Unit functions
Spray / suction hose
7
1 Spray / suction hose
2 Fresh-water hose
3 Connection sleeve, suction hose
4 Connection, fresh-water hose
5 Handle section
6 Lever, spray function release
7 Threaded connection, connection to the
spray / suction tube
Page 12 / 29
6
5
Puzzi 8/1 C
4
3
2
New Unit Information 05.2007
1
