine or modify a wide range of signals so they can be viewed appropriately on the oscilloscope display.
Page 73 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes The three subsections of the VERTICAL controls are located on the front panel as shown in Figure 2.8. The TDS1000B and TDS2000B oscilloscopes have a set of VERTICAL controls for each channel. Figure 2.8: TDS1001B and TDS2024B VERTICAL controls TDS1000B and TDS2000B Series Oscilloscopes –...
Page 74 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes VERTICAL control knobs The VERTICAL controls for each channel consist of two knobs, the VOLTS/DIV knob and the POSITION knob. VOLTS/DIV knob You use the VOLTS/DIV knob to set and change the vertical voltage scale for the displayed waveform.
Page 75 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes VERTICAL Control MENU Buttons A TDS1000B/TDS2000B oscilloscope includes menu-based functions that help select various commands for the VERTICAL control of each channel. You use the side- screen menu-based VERTICAL controls for a channel to select various functions, such as the input coupling type, bandwidth limit of the channel, and probe attenuation.
Page 76 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.9: Menu-based options for VERTICAL controls 2-30 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 77 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Coupling You use this menu option to select the coupling type for a channel. You can select AC, DC, or Ground. Bandwidth You use this menu option to set the Limit bandwidth limit of a channel at either the bandwidth of the oscilloscope (40 MHz,...
Page 78 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Probe You use this menu option to match a probe type of Voltage or Current. For voltage probes this menu option is used to match the probe attenuation of 1X, 10X, 20X, 50X, 100X, 500X, or 1000X. For current probes this menu option is used to set the probe attenuation of 0.2X, 1X, 2X, 5X, 10X, 50X, 100X,...
Page 79 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Invert You use this menu option to invert the displayed waveform vertically with respect to the ground level. Refer to the section, Using VERTICAL Controls, starting on page 3-1, for procedures that use the VERTICAL controls. TDS1000B and TDS2000B Series Oscilloscopes –...
Page 80 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes MATH MENU Controls You use the MATH MENU controls to perform math operations on displayed waveforms. You can choose to add two waveforms, subtract one waveform from another, multiply two waveforms, or perform a Fast Fourier Transform (FFT) on a waveform.
Page 81 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.10: Examples of MATH MENU functions TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-35...
Page 82 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Options Operation You use this menu option to select the type of operation you want to perform, such as subtraction, addition, multiplication, or FFT. Each operation activates a separate menu. CH1+CH2 This menu option is activated when you select the addition (+) operation for...
Page 83 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes CH1-CH2 This menu option is activated when you select the subtraction (-) operation to subtract one waveform from another. You can perform both CH1-CH2 and CH2-CH1 operations. In the TDS2004B, TDS2014B and TDS2024B models, you can also perform CH3- CH4 and CH4-CH3 operations.
Page 84 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes This menu option is activated when you select the FFT option to perform an FFT operation on the displayed waveform. The FFT menu contains the following selections: • Source signal as CH1, CH2, CH3, and CH4.
Page 85: Horizontal Controls
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes HORIZONTAL Controls You use the HORIZONTAL controls to regulate the horizontal acquisition and display of a waveform. These controls are needed to scale and position the time or frequency axis of the display, over the wide range of signals that need to be measured.
Page 86 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.11: TDS1012B and TDS2024B HORIZONTAL controls 2-40 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 87 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes HORIZONTAL Control Knobs The HORIZONTAL control section consists of two knobs, SEC/DIV and POSITION. SEC/DIV knob You use the SEC/DIV knob to control a waveform’s horizontal time scale. The horizontal center of the display is the time reference for expanding and compressing waveforms.
Page 88 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes A TDS1000B/TDS2000B oscilloscope includes menu-based functions to select various commands for the HORIZONTAL controls. To activate the HORIZONTAL menu-based functions, perform the following step: • In the HORIZONTAL section on the front panel, push the HORIZ MENU button.
Page 89 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.12: Menu-based options for HORIZONTAL controls TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-43...
Page 90 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Main You use this menu option to display the main horizontal time base setting for the displayed waveform. Window You use this menu option to adjust the Zone position and width of the window zone with the horizontal POSITION and SEC/DIV knobs.
Page 91: Trigger Controls
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes TRIGGER Controls You use the TRIGGER controls to reference the acquisition of signals. The TRIGGER controls enable you to set the trigger threshold conditions for an acquisition and to assign a holdoff time to the trigger. Figure 2.13 shows the TRIGGER controls.
Page 92 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes The TRIGGER controls on the front panel consists of the following: LEVEL knob You use this knob to set the trigger Level for a trigger. TRIG MENU button You use this button to display the trigger menu. The trigger menu contains options for trigger Type, Source, Slope, Mode and Coupling.
Page 93 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes FORCE TRIG button You use this button to force a signal acquisition to occur in the absence of a trigger signal. This manual trigger function can become necessary when you set the triggering mode to Normal, or you select SINGLE SEQ with the front panel button for this mode.
Page 94 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes TRIG MENU button To activate the TRIGGER menu-based functions, perform the following step: • In the TRIGGER section on the front panel, push the TRIG MENU button. The TRIGGER menu is activated on the display. Figure 2.14 shows the menu-based options for the TRIGGER controls.
Page 95 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You use the TRIG MENU button to display the trigger menu. You can select the appropriate trigger type by using the side-screen buttons. Each trigger type has a unique menu display. As a result, the menu options change according to the trigger type that you select.
Page 96 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Slope You select this menu option to specify a trigger on either the rising edge or the falling edge of a signal. Mode You use this menu option to select the type of triggering as Normal or Auto.
Page 97 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Coupling You use this menu option to select the trigger signal components that are applied to the trigger circuitry. You can set the trigger coupling as AC, DC, Noise Reject, HF Reject, and LF Reject.
Page 98 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Source You use this menu option to select an input source for a trigger signal. You can select various input sources, such as CH1, CH2, Ext, and Ext/5. You can also select CH3 and CH4 as input sources for the TDS2004B, TDS2014B, and TDS2024 oscilloscopes.
Page 99 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes A NTSC signal is shown in Figure 2.14a. This signal has been captured using the Autoset feature. The fields are shown by default. Figure 2.14a: Video fields TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-53...
Page 100 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You can also view the lines by pushing the appropriate side- screen menu button. The video lines of a NTSC signal are shown in Figure 2.14b. Figure 2.14b: Video lines 2-54 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 101 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You can set the oscilloscope to trigger on a particular line. This feature is very useful in production lines, where robots fitted with ‘electronic eyes’ can detect errors related to fitting of parts.
Page 102 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You use Pulse Width triggering to trigger on aberrant pulses. Menu Description Option Pulse You use this menu to trigger the oscilloscope on pulses. The trigger conditions are provided by the Source, When, and Pulse Width options.
Page 103 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Pulse You use this menu option to set the Width threshold pulse width. The oscilloscope will trigger according to the condition set in the When field. To set the threshold, select Pulse Width, and use the Multipurpose knob to choose a value.
Page 104 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Coupling You use this menu option to select the components of the trigger signal, which are applied to the trigger circuitry. You can set the trigger coupling as AC, DC, Noise Reject, HF Reject, and LF Reject.
Page 105: Menu Function Controls
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Function Controls You use the Menu Function Controls at the top of the front panel to perform various functions, such as saving and recalling setups and waveforms, taking automatic waveform measurements, and modifying the acquisition settings.
Page 106 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes The Menu Function Controls consist of eight menu-based function buttons. When you push a menu function button, the associated menu option options on the oscilloscope screen are activated. Figure 2.15 shows the front panel menu function controls.
Page 107 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes ACQUIRE Menu Function Controls You use the ACQUIRE Menu Function Controls to regulate the signal acquisition and processing system and select different types of acquisition modes for a signal. To activate the ACQUIRE menu, push the ACQUIRE menu button.
Page 108 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Sample You use this menu option to acquire 2500 sample points and display them at the sec/div setting. The Sample mode is the default mode for signal acquisition. Peak You use this menu option to select the Detect...
