Using TRIGGER Controls

In the previous module, you learned to use the
HORIZONTAL controls on the front panel. In this module,
you will learn to use the TRIGGER controls by following
various procedures that stabilize repeating signals as well
as to capture single-shot.
At the end of this module, you will be able to:
•
Use the TRIG MENU button to set various trigger
parameters, such as trigger type, slope, and coupling.
•
Set the trigger holdoff interval.
