Tektronix TDS1000B Series Operator's Manual page 118

2
Getting Started with the TDS1000B and TDS2000B Series Oscilloscopes
Menu
Option
Source
Type
Refer to MEASURE Menu Function Controls, starting on
page 6-37, for procedures using the MEASURE menu
function controls.
2-72 TDS1000B and TDS2000B Series Oscilloscopes – Operator Training Kit
Description
You use this menu option to specify the
source of a waveform as CH1 or CH2
for 2-channel oscilloscopes. The
options, CH3 and CH4 are available on
4-channel oscilloscopes.
You use this menu option to specify the
type of measurement to be made for
each source selection. You can select
from 11 types of measurements for
each of the 4 possible source
selections in 4-channel oscilloscopes,
and 2 possible source selections in 2-
channel oscilloscopes.