Page 109 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Refer to the section ACQUIRE Menu Function Controls, starting on page 6-6, for procedures using the ACQUIRE menu function controls. DISPLAY Menu Function Controls You use the DISPLAY menu controls to select the display characteristics for waveforms.
Page 110 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.17: DISPLAY menu 2-64 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 111 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Type You use this menu option to specify whether the waveform will be displayed in dots or as vectors. Persist You use this menu option to specify the duration for which each sample point is displayed.
Page 112 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Contrast You use this menu option to adjust the display contrast. Display You use this menu option to set the Style screen text as black on white (Normal) or as white on black (Invert). You can only select this option in the TDS1001B, TDS1002B, and TDS1012B oscilloscopes.
Page 113 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.18 shows the menu-based options for the CURSOR menu function controls. You control each menu option by pushing the side-screen button next to the option. Figure 2.18: CURSOR menu TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-67...
Page 114 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Type You use this menu option to specify cursor measurements of Amplitude or Time. Source You use this menu option to choose different cursor signal sources, such as CH1, CH2, MATH, Ref A, or Ref B, for a displayed waveform on 2-channel oscilloscopes.
Page 115 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Cursor 1 You use this menu display to adjust the position of cursor 1 and to observe the quantity represented by cursor 1. This could either be the time referenced to the trigger position, or the voltage referenced to the ground.
Page 116 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes MEASURE Menu Function Controls The MEASURE Menu Function Controls allow you to take predefined automated measurements of waveforms. There are 11 types of available measurements from which you can display up to five at a time. To activate the MEASURE menu, push the MEASURE menu button.
Page 117 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.19: MEASURE menu TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-71...
Page 118 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Source You use this menu option to specify the source of a waveform as CH1 or CH2 for 2-channel oscilloscopes. The options, CH3 and CH4 are available on 4-channel oscilloscopes.
Page 119: Save/Recall Menu Function Controls
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes SAVE/RECALL Menu Function Controls You use the SAVE/RECALL Menu Function Controls to save and recall up to 10 oscilloscope setups and 2 waveforms (4 waveforms each on the TDS2014 and TDS2024 oscilloscopes) from non-volatile memory or to save and recall oscilloscope setups, display images and/or waveforms from a USB flash drive.
Page 120 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.20a: Save options for the SAVE/RECALL menu Figure 2.20b: Recall options for the SAVE/RECALL menu 2-74 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 121 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You use the SAVE/RECALL menu to display the save and recall menus. You can select the following actions Save All, Save Image, Save Setup, Save Waveform, Recall Setup, or Recall Waveform. Each action has a unique menu display.
Page 122 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Select You use this menu option to specify the Folder USB flash drive folder where the files are to be saved. About Save You use this menu option to display the help information for Save All function The Save Image option configures the oscilloscope to save a display image on a USB flash drive.
Page 123 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes About You use this menu option to display the Saving help information for Save Image Images function. Select You use this menu option to specify the Folder USB flash drive folder where the display image file is to be saved.
Page 124 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Save To You use this menu option to choose whether the current oscilloscope setting is saved to a location in nonvolatile setup memory (Setup) or on a USB flash drive (File). Setup You use this menu option to specify which nonvolatile setup memory...
Page 125 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes The Save Waveform option configures the oscilloscope to save the specified waveform data. You can select various menu options for Save Waveform function. Menu Description Option Save You use this menu option to save the Waveform specified waveform data to one of 2 (4 on 4-channel models) non-volatile...
Page 126 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Select You use this menu option to specify the Folder USB flash drive folder where the waveform data file is to be saved. Save You use this menu option to save the display image to the automatically generated file name in the current USB flash drive folder.
Page 127 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Setup You use this menu option to specify which nonvolatile setup memory location to recall from. Select File You use this menu option to specify the USB flash drive folder where the setup file is to be recalled from.
Page 128 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes To REFX You use this menu option to specify the reference memory location to recall the waveform to. Select File You use this menu option to specify the USB flash drive folder where the setup file is to be recalled from.
Page 129 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes UTILITY Menu Function Controls You use the UTILITY Menu Function Controls to access the various oscilloscope setup utility functions. You can use the UTILITY Menu Function Controls to check the system status, set up hard copy and communication utilities, perform self-calibration for the oscilloscope, and change the language used in the oscilloscopes.
Page 130 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.21 shows the menu-based options for the UTILITY menu function controls. You can control each menu option by pushing the side-screen menu button next to the option. Figure 2.21: UTILITY menu 2-84 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 131 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option System You use this menu option to check the Status system status with respect to the VERTICAL, HORIZONTAL, and TRIGGER controls. Options You use this menu option to configure the rear USB port, set up printing utilities, GPIB address, set date and time of the oscilloscopes internal clock...
Page 132 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Language You use this menu option to select the display language for the side-screen menu from the various languages, such as English, French, German, Italian, Spanish, Portuguese, Chinese, Simplified Chinese, Japanese, and Korean.
Page 133 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.22 shows the menu-based options for the REF MENU function controls. You can control each menu option by pushing the side-screen menu button next to the option. Figure 2.22: REF MENU TDS1000B and TDS2000B Series Oscilloscopes –...
Page 134 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Ref X You use this menu option to turn on and off Reference X waveform. AUTORANGE Menu Function Controls You use the AUTORANGE Menu Function Controls to have the oscilloscope automatically adjust setup values to track a signal.
Page 135 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.23 shows the menu-based options for the AUTORANGE menu function controls. You can control each menu option by pushing the side-screen menu button next to the option. Figure 2.23: AUTORANGE menu TDS1000B and TDS2000B Series Oscilloscopes –...
Page 136 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Auto- You use this menu option to turn on or ranging off the AUTORANGE function. An LED light turns on adjacent to the AUTORANGE button that indicates when the function is active. Vertical You use this menu option to set up the AUTORANGE feature to track and...
Page 137 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Undo Auto- You use this menu option to recall the ranging previous setup. Refer to AUTORANGE Menu Function Controls, starting on page 6-55, for a procedure using the AUTORANGE menu function controls. TDS1000B and TDS2000B Series Oscilloscopes –...
Page 138: Enhanced Features
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Enhanced Features The TDS1000B and TDS2000B Series Oscilloscopes contain built-in procedures that enable you to perform both routine and complex tasks quickly. The controls that provide these enhanced features are: • HELP •...
Page 139 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Help System The Help System is a comprehensive and well-structured list of topics that cover the various features of the oscilloscope. In addition, the Help system also provides descriptive information on various menus and controls that you can access at any time.
Page 140 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.24: Index Help menu 2-94 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 141 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Show You use this menu to display the Topic selected topic or hyperlink. Page Up You use this menu to view the previous page. Page You use this menu to view the next Down page.
Page 142 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes You can view various Help topics by navigating through the hyperlinks using the multipurpose knob and then selecting the appropriate hyperlink. Hyperlinks These are links to other topics and are in the form of phrases marked by angle braces.
Page 143 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Context-Sensitive Help Feature In the previous section, you learned about the Index Help feature. In this section, you will look at the Context-Sensitive Help feature. This feature enables you to obtain information about the control or menu you are using.
Page 144 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.25: HELP screen 2-98 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 145 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.26 shows the menu options for HELP. You can control each menu option by pushing the side-screen button next to the option. Figure 2.26: HELP menu TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 2-99...
Page 146 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Show You use this menu to display the Topic selected topic or hyperlink. Index You use this menu to display the list of all the topics in the Help system. Help on You use this menu to view the topics Help...
Page 147 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Help Wizard The Help Wizard is a ‘smart’ option that anticipates your next move and generates messages at the bottom of the screen. It conveys the following types of information. • Directions to use another menu, such as when you push the TRIG MENU button.
Page 148 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Figure 2.27: Help on Help, with “Help Wizard” at the bottom of the display 2-102 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 149: Autoset Feature
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Autoset Feature This is another ‘smart’ feature of the TDS1000B and TDS2000B Series Oscilloscopes. When you push the AUTOSET button, the oscilloscope examines all channels for signals and displays only those channels with waveforms.
