Puzzi 8/1 C
View from below
7
6
1 Fresh-water hose to the spray/ suction
hose
2 Floor cover
3 Wheel, LH
4 Retaining screw, LH wheel
New Unit Information 05.2007
9
5
8
5
5 Air discharge, motor cooling air
6 Retaining screw, RH wheel
7 Wheel, RH
8 Retaining screws (9x), floor cover
9 Swivel casters (2x)
Unit functions
1
2
3
4
Page 9 / 29
