- Page 1 Installation Guide M-Series...
- Page 2 © FLIR Systems, Inc., 2017. All rights reserved worldwide. No parts of this manual, in whole or in part, may be copied, photocopied, translated, or transmitted to any electronic medium or machine readable form without the prior written permission of FLIR Systems, Inc.
-
Page 3: Table Of Contents
Contents Installing M-Series Camera Systems Additional References ..............4 Documentation Conventions ............5 Warnings and Cautions ................5 Installation Overview ................6 Installation Planning ................7 General Location Considerations ...........7 Camera Mounting Options..............8 Camera Video Options ..............8 Joystick Control Unit (JCU) ............9 Multiple JCU/Camera Installations ..........10 Physical Installation ................11 Installing the Camera Unit ............11 Installing the Joystick Control Unit (JCU) ........12... -
Page 4: Installing M-Series Camera Systems
• M-Series Operator’s Manual (FLIR Doc. # 432-0003-60-10) contains information about how to configure, use, and operate the camera. • M-Series Quick Start Guide (FLIR Doc. # 432-0003-60-11) is a double-sided card that shows the functions executed by the various JCU buttons. -
Page 5: Documentation Conventions
Installing M-Series Camera Systems Documentation Conventions For safety, and to achieve the highest levels of performance from the M-Series system, always follow the warnings and cautions in this manual when handling and operating the M-Series camera system. Warning! Warning notices are used to emphasize that hazardous voltages, currents, temperatures, or other conditions that could cause personal injury or death exist with this equipment, or may be associated with its use. -
Page 6: Installation Overview
You will need to supply the following items; required lengths vary depending on your boat's configuration. These items are available in standard lengths through FLIR Systems, Inc. • Electrical wire, for system power; up to 30.5 meters (100 feet), 3-conductor, gauge determined by cable length and supply voltage;... -
Page 7: Installation Planning
After installation, the forward direction of the camera may be verified and adjusted if required. Refer to M-Series Operator’s Manual (FLIR Doc. # 432- 0003-60-10). -
Page 8: Camera Mounting Options
This type of installation makes use of a mounting riser, an optional accessory available from FLIR Systems, Inc. To install using the mounting riser, the camera is first mounted to... -
Page 9: Joystick Control Unit (Jcu)
Installing M-Series Camera Systems Joystick Control Unit (JCU) Mount the JCU in a convenient area that is close to the monitor being used to display the M-Series video output. Ensure the area you choose has room for the cable under the JCU (refer to the M-Series ICD for dimensions). -
Page 10: Multiple Jcu/Camera Installations
PC to control the camera. Refer also to the M-Series ICD (FLIR Doc. # 432-0003-XX-YY) for interconnect diagrams showing several possible system configurations using more than one JCU. -
Page 11: Physical Installation
Installing M-Series Camera Systems Physical Installation Use a thread-locking compound such as Loctite 242 or equivalent with all metal-to-metal threaded connections. Installing the Camera Unit Two O-rings are provided for use during the camera installation. You should choose the one most appropriate for your configuration: •... -
Page 12: Installing The Joystick Control Unit (Jcu)
Standard JCU Mounting Instructions 1. Using the JCU template supplied as a guide in FLIR Doc. # 432- 0003-XX-YY, mark the location of the rectangular opening that will allow the JCU to be recessed in the vessel’s control console. -
Page 13: Electrical Connections
Installing M-Series Camera Systems 5. Insert the JCU into the hole and secure by turning the 4 corner screws clockwise. Rotate each screw one full turn and ensure the mounting clamps are rotated outward from the JCU housing. Tighten the screws to draw the mounting clamps up against the mounting surface and then tighten another quarter or half turn. -
Page 14: Proper Grounding
Installing M-Series Camera Systems Connections Quick Reference TABLE 1.1 Cable Label Wire Comment Power Nominal 12 Vdc / 24 Vdc Absolute range 10 Vdc to 32 Vdc 50 watt maximum Black DC return Green Chassis ground F-Style Coax Thermal camera video only F-Style Coax Use if only one display VIS/IR... -
Page 15: Video Connections
The video cables from the camera are terminated with F-type male connectors. Video cables of various lengths with F-type female connectors at one end and BNC-connectors at the other end are available from FLIR. The video cable used should be rated as RG59/U or better to ensure an adequate quality video signal. -
Page 16: M-Series Reference
M-Series thermal camera lenses are designed for the harsh outdoor environment and have a coating for durability and anti-reflection, but may require cleaning occasionally. FLIR Bezel Systems Inc. suggests that you clean the lens when image quality degradation is noticed or excessive contaminant build-up is seen on the lens. -
Page 17: Camera Body Cleaning And Inspection
Do not pressure wash the camera, especially around the FLIR logos, as that could force water through the camera seals. Clean the interface between the yoke and base often to prevent accumulation of debris or salt deposits. -
Page 18: External Standards
M-Series Reference Specifications TABLE 1.1 Environmental Operating temperature –25 °C to +55 °C (–13 °F to +131 °F) range Storage temperature range –40 °C to +85 °C (–40 °F to +185 °F) Automatic window defrost Standard (automatic at unit power-up) Manual window defog Select defog from the OSD or the Web Toolbar. -
Page 19: Acronyms
American National Standards Institute Application Programming Interface DLTV Daylight TV, used to reference visible-band cameras Export Administration Regulations Electromagnetic Interference Flat Field Correction FLIR Forward Looking Infrared Field of View Frames per Second (refresh rate) HFoV Horizontal Field of View Interface Control Document... -
Page 20: Feature Comparison Of M-Series Models
M-Series Reference Feature Comparison of M-Series Models The following table lists each M-Series model and its supported features. Each model is available in four variations, identified by a unique part number: • <9 Hz thermal frame refresh rate (FPS), NTSC video format •... -
Page 21: M-Series Accessories
M-Series Reference M-Series Accessories Part number Description 308-0163-25 Ethernet cable, Double shielded, RJ-45, LSZH, 25 ft 308-0163-50 Ethernet cable, Double shielded, RJ-45, LSZH, 50 ft 308-0163-75 Ethernet cable, Double shielded, RJ-45, LSZH, 75 ft 308-0163-100 Ethernet cable, Double shielded, RJ-45, LSZH, 100 ft 308-0164-25 Video cable, F-Type terminated on camera end, BNC terminated on monitor end, 25 ft... - Page 22 PH:+ 1 888 747 3547 Option 5 www.flir.com/maritime Support email: MaritimeCameraSupport@flir.com EUROPE Eurasian Headquarters FLIR Systems CVS BV Charles Petitweg 21 4847 NW Teteringen - Breda Netherlands PH: + 31 (0) 765 79 41 94 FX: + 31 (0) 765 79 41 99 flir@flir.com...