Page 150 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes The Autoset function can detect and display three types of signals. Moreover, it also displays a menu to view various aspects of the signal. The Autoset function can detect the following signals: •...
Page 151 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Sine The oscilloscope displays the following options when a sine wave or a similar signal is detected by the Autoset function. These options are shown in Figure 2.28. Figure 2.28: AUTOSET options for sine waves TDS1000B and TDS2000B Series Oscilloscopes –...
Page 152 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Multi-cycle You use this menu option to display sine several cycles with appropriate vertical and horizontal scaling. The oscilloscope displays Cycle RMS, Frequency, Period, and Peak-to-Peak automatic measurements. Single- You use this menu option to set the cycle sine...
Page 153 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Square Wave or Pulses The oscilloscope displays the following options when a square wave or a signal similar to it is detected by the Autoset function. These options are shown in Figure 2.29. Figure 2.29: AUTOSET options for square waves TDS1000B and TDS2000B Series Oscilloscopes –...
Page 154 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Menu Description Option Multi-cycle You use this menu option to display square several cycles with appropriate vertical and horizontal scaling. The oscilloscope displays Mean, Frequency, Period, and Peak-to-Peak automatic measurements. Single- You use this menu option to set the cycle horizontal scale so that it displays about...
Page 155 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Falling You use this menu option to display the Edge falling edge. The oscilloscope displays Fall Time, and Peak-to-Peak automatic measurements. Undo You use this menu option to recall the Setup previous setup.
Page 156 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Video The oscilloscope displays the following options when a standard NTSC, PAL, or SECAM video signal is detected by the Autoset function. These options are shown in Figure 2.30. Figure 2.30: AUTOSET options for video signal Menu Description Option...
Page 157 Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes ALL Lines You use this menu option to trigger on and display all lines. Line You use this menu option to display a Number specified line. Turn the USER SELECT knob to select a specific line number that the oscilloscope uses as a trigger.
Page 158: Default Setup Feature
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes DEFAULT SETUP Feature This feature enables you to recall the factory default setup, and is invoked by pushing the DEFAULT SETUP button. When you push the DEFAULT SETUP button, the oscilloscope displays the CH1 waveform and removes all other waveforms.
Page 159: Print / Save Feature
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes PRINT / SAVE Feature This feature enables you to either print the screen image to a printer or save data to a USB flash drive. When LED next to SAVE is unlit, pushing the PRINT button prints the image displayed on the screen.
Page 160: Summary
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes Summary In this module, you learned to: • Identify the models of the TDS1000B and TDS2000B series of oscilloscopes. • List the safety precautions to be observed before using an oscilloscope. •...
Page 161: Using Vertical Controls
Using VERTICAL Controls You have learned about the various front panel controls. In this module, you will learn to use the VERTICAL controls by following various procedures that vary the vertical resolution of a displayed waveform, or select special functions by using the VERTICAL MENU controls.
Page 162: Vertical Controls
Using VERTICAL Controls VERTICAL Controls The VERTICAL control section for each channel has two knobs, VOLTS/DIV and POSITION. VERTICAL control knobs The VERTICAL controls for each channel consist of two knobs, the VOLTS/DIV knob and the POSITION knob. VOLTS/DIV knob You use the VOLTS/DIV knob to set and change the vertical voltage scale for the displayed waveform.
Page 163 Using VERTICAL Controls Figure 3.1 shows the VERTICAL control sections of a 2-channel and a 4-channel oscilloscope respectively. Figure 3.1: TDS1012B and TDS2024B VERTICAL control section TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 164: Setting Up Vertical Controls
Using VERTICAL Controls Setting Up VERTICAL Controls Before you use the VERTICAL controls, you must ensure that the oscilloscope is set up for the VERTICAL controls. To set up a TDS1000B/TDS2000B oscilloscope for the VERTICAL controls, follow these steps: 1. Connect two P2220 probes to the CH1 and CH2 BNC input connectors on the front panel.
Page 165 Using VERTICAL Controls In the VERTICAL section, turn the VOLTS/DIV and POSITION knobs for CH1 2.00V in the top half of the display, and CH2 2.00V in the bottom half of the display. 5. In the TRIGGER section, use the LEVEL knob to set the trigger level readout at the bottom right of the display for CH1 (+slope symbol) 1.60V.
Page 166: Switching The Input Coupling
Using VERTICAL Controls After you set up your oscilloscope for VERTICAL controls, you can perform various procedures, such as switching the input coupling of a signal, modifying the vertical scale, and changing the vertical position of a waveform. Switching the Input Coupling Coupling is the method you use to connect an electrical signal from one device to another.
Page 167 Using VERTICAL Controls You can change the type of input coupling to view the various components of a signal. For example, you can use vertical AC coupling to view an AC signal, such as ripple, which is riding on a large DC offset. AC coupling allows you to view such signals without any special offset controls.
Page 168 Using VERTICAL Controls 3. Push the appropriate side-screen menu button to select Coupling AC. The waveform shifts down because AC coupling blocks the DC component of the signal. However, the ground reference arrow and the trigger level reference arrow at the left and right of the display, respectively, do not shift from their initial positions.
Page 169 Using VERTICAL Controls 6. Push the appropriate side-screen menu button to select Coupling DC. 7. Turn the CH1 POSITION knob counterclockwise to set the vertical position at 0.00 divs (0.00V). Notice that the flatness of the probe compensation waveform changes when you switch from AC coupling to DC coupling.
Page 170 Using VERTICAL Controls You can see the positive peaks of the waveform with 100 divisions of position offset, as shown in Figure 3.3. This allows you to analyze signal details that would otherwise not be visible. Figure 3.3: Vertical display, with 100 divisions of offset This procedure is applicable to scenarios where you need to observe the change in amplitude of a square wave inverter or a DC power supply when load is applied.
Page 171 Using VERTICAL Controls This high DC offset capability of the oscilloscope also allows logic pulses that are referenced away from ground to be positioned on screen for accurate measurements. This allows you to view logic signals, such as ECL, that have their high and low levels biased several volts from ground.
Page 172: Vertical Control Menu Buttons
Using VERTICAL Controls VERTICAL Control MENU Buttons You use the various side-screen menu buttons of VERTICAL controls to select special functions, such as the input coupling for the signal, the bandwidth limit of the oscilloscope, and the probe attenuation factor. The next procedure demonstrates the steps to use the side-screen menu buttons of VERTICAL controls to modify the vertical scale of a waveform.
Page 173 Using VERTICAL Controls 5. Push the appropriate side-screen menu button to select Volts/Div Fine. 6. In the VERTICAL section, turn the CH1 VOLTS/DIV knob to modify the vertical volts/division scale. You can now modify the vertical scale of a waveform with a fine resolution.
Page 174: Math Menu Controls
Using VERTICAL Controls MATH MENU Controls You use the MATH MENU controls to perform math operations, such as addition, subtraction, and multiplication of waveforms. For example, you can measure the difference in voltage between two points in a circuit by subtracting one waveform from another.
Page 175 Using VERTICAL Controls The following procedure enables you to add waveforms to verify the operation of a circuit that adds or subtracts signals. 1. On the top of the front panel, push DEFAULT SETUP. 2. On the top of the front panel, push the AUTOSET button.
Page 176 Using VERTICAL Controls You will see waveforms similar to those shown in Figure 3.4. The displayed waveform adjacent to the M icon at the left of the display is the sum of the waveforms of CH1 and CH2. The M icon indicates the MATH waveform, which appears in red in oscilloscopes with color displays.
Page 177: Subtracting Two Waveforms
Using VERTICAL Controls Subtracting Two Waveforms You can use the oscilloscope to subtract two waveforms to isolate and view the differential of the two signals, while rejecting common mode signals. For example, consider a situation where you need to evaluate a switching power supply FET with respect to switching time and load regulation effects.
Page 178 Using VERTICAL Controls 4. On the top of the front panel, push DEFAULT SETUP. 5. In the VERTICAL section, push the CH2 MENU button. 6. In the VERTICAL section, turn the CH1 and CH2 VOLTS/DIV knobs to set both channels for 500mV at the bottom of the display.
