Unit functions
Spray / suction tube
Spray nozzle on the floor tool
Guide handle
1 Spray nozzle
2 Guide handle
Page 14 / 29
Spray nozzle
The spray nozzle (1) sprays the fresh water -
cleaning agent mixture onto the carpet to be
cleaned.
1
Guide handle
The guide handle (2) can be used to exert an
2
appropriate pressure on the floor nozzle in order
to vacuum up the water - cleaning mixture
sprayed onto the carpet.
Puzzi 8/1 C
New Unit Information 05.2007
