Puzzi 8/1 C
Unit housing, wastewater tank removed
2
1
1 Unit housing, lower section
2 Air intake (drawn in air) opening with fluff
strainer
New Unit Information 05.2007
Fluff strainer
Filters coarse contaminations out of the drawn in
air in order to prevent damage to the suction
motor (M1).
Unit functions
Page 7 / 29