Page 179 Using VERTICAL Controls You will see waveforms similar to those shown in Figure 3.5. Figure 3.5: Display of CH1-CH2 Note that a slow ‘heart beat’ signal is differentially buried in the large common mode sine wave signals that are on both Channel 1 and Channel 2.
Page 180: Multiplying Two Waveforms
Using VERTICAL Controls Multiplying Two Waveforms You can use the oscilloscope to multiply a voltage and a current waveform to view power waveform of the two signals. To obtain the power waveform of the voltage and current waveforms, follow these steps: 1.
Page 181 Using VERTICAL Controls 4. On the top of the front panel, push DEFAULT SETUP. 5. On the top of the front panel, push the AUTOSET button. 6. In the VERTICAL section, push the CH2 MENU button. Push the Probe menu option button. Next push the Current menu option button.
Page 182 Using VERTICAL Controls You will see waveforms similar to those shown in Figure 3.6. Figure 3.6: Display of CH1xCH2 3-22 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 183: Performing Fft Operations
Using VERTICAL Controls Performing FFT Operations FFT is an algorithm used to transform time-domain information into frequency domain information. You use the FFT operation in an oscilloscope to view and measure repeating complex waves as sine wave components. For example, you can use FFT for radio frequency analysis of radio transmitters, as well as for vibration analysis of mechanical devices.
Page 184 Using VERTICAL Controls To perform an FFT operation by using the MATH MENU button of the VERTICAL controls, follow these steps: 1. Connect the CH1 probe tip to the 5V@1kHz pin and the CH1 ground lead to the ground reference pin directly below the 5V@1kHz pin on the front panel.
Page 185 Using VERTICAL Controls 8. Turn the HORIZONTAL POSITION knob clockwise to position the beginning of the frequency domain display at four divisions from the left of the display. 9. Push the appropriate side-screen menu button to select the FFT Zoom X5 option. The displayed FFT waveform shows the harmonic content of the calibrator signal.
Page 186: Summary
Using VERTICAL Controls Summary In this module, you learned to perform the following tasks: • Use the VERTICAL VOLTS/DIV knob to modify the calibration of the vertical scale of the display. • Use the VERTICAL POSITION knob controls to position a waveform on the vertical scale of the display.
Page 187: Using Horizontal Controls
Using HORIZONTAL Controls In the previous module, you learned to use the VERTICAL controls on the front panel. In this module, you will learn to use the HORIZONTAL controls by following various procedures that vary the horizontal position and scale of a displayed waveform.
Page 188: Horizontal Controls
Using HORIZONTAL Controls HORIZONTAL Controls The HORIZONTAL control section includes the SEC/DIV knob, POSITION knob, and SET TO ZERO button. (HORIZONTAL MENU controls will be covered in the next section of this module.) SEC/DIV knob You use the SEC/DIV knob to modify the time scale of a displayed waveform.
Page 189: Setting Up The Horizontal Controls
Using HORIZONTAL Controls Figure 4.1: The HORIZONTAL control sections Setting Up the HORIZONTAL Controls Before you use the HORIZONTAL controls in the operation exercises, you must ensure that the oscilloscope is set to its default setting. It is assumed that the Channel 1 probe tip is connected to the 5V@1kHz signal on the front panel and the probe ground clip is connected to the GND pin on the front panel.
Page 190 Using HORIZONTAL Controls To set up a TDS1000B/TDS2000B oscilloscope for the HORIZONTAL controls, follow these steps: 1. On the top of the front panel, push DEFAULT SETUP. 2. On the top of the front panel, push the AUTOSET button. You will see a waveform similar to that shown in Figure 4.2. Figure 4.2: TDS2000B horizontal setup TDS1000B and TDS2000B Series Oscilloscopes –...
Page 191: Setting The Delay Time For A Waveform
Using HORIZONTAL Controls After you set up the oscilloscope for HORIZONTAL controls, you can perform various procedures, such as setting the delay time for a waveform. Use the HELP feature for more information about the HORIZONTAL controls, Setting the Delay Time for a Waveform You can set the oscilloscope to display a waveform relative to the trigger point in time.
Page 192 Using HORIZONTAL Controls The following procedure enables you to set the delay time for a displayed waveform by changing the horizontal position of the trigger. This procedure assumes that the oscilloscope retains the settings specified for the previous procedure. To set the delay time for a displayed waveform, follow these steps: 1.
Page 193 Using HORIZONTAL Controls You will see the waveform delayed from the trigger point, similar to that shown in Figure 4.3. Figure 4.3: Delayed trigger position for a waveform In this procedure, you used the SEC/DIV knob to modify the time base setting of a waveform. You also used the HORIZONTAL POSITION knob to change the position of the trigger point from the center of the display.
Page 194: Horizontal Control Menu Button
Using HORIZONTAL Controls HORIZONTAL Control MENU Button In this section, you will learn to use the menu options offered by the HORIZ MENU button. Each option can be selected using the side-screen buttons and varied using the HORIZONTAL Control Knobs. Expanding the Waveform Display In the previous procedure, you set the oscilloscope to view a delayed waveform.
Page 195 Using HORIZONTAL Controls 3. A pair of vertical dotted lines is displayed. You use these lines to select a portion of the waveform that you want to view in a magnified form. 4. Turn the HORIZONTAL POSITION knob clockwise to position the vertical dotted line cursors around the last positive edge of the displayed waveform.
Page 196 Using HORIZONTAL Controls Figure 4.4: Position delayed and Window Zone 6. Push the appropriate side-screen menu button to select Window. 7. In the HORIZONTAL section, turn the POSITION knob to position the rising edge of the displayed waveform to the center of the display. 8.
Page 197 Using HORIZONTAL Controls Figure 4.5 shows an expanded waveform using the Window function. This procedure will be useful where you need to view magnified portions of a signal. A typical application is the analysis of response signals in a robot control system, relative to a stimulus signal.
Page 198 Using HORIZONTAL Controls This procedure is well suited for irregular waveforms such as the waveform from an audio amplifier, or a mechanical transducer. To study the output of a single shot signal, such as the output of an acoustic or mechanical transducer, you can use the SINGLE SEQ button to capture a single waveform and then use the HORIZONTAL POSITION and SEC/DIV knobs to expand it.
Page 199: Summary
Using HORIZONTAL Controls Summary In this module, you learned to perform the following tasks: • Use the SEC/DIV knob to modify the horizontal scale of a displayed waveform. • Use the HORIZONTAL POSITION knob to change the horizontal position of a displayed waveform. •...
Page 200 Using HORIZONTAL Controls 4-14 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 201: Using Trigger Controls
Using TRIGGER Controls In the previous module, you learned to use the HORIZONTAL controls on the front panel. In this module, you will learn to use the TRIGGER controls by following various procedures that stabilize repeating signals as well as to capture single-shot. At the end of this module, you will be able to: •...
Page 202: Trigger Controls
Using TRIGGER Controls Trigger Controls Triggering a signal at the correct point is essential to ensure the proper display of a waveform. You can use the TRIGGER controls on the front panel to stabilize repeating signals as well as to capture single-shot waveforms. Figure 5.1 shows the TRIGGER control sections on the front panel.
Page 203 Using TRIGGER Controls The TRIGGER controls on the front panel consist of the following: LEVEL knob You use this knob to set the triggering level while using the edge trigger. TRIG MENU button You use this button to display the trigger menu. The trigger menu contains various options such as trigger type, trigger source, and trigger mode.
Page 204: Trigger Menu Controls
Using TRIGGER Controls TRIG VIEW button You use this button to display the trigger waveform instead of the channel waveforms. You use this button to check how trigger settings, such as trigger coupling, affect the triggering signal. You need to keep this button pressed to view the trigger waveform.
Page 205 Using TRIGGER Controls You use Video triggering to trigger on the fields or lines of an NTSC, a PAL, or a SECAM standard video signal. When you choose video triggering on a TDS1000B/TDS2000B oscilloscope, the trigger is automatically referenced to the negative part of the video signal.
