Unit functions
Fresh-water tank
Water filter
„MAX" mark
1 Water filter in the fresh-water tank
2 Fresh-water tank
3 „MAX" mark, maximum water level in the
fresh-water tank
Page 6 / 29
Water filter
Filters contaminations out of fresh water in order
to prevent damage to the water pump (M2).
1
2
„MAX" mark
The „MAX" mark (3) in the fresh-water tank (2)
indicates the maximum water quantity, which
may be added to the fresh-water tank (2).
Note
If water is added to the fresh-water tank
above the „MAX" mark and this volume of
3
water is completely processed, it is possible
that the wastewater tank cannot accept the
whole volume of water and therefore
overflows.
Puzzi 8/1 C
New Unit Information 05.2007