Page 206 Using TRIGGER Controls 4. On the top of the front panel, push the AUTOSET button. 5. In the HORIZONTAL section, turn the SEC/DIV knob to set the time base setting on the display for M 2.50us. 6. In the TRIGGER section, push the TRIG MENU button. This step is for you to see that Edge is selected by default.
Page 207 Using TRIGGER Controls You will see a display showing the Edge triggering setup similar to that shown in Figure 5.2. Figure 5.2: Edge triggering TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 208: Selecting The Signal Coupling For A Trigger
Using TRIGGER Controls Selecting the Signal Coupling for a Trigger You can select the coupling type for a trigger when you choose Edge triggering. You can choose to select DC, Noise Reject, HF Reject, LF Reject, or AC coupling for a trigger.
Page 209 Using TRIGGER Controls This procedure assumes that the oscilloscope retains the settings from the previous procedure. To select a coupling type for a trigger, follow these steps: 1. In the TRIGGER section, push the TRIG MENU button. 2. Push the appropriate side-screen menu button to select Coupling HF Reject.
Page 210 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 5.3. This trigger signal has a slower rise time and is the result of the low pass HF reject filter. This trigger selection rejects the high-speed components in the triggering signal. Figure 5.3: Triggering waveform with HF Reject coupling 5-10 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 211 Using TRIGGER Controls HF Reject only allows signal components below 50 kHz to pass to the trigger circuit. This helps to reduce the effects of high frequency noise that might cause triggering problems. Noise Reject allows all components of a signal to pass to the trigger circuit, but increases the peak-to-peak signal required to trigger the signal.
Page 212: Using An External Trigger
Using TRIGGER Controls Using an External Trigger You can select various sources, such as an input channel or the power source of the oscilloscope, to trigger a displayed signal. Consider an example where you have a circuit that uses a clock signal as a reference.
Page 213 Using TRIGGER Controls The following procedure enables you to use an external trigger source or an unused channel, other than the displayed acquisition input channels, to trigger a displayed signal. You can use the external trigger input (or an unused channel) to trigger on certain unique aspects of this trigger signal, such as pulse width and edge level.
Page 214 Using TRIGGER Controls 4. On the top of the front panel, push the AUTOSET button. 5. Connect a (10X passive) probe to the EXT TRIG input connector. 6. Connect the external trigger probe tip to the CLK 20MHz signal on pin 2 and the external trigger probe ground lead to GND on pin 1 of the Training 1 signal board.
Page 215 Using TRIGGER Controls Figure 5.4: Eye Diagram display of pseudo random signal triggered by external clock signal TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit 5-15...
Page 216 Using TRIGGER Controls This eye diagram display shows that the positive and negative transition edges of the signal are all synchronized with the clock, as is expected. When the edges are not stable relative to the clock, then jitter is occurring. This is a very important issue for communications signals.
Page 217: Triggering On A Specific Pulse Width
Using TRIGGER Controls Triggering on a Specific Pulse Width A TDS1000B/TDS2000B oscilloscope can be set to trigger on a pulse based on its width. This feature can be used to isolate and analyze a unique pulse in a complex data stream.
Page 218 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 5.5. Figure 5.5: Pseudo random communications signal without holdoff 4. In the TRIGGER section, push the TRIG MENU button. 5. Push the appropriate side-screen menu button to select Type Pulse.
Page 219 Using TRIGGER Controls 6. Push the appropriate side-screen menu button to select Source CH1. This option may already be selected by default. 7. Push the appropriate side-screen menu button to select When =. This option may already be selected by default. 8.
Page 220 Using TRIGGER Controls You should see a display similar to the following Figure 5.6. Figure 5.6: Unique Pulses with pulse widths of approximately 297 ns This special pulse triggering condition shows the unique pulse in this signal that is very close to 300 ns in width. Pulse triggering allows you to trigger on and isolate pulses that are less than, equal to, greater than, or not equal to the pulse width value that you select.
Page 221 Using TRIGGER Controls This procedure is useful in scenarios where you need to trouble shoot disc drives and remote controls. A typical command signal of remote control has a 0.5 ms presignal pulse followed by a delay of 3 ms and then followed by a 7 ms six-bit biphase code word.
Page 222: Capturing A Single-Shot Signal
Using TRIGGER Controls Capturing a Single-shot Signal Noise from the signal, probes, and ground leads can cause signal distortions. For example, probe tips and ground leads have inductance. This inductance can interact with the probe and circuit capacitance to cause a damped sinusoidal variation on pulses with fast edge transitions.
Page 223 Using TRIGGER Controls To perform the step response procedure, follow these steps: 1. Connect the CH1 probe tip to the FAST RISE TIME signal on pin 16 and the CH1 ground lead to GND on pin 1 of the Training 1 signal board. 2.
Page 224 Using TRIGGER Controls 7. In the TRIGGER section, turn the LEVEL knob to set the trigger level to 200mV. 8. On the front panel, push the SINGLE SEQ button. The word Ready will appear at the top of the display. 9.
Page 225 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 5.7. Figure 5.7: Step response waveform with a ground lead Overshoot and ringing are caused by the inductance of the probe ground and signal tip leads that interact with the probe and circuit capacitance.
Page 226 Using TRIGGER Controls To view the step response signal without overshoot and ringing, follow these steps: 1. Pull the probe tip out of the probe tip lead. 2. Insert exposed probe tip into the probe socket on the Training 1 signal board. 3.
Page 227 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 5.8. Figure 5.8: Step response waveform without a ground lead Note that no ringing occurs in the step response when the probe ground and signal tip leads are kept short. This procedure points out the importance of keeping probe leads short when analyzing signals with fast rise and/or fall times.
Page 228: Trigger Holdoff Controls
Using TRIGGER Controls Trigger Holdoff Controls A complex repeating signal is difficult to trigger on and see as a stable waveform display. You can use advanced pulse triggering to capture the signal details of interest, or you can trigger on a different signal, if it is available. You can also use trigger holdoff to stabilize a complex repeating waveform.
Page 229: Assigning Trigger Holdoff To A Pseudo Random Signal
Using TRIGGER Controls Assigning Trigger Holdoff to a Pseudo Random Signal The following procedure enables you to assign a holdoff time for the trigger generated by the PSEUDO RANDOM signal from pin 5 of the Training 1 signal board. This enables you to see a stable waveform display.
Page 230 Using TRIGGER Controls Figure 5.10: Stable display of pseudo random communications signal by using trigger holdoff Observe that assigning a trigger holdoff time can stabilize the display of a repeating signal. You can also modify the horizontal scale of a displayed waveform by adjusting the SEC/DIV setting.
Page 231: Assigning Trigger Holdoff To An Am Signal
Using TRIGGER Controls You can assign a trigger holdoff to either Edge or Video triggering. In addition, you can assign a trigger holdoff when the oscilloscope is in the Normal or Auto trigger mode. It may be difficult to see a stable display for a repeating digital signal, such as a pseudo random signal, on an oscilloscope because edge transitions occur at many places within the waveform.
Page 232 Using TRIGGER Controls Figure 5.11 shows the updating overlay of the amplitude modulation region of an amplitude modulated (AM) signal. Figure 5.11: Complex AM signal without holdoff To observe a stable display of the amplitude modulation of a complex repeating signal, you must adjust the trigger level within the amplitude modulation region of the displayed waveform.
Page 233 Using TRIGGER Controls The next procedure enables you to analyze the amplitude modulation region of a complex repeating signal by assigning a trigger holdoff in the amplitude modulation region of the signal. To assign a trigger holdoff for an AM signal, follow these steps: 1.
Page 234 Using TRIGGER Controls 6. In the TRIGGER section, turn the LEVEL knob to set the displayed trigger level to 1.00V. 7. In the HORIZONTAL section, push the HORIZ MENU button. 8. Push the appropriate side-screen menu button to Set Trigger Holdoff. Turn the Multipurpose knob to set the displayed holdoff time to 100.0us.
Page 235 Using TRIGGER Controls You will see a waveform similar to that shown in Figure 5.12 Figure 5.12: Stable AM signal using trigger holdoff You can view the stable waveform display of the amplitude modulation region of an AM signal by assigning a trigger holdoff time to be within the amplitude-modulated region of the signal.
Page 236: Summary
Using TRIGGER Controls Summary In this module, you learned to perform the following tasks: • Use trigger level control for edge triggering. • Select the coupling type for a trigger. • Use an external signal to trigger signal acquisitions. • Trigger on a specified pulse width to isolate a pulse in a complex data stream.
Page 237: Using Menu Function Controls
Using Menu Function Controls This module provides information about the Menu Function Controls on the front panel and various primary control sections. At the end of this module, you will be able to: • Use the ACQUIRE Menu Function Controls to control how the oscilloscope acquires waveform data.
Page 238 Using Menu Function Controls • Use the SAVE/RECALL Menu Function Controls to store and retrieve oscilloscope settings and waveforms to and from the non-volatile memory of the oscilloscope or a USB flash drive. • Use the UTILITY Menu Function Controls to access system-related information about the status, as well as self-calibration control of the oscilloscope.
Page 239: Menu Function Controls
Using Menu Function Controls MENU Function Controls The MENU control section consists of the ACQUIRE, DISPLAY, CURSOR, MEASURE, SAVE/RECALL, UTILITY, REF MENU, AUTORANGE buttons. ACQUIRE button You use the ACQUIRE Menu Function Controls to regulate the signal acquisition and processing system. You can use the ACQUIRE Menu Function Controls to select the Sample, Peak Detect, or Average signal acquisition mode.
Page 240 Using Menu Function Controls MEASURE button The MEASURE Menu Function Controls allow you to make predefined automated measurements of waveforms. There are 11 types of measurements available and you can display up to 5 types at a time. SAVE/RECALL button You use the SAVE/RECALL Menu Function Controls to save and recall oscilloscope setups or waveforms to nonvolatile memory locations or to save and recall...
Page 241 Using Menu Function Controls REF MENU button You use the REF MENU Function Controls to turn on and off reference waveforms AUTORANGE button You use the AUTORANGE Menu Function Controls to have the oscilloscope automatically adjust setup values to track a signal. TDS1000B and TDS2000B Series Oscilloscopes –...
Page 242: Acquire Menu Function Controls
Using Menu Function Controls ACQUIRE Menu Function Controls You use the acquisition modes of a TDS1000B/TDS2000B oscilloscope to control how waveforms are acquired and displayed from the sample points taken on a signal. A TDS1000B/TDS2000B oscilloscope acquires 2500 sample points for each active channel during every acquisition of the respective signals.
Page 243 Using Menu Function Controls The Sample acquisition mode is the default acquisition mode. In this mode, the oscilloscope samples the signal in evenly spaced intervals to construct the waveform. You use the Peak Detect acquisition mode to detect glitches and high-speed noise in fast moving signals at slow time base settings.
Page 244: Using The Peak Detect Acquisition Mode
Using Menu Function Controls Using the Peak Detect Acquisition Mode You need to use Peak Detect when high-speed interference couples with electronic signals. Consider a situation where you need to test a complex signal that controls a mechanical robot. Glitches caused by various sources, such as light dimmers, motor controls, and design flaws, can interfere with the control signal and cause the robot to malfunction.
Page 245 Using Menu Function Controls The following procedure enables you to detect glitches in the signal at slow time base settings by selecting the Peak Detect acquisition mode: 1. Connect the CH1 probe to the VARIABLE AMPL WITH GLITCH signal on pin 15 and the CH1 probe ground lead to GND on pin 14 of the Training 1 signal board.
Page 246 Using Menu Function Controls 7. In the HORIZONTAL section, turn the SEC/DIV knob counterclockwise to set the displayed time base setting to M 100ms. 8. In the MENUS section, push the ACQUIRE button. The waveform is acquired by the default Sample acquisition mode.
Page 247 Using Menu Function Controls 10. You will see a waveform similar to that shown in Figure 6.2. Figure 6.2: A noisy variable amplitude signal with glitches acquired with the Peak detect and scan display modes Note that random glitches appear on the waveform. These glitches are not visible in the Sample acquisition mode.
Page 248: Using The Average Acquisition Mode
Using Menu Function Controls Using the Average Acquisition Mode You use the Average acquisition mode to reduce the random noise in a displayed signal by taking an average of multiple waveforms. The Average acquisition mode uses the Sample acquisition mode to acquire data and then takes an average of multiple waveforms to display a final waveform.
Page 249 Using Menu Function Controls 3. On the top of the front panel, push DEFAULT SETUP. 4. In the TRIGGER section, turn the LEVEL knob to set the trigger level to 400mV on the display. 5. Push the TRIG MENU button. 6.
Page 250 Using Menu Function Controls The waveform is acquired by the default Sample acquisition mode. You will now use the Average acquisition mode to reduce the displayed noise in the repeating signal. 1. On the top of the front panel, push the ACQUIRE menu button.
Page 251: Display Menu Function Controls
Using Menu Function Controls Figure 6.4: A noisy variable amplitude signal acquired with the Average acquisition mode You will observe that the signal noise is reduced when you shift from the Sample to the Average acquisition mode. DISPLAY Menu Function Controls You use the DISPLAY Menu Function Controls to control how waveforms are displayed.
Page 252: Selecting The Display Type
Using Menu Function Controls Selecting the Display Type You can select different display types, such as a vector or a dot display type, for a waveform by using the options of the DISPLAY menu. When you choose Vectors, straight lines connect the sample points on the display.
Page 253 Using Menu Function Controls 5. In the HORIZONTAL section, turn the SEC/DIV knob counterclockwise to set the displayed time base to 500ns. 6. On the top of the front panel, push the RUN/STOP button to stop signal acquisitions by the oscilloscope. You will see the caption Stop displayed at the top of the oscilloscope display.
Page 254 Using Menu Function Controls For Type Dots, you will see a waveform similar to that shown in Figure 6.5. Notice that this waveform is displayed by dots that represent the sample points and is very difficult to see. Figure 6.5: Waveform displayed in dots 6-18 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 255: Using Persistence
Using Menu Function Controls Using Persistence You use the Persist mode to allow old waveform data to remain visible with the current waveform data on the oscilloscope display. You can use persistence to track infrequent signal anomalies that accumulate in the oscilloscope display.
Page 256 Using Menu Function Controls 2. On the top right of the front panel, push the RUN/STOP button twice. This will start and then stop the accumulation of dots over many waveforms. You will see a waveform similar to that shown in Figure 6.6. Figure 6.6: A noisy signal with infinite persistence 6-20 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 257 Using Menu Function Controls 3. In the VERTICAL section, turn the CH1 POSITION knob to shift the waveform to the lower part of the display. Notice that all except the last waveform acquisition dots disappear from the display. You will see a waveform similar to that shown in Figure 6.7. Figure 6.7: A noisy signal with the final waveform acquisition dots displayed TDS1000B and TDS2000B Series Oscilloscopes –...
Page 258: Using The Xy Display Mode
Using Menu Function Controls Using the XY Display Mode You can display waveforms in the XY or YT formats. When you choose the XY display format, Channel 1 is displayed on the horizontal axis and Channel 2 is displayed on the vertical axis.
Page 259 Using Menu Function Controls 3. On the Training 1 signal board, push the POWER button until only the Analog PWR LED is on. 4. On the top of the front panel, push the DEFAULT SETUP menu button. 5. On the top of the front panel, push the AUTOSET button.
Page 260 Using Menu Function Controls 10. On the Training 1 signal board, turn the ADJ knob to display the XY signal as a circle. The circle means that both of the signals are sine waves and are 90º out of phase with respect to each other. You will see a waveform similar to that shown in Figure 6.8.
Page 261: Cursor Menu Function Controls
Using Menu Function Controls CURSOR Menu Function Controls You can use the CURSOR Menu Function Controls to measure the vertical or horizontal details of a waveform. You can manually select the horizontal (voltage) and vertical (time) cursors to view the values of the cursor positions. The horizontal and vertical cursors are visible as dotted lines on the screen.
Page 262 Using Menu Function Controls To measure the vertical scale of a waveform, follow these steps: 1. Remove the CH2 probe tip from pin 11 PHASE SHIFT SINE WAVE on the Training 1 signal board. 2. On the top of the front panel, push the DEFAULT SETUP menu button.
Page 263 Using Menu Function Controls 8. Select Cursor 2. Turn the Multipurpose knob to position the associated cursor on the highest peak of the waveform. 9. Read the peak-to-peak volts (amplitude) measurement for the waveform in the side-screen menu box ΔV. You will see a waveform similar to that shown in Figure 6.9.
Page 264: Measuring The Horizontal Scale
Using Menu Function Controls Measuring the Horizontal Scale The following procedure enables you to manually measure horizontal timing details on a waveform and display the period and frequency of the waveform. This procedure assumes that the oscilloscope retains the settings from the previous procedure. To measure horizontal timing details on a waveform, follow these steps: 1.
Page 265 Using Menu Function Controls 5. Read the period, frequency, and delta amplitude measurements for the waveform in the side-screen menu box Δt. You will see a waveform similar to that shown in Figure 6.10. The measurements displayed in Δt are the period, frequency, and delta amplitude measurements for the 5 kHz SINE signal from pin 10 on the Training 1 signal board.
Page 266: Measuring Pulse Width
Using Menu Function Controls Measuring Pulse Width Pulse width is the time period during which a pulse shifts from low to high and then back to low again. Pulse width is measured at 50% of the full peak-to-peak voltage. You can measure the width of a pulse by using the CURSOR menu.
Page 267 Using Menu Function Controls 4. On the top of the front panel, push the AUTOSET button. 5. In the HORIZONTAL section, turn the SEC/DIV knob to set the time base for M 25.0ns on the display. 6. On the top of the front panel, push the CURSOR menu button.
Page 268 Using Menu Function Controls You will see a waveform similar to that shown in Figure 6.11. The measurement displayed in Δt is the pulse width for the D-10 MHz signal from pin 3. Figure 6.11: Pulse width measurements of a 10 MHz data signal using cursors 6-32 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 269: Measuring Rise Time
Using Menu Function Controls Measuring Rise Time Rise time is the time taken by the leading edge of a pulse to rise from 10% to 90% of its peak-to-peak amplitude. You can measure the rise time of a pulse by using the CURSOR menu.
Page 270 Using Menu Function Controls 4. In the VERTICAL section, push the CH1 MENU button. 5. Push the appropriate side-screen menu button to select Volts/Div Fine. 6. In the VERTICAL section, turn the CH1 VOLTS/DIV knob to set the waveform peak-to-peak amplitude to five vertical divisions of the graticule.
Page 271 Using Menu Function Controls 10. Ensure Cursor 1 is selected. Turn the Multipurpose knob to position the associated cursor at the point where the waveform crosses the second graticule below the center of the screen. This is the 10% point on the waveform. 11.
Page 272 Using Menu Function Controls You will see a display similar to that shown in Figure 6.12. The measurement displayed in Δt is the rise time for the D- 10 MHz signal from pin 3 on the Training 1 signal board. Figure 6.12: Rise time measurement of a 10 MHz data signal 6-36 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 273: Measure Menu Function Controls
Using Menu Function Controls MEASURE Menu Function Controls You can take various automatic measurements with a TDS1000B/TDS2000B oscilloscope. You use the MEASURE Menu Function Controls to take automatic measurements, such as signal frequency, period, rise time, fall time, positive width, and amplitude, of most displayed signals.
Page 274 Using Menu Function Controls 4. On the top of the front panel, push the AUTOSET button. 5. In the MENUS section, push the MEASURE menu button. 6. Push the appropriate side-screen menu buttons to select CH1 None. 7. Push the appropriate side-screen menu button to select Type Freq.
Page 275 Using Menu Function Controls 9. Push the next side-screen menu buttons to select CH1 None. 10. Push the appropriate side-screen menu button to select Type Period. 11. Push the appropriate side-screen menu button to select Back. 12. Push the next side-screen menu buttons to select CH1 None.
Page 276 Using Menu Function Controls 16. Push the appropriate side-screen menu button to select Type Pk-Pk. 17. Push the appropriate side-screen menu button to select Back. 18. Push the final side-screen menu button to select CH1 None. 19. Push the appropriate side-screen menu button to select Type Cyc RMS.
Page 277 Using Menu Function Controls You will see a display of measurements similar to that shown in Figure 6.13a. Figure 6.13a: Square waveform with five automatic measurements The frequency, period, mean, peak-to-peak, and cycle RMS measurements for the CH1 input signal are shown in the side-screen menu.
Page 278 Using Menu Function Controls Figure 6.13b shows the Positive Width being monitored on all four digital signals. The fifth measurement is the Negative Width of the fourth signal. Figure 6.13b: Multiple Signals with the Same Measurements 6-42 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 279: Saving And Recalling A Setup
Using Menu Function Controls SAVE/RECALL Menu Function Controls You use the SAVE/RECALL Menu Function Controls to save and recall setups and waveforms. You can save and recall instrument setups from the oscilloscope’s 10 nonvolatile memory locations or from a USB flash drive. In addition, the SAVE/RECALL Menu Function Controls allow you to save a waveform from any input channel, MATH, or reference memory location and save this wave to...
Page 280 Using Menu Function Controls 3. On the top of the front panel, push the DEFAULT SETUP menu button. 4. On the top of the front panel, push the AUTOSET button. 5. In the VERTICAL section, push the CH1 MENU button. 6.
Page 281 Using Menu Function Controls 10. In the HORIZONTAL section, push the HORIZ MENU button. 11. Push the appropriate side-screen menu button to select Window Zone. 12. On the top of the front panel, push the SAVE/RECALL menu button. 13. Push the appropriate side-screen menu button to select Action Save Setup.
Page 282 Using Menu Function Controls You will see a display similar to that shown in Figure 6.14. Figure 6.14: Saving an instrument setup 6-46 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 283 Using Menu Function Controls To recall a setup, follow these steps: 1. On the top of the front panel, push the DEFAULT SETUP menu button. This will display the sine wave at 1.00V vertical and M500us horizontal settings. 2. On the top of the front panel, push the SAVE/RECALL menu button.
Page 284: Saving And Recalling A Waveform
Using Menu Function Controls Saving and Recalling a Waveform The following procedure enables you to save and recall a waveform. This procedure assumes that the oscilloscope retains the settings from the previous procedure. To save and recall a waveform, follow these steps: 1.
Page 285 Using Menu Function Controls 5. Push the appropriate side-screen menu button to select Save to Ref. 6. Push the appropriate side-screen menu button to select Source CH1. 7. Push the appropriate side-screen menu button to select To RefA. 8. Push the appropriate side-screen menu button to select Save.
Page 286 Using Menu Function Controls You will see a display similar to that shown in Figure 6.15. Notice that both the saved Ref A and the updating CH1 waveforms are displayed. Figure 6.15: Saved and updating waveforms displayed 6-50 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 287: Utility Menu Function Controls
Using Menu Function Controls UTILITY Menu Function Controls You use the UTILITY Menu Function Controls to access the different utility menus of a TDS1000B/TDS2000B oscilloscope. The UTILITY menu allows access to various tasks, such as displaying the system status for the different control sections of the oscilloscope, changing the display language, setting up the instrument GPIB address, and checking the oscilloscope error log.
Page 288 Using Menu Function Controls 3. Push the appropriate side-screen menu button to select Vertical CH1 CH2. For the TDS2014 and TDS2024 oscilloscopes, you will select either Vertical CH1 CH2 or Vertical CH3 CH4. You will see a display similar to that shown in Figure 6.16. Vertical System Status is displayed.
Page 289: Ref Menu Function Controls
Using Menu Function Controls In the following procedure, you will change the display language of a TDS1000B/TDS2000B oscilloscope. This procedure assumes that the oscilloscope retains the settings from the previous procedure. To change the display language, follow these steps: 1. On the top of the front panel, push the UTILITY menu button.
Page 290 Using Menu Function Controls To turn on and off reference waveform A, follow these steps: 1. On the top of the front panel, push the REF MENU button. 2. Push the appropriate side-screen menu button to turn off Ref A. 3.
Page 291: Autorange Menu Function Controls
Using Menu Function Controls AUTORANGE Menu Function Controls You use the AUTORANGE Menu Function Controls to have the oscilloscope automatically track and adjust settings as a signal changes. Automatic Adjustment of Oscilloscope Settings In the following procedure, you watch the AUTORANGE function automatically adjust settings as you move probe from one point to another.
Page 292 Using Menu Function Controls 6. Ensure the Vertical and Horizontal option is selected. 7. Move the CH1 probe tip to D-10 MHz signal on pin 3 of the Training 1 signal board. Notice that the oscilloscope automatically changed the timebase setting from 25.0 ns to 50.0 ns. 6-56 TDS1000B and TDS2000B Series Oscilloscopes –...
Page 293: Summary
Using Menu Function Controls Summary In this module, you learned to: • Use the ACQUIRE Menu Function Controls to control how the oscilloscope acquires waveform data. • Use the DISPLAY Menu Function Controls to define how the oscilloscope displays waveforms. •...
Page 294 You have now completed all chapters of the TDS1000B and TDS2000B Series Oscilloscope Operator Training Kit. Tektronix congratulates you for your initiative to be a better oscilloscope user 6-58 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 295: Appendix A: Training 1 Signal Board: Signal Definitions
Appendix A Training 1 Signal Board: Signal Definitions Following is the regulatory compliance information for the Training 1 signal board. European EC Council EMC Directive 89/336/EEC, Union amended by 93/68/EEC. Demonstrated using: • IEC 61326:1997 Product Family Standard for Electrical Equipment for Measurement, Control, and Laboratory Use-EMC Requirements •...
Page 296 Appendix A Training 1 Signal Board: Signal Definitions Australia EMC Framework, demonstrated per and New Emission Standard AS/NZS 2064 Zealand (Industrial, Scientific, and Medical Equipment). Complies with the requirements of FCC, CFR Title 47, Part 15, Subpart B, Class A. TDS1000B and TDS2000B Series Oscilloscopes –...
Page 297 Appendix A Training 1 Signal Board: Signal Definitions Figure A1.1 depicts the layout of the Training 1 signal board. Figure A1.1: Training 1 signal board TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 298 Appendix A Training 1 Signal Board: Signal Definitions Pins 1, 7, 8, and 14 Description These pins provide the ground reference for the Training 1 signal board. Pin 2 CLK 20MHz Specification 20 MHz digital signal, 4 V peak-to-peak Description This signal is the control clock for all of the digital signals on the Training 1 signal board.
Page 299 Appendix A Training 1 Signal Board: Signal Definitions Pin 4 BURST (also found on the 2x8 pin connector) Specification Digital signal, 4 V peak-to-peak Description This signal is a repetitive pulse stream consisting of four groups of eight 16 to 24 ns pulses separated by 1.3 ms of inactivity.
Page 300 Appendix A Training 1 Signal Board: Signal Definitions Pin 6 METASTABLE Specification Digital signal, 3 V peak-to-peak Description This signal is a 10 MHz square wave that contains an occasional glitch caused by a metastable state in the flip-flop. A logic analyzer or an advanced oscilloscope set to trigger on narrow pulse widths will find these glitches.
Page 301 Appendix A Training 1 Signal Board: Signal Definitions Description This amplitude modulated signal uses a 5 kHz sine wave signal source and a 1 MHz carrier frequency. The output should look like a sine wave with a positive DC component and an inverted sine wave with a negative DC component with shading between.
Page 302 Appendix A Training 1 Signal Board: Signal Definitions Pins 10 and 5kHz SINE and PHASE SHIFTED SINE WAVE Specification Analog signal Positive phase shift: 0–135 degrees Frequency: About 5 kHz Amplitude: 1 V Description The phase difference between these two 5 kHz sine waves is varied using a potentiometer.
Page 303 Appendix A Training 1 Signal Board: Signal Definitions Pins 12 and DIFF + and DIFF – Specification Analog signals Frequency: 7 Hz, with 1 Hz background Amplitude: 2 V common with 250 mV differential Description The differential signal from pin 12 and pin 13 is a 1 Hz heartbeat signal with a 250 mV amplitude.
Page 304 Appendix A Training 1 Signal Board: Signal Definitions Pin 15 VARIABLE AMPL WITH GLITCH Specification Analog signal Frequency: 10 Hz Amplitude: Variable between 1 V and 4 V, following sine wave at 0.1 Hz rate 20 ns asynchronous glitch, 5 V amplitude, at 1 Hz rate Description This signal is a 10 Hz square wave with an...
Page 305 Appendix A Training 1 Signal Board: Signal Definitions Pin 16 FAST RISE TIME Specification Analog signal Amplitude: About 0.6 V 1 ns to 2 ns rise time Description This signal is a 100 ns wide 0.6 V pulse with a rise time of <2 ns.
Page 306 Appendix A Training 1 Signal Board: Signal Definitions A-12 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...
Page 307: Appendix B: Glossary
Appendix B Glossary Term Description A mode that blocks the DC component of Coupling a signal but passes the dynamic (AC) component of the signal. Useful for observing an AC signal that is normally riding on a DC signal. Acquisition The process of sampling signals from input channels, digitizing the samples, processing the results into data points, and...
Page 308 Appendix B Glossary Aliasing A phenomenon caused by the undersampling of frequency components that exceed the Nyquist frequency. Aliasing is said to occur when frequency components that are above the Nyquist frequency appear as lower frequency components on the oscilloscope screen. Attenuation The degree the amplitude of a signal is reduced when it passes through an...
Page 309 Appendix B Glossary Autorange A feature that automatically adjusts the vertical and/or horizontal setup values to track a signal. If the signal changes, the setup continues to track the signal. Autoset A feature that automatically sets the vertical, horizontal, and trigger controls to provide a usable display.
Page 310 Appendix B Glossary Cursors Paired markers that you can use to make measurements between two waveform locations. The oscilloscope displays the values (expressed in volts, time, or frequency) of the position of the active cursor and the distance between the two cursors.
Page 311 Appendix B Glossary Display The word used to refer to the screen of the oscilloscope. Edge Triggering that occurs when the Trigger oscilloscope detects the source passing through a specified voltage level in a specified direction (the trigger slope). External Triggering that occurs when the Trigger oscilloscope detects the external input...
Page 312 Appendix B Glossary Hard Copy An electronic copy of the display in a format useable by a printer or plotter. Holdoff A specified amount of time that must elapse after a trigger signal before the trigger circuit will accept another trigger signal.
Page 313 Appendix B Glossary Persistence A method of retaining old data on the display for a period of time. With persistence turned off, the points decay quickly. With persistence on, the points decay more slowly or not at all, depending on the setting. PictBridge®...
Page 314 Appendix B Glossary Time Base The set of parameters that let you define the time and horizontal axis attributes of a waveform record. The time base determines when and how long to acquire record points. USB Flash The USB port used to connect a USB flash Drive Port drive for data storage or retrieval.
Page 315 Appendix B Glossary Video Triggering on the sync pulse of a Trigger composite video signal. XY Format A display format that compares the voltage level of two waveform records point by point. It is useful for studying phase relationships between two waveforms. YT Format The conventional oscilloscope display format.
Page 316 Appendix B Glossary B-10 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit...

This manual is also suitable for:

Tds2000b series

Tektronix TDS1000B Series Operator's Manual

Quick Links

Related Manuals for Tektronix TDS1000B Series

Summary of Contents for Tektronix TDS1000B Series

This manual is also suitable for:

Table of Contents
